OCEANIC SYSTEMS 15.6” SECONDARY DISPLAY
Part Numbers: 5115
USER MANUAL
Revision 1.00

1 of 7
1 Introduction ........................................................ 2
1.1 Product Features ............................................... 2
2 Unit Dimensions ................................................... 3
3 Installation........................................................... 4
3.1 Unpacking The Box ............................................ 4
3.2 Mounting The Unit............................................. 4
3.3 Connecting The Display............................. ......... 4
4 User Controls ...................................................... 5
5 Technical Support ................................................ 6
6 Warranty ............................................................ 7

INTRODUCTION
1
2 of 7
The Oceanic Systems’ 5115 NMEA2000® Secondary Display is a 15.6”, high bright, sunlight
readable 1000cd/m2 display.
The 15.6” Secondary Display is designed for the Poseidon® System and contains a button panel
to control the brightness of the backlight to the display.
1.1 PRODUCT FEATURES
The Oceanic Systems’ NMEA2000® Secondary Display has the following features:
• Sunlight readable dimmable display using our BlackGlass™ technology
• 1920 x 1080 FHD resolution
• Touchscreen using capacitive touch
• Button panel providing: Power On/Off, Brightness Up and Brightness Down
• CAT 5 Ethernet connections
• Toughened glass
• IP rating of IP67 for front and IP20 for rear of the display

UNIT DIMENSIONS
2
3 of 7
Outside/overall dimensions 398mm x 252mm x 46mm
Inside/active area dimensions 345mm x 194mm
Diagonal 15.6”
398mm
252mm
46mm

3INSTALLATION
4 of 7
3.1 UNPACKING THE BOX
You will nd the following items in the shipping box:
1x 15.6” Secondary Display
1x 5m USB cable
1x 2m DC Power cable
1x Mounting kit (x4 screws and x4 mounting clamps)
1x User Manual (this document)
3.2 MOUNTING THE UNIT
1. The unit should be mounted through a panel to a at surface min 8mm, max 25mm.
2. It can be mounted 45 degrees either way of vertical.
3. Ensure adequate ventilation behind the product to prevent heat build up with a minimum of
50mm clearance.
4. Remember to allow enough clearance for access to cables and connectors. Cables should be
retained to prevent damage to connectors.
5. The unit should be sealed to the mounting surface using a suitable silicone sealant. This
Silicone sealant will be part of the seal used to provide the IP rating for the front of the
product.
6. Using the 4 mounting clamps to the rear of display secure the unit to the mounting surface
by tightening the screws.
370mm
242mm

4
5 of 7
USER CONTROLS
The button panel on the screen provides the following
DIM
Each press will decrease the brightness level. Holding the button will continue to decrease the
brightness until the minimum level is reached.
BRIGHT
Each press will increase the brightness level. Holding the button will continue to increase the
brightness until the maximum level is reached.
STANDBY
Switches the screen on or off.
DIM BRIGHT STANDBY

6 of 7
5TECHNICAL SUPPORT
If you require technical support for any Oceanic Systems products you can reach us using any of
the following:-
●Tel (UK): [phone]
●Tel (USA): [phone]
●Fax: [phone]
●Email: [e-mail]
●Web: www.osukl.com
●Post: Oceanic Systems Ltd
Unit 10-11 Milton Business Centre
Wick Drive, New Milton, Hampshire BH25 6RH
Oceanic Systems (UK) Ltd
Unit 10-11 Milton Business Centre, Wick Drive,
New Milton, Hampshire, BH25 6RH, United Kingdom
Tel (UK): [phone] Tel (USA): [phone]
Fax: [phone] Email: [e-mail]
Web: www.osukl.com
Copyright © 2019 Oceanic Systems (UK) Ltd. All rights reserved. Our policy is one of continuous product improvement so product
specications are subject to change without notice. Oceanic Systems products are designed to be accurate and reliable.
However, they should be used only as aids to vessel monitoring, and not as a replacement for traditional navigation and vessel
monitoring techniques. NMEA2000® is a registered trademark of the National Marine Electronics Association.

