Oasis D150 User manual

USER GUIDE
D150, D165
‧Safety information
‧How to use
‧Warranty
‧Contacts
Evolution-Classic.
Dehumidier
1

2
EN Safety Information
BEFORE THE INSTALLATION AND USE OF
THE APPLIANCE, CAREFULLY READ THE
SUPPLIED INSTRUCTION.
The manufacturer is not responsible if an
incorrect installation and use causes injuries and
damages. Always keep the instruction with the
appliance for future reference.
Digital version of manual is available Online at
www.oasis.ie
The appliance is not intended for use by person
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction unless
they have been given supervision or instruction
concerning use of the appliance in a safety way
and understand the hazards involved.
This machine must not be operated by children.
Keep children away from the device. Do not let
children play with the appliance. Children without
supervision should not clean and maintenance
appliance.
Appliances only for indoor use.
Do not use means to accelerate the defrosting
process or to clean, other than those
recommended by the manufacturer.
Safety Information
Safety Information
WARNING: Appliance shall be installed,
WARNING: Flammable material. The
operated and stored in a room with a oor
area larger than 4m2.
appliance contain a ammable refrigerant
R290/Propane.
The appliance shall be stored in a room without
continuously operating ignition sources (for
example:, open ames, an operating gas
appliance or an operating electric heater.
Do not pierce or burn.
Be aware that refrigerants may not contain an
odor.
Keep ventilation openings clear of obstruction.
Servicing shall be performed only as
recommended by the manufacturer.
The appliance shall be stored in well-ventilated
area where the room size corresponds .
The appliance shall be stored in a room without
continuously operating open ames (for example
an operating gas appliance) and ignition sources
(for example an operating electric heat.
Disposal of Electrical Appliance
Do not dispose this product as
unsorted municipal waste Collection
of such waste separately for special
treatment is necessary.
Wild disposal of waste in forests and landscapes
endangers your health when hazardous
substances leak into the ground-water and nd
their way into the food chain.

3
EN Operating and Maintenance
CHOOSING A LOCATION
1. Use the dehumidier in any enclosed room or
area such as a workshop, basement, or living
area where you want moisture removed. For
best results, keep all doors and windows
closed.
2. Good airow is essential for dehumidifying.
Make sure there is at least 15 cm of space
between the rear of the dehumidier and any
wall or other obstruction such as furniture or
appliances.
3. The dehumidier should be in an upright
position and on a level surface.
4. The dehumidier has four casters for ease of
movement.
5. These dehumidiers are built for free-standing
use only and are not designed to be built in.
OPERATING YOUR DEHUMIDIFIER
1. Check the available power supply against
the dehumidier data plate to assure correct
electrical service. Plug power cord into
grounded wall outlet.
2. The Humidistat Knob should be securely
tted to the exposed stem on the front
Grille. The Knob is packed in a bag stapled
around the power cord in the receptor
bucket. All models are equipped with an
automatic humidistat control that will switch
the dehumidier on and o to maintain the
chosen humidity level. When you operate the
dehumidier for the rst time in a particular
area, set the humidistat dial on mid-point.
Allow the dehumidier to operate at this
setting for two or three days.
3. Frost or ice on the cooling coils - The cooling
coils in the back of the dehumidier may get
frost covered if the room temperature or the
amount of moisture in the air (relative humidity)
is too low. This condition usually happens
in the fall, winter, or spring months. The
dehumidier is designed to remove moisture
when the room temperature is above 3 C.
DISPOSAL OF WATER
All models are equipped with a 9-1/2 litre
capacity water receptor and an automatic shut-
o system to prevent overow when the receptor
gets full. When the water in the receptor rises to
a certain level, a oat switch shuts o the system
and turns on the red light on the front panel. The
receptor should then be removed and emptied.
You will notice that when the receptor is removed,
the system will again begin operating, unless
the control dial has been turned to the “OFF”
position.
To empty the receptor, turn the control dial to
the “OFF” position. Take hold of the receptor
with both hands and carefully slide it out.
Empty the water and replace the receptor in the
dehumidier. Turn the control dial to your desired
setting.
Use of the tting on the drip tray - When you
remove the water receptor, you will notice that
there is a threaded tting on the bottom of the
drip tray. This is made for the attachment of a
standard garden hose that can continuously
drain the water from the drip tray into a oor
drain. When you connect the hose tting to the
drip tray, it should turn easily. Do not force the
hose tting onto the drip tray as it could damage
the threads. Make sure the drain hose is below
the level of the drip tray or it will not drain properly.
If you place the dehumidier directly over a oor
drain, a short piece of hose is required to direct
the water into the drain or it will drip on the
dehumidier frame and splash out onto the oor.
Do not throw away the receptor. You may need it
to dehumidify an area that does not have a oor
drain.
Safety Information
How to Use All models are equipped with an automatic
system to defrost the coils. The Defrost cycle
operates on a pre-programmed time frame.
The system includes an electronic timer
and a hot Gas valve to ensure the coils are
quickly defrosted. The preprogrammed cycle
is initiated more frequently in low ambient
temperatures.

