Observator MET-LINK User manual

Observator Instruments V1.02 Copyright 2017 ©
Page 1
! !
!
!
!
! !
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
MET-LINK Wind Sensor
Manual
Version 1.02 – Oct 2017
Author: Observator Instruments
MET-LINK
ABN 56 007 283 963
8-10 Keith Campbell Court, PO Box 9039
Scoresby, VIC 3179 AUSTRALIA
Tel: +61 3 8706 5000, Fax: +61 3 8706 5049
Email: info.au@observator.com
Web: www.observator.com
!
ANDROID 4.4
& above
COMPATIBLE
!

MET-LINK USER MANUAL V1.02
Observator Instruments V1.02 Copyright 2017 ©
!
Page!2!
Document History
Paper copies are valid only on the day they are printed. Contact Observator Instruments if any
doubt about the accuracy of this document.
Revision History
This document has been revised by:
Revision Number
Revision Date
Summary of Changes
Author
V1.01
31-07-17
Updated general content
Ludovic Grosjean
V1.02
24-10-17
Warranty conditions
Ludovic Grosjean
Reference Documents
Please see the following documents for more information:
Document
Name
Download from
Author
Online
Training
documents
http://download.observator.com/files/?dir=User manuals/MET-Link
Ludovic
Grosjean
Maximet
Manual
http://download.observator.com/files/?dir=User manuals/MET-Link
Gill
Distribution list
This document has been distributed to:
Name
Company, Position
Action
Dana Galbraith
Director at Observator
Instruments
Review
Niran Pelpola
Manager at Observator
Instruments
Review
ABN 56 007 283 963
8-10 Keith Campbell Court, PO Box 9039
Scoresby, VIC 3179 AUSTRALIA
Tel: +61 3 8706 5000, Fax: +61 3 8706 5049
Email: info.au@observator.com
Web: www.observator.com
!

MET-LINK USER MANUAL V1.02
Observator Instruments V1.02 Copyright 2017 ©
!
Page!3!
INDEX
INDEX...................................................................................................................................... 3
1. MET-LINK INTRODUCTION ........................................................................................... 5
2. APPLICATIONS .............................................................................................................. 6
3. SAFETY .......................................................................................................................... 7
4. SPECIFICATION ............................................................................................................. 8
5. PINOUT & WIRING DIAGRAM ..................................................................................... 11
6. DESCRIPTION .............................................................................................................. 12
7. ACCESSORIES ............................................................................................................ 13
8. INSTALLATION ............................................................................................................ 14
Install the sensor for the first time..................................................................................... 14
Charging the battery ........................................................................................................... 16
9. ANDROID APPLICATION INTERFACE ....................................................................... 17
Activate the GPS location & Bluetooth ............................................................................. 17
Pair the sensor via Bluetooth ............................................................................................. 18
Launch the app & connect to sensor ................................................................................ 19
Record data .......................................................................................................................... 20
Export data ........................................................................................................................... 21
View a record ....................................................................................................................... 22
Comment a record ............................................................................................................... 23
Turn off MET-LINK interface ............................................................................................... 24
Quit the application ............................................................................................................. 24
Delete a record .................................................................................................................... 25
Access additional information ........................................................................................... 26
Read the Bluetooth battery level........................................................................................ 26
Export in local folder ........................................................................................................... 27
10. DEPLOYMENT .............................................................................................................. 28
Deploy the sensor ............................................................................................................... 28
Retrieve the sensor ............................................................................................................. 29
11. MAINTENANCE & CALIBRATION ............................................................................... 30
Battery replacement ............................................................................................................ 30
Long term storage ............................................................................................................... 32
12. SERVICE & SUPPORT COVERAGE ........................................................................... 33
Warranty conditions ............................................................................................................ 34
Contact & more information ............................................................................................... 34
!

MET-LINK USER MANUAL V1.02
Observator Instruments V1.02 Copyright 2017 ©
!
Page!4!
!
Page intentionally left blank
!

