Odys Winbook 14 User manual


V1.1.0
Table of Content
Table of Content...............................................................................1
Safety Precautions...........................................................................2
Conformity........................................................................................5
Listening Cautions............................................................................6
Support.............................................................................................7
Appropriate use................................................................................8
Cleaning...........................................................................................8
Feature Summary.............................................................................8
Accessories......................................................................................8
Buttons & Ports ................................................................................9
Using the keyboard ........................................................................11
Charging Battery ............................................................................13
Add SSD Memory...........................................................................14
Transferring Files............................................................................16
Turning On/Off................................................................................16
Screen Lock ...................................................................................16
Using the Screen............................................................................17
Bluetooth Connection.....................................................................20
Access Internet - Wifi .....................................................................21
Using the Web Browser..................................................................23
Sending/Receiving E-Mails ............................................................25
Photo Playback ..............................................................................27
Camera usage................................................................................29
One Drive - File Explorer................................................................30
Tablet Mode....................................................................................31
System Settings .............................................................................32
Troubleshooting..............................................................................33
Specifications .................................................................................35
Warranty Conditions.......................................................................37

2
Safety Precautions
Do not subject the device to severe impact or drop it from
heights.
Do not use the device in extreme hot or cold, dusty or damp
conditions. Do not expose it to direct sunlight.
Avoid using the device near strong magnetic fields.
Keep the device away from water and other liquids. In the event
that water or other liquids enter the device, power off the product
immediately and clean the device.
Do not use chemicals to clean the device in order to avoid
corrosion. Clean it with a dry cloth.
We are not responsible for damage or lost data caused by
malfunction, misuse, modification of the device or battery
replacement.
Do not attempt to disassemble, repair or modify the product. This
will invalidate the warranty.
If the device will not be used for an extended period of time,
please charge the battery at least once per month to maintain
battery life.
Charge the battery if:
a) The battery level icon displays (An empty battery)
b) The device powers off automatically when restarted.
c) There is no response when pressing keys with keys
unlocked and battery full.
When the device is being formatted or transferring a file, do not
interrupt the connection. Otherwise, data may be corrupted of
lost.
Please use and install data using the attachments/accessories
provided and only according to the manufacturer’s instruction.
Please refer to the information on the bottom of the device for
electrical and safety information before installing data or
operating the device.
To reduce the risk of fire or electric shock, do not expose this
device to rain or moisture. The device should not be exposed to
dripping or splashing. Never place objects filled with liquids, such
as vases, on the device.
There is danger of explosion if the battery is replaced incorrectly.
Replace only with the same or equivalent type.

3
The battery (battery or batteries or battery pack) should not be
exposed to excessive heat such as sunlight, fire or the like.
Please follow responsible procedures for battery disposal.
If the power adaptor is disconnected from the device, the device
will remain operable as long as the battery has sufficient charge.
The power adaptor is a CLASS II apparatus with double
insulation, and no external ground is provided.
Safety symbol explanation:
- The lightning flash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of non-insulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock.
- To reduce the risk of electric shock, do not remove the cover
(or back) as there are no user-serviceable parts inside. Refer
servicing to qualified personnel.
- The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance instructions in the literature
accompanying the device.
Do not leave the device on in a confined space such as a book
case or similar. The ventilation should not be impeded by
covering the ventilation openings with items such as newspaper,
table-cloths, curtains, etc.
No open flames, such as lighted candles, should be placed on
the device.
Use the device in moderate climates.
Never disconnect the USB cable from your e-book reader to the
PC during a data transfer or formatting. Correctly disconnect the
device from the operating system. Information loss and
malfunctions can occur.

4
Note
Please only charge the battery while the device is turned
off. The charging time will be shorter and the lifetime of the
battery will be enlarged. Please fully charge the battery
before first use.
Disposal
Correct disposal of this product. This marking indicates that
this product should not be disposed of with other household
waste in the EU. To prevent possible harm to the
environment or human health from uncontrolled waste
disposal, recycle it responsibly to promote the sustainable
reuse of material resources. To dispose of your used device,
please use the return and collection systems available in your
area or contact the retailer where the product was purchased.
They can take this product for safe environmental recycling.
Note
Please note that the internal battery can only be replaced
by qualified personnel.
If necessary please contact to the ODYS customer service
at www.odys.de.

