OHD QuantiCheck User manual

QUICK START GUIDE

1
USB-C
charging cable
Ensure your QuantiCheck®is fully charged before
use. Charging can be done via the USB-C port
on the side of the device.
Charging your QuantiCheck®
2
3
Attach the optional LED extender into the
USB-C port if the light on the device is not
visible for indication.
Attach optional LED extender
Press and hold power button until green
light ashes then release.
Turn on QuantiCheck®
*Always use USB-C cable supplied
4
Attach QuantiCheck®on to the mask.
Attach QuantiCheck®device

6
57
Squeeze or press and hold QuantiCheck® to
perform check. Draw a breath until the blinking
purple light turns solid, then hold your breath static
for up to 10 seconds and wait for result.
Perform fit check
Don your mask and tighten the appropriate straps.
Don mask LED indicator - Pass
Rapid ashing purple light indicates over breath.
Wait a few seconds for purple light to blink slowly.
Try again but with a shallower breath.
7.1 LED indicator - Over breath
A green light illuminates on the LED indicator
for a passed test.

Download and install the QuantiCheck®
app on your device.
Available for IOS, Android, PC and can be
connected wirelessly via Bluetooth®.
2Install the QuantiCheck®app
Press and hold power button until green light
blinks then release.
3Turn on your QuantiCheck®
ON
Turn on Bluetooth®
ON
Turn on Location
Services
Using the QuantiCheck®app
A red light blinking on the LED indicator for a
failed check. Wait until the LED indicator ashes
purple signalling a retest for the t check.
7.2 LED indicator - Fail
1
Connect your QuantiCheck® to your PC via the USB
port. Alternatively your device can be connected to
your smart phone via Bluetooth®.
Connect to your PC
PC

6
Attach QuantiCheck® to mask and don. To perform a
t check -
“see point 6 on how to perform a check.
Don your mask and perform a fit check
A solid green band will display on the app for a
passed check or a solid red band for failed check.
7Pass or Fail indication
4
5
*Wait for the app to discover your QuantiCheck®device
*On Windows, device needs rstly to be paired to the PC via Bluetooth®.
Connect to your device
Under users select “Choose User” and select the
user or add new user.
Choose user
Waiting for QuantiCheck device
***
Discovered Devices:
06-11-201914.28:04
Users
CHOOSE USER
Add User
Graham
Tony
Mike
Cancel...
RESULT
Future Technology
06-11-201914.28:04
Users
Future Technology
CHOOSE USER
RESULT

8A
9
To see the list of results press the ‘Reports’ icon
on the foot of the app.
A positive pull t check trace line shows a single
large uctuation, followed by a gently increasing
line before rising again at the end of the t check
upon releasing breath.
View your results Passed fit check
To share or download your results locate the relevant
icon below the reports and share or download.
A negative pull t check trace line shows large
uctuations or drops rapidly when there is a
leak or a poorly tted mask.
Share and download results BDamaged or leaking seal
06-11-2019 14.28:04
Users
Future Technology
CHOOSE USER
RESULT
06-11-2019 14.28:04
Users
Future Technology
CHOOSE USER
RESULT
06-11-2019 14.28:04
Users
Future Technology
CHOOSE USER
RESULT
06-11-2019 14.28:04
Users
Future Technology
CHOOSE USER
RESULT
06-11-2019 14.28:04
Users
Future Technology
CHOOSE USER
RESULT
06-11-2019 14.28:04
Users
Future Technology
CHOOSE USER
RESULT
06-11-2019 14.28:04
Users
Future Technology
CHOOSE USER
RESULT
06-11-2019 14.28:04
Users
Future Technology
CHOOSE USER
RESULT
06-11-201914.28:04
Reports
Reports
06-11-201914.28:04
Reports
Reports
N/A 06-11-2019 14:32:31
N/A 06-11-2019 14:48:36
N/A 06-11-2019 15:28:15
N/A 06-11-2019 16:52:40
N/A 06-11-2019 17:15:24
N/A 06-11-2019 17:27:22
06-11-201914.28:04
Reports
Reports
N/A 06-11-2019 14:32:31
N/A 06-11-2019 14:48:36
N/A 06-11-2019 15:28:15
N/A 06-11-2019 16:52:40
N/A 06-11-2019 17:15:24
N/A 06-11-2019 17:27:22

Contact us
OHD LLLP Tel: [phone]
www.ohdglobal.com
Technical Support
[email protected]
Manufactured by Design Reality