MET-LINK USER MANUAL V1.02
Observator Instruments V1.02 Copyright 2017 ©
!
Page!5!
1. MET-LINK INTRODUCTION
Thanks for purchasing the new MET-LINK wireless for the Gill Maximet line of weather
sensors.
What is MET-LINK?
The MET-LINK handheld solution is comprised of a Gill Maximet sensor, a MET-LINK
wireless interface and a MET-LINK Android Application for your Bluetooth-enabled
Android device.
This new development allows the user to pair the Gill Maximet’s weather sensor
parameters to a useful and full featured tablet and phone application. The MET-LINK
system can be ordered with a GMX-500 with GPS option, GMX-300 or GMX-200. The
MET-LINK compact wind sensors have all the features of the Maximet Gill sensors but
are purpose built to minimize power demand and cost.
Simple to operate, upgradeable, and can be customized with a wide range of
accessories, MET-LINK is a compact field instrument. The sensor is connected to the
wireless module for quick field or process reading. Logged records can be exported
directly from the Android Application to email, Drobox or any number of data
destinations.
The MET-LINK interface module provides rechargeable power to the sensor and
manages wireless communication to a Bluetooth enabled Android device. Sensor can
be powered for up to 5 hours. The module is lightweight, compact, and can be attached
to a tripod.
The MET-LINK Android smartphone application has a large range of features that
support data visualization, data logging, and data management. Data can be viewed
locally (on device) or exported in excel format via Bluetooth, email or GPRS to external
data servers. Logged data is time/date stamped and location tagged for mapping.
MET-LINK can be customized and is upgradeable. The MET-LINK handheld solution
offers un-paralleled ease of use, accuracy, and a very competitive price.
Download the APP today and run in DEMO mode to become instantly familiar with
intuitive operations.

MET-LINK USER MANUAL V1.02
Observator Instruments V1.02 Copyright 2017 ©
!
Page!6!
2. APPLICATIONS
MET-LINK device typical use include applications such as:
1. Quick & Remote deployments.
2. Portable accurate weather readings.
3. Fire Fighting.
4. Tactical/Defence.
5. Civil works and Safety.
6. Wind related sports (paragliding).
7. Military (UAV launching).
8. Boat applications.
9. Police deployment.
10. Pollution & Chemical hazard.
The MET-LINK system is a great reference tool for wind checking on the spot. The freedom to port
data directly to a phone, tablet or laptop offers the end user, field work efficiencies and an ordered
means of managing data.

MET-LINK USER MANUAL V1.02
Observator Instruments V1.02 Copyright 2017 ©
!
Page!7!
3. SAFETY
!
!
!
!
!
!
!
For correct functioning of Observator MET-LINK, the
sensor must be installed according installation
instructions.
!
!
!
Always read and follow Maximet instructions.
!
!
!
Always make sure to securely attach MET-LINK
interface module.
!
!
!
!
!
!
!
After end of life dispose this product according local
regulations or return to manufacturer.

MET-LINK USER MANUAL V1.02
Observator Instruments V1.02 Copyright 2017 ©
!
Page!8!
4. SPECIFICATION
Maximet sensor Dimensions
Length
222mm
Diameter
142mm
!
!
!
!
!
!
!
!
MET-LINK wireless module Dimensions
Length
191mm
Diameter
55mm

MET-LINK USER MANUAL V1.02
Observator Instruments V1.02 Copyright 2017 ©
!
Page!9!
Connectivity
MET-LINK interface (Bluetooth Module)
SPP profile
Power Supply
Extended rechargeable Lithium Ion battery
13Wh
(Battery life ~5 hours of
operation)
Power supply, charge through 12V power pack, powers on when Sensor is plugged in
Maximet GMX-500 (Gill Sensor)
Tem pe ra tur e, Humidity & Pressure
§ Air Pressure / Temperature
§ Humidity
§ Naturally aspirated UV stable radiation
shield
§ Protection against wind-blown
precipitation/dust
Wind
§ Wind speed & direction
§ Apparent and true wind (with GPS)
§ WMO wind averages and gust
§ Compass
§ GPS (optional) gives height above sea
level, latitude and longitude
GPS (OPTION)
§ Height above sea level (m)
§ MSL pressure
Parameters
§ Tem pe ra tur e (°C, °F, °K)
§ Relative humidity (% Rh, g/m3, g/kg)
§ Barometric pressure (hPa, bar, mm Hg)
§ Absolute humidity (g/m3)
§ Wind speed (m/s, km/hr, mph, kts, ft/min)
§ Wind direction (°)
§ True/apparent wind
Android App
Log files have embedded location, time & date, comments and photos
Logging of comma delimited data sentence
Statistic and smart Graph viewer tool
Fast data export
Battery Status and Charge indicator
Sensor status
!
!
!
!
!
!
Compatibility
Android Application for Smartphone & Tablet
Version 4.4 & above
Capabilities
Wind speed
(From sensor)
Tem pe ra tur e
(From sensor)
Location
(From sensor/phone)
! !

