OCTAPAD SPD-20X User manual

SPD-20X/SPD-20X-BK
SERVICE MANUAL
17057035E0
2017. 11. 24 p. 2 Added parts for SPD-20X-BK.

No. Part Code Part Name Q’ty
1 0333661017 TOP CASE (for SPD-20X)
17042121 TOP CASE (for SPD-20X-BK)
1
1
2 0333661018 BOTTOM CASE (for SPD-20X)
17042122 BOTTOM CASE (for SPD-20X-BK)
1
1
3 ******* POWER BUTTON 1
4 ******* CABLE CLAMP 1
5 ******* KNOB 1
6 ******* PAD METAL BOARD 8
7 ******* T-SPRING 4
8 ******* RUBBER SWITCH (4 POINTS) 1
9 0344639246 RUBBER SWITCH (4 X 3) 1
10 0344639247 RUBEER PAD COVER 8
11 ******* RUBEER FOOT 4
12 0344639250 PAD CUSHION (PORON) 8
13 ******* EV (WITH HOLE) 3
14 ******* EV (WITHOUT HOLE) 29
15 ******* 2MM DOUBLE STICKER 8
16 0353809027 FRONT COVER 1
17 0353809028 REAR COVER 1
18 17042119 PANEL BOARD 1
19 17042120 MAIN BOARD 1
20 ******* SD BOARD 1
21 ******* CONNECTION BOARD 1
22 0551000779 PIEZO SENSOR 8
23 ******* PCB SUPPORT HOLDER 3
24 0173162003 LCD UNIT 1
EXPLODED VIEW FOR PAD
* The part which code is ******** is not supplied.

Adaptor
SPD-20X UNIT WITH PLASTIC BAG
Gift box
553 x 455 x 140
Left Protector
Right Protector
Master carton
7507 x 563 x 465
PACKAGING EXPOLED VIEW
No. Part Code Description Q’ty
******* GIFT BOX 1
******* PROTECTION SIDE (LEFT) 1
******* PROTECTION SIDE (RIGHT) 1
******* PLASTIC BAG
1
******* OWNER’S MANUAL
1
0462222619
0462222621
AC ADPTOR + POWER CORD (220V EU)
AC ADPTOR + POWER CORD (220V IN)
1
******* MASTER CARTON
1
Gift box unit
MASTER CARTON PACKAGING
GIFT BOX PACKAGING
* The part which code is ******** is not supplied.

PN:0305000505F
PC069-MB_V1.7
12V
GND
USB
SD_Card
KZB
LCD
20150330
DC1
DC IN
J2 FOOT SW
J1
J15
LINE IN
R368
C196
C198
R323
R288 R298 R344
C230
C176 U18
R300
T22
R312
R296
R311
T21
C175
T25
R316 R315
T26
RV1
RV1111G-B10K
J10
HEADPHONE
R297
C185 C177
R299
C178
R314
T24
J12
LINE OUT R
R308
C183
C184
C232 R376
R345
C231
C179
R301
R290
R305
R346
R307
C182
U19
C181
R309
R347
R310 C174 C233
R377
R373
C218
C214
U12
C1
C2
J5
R47
R51
C4
C3
C220
T27
D36
C161 R283R282
R335
U17
R334 C206
R320
C195
C197
R369
S1 J9
EXTP4
J8
EXTP3 J7 EXTP2 J6 EXTP1
MIDIOUT1
MIDIOUT
MIDIIN1
MIDIIN
U11
U10
C173
J3
LCD
C73
S3
PS2230
R294
C209
F1
D33
D40
C132
C140
J4
R129
R111
R109
L4
R112
R110
R130
R104
JTAG1
R117
C62
R97 R99
C61
R285
C147
Y1
J13
C169
R277
R375
R278
C188
R284
Q2
D37
D42
D41
R287
C244
R371
C221
C219
R374R372
R333 C205
R326
J11
LINEOUTL/MONO
R306
C187
T23
R313
C225
R356
C224
C215
C216
R352 R359 R360 R354 R355
R361
R362
C217
C154
C155
U23
R116
R115
C157
R132
C204
C159
R332 R340
R331
C158
R341 R351
C168 C156
R330 R281
R280
R279
R266 C151
C149 C150 C148
C9
C21
C28
C31
C14
C13
R56
R46
C12
X1
R273 R275 R274 R276
D39
R54
C25
C22 C24
C26
L1
C8
C6
R55
C5
C29
C23
C7
C27
L2
C10
R98
C172
R103
R69
Q3
C201 J16
SD
PC069-MB_V1.7_TOP
PN:0305000506e
+
-ALL/ENTER
DOWN
EDIT
COPY
CHAIN
FlnCho
Dly
Rev
EFFECTS
B
A
PAD BANK
PATCH/VALUE
UP BANK A/B LAYER FXON/OFF
SELECT
SYSTEM
FX/UTILITY
MIDI/PEDALSOUND
GND
SDA
SCK GND
STB
5V
PC069-KZB-V1.4A
20150317
JP2
SW16
SW13
D6
D5
JP10
JP9
JP8
JP5
JP4
JP3
JP1
SW18
SW17
SW15
SW14
SW12
SW11
SW10
SW9
SW8
SW7
SW4
SW3
SW2
SW1 LED26 LED23
LED15
LED13
LED12
LED11
LED10
LED9
LED8
LED7 LED6
LED5
LED4
LED3
LED2
LED1
J1
D26
D25 D24 D23
D21
D16 D15 D14 D13
D11
D4
D3
D2 D1
C1
LED99
PAD8 PAD7 PAD6 PAD5
PAD4 PAD3
PAD2
PAD1
20150326
PC069-JKB-V3.0
J4
J3
J2J1
J8 J7 J6 J5
J11
PN:0305000505F
20150402
PC069-SD-V2.0
J17
SD
10X6X20 环
1
8
1
1
1-1
PCB CONNECTION CABLE BOM
L=60
XH-21007-28#
XH-6 L=170
2651-28# XH-6
1
Main board J5
ACTIONQTYLENGTH(mm)
PANEL CONTROL BOARD J1
1-1-1
NO.
XH-10
L=100
2651-28# XH-10
L=250
SCN-16 2651-28#
XH-16
L=200
2651-28# XH-6
1-1-21-1-31-1-41-1-5
LCD
CONNECTION
piezo sensorpiezo sensor
piezo sensor
piezo sensor
piezo sensor
piezo sensor
piezo sensorpiezo sensor
piezo sensor
Assembling
Assembling
Soldering
Soldering
Soldering
Main board J3
Main board J16
Main board J13
LCD unit
SD CARD BOARD
PIEZO SENSOR Main BOARD
Main BOARD
black
red
SPD-20X SERVICE MANUAL