5
Conformity
We,Axdia International GmbH, hereby declare
that this Windows device corresponds to the basic
requirements and relevant regulations outlined in
guideline 2014/53/EU, 2014/30/EU, 2014/35/EU.
The CE declaration of conformity for this product
may be found on the following link:
https://www.odys.de/web/web_lan_en_hmp_4_mp_6.html
Please note the following for the regulations on the use of the 5GHz
WLAN within the EU:
This device is suitable for operation in the following European
countries: Germany, Belgium, Netherlands, Luxembourg, Austria,
Switzerland, France, Spain, Portugal, Italy, Greece, Norway,
Sweden, Finland, Denmark, Liechtenstein
Within the European Union, operation of the WIFI function in
buildings is not restricted. Operation outside of buildings is
restricted.

6
Listening Cautions
Hearing Safety
Listen at a moderate volume: Using headphones at a high
volume can impair your hearing. This product can produce
sounds in decibel ranges that may cause hearing loss for a
normal person, even for exposure less than a minute. The
higher decibel ranges are offered for those that may have
already experienced some hearing loss. Sound can be
deceiving. Over time your hearing ‘comfort level’ adapts to
higher volumes of sound. So after prolonged listening, what
sounds ‘normal’ can actually be loud and harmful to your
hearing. To guard against this, set your volume to a safe
level before your hearing adapts and leave it there. To
establish a safe volume level: Set your volume control at a
low setting. Slowly increase the sound until you can hear it
comfortably and clearly, without distortion. Listen for
reasonable periods of time: prolonged exposure to sound,
even at normally ‘safe’ levels, can also cause hearing loss.
Be sure to use your equipment reasonably and take
appropriate breaks. Be sure to observe the following
guidelines when using your headphones. Listen at
reasonable volumes for reasonable periods of time. Be
careful not to adjust the volume as your hearing adapts.
Do not turn up the volume so high that you can’t hear
what’s around you. You should use caution or temporarily
discontinue use in potentially hazardous situations. Do not
use headphones while operating a motorized vehicle,
cycling, skateboarding, etc.; it may create a traffic hazard
and is illegal in many areas.

7
Support
On our website you will find the latest information about this product,
other products of our enterprise, our company itself and valid
warranty terms. The latter you will find under Service - Downloads.
Firmware upgrades for this device are also offered on our website.
For questions or problems read our FAQs on our website or contact
our after sales service.
Manufacturer
Axdia International GmbH
Formerweg 9
D-47877 Willich (Germany)
Tel: +49(0) 2154 / 8826-0
Fax: +49(0) 2154 / 8826-100
Web: www.odys.de
Support-Hotline: +49 (0)2154 / 8826-101
E-Mail: [email protected]

8
Appropriate use
Device is designed for playing music and video files in commonly
used formats, showing photos and access internet functions using
the build in Wi-Fi function. It is exclusively meant for this purpose
and must only be used for the same.
This also includes paying attention to all information contained in
this operating manual, especially in the safety instructions. Any
other usage is considered to be improper and may lead to material
damages and even personal injuries. Moreover it will result in the
immediate loss of guarantee. The manufacturer does not bear any
liability for damages caused due to improper use.
This manual may not reflect your actual device’s operation. All
information is subject to change without prior notification.
Please follow your actual device’s operational procedures.
Cleaning
• Please only clean the device using a cloth.
• Please don’t use any chemicals or solvents.
Feature Summary
Wi-Fi Connectivity
With the latest Wi-Fi technology, this device can connect you to the
Internet wherever you are.
Third-party Application Support
With the built-in Windows OS, you can install a large number of
third-party applications in this device.
Entertainment
You can enjoy music, movies, pictures and e-books with the
Netbook. Accessories
Charger
Quick start

