Ocean Matrix OMX-10HMIP0002 User manual

OMX-10HMIP0002 Transmitter
OMX-11IPHM0002 Receiver
H.264 1080p/60 HDMI Over IP Extender with PoE, RS-232, IR
INSTALLATION & SPECIFICATIONS
Rev1a
Ocean Matrix
812 Kings Highway •SaugerƟes, NY 12477
www.oceanmatrix.com
Transmitter Kit Includes:
One Transmitter
One 5VDC/1A Power Adapter
One IR Transmitter Cable
One IR Blaster Extension Cable
Remote Control
Two Mounting Brackets & Screws
One Phoenix Plug
Set Up and Installation CD
Receiver Kit Includes:
One Receiver
One 5VDC/1A Power Adapter
One IR Receiver Cable,
One IR Blaster Extension Cable
Remote Control
Two Mounting Brackets & Screws
One Phoenix Plug
Set Up and Installation CD
OMX-10HMIP0002 Transmitter OMX-11IPHM0002 Receiver

2
Ocean Matrix OMX-10HMIP0002 & OMX-11IPHM0002
Installation
SPECIFICATIONS
Protocol H.264 Encoder over TCP/IP
Compliance HDMI, HDCP
Audio Format LPCM, Audio sampling rate 48KHZ
Transmission
Distance 394 feet/120m over Cat5e/6
IR Frequency 38-56kHz
Streaming Bit Rate 15Mbps
1 RS232 Port
2 IR Ext
3 Channel Group ID
4 Channel Down
5 Channel Up
6 Reset Button
7 Power Input
8 LED Indicators: Green—Data Status /
Red—Power On
9 HDMI Output
10 CAT5e/6 I/O
11 IR-RX
1 RS232 Port
2 IR Ext
3 Channel Group ID
4 Channel Down
5 Channel Up
6 Reset Button
7 Power Input
8 LED Indicators: Green—Data Status /
Red—Power On
9 HDMI Output
10 HDMI Input
11 CAT5e/6 I/O
12 IR-TX
OMX-10HMIP0002 TRANSMITTER
OMX-11IPHM0002 RECEIVER
SPECIFICATIONS
Default Baud Rate 2400bps
Supports IGMP, DHCP
Input Voltage 5VDC@1A
Enclosure Black Powder-Coated Steel
Dimensions Each Unit
(LxWxH) 4 3/4 x 3 1/8 x 1 1/8 inches
Weight Each Unit 9.88 oz
Ocean Matrix
www.oceanmatrix.com
1 2 4 53 6
1 2 3 4 5 6
7 8 9 10 11 12
7 8 9 10 11

3
CONFIGURATION—Refer to instructions on the included CD
1. When connecting a point-to-point application there is no need to configure the transmitter nor the receiver.
2. To configure point-to-many, many-to-point, or many-to-many, ensure each transmitter and receiver has a unique
IP and MAC address and that each transmitter has a unique group ID number using the IPTV Control Center
Program GUI on the CD.
3. This extender system has been assigned a unique default MAC address for each transmitter and receiver, so there
is no need to set the MAC for each unit. You will need to set the IP address and Group ID.
Ocean Matrix
www.oceanmatrix.com
SETTING THE IP ADDRESS—Refer to instructions on the included CD
1. DHCP (Dynamic host configuration): When using a DHCP switch, enable DHCP so that the switch assigns a
unique IP for the transmitter and receiver. Don’t change the IP for the units manually.
2. Set the IP Via Web Browser: When using a switch that doesn’t support DHCP, change the default IP manually:
Transmitter: 192.168.1.11
Receiver: 192.168.1.12
INPUT RESOLUTION
50Hz 576i/576P/720P/1080P/1080i
60Hz/59.94Hz 480i/480p/720p/1080p
30Hz/29.97Hz 1080P
24Hz 1080P
25Hz 1080P
VESA 60Hz 640x480/800x600/1024x768/1280x768/1280x960/1280x1024/1680x1050/1920x1080/1280x720/
1360x768/1400x1050
INSTALLATION—Refer to instructions on the included CD
1. Use an Ethernet cable to connect the PC and the extender.
Ensure that the transmitter and the PC are in the same domain.
The IP address of the PC should be different from the IP address of the transmitter and receiver
Access the Network Setting Control Panel in Windows to change the IP address to 192.168.1.1
Press "OK" to save the configuration.
Continued
Ocean Matrix OMX-10HMIP0002 & OMX-11IPHM0002
Installation