4
EN Operating and Maintenance
SERVICE AND MAINTENANCE
For your protection, always disconnect the
service cord from the electrical outlet and remove
the water receptor before starting service and/or
maintenance.
1. Cleaning the cabinet: Wipe the exterior with
a soft, damp cloth. Do not use solvents or
cleaning agents. Dust may be removed with
the brush attachment of a vacuum cleaner.
2. Cleaning the air lter: Remove air lter from
rear of unit by pushing “arrow indicators”
gently inwards, remove lter. Brush lightly or
wash in warm sudsy water.
3. Cleaning the water receptor: Wash in warm
sudsy water. Rinse and dry.
4. Storage: Thoroughly clean and dry the
dehumidier. Cover and store in a clean, dry
area.
5. Service hint: To save yourself unnecessary
expense, make the following checks before
delivering your dehumidier to a service
centre.
A. Insucient moisture removal - little or no
water collection.
1. Poor air circulation - See “Choosing a
location” paragraph 2.
2. Room temperature and relative humidity
– See “Operating your dehumidier”
paragraph 3.
B. Runs continuously.
1. Check humidistat control setting. Is it on
“Max Dry”?
2. Are windows and doors closed?
3. Is area too large for the capacity of your
unit?
C. Dehumidier will not start.
1. Check control dial.
2. Check outlet. Plug a lamp or other
appliance into outlet to make certain
power is available.
3. Check fuse or circuit breaker.
4. If using an extension cord, make sure it is
good by checking it with other appliances.
Replacement of the power cord should
ELECTRICAL INFORMATION
1. Available power supply must agree with that
listed on the dehumidier data plate. If an
extension cord is used at any time, it should
be suitably rated, taking account of the rating
as specied on the rear of the unit.
2. Never operate a dehumidier in an
environment where it is likely that standing
water will accumulate around the unit. If this
condition should occur, FOR YOUR SAFETY,
UNPLUG THE SERVICE CORD before
stepping into the water accumulated around
the dehumidier.
3. DO NOT operate the dehumidier if it is in a
damaged condition.
4. If the supply cord is damaged, it must be
replaced by the manufacturer or its service
agent or a suitably qualied person in order
to avoid a hazard.
only be carried out by properly trained
and equipped personal, or return the
Dehumidier to the dealer.

5
EN Warranty
DEHUMIDIFIER EXPORT
WARRANTY.
For the year after purchase: Manufacturer,
through its authorized distributor organization
will replace any part of said Dehumidier which
is found to be defective. This warranty includes
freight, or postage only for parts from the factory
to port of embarkation.
The customer will pay for: pickup and delivery
of the Dehumidier to a Service Agency for
diagnosis and service; All costs for labor and
transportation.
For the second through fth year following
expiration of the one-year warranty period;
Manufacturer, through its authorized distributor
organization will replace any part of said
Dehumidier sealed refrigeration system, which
is found to be defective. This warranty includes
freight or postage only for parts from the factory
to port of embarkation. The customer will pay
for: pickup and delivery of the Dehumidier
to Service Agency for diagnosis and service;
Analysis charge for determining defects; All
costs for labor and transportation.
Only service and parts obtained from
manufacturer`s authorized distributor are
covered by this warranty. It does not cover
normal responsibilities of the user.
NORMAL RESPONSIBILITIES OF
THE USER
1. Use of the machine in accordance with
instructions in the customer`s manual.
2. Proper installation in accordance with printed
instructions.
3. Any damage to nish after installation.
4. Cleaning of condenser or evaporator coils.
5. Service required due to Acts of God. oods,
re, alteration, abuse or misuse.
6. Connection to power supply of proper
voltage as shown on date plate, replacement
of blown fuses (the fuse to be of similar type
and rating), repair of any loose connections
or defects in wiring that is part of the building
power supply.
The user should keep a copy of the bill of sale,
cancelled check, or payment record, verifying
purchase date to validate this guarantee.
There are no other warranties expressed or
implied, covering this appliance, except this
warranty which is in lieu of all other warranties
including any implied warranty of merchantability
or tness for a particular purpose. In no event
shall the manufacturer be liable for special
indirect or consequential damages, nor for any
delay in the performance of this warranty due to
cause beyond its control.
The manufacturer authorizes no other person
to change or add to any of the obligations
hereunder.
WARNING:
This warranty for this machine is
automatically voided if this machine is
altered, modied, or combined with any
other machine or device. Alteration or
modication of this machine may cause
serious ooding and/or hazardous electrical
shock or re.
Except as set forth herein, the Manufacturer
makes no other warranty, guarantee
or agreement expressed, implied or
statutory, including any implied warranty of
merchantability or tness for a particular
purpose.

6EED0002-IM-2010
www.oasis.ie
[email protected]
OASIS IRELAND
OASIS POLAND
Bunree Industrial Est., Ballina,
Co. Mayo, Ireland, F26 D5R3
+ 353 96 71222
ul.Gutenberga 20,
44-164, Gliwice, Poland
+ 48 32 332 65 01
DOWNLOADS
www.oasis.ie/support-downloads
