Ocean Matrix OMX-07MXMX0001 User manual

OMX-07MXMX0001
Mixed Input Type-C VGA HDMI 2.0
HDBaseT Switch

HDBaseT 2.0
HDMI 2.0
Supports 4K@60Hz YUV 4:4:4, 18G, HDR10
VGA x 1, USB Type-C x 1, and HDMI x 2 Inputs
Transmits 1080p@60Hz up to 70m and 4K@60Hz up to 40m
HDCP 2.2 & 1.4 Compliant
Audio Sampling Rate up to 192 KHz, supports Max 7.1CH
Supports Embedded Analog Audio & External Mic Input
Supports Analog/SPDIF Audio Extraction, Analog Output Support PCM2.0, SPDIF
Output Supports Dolby, DTS, Max 5.1CH
Wide-band Bi-Directional IR Routed Control (38-56KHz), IR Extender to Control
Device
Supports RS232 Pass Through
LCD Panel to Indicate IR Routing, RS232, TCP/IP, PC Tool Control
Supports POC (Receiver Powered by HDBaseT Switch)
The Ocean Matrix OMX-07MXMX0001 is a 4-port HDBaseT switch that allows switching
between four sources (1x Type-C, 1x VGA, 2x HDMI) to both HDMI and HDBaseT
outputs simultaneously. The switch supports HDMI resolutions up to 4K@60Hz
YUV4:4:4, and will transmit 1080p up to 70m, and 4K up to 40m via the HDBaseT
output. The OMX-07MXMX0001 also supports audio extraction and audio mixing.
Note: The OMX-07MXMX0001 does not allow for simultaneous HDMI and HDBaseT
output.
Description:
Features:
IR Blaster Cable
IR Receiver Cable
Mounting Ears x 4
Machine Screws (KM3*4) x 8
3PIN-3.81mm Phoenix Connector x 2
24V/1A Locking Power Adapter
Item Includes:

Specifications:
Operating Temperature Range: 23 to +104°F (-5 to +40°C)
Storage Temperature Range: 14 to +140°F (-10 to +60°C)
Operating Humidity Range: 5 to 90 % RH (No Condensation)
Input Video Signal: 0.5-1.0 volts p-p
Input DDC Signal: 5 volts p-p (TTL)
Bandwidth: 18Gbit/s
Video Formats Supported: 4K@60Hz, YUV4:4:4 / 4k@30Hz/1080P/1080i/720P
HDCP Compliance: HDCP 2.2 & HDCP 1.4
Output Video: HDMI 2.0 and HDMI 1.4 (HDBaseT and HDMI)
Audio Formats Supported: PCM 2.0, Dolby 5.1, DTS 5.1 Digital Audio
Maximum Transmission Distance: 1080P @ 70m, 4K @ 40m (HDBT output) | 4K@ 6M /
1080p @ 15m (HDMI Output)
Power Consumption: 16.5wtts (Max)
Dimensions (LxWxH): 9.25 x 5.38 x 1.5in (235 x 137 x 39mm)
Weight: 2.61lbs (1.175kg)

Operation Controls and Functions:
Control - RS232 pass through for PC tool control / Ethernet for IP / web control / IR Extender for switch control
Audio In - PC audio in for VGA input only / HDMI analog PCM2.0 audio embedded
Audio SPDIF Out - Dolby, DTS, Max 5.1CH
Analog PCM2.0 Audio Out
IR-In / IR-Out - for remote controlling
DC 24V / 1A - power supply input
Mic In - microphone input
Mic Switch - left switch for 48V mode, middle for Mic mode, and right for line mode (analog PCM2.0 audio
embedded)
Video Input - Type C-1 usb c in / PC-2 VGA in / HDMI-3 & HDMI-4
Video Output - HDMI / HDBT/POC HDBT out (connects HDBaseT receiver / other HDBaseT prodcuts)
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Switcher:
LCD Screen - Displays switch information
Function Buttons - Up, Down, Left, and Right
Function Button - Menu, and Enter
1.
2.
3.
Note: When you need to use MIC in / embedded analog audio function, please set the audio input mode for "analog"
then switch the MIC switch to choose the audio format (48V / Mic / Line)

Connection Diagram

Operation Controls and Functions:
4
67
HDMI Out 1
HDMI Out 2
IR Out
IR In
DC/12-24V Input
Factory Use Only
CAT5e/6
RS232
1.
2.
3.
4.
5.
6.
7.
8.
3
1
8
5
Receiver:
2

Menu Display
When pressing the menu button, options include "VIDEO SET", "AUDIO SET", "EDID
SET", "MIC IN VOL SET", "ANAL OUT VOL SET", "IP QUERY", "UART QUERY", "REST
SET".
1) VIDEO SET: For input switch, select VIDEO SET, press enter, use the left & right
buttons to select current input signal and hit enter again to finish setting.
2) AUDIO SET: 3 audio input modes are supported, HDMI (audio input from signal),
analog (audio embedded), Mute (silent mode), select AUDIO SET press the enter
button, then use the left & right buttons to select audio input. Press enter again to finish
setting.

