Ocean Way Audio S12A MKIII Instruction Manual

Manual of Operations
Ocean Way Audio S12A MKIII

Contents
1) S12A MKIII Description
2) Safety Instructions and Warnings! (please read carefully)
3) Inputs and Controls
4) Specifications
5) Warranty

1) S12A MKIII Sub Description
The S12A sub-bass cabinets is a single 12” long throw woofer in a bass reflex cabinet extending the
response down to 25Hz. It is powered by an 800 watt amplifier. Ideal to pair with any of our loudspeakers to
achieve great SPL and low end extension.
The Voltage auto selects between 100v and 240v-115W 50/60HZ
DO NOT REMOVE MAINS CONNECTOR GROUND, IT IS ILLEGAL AND DANGEROUS

Read the information for use
Please keep this user manual in a safe place during the lifetime of the product.
Heed all warnings.
Follow all instructions.
Do not use this product near water (for example, in damp rooms or near a swimming pool).
Clean only with dry cloth.
Do not cover the heat sink. Install in accordance with the user manual.
Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus that
produce heat.
Protect the power cord from being walked on, pinched or damaged in any other way. Pay particular
attention to plugs and the point where they exit from the Amplifier Unit.
The Amplifier Unit can only be disconnected from the power supply by removing the plug, which must
be freely accessible at all times. Unplug this Amplifier Unit during lightning storms or when unused for
long periods of time.
Refer all servicing to qualified service personnel.
2) Safety Instructions and Warnings

Servicing
Do not attempt to service this product yourself, as opening or removing covers may expose you to
dangerous voltage or other hazards. The amplifier may only be opened by qualified personnel. Please
refer to your dealer/distributor.
Servicing and Replacement Parts
All service and repair work must be carried out by an authorized dealer/distributor. When replacement parts
are required, please ensure that the dealer/distributor only uses replacement parts specified by the
manufacturer. The use of unauthorized replacement parts may result in injury and/or damage through fire
or electric shock or other electricity - related hazards.
Ventilation and heat sink
The heat sink is provided to ensure reliable operation of the Amplifier Unit and to protect it from
overheating. The heat sink must not be blocked or covered. This product should not be installed unless
proper ventilation is provided or manufacturer’s instructions have been adhered to.
Water and Moisture
Do not use this product near water (for example, in damp rooms or near a swimming pool).
Cleaning
Unplug the Amplifier Unit from the wall outlet before cleaning. Do not use liquid or aerosol cleaners.

Power -Cord Protection
Power supply cords should be routed so that they are not likely to be walked on or pinched by items
placed upon them or against them, paying particular attention to cords and plugs, and the point where
they exit from the Amplifier Unit.
Lightning
For added protection of the product during lightning storms, or when it is left unattended and unused for
long periods of time, unplug it from the wall outlet. This will prevent damage to the product due to
lightning and power-line surges. Disconnection from the mains power supply can only be achieved by
removing the plug from the mains socket and by external disconnection of all poles from the mains.
Accessories
Do not place this product on an unstable cart, stand, tripod, bracket, or table. The product may fall,
causing serious injury, and serious damage to the product.

Connecting
When you connect this speaker to other equipment, turn off the power and unplug all of the equipment
from the supply source. Failure to do so may cause an electric shock and serious personal injury. Read
the user's manual of the other equipment carefully and follow the instructions when making the
connections.
Sound Volume
Reduce the system volume to minimum before you turn on the amplifier to prevent sudden high levels
of sound which may cause hearing or speaker damage.
Precautions when connecting to MAINS IN
When mounting or connecting the product always disconnect it from mains. Only connect the product to
an appropriate AC circuit and outlet, according to the requirements indicated on the rating plate. If a
power cut occurs while the amplifier is switched on, it will restart automatically once the power supply
has been restored. All settings prior to the loss of power will be maintained. IMPORTANT: Always
connect the Product to mains through the MAINS IN connector on the Amplifier Unit.

3) Inputs and Controls S12A MKIII

Inputs and Controls S12A MKIII
The Power Switch (toggle) has three positions.
1.) In the left most position the unit is powered OFF.
2.) In the center position the unit is in Auto mode. It can
be powered on uniting the 12V trigger inputs or
by feeding audio into the input XLR. In the absence of
either it will enter STANDBY mode with the red LED
illuminating.
When the trigger is activated or audio is supplied it will
power up and the green LED will illuminate.
3.) The right most position is will power up to ON with the
green LED illuminating. It will remain ON in this position.

