Ocean Matrix OMX-01HMBT0003-R User manual

1 Power LED Indicator
2 Factory Use Only
1 32
OMX-01HMBT0003-R HDBaseT 4K HDMI Receiver
INSTALLATION & SPECIFICATIONS
Ocean Matrix
www.oceanmatrix.com
7 8 94 5 6
3 Plug in AC Adapter Power Supply
4 HDBaseT In—Connect to TX
5 IR-IN Port-Connect IR Cable
6 IR-Out Port-Connect IR Cable
7 HDMI Out—Connect to Display
8 USB Ports– Connect to USB device such as a mouse or keyboard
9 RS232 3-Pin Connection
Display
Receiver
Source RS232 3 Pin
Equipped Device
Application with Wall Plate Transmitter OMX-01HMBT0003-T
NOTE: This transmitter does not support KVM/USB Functions of the OMX-01HMBT0003-R Receiver
Transmitter
Front Back
Computer w/RS232
3 Pin Connection
IR Control Equipment
Power
Supply

Ocean Matrix
www.oceanmatrix.com
Application with a Desktop Transmitter
Display
Transmitter
Receiver
Plug In Power
Supply to
TX OR RX
RS232 3 Pin Equipped Device
Keyboard
Mouse
Computer w/RS232 3 Pin Connection
FEATURES
Extends Two-Way IR & RS232 3-Pin Pass Through
Transmission Distance: 1080P Up to 230 Feet, 4K up to 131 Feet
Up to 7.1 Channels HD Audio
Two-Way 24V PoC
Rugged Black Powder-Coated Metal Enclosure
CE, FCC Certified
Includes:(2) Mounting Ears, (1) RS232 Connector, (1) 24V/1A Power Supply
SPECIFICATIONS
Compliance HMDI 2.0b, HDCP2.2, HDCP 1.4
Video Bandwidth 18Gpbs
HDMI Video
Resolutions up to 4K2K@50/60Hz(YUV4:4:4), 4K2K@30Hz, 1080P@120Hz,1080P 3D@60Hz
Color Space/Depth RGB/YCbCr 4:4:4, YCbCr 4:2:2/ 10-bit, 12-bit
HDMI Audio Formats LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1,
Dolby Digital+, Dolby TrueHD, DTS-HD Mas-
ter Audio, Dolby Atmos, DTS:X
Power Consumption 7.5W
Dimensions (HxWxD) 0.8 x 6.8 x 3.8 in
Weight 0.92 lb

3
SAFETY PRECAUTIONS
 To prevent fire or shock hazard, do not expose this equipment to dust or high humidity. Do not use in an
unprotected outdoor installation or in areas classified as overly damp or wet.
 The installation temperature should be kept between 32°F to 140°F (0°C to 60°C). Avoid direct sunlight exposure or extreme
changes of temperature over a short period of time.
 Do not place the unit on an unstable base and avoid heavy impact.
 Proper ventilation is required for permanent installation. Do not block or cover enclosure openings as they protect the unit from
overheating.
 Prior to cleaning, turn the power off and unplug the unit from all connections. Use a damp cloth. Do not use liquid or aerosol
cleaners.
 Do not overload outlets and extension cords as this may result in a risk of fire or electric shock.
 Enclosure entry is dangerous. Never push objects of any kind, including liquids, through openings as they may touch dangerous
voltage points or short-out parts that could result in a fire or electric shock.
 Do not open or service this unit yourself as opening or removing covers may expose you to dangerous voltage and other hazards.
 There are no user-serviceable parts inside the unit. If the unit requires service contact your authorized dealer, or authorized repair
service company.
Rev1a
Ocean Matrix
812 Kings Highway •SaugerƟes, NY 12477
www.oceanmatrix.com