7 of 7
WARRANTY
6
Oceanic Systems warrants this product to be free from defects in materials and workmanship for
one year from the date of original purchase. If within the applicable period any such products shall
be proved to Oceanic Systems satisfaction to fail to meet the above-limited warranty, such products
shall be repaired or replaced at Oceanic Systems option. Purchaser’s exclusive remedy and Oceanic
Systems sole obligation hereunder, provided product is returned pursuant to the return requirements
below, shall be limited to the repair or replacement, at Oceanic Systems option, of any product not
meeting the above limited warranty and which is returned to Oceanic Systems; or if Oceanic Systems
is unable to deliver a replacement that is free from defects in materials or workmanship, Purchaser’s
payment for such product will be refunded. Oceanic Systems assumes no liability whatsoever for
expenses of removing any defective product or part, or for installing the repaired product or part or
a replacement therefore or for any loss or damage to equipment in connection with which Oceanic
Systems products or parts shall be used. The foregoing warranties shall not apply with respect to
products subjected to negligence, misuse, misapplication, accident, damage by circumstances beyond
Oceanic Systems control, to improper installation, operation, maintenance, or storage, or to other
than normal use or service.
THE FOREGOING WARRANTIES ARE EXPRESSLY IN LIEU OF AND EXCLUDES ALL OTHER EXPRESS
OR IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND OF FITNESS FOR A PARTICULAR PURPOSE.
Statements made by any person, including representatives of Oceanic Systems, which are inconsistent
or in conict with the terms of this Limited Warranty, shall not be binding upon Oceanic Systems
unless reduced to writing and approved by an ofcer of Oceanic Systems.
IN NO CASE WILL OCEANIC SYSTEMS BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES,
DAMAGES FOR LOSS OF USE, LOSS OF ANTICIPATED PROFITS OR SAVINGS, OR ANY OTHER LOSS
INCURRED BECAUSE OF INTERRUPTION OF SERVICE. IN NO EVENT SHALL OCEANIC SYSTEMS
AGGREGATE LIABILITY EXCEED THE PURCHASE PRICE OF THE PRODUCT(S) INVOLVED. OCEANIC
SYSTEMS SHALL NOT BE SUBJECT TO ANY OTHER OBLIGATIONS OR LIABILITIES, WHETHER ARISING
OUT OF BREACH OF CONTRACT OR WARRANTY, TORT (INCLUDING NEGLIGENCE), OR OTHER THEORIES
OF LAW WITH RESPECT TO PRODUCTS SOLD OR SERVICES RENDERED BY OCEANIC SYSTEMS, OR ANY
UNDERTAKINGS, ACTS OR OMISSIONS RELATING THERETO.
Oceanic Systems does not warrant that the functions contained in any software programs or products
will meet purchaser’s requirements or that the operation of the software programs or products will
be uninterrupted or error free. Purchaser assumes responsibility for the selection of the software
programs or products to achieve the intended results, and for the installation, use and results
obtained from said programs or products. No specications, samples, descriptions, or illustrations
provided by Oceanic Systems to Purchaser, whether directly, in trade literature, brochures or other
documentation shall be construed as warranties of any kind, and any failure to conform to such
specications, samples, descriptions, or illustrations shall not constitute any breach of Oceanic
Systems limited warranty.
WARRANTY RETURN PROCEDURE
To apply for warranty claims, contact Oceanic Systems or one of its dealers to describe the problem
and determine the appropriate course of action. If a return is necessary, place the product in its
original packaging together with proof of purchase and send to an Authorized Oceanic Systems
Service Location. You are responsible for all shipping and insurance charges. Oceanic Systems will
return the replaced or repaired product with all shipping and handling prepaid except for requests
requiring expedited shipping (i.e. overnight shipments). Failure to follow this warranty return
procedure could result in the product’s warranty becoming null and void.
Oceanic Systems reserves the right to modify or replace, at its sole discretion, without prior
notication, the warranty listed above.