Inputs and Controls S12A MKIII
GAIN is the volume control. A suggested starting position is 12 o’clock when matched
with HR5 speakers. Adjust up
or down to suit positioning in your room. (Closer to a wall or a corner on the floor will
increase the low frequency response.
LF Adjust incorporated a LF shelf @ 45 Hz +/- 5 db in 1 db increments
Crossover switch selects frequencies from 60 / 65 / 70 / 75 / 80 /85 / 90 /95 / 100 / 110 /
120hz
Delay adjusts from 0 to 20 ms.
12V trigger (AC or DC) will turn the unit on and off when power switch is in center (Auto)
position. The jacks are paralleled to daisy chain to other auto powered products. With
switch in center position and no trigger utilized, the unit will power ON when audio is
sent to the input XLRs.
Balanced XLR IN & OUT jacks are paralleled and a direct feed through. Signal does not go
through any electronics.

4) S12A MKIII Specifications
Tech Specs
S12A MKIII
Powered
YES
Driver Configuration
Single 12” Woofer
LF Driver Size
12"
LF Driver Power Amp
800w/D
Analog Inputs
Balanced
Frequency Range
25Hz>150Hz
Maximum Peak SPL
110db
Enclosure Type
Ported
Height
18"
Width
18"
Depth
21.5"
Weight
76 lbs

Ocean Way Audio speakers are under limited warranty as described in the following conditions.
1. Warranty period starts as of date of purchase from the authorized dealer.
2. OWA reserves the right to request original purchase receipt as proof of the date of purchase.
3. Electronic components and cabinetry are warranted for a period of two (2) years against manufacturing defect, covering
parts and labor for necessary repairs.
4. Speaker driver components are warranted for a period of one (1) year against manufacturing defect.
5. The manufacturer’s warranties are limited to physical defects in the materials, parts and workmanship used in making the
product.
6. Misuse, incorrect installation, handling, repairs or modifications performed by unauthorized persons, abnormal conditions,
damage due to accidents such as power surges, water, fire, or any other are excluded from any warranty claims.
7. OWA warrants all service repairs and replacements for 180 days from the date of return to the customer/owner.
Technical Support and Service
For warranty service and assistance, contact the original authorized dealer/distributor to arrange for return and/ or repair of the
product. OWA will strive to satisfy all service requests in the fastest manner possible. Under the warranty, OWA will repair, or at
its discretion, replace the product at no charge, provided it is returned (postage paid) to an authorized OWA service center. Any
shipping or duties incurred are the customer’s responsibility. Products should be returned suitably packaged to protect from
shipping damage, or in their original packaging. OWA shall be the sole and final authority to determine the validity of all warranty
issues. All non-warranty repairs for current products will be charged according to the service repair pricing schedule. Repair
prices will either be based on a flat fee for repair or replacement, or will be estimated depending on the repair deemed necessary.
5) Warranty

Ocean Way Audio
History

It all started with speakers. Ocean Way Recording began in 1968, as a showcase for
Allen’s custom monitors.
Allen needed impressive sounding material for his speakers so he began to record music
that sounded dramatic! The studio business boomed and he met the demand with many
rooms in several locations. At the peak of the studio business, Allen designed and owned
four recording studio complexes.
Five time Grammy® Award winning Allen Sides has personally recorded over 1,000
albums, many of which have become audiophile classics. He has worked with the finest
and most famous artists of the last four decades. Albums recorded in Allen’s studios have
sold over a billion copies. Allen’s hearing capabilities enables our engineers to translate
every sonic nuance, bringing a new dimension and understanding to what is possible in
high-end speaker design. His ears are our final design tool.
About Ocean Way

Through-out the history of Ocean Way Studios, we built the monitor systems for all the control rooms
and private studios for selected elite cliental.
These many accomplishments, paved the way for
Ocean Way Audio
The HR Series delivers “the” sound of Ocean Way Studios in a free standing design.
Engineering speaker systems for professionals; incorporating over 45 years of award winning experience
Ocean Way Hollywood Ocean Way Nashville Ocean Way Record One Ocean Way St. Barts