9
Buttons & Ports

10
1. Microphones
2. Front camera
Front-facing camera for taking avatar
pictures.
3. Speaker
4. Status indicator
Device On/Off, Caps Lock, Touchpad locked
5. Power jack
Charge and power the device with the
included power adapter.
6. Charging
indicator
Lights up red while the device is charging.
Turns off when the battery is fully charged
7. USB 3.0
connection
Support for USB stick, Surf stick, Keyboards
and Mouse.
8. Mini HDMI
To connect an external monitor.
9. Headphone jack
Audio output connection for head-phones
Note: Speaker output is automatically
disabled when headphones are connected to
the player.
10.USB 2.0
connection
Support for USB stick, Surf stick, Keyboards
and Mouse.
11.Micro SD slot
To insert a Micro SD memory card.
12.Fingerprint
Fingerprint scanner to unlock your pc.
13.Touchpad
14.Left Mouse Key
15.Right Mouse
Key
16.Memory
extension
To expand the SSD Memory
(in variations 2242 and 2280 with Key B or
B+M and SATA Interface).

11
Using the keyboard
Note:
When the device overlaps on the keyboard, the display will be
turned off; as soon as it is erect, the display will be turned on again.

12
Keyboard parts
Note: Some keys have several different assignments!
Important key combinations can be found at the chart below.
(1)
Esc
Fn + Esc: Fn Lock /
unlock
(12)
Screen mode
(when a second screen is
connected)
+Fn: F11
(2)
Sound on/off (mute)
+Fn: F1
(13)
Settings
+Fn: F12
(3)
Decrease volume
+Fn: F2
(14)
Print
+Fn: lock touch pad
(4)
Increase volume
+Fn: F3
(15)
Insert
(5)
Previous track
+Fn: F4
(16)
Remove
(6)
Playback / Pause
+Fn: F5
(17)
On/off button and blue
status LED when power is
on
(7)
Next track
+Fn: F6
(18)
Fn function key
(8)
Open Browser
+Fn: F7
(19)
Windows key
(9)
Open the eMail
Program
+Fn: F8
(20)
Fn unlocked:
Fn + y for entering |
Fn + x for entering <
Fn + c for entering >
(10)
Search
+Fn: F9
(21)
Context menu
(11)
Turn the screen on/off
+Fn: F10
(22)
Fn + -key: Decrease
brightness
(23)
Fn + -key: Increase
brightness

13
Charging Battery
The device has a built-in rechargeable battery. No extra battery
installation is required. Just charge the device when it indicates low
battery.
To charge the battery, connect the device to any standard wall
outlet using the power adaptor. It takes about 5 hours to fully charge
the battery.
Note:
a. We advice to use only the delivered power adapter with this
winbook.
b.You can operate the device even when it is being charged. But for
extended battery life, it is suggested NOT to use the device when
it is charging.
c. It is recommended to charge the battery before you use the
device for the first time.
d. For maximum performance, lithium-ion batteries need to be used
often. If you don’t use the device often, be sure to recharge the
battery at least once per month.
e.Should the rechargeable battery of the device discharge
completely, connect the device to the main power source for
approximately 5-10 minutes before attempting normal operation.
f. In some cases devices, which have been charged for longer
periods of time, may not be able to be switched back on. Should
this occur, reset the device.

14
Add SSD Memory
M.2 Slot on the bottom of the Winbook for the expansion of an SSD
memory (in the variations 2242 and 2280with Key B or M+B and
SATA Interface).
Place the device on a soft, even flat surface, on the back of the
screen so that the label is legible on the lower right side of the SSD
tray.
Insert the memory in the M.2 slot paying close attention to the
correct orientation.
Damage to the Memory and slot may occur if not inserted correctly.
- Memory modules with Key B have one separate socket area
consisting of 5 separate contacts. Insert the module and
insure that the contacts are located at the bottom of the
module.
- Memory modules with Key B + M have two separate socket
areas. Insert the module and insure that the contacts are
located at the bottom of the module.
When the memory is installed, fix it in the appropriate position
(depending on the memory) with the screw (included in the slot).
To remove the memory, you must first unscrew the mounting screw
and then use a screwdriver to pry the memory and then pull it out to
the rear.

