Ocean Matrix OMX-PSW24 User manual

OMX-PSW24
24 x 1 Video / Stereo Audio
Passive Switcher
www.oceanmatrix.com
Thank you for purchasing this Ocean Matrix component. This unit
is designed to give you years of trouble free professional opera-
tion for your most demanding applications. It is our goal to develop
long term partnerships with our customers through our commitment
to exceed their expectations.
Instruction Manual
For Repair Information or to view the entire Ocean Matrix product line, please visit our web site.

24x1 Video & Stereo Audio
Passive Switcher
OMX-PSW24
800 Kings Highway • Saugerties, NY 12477
A Division of Tower Products, Inc.
The OMX-PSW24 is a high quality 24 x 1 Video and Stereo Audio Passive Switcher. This device is
designed as a general purpose signal switcher for selection of 24 inputs to a single output using top
grade, high visibility lockout mechanical switches.It may also be used to fit the needs of facilities where
“signal sniffing” is needed. It may also be used to expand the inputs of Video devices.
The OMX-PSW24 may also be used as a 1 x 24 assignment switcher where one set of signals can be
fed to any of twelve feeds.
The use of this device is very simple. As a source switcher, simply plug the signal feeds via the rear
connectors into the switcher. By pushing the corresponding front panel button, the signal (Video and
Audio), is selected to the output connectors.
The OMX-PSW24 may also be used as an “assignment switcher”. A signal can be fed into the output
terminal and selectively distributed to any one the twelve signal paths. With this technique, the switch-
er is actually used in “reverse” of conventional configuration.
Video Inputs: 24 Video via BNC connectors
Non terminating MBB
Audio Inputs: 48 (24 L&R Stereo pairs) via RCA connectors
Outputs: Video: 1 via BNC connector
Audio: Stereo Pair (L, R) via RCA connectors
Dimensions: 1.75"H x 7"D x 19"W (EIA Rackmount)
Weight: 3.5 Lbs. (without shipping carton)
SPECIFICATIONS
OPERATING THE OMX-PSW24