MET-LINK USER MANUAL V1.02
Observator Instruments V1.02 Copyright 2017 ©
!
Page!10!
!
Wind Speed
Range
0.1m/s to 60m/s
Accuracy
±3% to 40m/s
±5% to 60m/s
Resolution
0.01m/s
Starting Speed
0.1m/s
Sampling Rate
1Hz
Units
(m/s, km/hr, mph, kts. Ft/min)
Wind Direction
Range
0-359°
Accuracy
±3° to 40m/s
±5° to 60m/s
Resolution
1°
Sampling Rate
1Hz
Units
(Degrees)
Temperature & Dew Point
Range
-40°C to +70°C
Accuracy
±0.3°C @ 20°C
Resolution
0.1°C
Sampling Rate
1Hz
Units
(°C, °F, °K)
Humidity
Range
0-100%
Accuracy
±2% @ 20°C (10%-90% RH)
Resolution
1%
Sampling Rate
1Hz
Units
(% Rh, g/m3, g/kg)
Pressure
Range
300 to 1100
Accuracy
±0.5hPa @ 25°C
Resolution
0.1hPa
Sampling Rate
1Hz
Units
(hPa, bar, mm Hg, inHg)

MET-LINK USER MANUAL V1.02
Observator Instruments V1.02 Copyright 2017 ©
!
Page!11!
5. PINOUT & WIRING DIAGRAM
!
!
The Pinout configuration of the MET-LINK is the following:
! !
Pin Number
Meaning
#1
Signal GND
#2
Supply +Ve
#3
Supply -Ve
#4
RS422/485 TXD+
#5
RS232 TXD,
RS422/RS485 TXD-
#6
RS422/RS485 RXD+
#7
RS232 RXD,
RS422/RS485 RXD-
#8
Comms Select-Only
#9
SDI-12 Data

MET-LINK USER MANUAL V1.02
Observator Instruments V1.02 Copyright 2017 ©
!
Page!12!
6. DESCRIPTION
When the product is delivered, this is what you will find in the box:
!
!
!
!
!
!
!
!
!
!
!
!
!
!
Items found in the box
Figure 1.1.
Maximet sensor
Figure 1.2.
MET-LINK interface Module
Figure 1.3.
Charging cable
Figure 1.4.
Standard Li-ion battery

MET-LINK USER MANUAL V1.02
Observator Instruments V1.02 Copyright 2017 ©
!
Page!13!
7. ACCESSORIES
Observator Instruments offers a wide range of
accessories for MET-LINK range of product directly
available from the website:
!
!
!
!
!
!
!
!
!
Accessories
Figure 2.1.
Spare Maximet sensor
Figure 2.2.
Spare charging adapter
Figure 2.3.
Spare Li-ion extended
batteries
Figure 2.4.
Case
Figure 2.5.
Spare Bluetooth MET-LINK
interface module

MET-LINK USER MANUAL V1.02
Observator Instruments V1.02 Copyright 2017 ©
!
Page!14!
8. INSTALLATION
Install the sensor for the first time
Connect the Li-ion battery to the MET-LINK interface module (normally installed when provided),
if not please follow the instruction described in the chapter “Maintenance & Calibration” section
“Battery replacement”.
To Install the Android application on your smartphone, use the following link, download and
install the “.Apk file” (for smartphone):
https://play.google.com/store/apps/details?id=obs.metlink&hl=en
1. Connect MET-LINK sensor to the Maximet module by matching the pin and turning the
module screw.
Download & Install MET-LINK application:
! !