15
Setting up the memory
Important!
Please note that new SSD modules may not have been previously
formatted.
New SSD modules must first be partitioned and formatted using the
Windows Computer Management tool, otherwise the memory will
not be displayed.
1. Simply enter "Disk" in the Cortana search box at the bottom left of
the desktop to open the Computer Management.
2. Click on "Create and format hard disk partition" in the results list.
If necessary, you will be prompted to initialize the new drive.
3. Right-click the unassigned area of the new SSD and select "New
Simple Volume ..." from the context menu.
4. Follow the wizard to complete the setup.
To view the files on the additional memory, invoke Explorer by
clicking the explorer icon and selecting the directory of the memory.

16
Transferring Files
Before reading or playing back the files, these must be transferred
from the Internet or from a computer to the device. To do this, use a
USB memory as usual.
Please note:
A direct USB connection with another PC is unfortunately not
possible.
Turning On/Off
To turn on the device, press and hold the Power button on the unit
until you see the boot-up screen then release. It may take a few
minutes to start up the system, please wait before you proceed.
To turn off the device, press and hold the [Power] button until you
see the turn off picture. Drag down the picture as indicated.
Tip: This device will sleep with the screen off if it stays inactive for a
few seconds. You can briefly press the Power button to turn on the
screen and wake it up.
Screen Lock
After the system start-up, the start screen appears.
The individual icons provide quick access to the applications that
you use most. The display can be adapted to suit your needs.
Examples are including Internet Explorer or applications for e-mail,
photos and contacts.
Caution!
This view may vary and could show different or less elements at
your device.

17
Using the Screen
Once started, the Windows desktop will be displayed.
Elements of the Task Bar
Search ( Cortana)
Use the search box to
search the internet for
certain terms or to
easily locate device
settings and
installed Applications.
Windows Key
to return to the initial
display.
Click this symbol to display all
opened applications next to
another or to display the active
application in the foreground.
NOTICE: This function is only
available when at least one
application is running.
Important settings or background applications may be found here.
Battery Status and Settings
Wireless Network Settings
Volume Settings
Open the Function Bar (See below)

18
Function Bar
Clicking the appropriate icon on the Taskbar to open the function bar like
this. Here you may find important information and settings.
Elements of the Function Bar
To switch between the
tablet mode with tiles and
the PC mode with
desktop.
To connect to a second
monitor.
Establish Bluetooth
connections with other
devices
Display brightness setting
Open the notes program
„One Note“
Activate or deactivate WiFi
Functions
To enter the System
Settings
Activate predefined idle
periods
Activate or deactivate
energy savings mode
Turn position identification
on or off
Establish or manage
VPN Connections
Activate the Airplane
mode.
Attention!
All wireless connections
will be disabled.
Activate or deactivate the
Bluetooth function

19
Display all Applications
The device supports most of popular third-party applications. It has
many useful pre-installed applications such as music player, video
player, photo viewer, alarm clock, calculator, etc. Furthermore, you
can add more applications to the device by installing them manually.
To display a list of all installed applications, refer to the above
instructions.
Note: You cannot uninstall the pre-installed applications.
Some of the applications developed for Windows mobile might not
run properly on the device. Please consult the respective software
developer for further information or support.
Note: Installed on this unit are various third-party applications
(Apps), whose author is not Axdia International. All rights and
obligations remain the sole responsibility of the author of these
applications.
Axdia accepts no liability for any malfunction of third-party apps. For
support or license inquiries please contact the respective owners
directly.
Contact information may usually be found within the application.
Caution! Please note that the installation of third-party application
occurs on your own risk! Any up normal behavior or damage that is
caused by installing third-party applications will not be an integral
part of the warranty
Table of contents
Other Odys Laptop manuals