3) EDID SET: 4 EDID modes are supported, 4K60 (default), 1080P (default), COPY
HDMI, COPY HDBT. Select EDID SET press the enter button, then use the left & right
buttons to select desired EDID setting. Press enter again to finish setting.
4) MIC IN VOl SET: MIC input volume adjustment from 0-10 (max). Select MIC IN VOL
SET press the enter button, then use the left & right buttons to select desired volume
setting. Press enter again to finish setting.
5) ANAL OUT VOL SET: Analog audio out volume adjustment from 0-10 (max). Select
ANAL OUT VOL SET press the enter button, then use the left & right buttons to select
desired volume setting. Press enter again to finish setting.

6) IP QUERY: Default IP address 192.168.1.168. DHCP: off, use the left & right buttons
to select desired DHCP status setting and press enter to finish setting.
7) UART QUERY: The device supports the following baudrates, 9600, 19200, 38400,
57600, and 115200 (default). To check current baudrate, select UART QUERY and
press enter.
8) SYSTEM RESET: To factory reset, press enter on SYSTEM RESET.

Dual way IR use:
1) “IR IN” is for HDBT output, “IR OUT” is for input channel.
2) OMX-07MXMX0001 receiver supports connections with IR-RX cables to control the
OMX-07MXMX0001 switch by remote.
3) The OMX-07MXMX0001 switch supports connection with IR-RX cable (IR in) to
control TV by remote.
4) The OMX-07MXMX0001 “IR Ext” supports connection with IR-RX cables to control the
OMX-07MXMX0001 by remote.
The OMX-07MXMX0001 can pass the IR signal through the IR system to the HDMI
source or pass the IR signal from the HDMI source to the HDMI sink.
IR System
IR IN IR OUT
PC Tool Control
1) Download the “swe01b_4-Input HDMI Switcher.exe”software to your computer from
included disk, then open it.
2) Using USB to RS232 cable connect to the RS232 port of the OMX-07MXMX0001 switch.
3) Press “Search” button to find out the right port then click “Open Port”.

Port Setup
1) Communication port setting: in PC windows system run the “swe01b_4-Input HDMI
Switcher.exe”software,in RS232 INFO. ,select correct port (communication port) and
baud (should be same to baudrate in UART QUERY for connection)
2) Click “Search” to refresh communication port.
3) “Open Port”: in disconnect status,”Close Port”: connected to device.

4) If you are receiving “ERROR” the COM port is invalid and is not connected correctly,
press “OK” to refresh again.
Control Interface
5) Below will show current COM port info. and baudrate when connected to device:

1). Video Input: Switch Type C, VGA, HDMI input.
2). EDID Mode:
4K60: Default EDID 4K@60Hz
1080P: Default EDID 1080P@60Hz
HDMI: Copy HDMI out EDID for input (Copy mode)
HDBT: Copy HDBT out EDID for input (Copy mode)
3) Audio Input Mode: Click to choose input option, HDMI, Analog, Mute, (HDMI: audio of
Type C/VGA/HDMI, Analog: audio embedded/MIC in)
4) MIC: VOL control, the number “5” shows the current volume. (Please note:you can
only set the MIC VOL when choosing “Analog” for audio input)
5) Analog Output: VOL control,the number “5” shows the current volume. (Please
note:you can not set VOL when audio input is “Mute”)
6) Setting: Factory reset.
Note: Please set the audio input mode for “Analog” first by panel/PC tool/Web GUI when
you need to use MIC in/Analog audio embedded function.
① Mac Address: Can not modify
② IP Address: supports modify
③ Net Mask Address: supports modifying
④ Gate Way Address: supports modifying
⑤ DHCP ON/OFF
⑥ Apply: Click to confirm modified static IP