MET-LINK USER MANUAL V1.02
Observator Instruments V1.02 Copyright 2017 ©
!
Page!15!
2. Press on the MET-LINK interface module button and notice the blue LED indicator turning on.
If you cannot see the blue indicator light, it means the MET-LINK interface module is not powered.
Note: In the event where the indicator is not lighting up, ensure that the MET-LINK interface module
has enough battery (refer to the “Charging Battery” section of this manual) and ensure that the long
term storage switch inside the Bluetooth module is on.
Note: If storing the Wireless interface more than 6 months, please power off the device.
LED STATUS
COLOR
MEANING
Flashing Blue
Bluetooth available for pairing
Flashing Green
Device is paired
Flashing Red & Green
Battery is charging or charged
No LED
MET-LINK interface module off
3. Run the app: go to the chapter “Android Application interface” of this document.
Blue LED is on
Long term storage
switch is on

MET-LINK USER MANUAL V1.02
Observator Instruments V1.02 Copyright 2017 ©
!
Page!16!
Charging the battery
1. Connect the provided charging adapter to the MET-LINK interface module and apply power.
2. At any time, you can monitor the charging status of the module by pressing on the MET-
LINK interface button. The LED indicator is flashing green and red to indicate that the
battery is charging.
3. We highly recommend to use the application to monitor the battery level, please refer to
section “Read the Bluetooth battery level” in the chapter “Android Application Interface”.
Note: The best way to verify if the battery is fully charged is to use the Android Application to monitor
the battery level. The user should expect that the charge will take 90 minutes and up to 3 hours of
charge if the battery is fully flat.
4. When battery is fully charged, disconnect the charging cable.

MET-LINK USER MANUAL V1.02
Observator Instruments V1.02 Copyright 2017 ©
!
Page!17!
9. ANDROID APPLICATION
INTERFACE
Activate the GPS location & Bluetooth
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
! !
1. Go to your phone options
2. Activate the GPS location of your phone
3. Activate Bluetooth

MET-LINK USER MANUAL V1.02
Observator Instruments V1.02 Copyright 2017 ©
!
Page!18!
Pair the sensor via Bluetooth
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
After having activated the Bluetooth of
your phone:
1.
Turn on the MET-LINK
interface by pressing on the
blue button, make sure that the
blue LED indicator turns on.
Blue indicator
is flashing
Note: Step 2 to 5 are to be completed only the first
time you connect a new sensor.
2.
Go to the Bluetooth settings, scan to find the
new device. Select the new sensor to pair and
press pair.
3. Wait while pairing the sensor.
4. Allow pairing by pressing “Ok”.
5.
Sensor is now shown as paired, you can now
run MET-LINK Application.

MET-LINK USER MANUAL V1.02
Observator Instruments V1.02 Copyright 2017 ©
!
Page!19!
Launch the app & connect to sensor
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
1.
Search for “MET-LINK” App in Google Play
store or alternatively scan the QR code
below. Download and open the software.
2. Wait for the app to load.
3.
Search for device to connect to by pressing
on “Find Device”. If you cannot see the
device, make sure that the MET-LINK
interface module is available and the blue
LED is on.
4.
Select device from the available list. You
will notice the LED indicator turns green
when app is successfully connected to the
module.
Note: If you want to turn off the module, make
sure you disconnect the wireless module from
the app.
Green
indicator is
flashing

MET-LINK USER MANUAL V1.02
Observator Instruments V1.02 Copyright 2017 ©
!
Page!20!
Record data
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
1.
When connecting to the sensor for the first time, wait few seconds in
order to load the data and select “Logging” menu.
2. Press on “Start Logging” to start the record.
3.
A record message will be displayed while recording. Press “Stop
Logging” when required.
4. If the user did not take a picture, the app will offer the user to record
a picture on the database, press “Ok”.
5. Take a picture.
6.
Press “Save” to save the picture in the database, alternatively press
“Discard” to take another picture.
Table of contents
Other Observator Measuring Instrument manuals
