OHM TCS-C Series User manual

OHM（ChongQing）Electronic Technology CO.,LTD.
Tel: [phone] Fax: [phone] Service:400-920-9120
Quality Assurance
OHM (ChongQing) Electronic Technology CO., LTD. (hereinafter referred to as OHM) warrants
that the product completely conforms to various technical parameters listed in the instructions at
delivery and that it can be able to normally function as along as it is correctly installed and
operated as required.
Warranty Commitment
This product has one year of warranty period since the date of delivery. The company promises to
make repair when any damage or fault that is not caused by human factors occurs during the
warranty period. The product needing repair must be sent to maintenance station designated by
the company.
The foregoing warranty scope does not include consumable parts like relays, fuses, batteries and
so on, or system damages caused by installation error, as well as does not contain faults that are
caused by improper use or unauthorized changes by the customer.
Remark
This manual describes basic principle, operation and application, installation and system
maintenance of TCS-C series. Before installation and using, carefully read this manual and
properly keep it for future reference. This manual may be updated at any time as needed. If
needed, contact the dealer or manufacturer to obtain the latest version.

OHM（ChongQing）Electronic Technology CO.,LTD.
Tel: [phone] Fax: [phone] Service:400-920-9120

Table of Contents
1、Safety instructions..................................................................................................................................1
1.1 Intended Use..................................................................................................................................1
1.2 Safety instructions for installation and operation......................................................................1
1.3 Precautions.....................................................................................................................................2
2、Introduction.............................................................................................................................................4
2.1 Basic introduction..........................................................................................................................4
2.1.1 Basic function......................................................................................................................4
2.1.2 Special function..................................................................................................................8
2.1.3 Function customization......................................................................................................9
2.2 Introduction to transmitter...........................................................................................................10
2.2.1 Transmitter size................................................................................................................10
2.2.2 External view of transmitter............................................................................................10
2.3 Introduction to receiver...............................................................................................................12
2.3.1 Receiver size.....................................................................................................................12
2.3.2 External view of receiver.................................................................................................12
2.4 Accessories..................................................................................................................................15
2.5 System wiring diagram...............................................................................................................15
3、System settings....................................................................................................................................16
3.1 Setting of power-saving protection............................................................................................16
3.2 Setting of frequency and address code....................................................................................16
3.3 Bus communication setting........................................................................................................16
4、Transmitter operation..........................................................................................................................
17
4.1 Transmitter installation................................................................................................................17
4.2 Transmitter startup.......................................................................................................................17
4.3 Transmitter shutdown..................................................................................................................17
4.4 Table on transmitter indicator lamp status...............................................................................17
4.4.1 Power indicator lamp.......................................................................................................17
4.4.2 Status indicator lamp.......................................................................................................17
5、Receiver operation...............................................................................................................................18
5.1 Receiver installation....................................................................................................................18
5.1.1 Precautions.......................................................................................................................18
5.1.2 Installation steps...............................................................................................................18
5.2 Status indicator lamps of receiver.............................................................................................19
6、Use of charger......................................................................................................................................20
7、Simple troubleshooting........................................................................................................................21
8、Maintenance.........................................................................................................................................23
9、Technical parameters of system........................................................................................................24
10、Packing list (standard configuration)...............................................................................................28

OHM（ChongQing）Electronic Technology CO.,LTD.
Tel: [phone] Fax: [phone] Service:400-920-9120
Ver.: 2016.01.1.0.3 Operating Manual for TCS-C Page 1 of 28
1、Safety instructions
¾Read through these operating -manual carefully before working with the radio control system.
¾As an integral part of the radio control system, the operating instructions shall be always kept
by -responsible personnel.
¾The term “machine” used in the operating manual refers to various equipment controlled by
the radio control system in general;
1.1 Intended Use
¾The radio control system is used to control machines and for data transfer. Observe the job
safety and accident prevention regulations applicable to each application.
¾The use also includes reading the operating instructions and adhering to all safety
information contained therein.
¾The radio control system must not be used in areas where there is a risk of explosion, nor for
the control of machines used to convey persons, unless it is explicitly approved by the
manufacturer for these uses.
¾Modifications to the radio control system must only be carried out by specialist personnel who
have been trained and authorized by OHM. All modifications must be documented at the
factory in the form of documents.
¾The safety devices of radio control system must not be modified, removed or bypassed. It is
absolutely forbidden to make modifications to any part of complete emergency stop link of the
radio control system.
1.2 Safety instructions for installation and operation
¾The electrical connection for the receiver can only made by professional electricians. It shall
be connected as per bundled output wire diagram.
¾The receiver can only be opened by trained personnel. Live parts inside the system may have
life-threatening voltage. Make sure to cut off the power supply to the machine before opening.
¾Note that the presence of persons in the danger zone-in particular beneath the load of
cranes-is prohibited in every instance.
¾Select a safe operation location for the radio control system, from which you have a good and
complete view of the working movements of the machine, the load movements and the