ROLAND SPD-20X TEST INSTRUCTION 2015/8/11, Anders
TEST MODE (VER 011)
To Enter TEST MODE, hold both [SELECT] and [CHAIN] button, and then boot SPD-20X.
To check Firmware Version:
F W V E R : a a a
S U M : b b b b b b b b
aaa: the current FirmWare version number. Update via SD card.
bbbbbbbb: Firmware checksum, don’t care.
After several seconds, Display change to:
C a l . S B _ S U M . . .
At this moment, system will calculate SoundBank checksum, to check the integrality of the
SoundBank. This feature is only available on MP-3 and later units. MP-1 & MP-2 units can’t
get the calculation result.
To check SoundBank, after Firmware check, wait 6 to 7 minutes, Display change to:
S o u n d B a n k : c c c c
S U M : d d d d d d d d
cccc: Soundbank firmware (bootloader) version.(not the FirmWare version). Only updateable
in factory.
dddddddd: SoundBank checksum. If one unit has different checksum, it will not sound, or
some instruments will not sound. Update via SD card.
Press [▲] to check LCD and LED.
Display LCD will be full-on and later comes numbers & letters. After that all button/indicator
LED blink several times.
Press [BANK A/B] to check Pads.
Pad number will be shown on upper screen and velocity on lower screen. Strike each pad
multiple times with same velocity (to check equality) and max velocity (to check crosstalk).
If crosstalk problem happens, strike on one PAD other PAD’s name will be displayed.
Press [LAYER] to check SD card.
Display will be updated when SD card is inserted or ejected.
Press [FX ON/OFF] to check buttons.
Press any button, its name will be displayed. Can’t return to other check modes.
Power OFF to exit test mode.
PAD NO.
To check other features instead of SoundBank checksum,
Press [▲], [BANK A/B], [LAYER] or [FX ON/OFF] when calculating SoundBank checksum.

ROLAND SPD-20X TEST INSTRUCTION 2015/8/11, Anders
TEST MODE (VER 010)
To Enter TEST MODE, hold both [SELECT] and [CHAIN] button, and then boot SPD-20X.
To check Firmware Version:
F W V E R : a a a
S U M : b b b b b b b b
aaa: the current FirmWare version number. Update via SD card.
Bbbbbbbb: Firmware checksum, don’t care.
Soundbank version and checksum is not available in this version.
To check LCD and LED:
After several seconds, LCD & LED tests will be followed automatically.
Display LCD will be full-on and later comes numbers & letters. After that all button/indicator
LED blink several times.
To check Pads:
After LCD & LED check, it goes to PAD check automatically.
Pad number will be shown on upper screen and velocity on lower screen. Strike each pad
multiple times with same velocity (to check equality) and max velocity (to check crosstalk).
If crosstalk problem happens, strike on one PAD other PAD’s name will be displayed.
To check Buttons:
After Pad check, Press [SELECT] and [CHAIN] again to check buttons.
Press any button, its name will be displayed.
To check SD card:
After Button check, Press to [SELECT] and [COPY] to check SD card.
Display will be updated when SD card is inserted or ejected.
Power OFF to exit test mode.
TO RESTORE TO FACTORY SETTINGS (all version)
Boot Device Normally.
Press [EDIT] button.
Press [SYSTEM] button.
Use [▲] or [▼] to select FACT.RESET.
F A C T O R Y R E S E T
P R E S S [ E N T E R ]
Press [ALL/ENTER]
F A C T O R Y R E S E T
S u r e ? Y e s
Use [-] or [+] to select Yes.
Press [ALL/ENTER] again to confirm.
Pls be aware that in VER 010 test mode, test order is determined, you must follow
the sequence.