4
INSTALLATION—Refer to instructions on the included CD
2. Login into a Browser:
192.168.1.11 (TX default IP) or 192.168.1.12( RX default IP)
Setup IP address for the TX and RX. TX requires user name: admin and password: admin
Setup a unique IP address for each TX and each RX, IP: 192.168.1.XX (XX:1-255)
IP addresses for each TX and RX must be different and can’t be the same as the PC’s address.
3. After selecting “Use DHCP” or reset the IP Address, click “Submit” (transmitter) or “update DHCP” (receiver).
4. Click ‘Reboot’
5. Wait 30 to 60 seconds and restart the extender.
6. Setting the Group ID and Baud Rate Using the Remote Control
Factory Reset: When the Channel LED displays 00 on each unit, press the G/B button on the remote
control to select Group ID or Baud Rate. Press the Factory Reset.
Choose Group ID 00-63: press the G/B button to switch to Group ID mode and press + or—on the control
to change to the previous or the next Group ID or press the numbers.
Choose the Baud Rate: press the G/B button to switch to Baud Rate mode and press + or—on the control
to change the Baud Rate.
Choosing the Source
As an example, if the connection is:
The group ID of the transmitters is: TX1 (01), TX2 (02), TX3 (03)
If you need to display Source on TV1, then set the Group ID of RX1 the same as TX1.
7. Setting the Group ID and Baud Rate Using a Browser
Use an Ethernet cable to connect the PC and the extender.
Ensure that the transmitter and the PC are in the same domain.
Connect the TX or TX with the 5VDC/1A power supply
Login in IE: 192.168.1.11 (TX default IP) or 192.168.1.12( RX default IP)
TX requires user name: admin and password: admin
Change Group ID at ‘Stream Setting’. Choose 00-63.
Click ‘Submit’ (transmitter) or ‘Update’ (receiver).
Setting the Baud Rate—Login in IE: 192.168.1.11 (TX default IP) or 192.168.1.12( RX default IP). See baud
rates above. Default baud rate is 2400.
RS232 devices—the transmitter and the receiver must have the same baud rate as the RS232 device.
When you change the baud rate using the Remote Control and through the Web Browser, the last change
will be used by the transmitter and receiver.
Ocean Matrix
www.oceanmatrix.com
F0 2400 default
F1 4800
F2 9600
F3 19200
F4 28800
F5 38400
F6 57600
F7 115200
Source (DVD1) - TX (TX1) - Gigabit Switch – RX (RX1) - TV1
Source (DVD2) - TX (TX2) - Gigabit Switch – RX (RX2) - TV2
Source (DVD3) - TX (TX3) - Gigabit Switch – RX (RX3) - TV3
Ocean Matrix OMX-10HMIP0002 & OMX-11IPHM0002
Installation

5
PREPARING THE SWITCH—Refer to instructions on the included CD
1. A switch is required when connecting point-to-many, many-to-point, or many-to-many.
2. If the switch supports IGMP to manage Group ID and DHCP to assign IP addresses to TX and RX automatically
then enable the DHCP switch —see SETTING THE IP ADDRESS on page 3).
3. If the switch does not support DHCP, include a DHCP device such as a router to the network/ethernet setup.
POINT-TO-POINT CONNECTION—Refer to instructions on the included CD
1. Connect cable ONLY when power is OFF.
2. Connect the source and the TX using HDMI cable.
3. Connect the HDMI looping output of the TX to the local HDMI display.
4. Connect another HDMI display to the HDMI RX using HDMI cable.
5. Connect the TX and the RX with Cat5e/6 cable.
6. Connect the IR TX cable to the IR TX port on the transmitter.
7. Connect the IR RX cable to the IR RX port on the receiver to control the source at the RX end.
8. Connect one RS232 cable from the PC or system to the RS232 port on the TX.
9. Connect one RS232 cable from the RX to the RS232 device to be controlled.
10. Plug in the included power supplies to turn on the TX and RX.
Ocean Matrix OMX-10HMIP0002 & OMX-11IPHM0002
Installation
Point to Point Configuration Examples
Ocean Matrix
www.oceanmatrix.com