OHM（ChongQing）Electronic Technology CO.,LTD.
Tel: [phone] Fax: [phone] Service:400-920-9120
Ver.: 2016.01.1.0.3 Operating Manual for TCS-C Page 2 of 28
surrounding working conditions.
¾It is not permissible to put a radio transmitter unattended to one side. Always switch the radio
transmitter off when it is not required. This applies in particular if you change location, when
working without radio control, during breaks and at the end of work. Always safeguard the
radio transmitter against use by unauthorized persons, for example by locking it away.
¾In the event of an emergency or a fault of the crane or machine, make sure to immediately
-push emergency stop switch on the transmitter.
¾Only operate the radio system when it is in perfect working order. Faults and defects that
could influence safety must be rectified before the system is put back into operation, by
specialists who have been trained and authorized by OHM.
¾Note that the operational directions of the machine may appear inverted depending on
operating location and viewing angle to the machine. This will apply in particular to rotary
cranes, if your location changes from inside to outside the radius of the crane. The operator
must make himself familiar with directional markings on the machine before the start of work.
¾Repairs to the radio control system may only be carried out by specialist personnel who have
been trained and authorized by OHM. Use original replacement parts and accessories;
otherwise safety of the radio control system can no longer be guaranteed and our extended
warranty will be avoided.
¾Remain vigilant when working with the radio system and familiarize yourself with its functions.
This applies in particular if you are working with it for the first time or if you work with it only
occasionally.
¾Check each time before starting work the function of the emergency stop switch. If you start
the transmitter with the emergency stop switch pressed, the status LED will go out. If the
status LED does not go out, you will have to disable the radio control system immediately by
removing the battery from the transmitter and contact the radio control system service
engineer.
1.3 Precautions
¾Always check housing and buttons of the transmitter. In case of damage found, immediately
replace it.
¾Always pay attention to and check voltage of the transmitter; in case of no power or
insufficient voltage, immediately replace the battery.
¾Make sure emergency stop switch is working order before working.
¾In case of any abnormal condition, immediately push the emergency stop switch.

OHM（ChongQing）Electronic Technology CO.,LTD.
Tel: [phone] Fax: [phone] Service:400-920-9120
Ver.: 2016.01.1.0.3 Operating Manual for TCS-C Page 3 of 28
¾In case of temporary disuse or end of operation, pushdown the emergency stop switch.
¾Do not use 2 (or more) transmitters to operate the same set of equipment at same time.
¾Do not use the same frequency within the same one factory area (or 300m scope) to avoid
mutual interference.

OHM（ChongQing）Electronic Technology CO.,LTD.
Tel: [phone] Fax: [phone] Service:400-920-9120
Ver.: 2016.01.1.0.3 Operating Manual for TCS-C Page 4 of 28
2、Introduction
TCS-C series is a set of joystick or linear lever systems debuted by OHM, including TCS-C18;
TCS-C26; TCS-C32; TCS-C64; TCS-C80; TCS-C6X; TCS-C8X; TCS-C_ _FK. Among which,
TCS-C_ _FK system is a system with display screen, such as TCS-C32FK.
2.1 Basic introduction
2.1.1 Basic function
TCS-C18
Transmitter: 2 two-gear XY-Axis joysticks, 1 power
indicator lamp, 4 side-push-buttons, 1 emergency stop
switch
Receiver: 18 relays and 1 emergency relay, CAN bus
output (specially customized)

OHM（ChongQing）Electronic Technology CO.,LTD.
Tel: [phone] Fax: [phone] Service:400-920-9120
Ver.: 2016.01.1.0.3 Operating Manual for TCS-C Page 5 of 28
TCS-C26
Transmitter: 2 four-gear XY-Axis joysticks, 1 power
indicator lamp, 4 side-push-buttons, 1 emergency stop
switch
Receiver: 26 relays 1 emergency relay, CAN bus
output (specially customized)
TCS-C32
Transmitter: 2 multi-gear XY-Axis joysticks, 1 power
indicator lamp, 6 side-push-buttons, 1 emergency stop
switch, several toggle switches, several
potentiometers.
Receiver: 32 relays, 4 analog output, CAN bus output
(specially customized)