ROLAND SPD-20X TEST INSTRUCTION 2015/8/11, Anders
RED
BLACK
REAR CONNECTION CHECK
Tools and Materials
· Monitor Speakers
· Headphone
· Mono 1/4” Cable *2
· Stereo 1/4” Cable
· Stereo 1/8’ Cable
· FD-8 or DP-2 pedal
· PD-8 pad
· MIDI cable
· Footswitch FS-5U with PCS-31L cable
· Power Adaptor
Connect all rear jacks as shown in the diagram and power on.
To check PHONES:
Connect a headphone to [PHONE] jack. Listen to the headphone while striking on pads.
In the Headphone it should be stereo output. Meanwhile, rotate [VOLUME] knob to
check it.
To check OUTPUTs:
Connect [OUTPUT] jacks to Monitor Speakers via 1/4” Cable*2. Both speakers should
have sound when striking pad.
To check LINE IN:
Connect [LINE IN] jack to any audio source via Stereo 1/8” Cable. Play the audio source
and listen in Headphone or Monitor Speakers.
Headphone
Audio
Source
Monitor
Speakers
FD-8 or DP-2
(as HH CTRL)
PD-8
(as TRIG 4) PD-8
MIDI Device
or
Computer
FS-5U
Power
Adaptor

ROLAND SPD-20X TEST INSTRUCTION 2015/8/11, Anders
To check HH CTRL:
Turn the switch to [HH CTRL], press down DP-2 or FD-8, there should be a close pedal
(pedal chick) sound. Instrument belong to HH group should be able to be controlled by
the pedal. For example, default PATCH 1, PAD 8 can be controlled by pedal.
To check TRIGGER INPUTs:
Turn the switch to [TRIG 4]. Connect PD-8 to any TRIGGER INPUT via 1/4” stereo cable.
Press [EDIT] button, then press [SOUND] or [MIDI/PEDAL] button.
Strike PD-8 from TRIG 4 to TRIG 1. Its name will be displayed on the top-right screen.
For example, TRIG 1 Head: EX1H, TRIG 1 Rim: EX1R.
Press [EDIT] again to exit.
To check MIDI:
Connect MIDI jacks to any MIDI device or computer. Be aware of note differences on
midi devices.
Strike any pad and then check sound on device or data on computer.
Send note from midi device or computer, check sound on SPD-20X.
To check FOOT SW:
Connect FS-5U as instructed via PCS-31L cable. Press down switch pedal to change
patch forward or backward. Make sure the FOOT SW function is set to PATCH SHIFT
under [MIDI/PEDAL] → [FOOT SW] menu.
To check DC IN:
Drag the power adaptor output jack multiple times, and check the power will be cut
off or not.
UPDATE MODE
How to update Firmware
Save the firmware file on SD card, name it as SPD20AFW.BIN. Insert SD card. Boot SPD-20X
while holding both [-] and [+] buttons.
S P D - 2 0 X U P D A T E
F i r m w a r e U p d ?
Press [ALL/ENTER] in this screen. Wait until it shows COMPLETED. It might take 10 seconds.
How to update Soundbank
Save the soundbank file on SD card, name it as SPD20ASB.BIN. Insert SD card. Boot SPD-20X
while holding both [-] and [+] buttons. Use [▲] or [▼] to swap menu.
S P D - 2 0 X U P D A T E
S o u n d b a n k U p d ?
Press [ALL/ENTER] in this screen. Wait until it shows COMPLETED. It might take 1.5 - 2 hours.
How to update Patches:
Save the patch file on SD card, name it as SPD20ASP.BIN. Insert SD card. Boot SPD-20X while
holding both [-] and [+] buttons. Use [▲] or [▼] to swap menu.
S P D - 2 0 X U P D A T E
S p i F l a s h U p d ?
Press [ALL/ENTER] in this screen. Wait until it shows COMPLETED. It might take 30 seconds.

MAIN BOARD(TOP) PC069-MB-V1.7
SPD-20X SERVICE MANUAL

MAIN BOARD ( BOTTOM) PC069-MB-V1.7
SPD-20X SERVICE MANUAL

PANEL CONTROL BOARD(TOP)
PC069-KZB-V1.4A
SPD-20X SERVICE MANUAL

PANEL CONTROL BOARD(BOTTOM)
PC069-KZB-V1.4A
SPD-20X SERVICE MANUAL

SD CARD BOARD
PC069-SD-V2.0
SPD-20X SERVICE MANUAL