6
Ocean Matrix
www.oceanmatrix.com
Ocean Matrix OMX-10HMIP0002 & OMX-11IPHM0002
Installation
POINT-TO-MANY CONNECTION—Refer to instructions on the included CD
1. Set the IP addresses for the transmitter and the receiver and prepare the switch as instructed previously.
2. Connect the source device and the TX using HDMI cable.
3. Connect the HDMI looping output of the TX to the local HDMI display.
4. Connect the TXs and the switch/router using CAT5e/6 cable.
5. Connect the HDMI displays and the HDMI RXs using HDMI cable.
6. Connect the IR TX cable to the IR TX port on the transmitter.
7. Connect the IR RX cable to the IR RX port on the receiver to control the source at the RX end.
8. Connect one RS232 cable from the PC or system to the RS232 port on the TX.
9. Connect one RS232 cable from the RX to the RS232 device to be controlled.
10. Turn the TX and the RX on using the included power supplies.
11. Notes
Daisy chain the switch if more RJ45 ports are needed
You can add up to 255 receivers
MANY-TO-MANY CONNECTION—Refer to instructions on the included CD
1. Set the IP addresses for the transmitter and the receiver and prepare the switch as instructed previously.
2. Connect the source device and the TX using HDMI cable.
3. Connect the HDMI looping output of the TX to the local HDMI display.
4. Connect the TXs and the switch/router using CAT5e/6 cable.
5. Connect the RXs and the switch/router using CAT5e/6 cable
6. Connect the HDMI displays and the HDMI RXs using HDMI cable.
7. Connect the IR TX cable to the IR TX port on the transmitter.
8. Connect the IR RX cable to the IR RX port on the receiver to control the source at the RX end.
Continued
Point to Many Configuration Example

7
Ocean Matrix
www.oceanmatrix.com
Ocean Matrix OMX-10HMIP0002 & OMX-11IPHM0002
Installation
MANY-TO-MANY CONNECTION—Refer to instructions on the included CD
9. Connect one RS232 cable from the PC or system to the RS232 port on the TX.
10. Connect one RS232 cable from the RX to the RS232 device to be controlled.
11. Turn the TX and the RX on using the included power supplies.
12. Choose the source with the Remote Contol or Web Browser (see previous instructions)
13. Notes
Daisy chain the switch if more RJ45 ports are needed
You can add up to 64 transmitters
The total quantity of transmitters and receivers cannot exceed 255
There is no need to use a power
adapter for the TX and RX when
connecting with a PoE Switch.
Many to Many Configuration Example

8
SAFETY PRECAUTIONS
To prevent fire or shock hazard, do not expose this equipment to dust or high humidity. Do not use in an
unprotected outdoor installation or in areas classified as overly damp or wet.
The installation temperature should be kept between 32°F to 140°F (0°C to 60°C). Avoid direct sunlight exposure or extreme
changes of temperature over a short period of time.
Do not place the unit on an unstable base and avoid heavy impact.
Proper ventilation is required for permanent installation. Do not block or cover enclosure openings as they protect the unit from
overheating.
Prior to cleaning, turn the power off and unplug the unit from all connections. Use a damp cloth. Do not use liquid or aerosol
cleaners.
Do not overload outlets and extension cords as this may result in a risk of fire or electric shock.
Enclosure entry is dangerous. Never push objects of any kind, including liquids, through openings as they may touch dangerous
voltage points or short-out parts that could result in a fire or electric shock.
Do not open or service this unit yourself as opening or removing covers may expose you to dangerous voltage and other hazards.
There are no user-serviceable parts inside the unit. If the unit requires service contact your authorized dealer, or authorized repair
service company.
Rev1a
Ocean Matrix
812 Kings Highway •SaugerƟes, NY 12477
www.oceanmatrix.com
FCC Caution
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Class A Interference Statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
Federal Communications Commission (FCC) Compliance Notices