OHM（ChongQing）Electronic Technology CO.,LTD.
Tel: [phone] Fax: [phone] Service:400-920-9120
Ver.: 2016.01.1.0.3 Operating Manual for TCS-C Page 6 of 28
TCS-C64
Transmitter: 3 multi-gear XY-Axis joysticks, 1 power
indicator lamp, 6 side-push-buttons, 1 emergency stop
switch, several toggle switches, several
potentiometers.
Receiver: 49relays, 4 analog output, CAN bus output
(specially customized)
TCS-C80
Transmitter: 4 multi-gear XY-Axis joysticks, 1 power
indicator lamp, 8 side-push-buttons, 1 emergency stop
switch, several toggle switches, several
potentiometers.
Receiver: 49 relays, 4 analog output, CAN bus
ProfiBus output (specially customized)

OHM（ChongQing）Electronic Technology CO.,LTD.
Tel: [phone] Fax: [phone] Service:400-920-9120
Ver.: 2016.01.1.0.3 Operating Manual for TCS-C Page 7 of 28
TCS-C6X
Transmitter: 6 linear levers, 1 power indicator lamp, 4
side-push-buttons, 1 emergency stop switch, several
toggle switches, several potentiometers, 1 external
antenna.
Receiver: 6 PWM output, 2 analog output, several
toggle switches or CAN bus output.
TCS-C8X
Transmitter: 8 linear levers, 1 power indicator lamp, 6
side-push-buttons, 1 emergency stop switch, several
toggle switches, several potentiometers, 1 external
antenna.
Receiver: 8 PWM output, 2 analog output, several
toggle switches or CAN bus output.
Note:
¾Emergency stop switch: When an emergency occurs, pushdown this switch to immediately
stop action of the controlled equipment. This switch is of rotating and drawing types.

OHM（ChongQing）Electronic Technology CO.,LTD.
Tel: [phone] Fax: [phone] Service:400-920-9120
Ver.: 2016.01.1.0.3 Operating Manual for TCS-C Page 8 of 28
2.1.2 Special function
Impact shutdown function
¾When the transmitter is impacted externally, the transmitter will automatically shut down.
Weightlessness shutdown function
¾When it detected that the transmitter is in gravity-free condition, the transmitter will
automatically shut down. For example, when the transmitter accidentally falls off or one
operator tosses the transmitter to another operator, this can prevent mis-operation caused by
falling of the transmitter.
Tilt shutdown function
¾When the transmitter reaches a certain tilt angel or faces down, the transmitter will
automatically shut down.
Manual frequency switching function
¾Under radio operation, long press “Start” key for 5s; then the transmitter buzzer rings and
frequency change to another channel.
Standby transmitter
¾It has the same functions as the original transmitter and does not have the Smart Card.
When the original transmitter fails, remove its Smart Card and insert it into the standby
transmitter; then the standby transmitter can replace the original one and immediately work
One-to-many function (as shown in the figure)
¾One transmitter can control several receivers.
¾Through selection function on the transmitter, select one receiver for control or several
receivers for synchronous control.

OHM（ChongQing）Electronic Technology CO.,LTD.
Tel: [phone] Fax: [phone] Service:400-920-9120
Ver.: 2016.01.1.0.3 Operating Manual for TCS-C Page 9 of 28
Many-to-one function (as shown in the figure)
¾Several transmitters can control the same one receiver.
¾Through “takeover/release” function, select control and decontrol on the receiver.
¾The receiver can only be taken over by the transmitter under “release” status.
Many-to-many function (as shown in the figure)
¾Several transmitters can control several receivers.
¾Through “takeover/release” function on the transmitter, select control and decontrol on the
receiver.
¾The receiver can only be taken over by the transmitter under “release” status.
2.1.3 Function customization
Under the premise of meeting basic parameters of the radio controller, special radio control
system can be customized according to the customer’s actual site demands.

