Ocean Matrix OMX-MDA6 User manual

OMX-MDA6
1x6 Video & Stereo Audio
Distribution Amplifier
www.oceanmatrix.com
Thank you for purchasing this Ocean Matrix component. This unit is designed
to give you years of trouble free professional operation for your most
demanding applications. It is our goal to develop long term partnerships with
our customers through our commitment to exceed their expectations.
Instruction Manual
For Repair Information or to view the entire Ocean Matrix product line, please visit our web site.

1x6 Video & Stereo Audio
Distribution Amplifier
OMX-MDA6
800 Kings Highway • Saugerties, NY 12477
A Division of Tower Products, Inc.
The OMX-MDA6 is a compact, high quality video and stereo audio signal distribution amplifier. With a
video bandwidth better than 10MHz, the OMX-MDA6 is perfectly suited for distribution of any com-
posite video signal such as a colorbar test signals,VTR program signals or blackburst. The audio sec-
tion of the OMX-MDA6 is designed for superb quality performance in the areas of isolation bandwidth.
Applications such as dual language, stereo program audio distribution can easily be accommodated
by this high performance product.
VIDEO
Inputs: 1Vp-p, 75Ωterminated or looped: BNC connectors
Outputs: 1Vp-p into 75Ω, BNC Connectors, 6 outputs: rear panel mounted
Gain: -3dB to +3dB, internally adjustable
Frequency Response: DC - 10MHz ±0.3dB
Output Noise: Better than 65dB <1Vp-p
AUDIO
Inputs: Unbalanced 10KΩ, looping RCA connectors
Outputs (per channel): 6 outputs, 10KΩ, Unbalanced 0dB nominal (unity), RCA connectors
Frequency Response: 10Hz - 30KHz, @ 0: -1.2dB
Signal To Noise Ratio: 85dB: 20Hz - 20KHz
Stereo Crosstalk: >110dB
Harmonic Distortion: <0.05%
GENERAL
Power: 110VAC 50/60Hz, 10 Watts (220V Model OMX-EU/MDA6)
Dimensions: 1.625”H x 8.25”W x 6”D, Steel Housing
Weight: 2.5 lbs. (less shipping carton)
SPECIFICATIONS

1x6 Video & Stereo Audio
Distribution Amplifier
OMX-MDA6
800 Kings Highway • Saugerties, NY 12477
A Division of Tower Products, Inc.
If the OMX-MDA6 is the only DA in your system,
you must terminate the video input with a 75Ωter-
minator (installed on unit). Without proper termi-
nation of the OMX-MDA6 will not function proper-
ly. Feed the video signal into the unit by connect-
ing to the BNC input. Terminate the other BNC
connector in the input section if the OMX-MDA6 is
being used as a single unit. The Diagram at Right
shows a basic setup using a MasterVCR distribut-
ing a signal to two other VCRs.
Note: There is no need to terminate audio
connectors.
If the OMX-MDA6 is one unit in a series of DAs
(bridging), then the other BNC in the input section
that has the terminator in place is used to “loop” to
the inputs of the other DAs. You must remove the
terminator from each DA that is looping to another.
The last DA in the chain must be terminated. See
sample Diagram at Right.
LOOPING DASINA SERIES
INPUT TERMINATION
The OMX-MDA6 is shipped from the factory already calibrated and ready to use. There is no need for
any customer adjustments for normal use of the unit. There are, however, certain procedures that must
be observed to assure proper performance of the unit in your system.
GENERAL OPERATION
75Ω
75Ω
Master Video Out
to OMX-MDA6 In Master Audio Out to Input
Master Source
Master Video Out
to OMX-MDA6 In Master Audio Out to Input
Master Source

1x6 Video & Stereo Audio
Distribution Amplifier
OMX-MDA6
800 Kings Highway • Saugerties, NY 12477
A Division of Tower Products, Inc.
1. To prevent fire or shock hazard, do not expose this equipment to the environment of Humidity
and/or dust. Do not use this equipment in an unprotected outdoor installation or any area classi-
fied as a wet area.
2. The operating temperature of this product must be kept between -40°C and +95°C. Direct sun-
light or an intense source of heat, direct or ambient, must not be introduced to the product
either by induction or contact.
3. Always keep the product on a stable and secure base or enclosure. Do not drop the product or
subject it to sudden heavy impact.
4. Provide adequate ventilation so that thermal characteristics do not cause an increase in product
temperature to resulting in overheating.
5. Do not clean the unit by using electrically conductive or corrosive chemicals. Always be certain
to unplug the unit from AC wall power before any major cleaning. Use a damp cloth only for
cleaning.
6. Do not subject the product to electrical mains power over voltage:The product must be used at
the rated supply voltages indicated on the product rear panel only.
7. Do not plug the product into an overloaded electrical outlet. This may result in fire or electrical
shock.
8. Object Ingress and Liquid Entry: Never insert or push sharp metal objects into the product or use
such devices for an attempt at opening or servicing the product. Servicing should be referred to
a trained and qualified technician only. Do not allow liquid of any type to enter the unit. Do not
allow the unit to be submersed in water as this may cause a shock hazard.
9. A trained qualified technician should perform all servicing of the unit. There are no serviceable
components within the unit for user access.
Safety Precautions