Note: When you click for DHCP ON, then IP Address, Net Mask Address, Gate Way
Address frames all become grey and can not be modified.
WEB Control
Change the IP address of your PC
1) Connect the Ethernet port of HDBaseT switch to the Ethernet port on PC by a straight
pin to pin cable with RJ45 connectors.
2) Configure your PC as follows:
① Click Start > Control Panel > Network and Sharing Center.
② Click Change Adapter Settings.
③ Highlight the network adapter you want to use to connect to the device and click

Change the settings of this connection:
3). The local Area commotion properties window for Network selection appears as
below.
4). Click the Highlight Internet Protocol Version 4 (TCP/IPv4).
5). Click Properties.
6). Select Use the following IP Address for static IP addressing and fill in the details. For
TCP/IPv4 you can use any IP address in the range 192.168.1.1 to 192.168.1.255
(excluding 192.168.1.168).
7). Click OK.
8). Click Close.
(Default IP Address: 192.168.1.168; MASK: 255.255.255.0; Gateway:192.168.1.1)

Enter WEB and Control
1) Enter the default IP address of the matrix: 192.168.1.168. 2). You will see following
picture and control:
Control software operation:
The serial control software is illustrated with SSCOM32 as an example. Basic Settings:
Command Control

Double-click the software in the installation package to run specifically (as shown in figure 1 ) and
install the RS232 software on the computer.
Enter the main interface of the software, as shown in the figure below.
Please use USB to RS232 cable to connect PC and device,open RS232 software. In the parameter
configuration area of the RS232 program, select the serial number that the serial port connects with
PC, and set the baud rate of the communication protocol: 115200 (default), data bits: 8. Stop bits: 1,
Parity: None, you can input the instruction in the command input area and control the machine or
remote receiver.

Instructions:
1). All commands start from “#”, “%d” parameters
2). The “_” in the commands cannot omit
The following table is only an example. Please refer to the list of instructions.
Please refer to above “Command list” for details.
For example:
Operation format
Video Input Channel Switch:
#video_d in1 (Switch to Type C input) Audio embedded in: #audio_d enc=1 value=7 (MIC VOL
adjust to 7) Audio IIS out VOL Set: #audio_d iis=7 (Analog audio VOL adjust to 7) EDID Mode Set:
#edid_d mode=2 (Copy EDID of HDMI out for input) Baudrate Set: #uart baud=0 (Current baudrate
set is 9600) DHCP Set: #ip dhcp=1 (DHCP open)
Power Off and Reboot Input Priority Mode
When the OMX-07MXMX0001 switch reboots and it inspects the current input signal in “None”
status, device will auto switch to a higher priority input signal (If there is no higher priority input than
the current one, it will switch to a lower priority input). Priority table for input:

Note:
1) If the current input has signal, the device will not auto switch to other input when rebooting, it will
keep the current input.
2) When all inputs have no signal, device saves last switch port when rebooting.
3) The priority mode is only valid when the device has signal input.
RS232 Pass through
By RS232 Command, the OMX-07MXMX0001 switch can send RS232 data to control the receivers,
also the receiver can send RS232 data to control the OMX-07MXMX0001 switch.
Please refer to the command list which is included in the manual
Micro USB for Firmware Upgrade
MCU application layer upgrade
1) The user should use the CD in colorbox, read and install software "UART_ISP.exe" on PC;
2) Connect unit to PC with USB cable from micro USB port,click "UART_ISP.exe" software,
REFRESH and choose correct COM port that connect to product,and baudrate 115200(default).The
baud rate setting is consistent with the host baud rate.
3) Type in “A1” in PORT and choose update program file in PATH,then click UPDATA wait for
update until it prompt “Succeed” informations and upgrade completed:
GUI Application Layer Upgrade
1). Connect unit to PC with USB cable from micro USB port,click "UART_ISP.exe" software,
REFRESH and choose correct COM port that connect to product,and baudrate 115200(default).The
baud rate setting is consistent with the host baud rate.
2). Type in “A1 01” in PORT and choose update program file in PATH,then click UPDATA wait for
update until it prompt “Succeed” informations and upgrade completed:

GUI Web Upgrade
1) Connect unit to PC with USB cable from micro USB port,click "UART_ISP.exe" software,
REFRESH and choose correct COM port that connect to product,and baudrate 115200(default).The
baud rate setting is consistent with the host baud rate.
2)Type in “F0 01” in PORT and choose update program in PATH,then click UPDATA wait for update
until it prompt “Succeed” informations and upgrade completed:
Note:If the upgrade progress
bar is stopped in the middle of
the upgrade, then the host will
need to be rebooted, then the
serial port will be upgraded.