OHM（ChongQing）Electronic Technology CO.,LTD.
Tel: [phone] Fax: [phone] Service:400-920-9120
Ver.: 2016.01.1.0.3 Operating Manual for TCS-C Page 10 of 28
2.2 Introduction to transmitter
2.2.1 Transmitter size
¾TCS-C18 ( L x W x H ): 254mm x 130mm x 168mm
¾TCS-C26 ( L x W x H ): 254mm x 130mm x 168mm
¾TCS-C32 ( L x W x H ): 317mm x 162mm x 181mm
¾TCS-C64 ( L x W x H ): 317mm x 162mm x 181mm
¾TCS-C80 ( L x W x H ): 418mm x 216mm x 194mm
¾TCS-C6X ( L x W x H ): 254mm x 130mm x 168mm
¾TCS-C8X ( L x W x H ): 317mm x 162mm x 181mm
Note: Excluding special system.
2.2.2 External view of transmitter
¾Model: TCS-C18, TCS-C26, TCS-C32, TCS-C64, TCS-C80

OHM（ChongQing）Electronic Technology CO.,LTD.
Tel: [phone] Fax: [phone] Service:400-920-9120
Ver.: 2016.01.1.0.3 Operating Manual for TCS-C Page 11 of 28
1．Upper housing of transmitter 2．Lower housing of transmitter
3．XY-Axis joystick 4．External antenna
5．Status indicator lamp 6．Toggle switch
7．Emergency stop switch 8．Potentiometer
9．Hook 10．Smart Card slot
11．Side-push-button 12．Battery compartment
Note: The figure only shows TCS-C80 housings which are only for reference.
¾Model: TCS-C6X, TCS-C8X
1．Upper housing of transmitter 2．Lower housing of transmitter
3．Linear lever 4．External antenna
5．Status indicator lamp 6．Toggle switch
7．Emergency stop switch 8．Potentiometer
9．Hook 10．Smart Card slot
11．Side-push-button 12．Battery compartment
Note: The figure only shows TCS-C8Xhousings which are only for reference.

OHM（ChongQing）Electronic Technology CO.,LTD.
Tel: [phone] Fax: [phone] Service:400-920-9120
Ver.: 2016.01.1.0.3 Operating Manual for TCS-C Page 12 of 28
2.3 Introduction to receiver
2.3.1 Receiver size
¾Small-sized receiver housing ( L x W x H ): 248mm x 206mm x 75mm
¾Medium-sized receiver housing ( L x W x H ): 298mm x 206mm x 75mm
¾Large-sized receiver housing ( L x W x H ): 310mm x 206mm x 103mm
¾D-type receiver housing ( L x W x H ): 310mm x 375mm x 103mm
(excluding antenna, excluding waterproof cable lug or heavy-duty connector)
2.3.2 External view of receiver
1．Upperhousingofreceiver
2．Lower housing of receiver
3．Waterproof cable lug
4．Waterproof cable lug
5．Antenna cable
6．Receiver mask
7．Indicator lamp window
8．Shock pad fixing hole
9．Heavy-duty connector

OHM（ChongQing）Electronic Technology CO.,LTD.
Tel: [phone] Fax: [phone] Service:400-920-9120
Ver.: 2016.01.1.0.3 Operating Manual for TCS-C Page 13 of 28

OHM（ChongQing）Electronic Technology CO.,LTD.
Tel: [phone] Fax: [phone] Service:400-920-9120
Ver.: 2016.01.1.0.3 Operating Manual for TCS-C Page 14 of 28
Note:
¾Small-sized receiver housing is applicable to C series CAN bus system
¾Medium-sized receiver housing is applicable to TCS-C18 (Relay type)
¾Large-sized receiver housing is applicable to TCS-C26 (relay type), TCS-C32(relay type),
TCS-C64 (relay type and ProfiBus type), TCS-C80 (relay type and ProfiBus type), TCS-C6X
(PWM type), TCS-C8X (PWM type)
¾D type receiver shell is applicable to TCS-C80 (Relay type)

OHM（ChongQing）Electronic Technology CO.,LTD.
Tel: [phone] Fax: [phone] Service:400-920-9120
Ver.: 2016.01.1.0.3 Operating Manual for TCS-C Page 15 of 28
2.4 Accessories
Shoulder belt Shock pad Whip antenna
Charger OHM battery pack Sucker antenna (optional)
2.5 System wiring diagram
Specially customized; see bundled output diagram.

OHM（ChongQing）Electronic Technology CO.,LTD.
Tel: [phone] Fax: [phone] Service:400-920-9120
Ver.: 2016.01.1.0.3 Operating Manual for TCS-C Page 16 of 28
3、System settings
3.1 Setting of power-saving protection
Transmitter mainboard switch, as shown in the right figure
Frequency group
Power-saving
status
0 No. 1 Yes
1 No. 2 Yes
2 No. 3 Yes
3 No. 4 Yes
4 No. 1 No
5 No. 2 No
6 No. 3 No
7 No. 4 No
3.2 Setting of frequency and address code
Frequency and address code are stored in system’s ADCOM chip and Smart Card and can only
be modified by specialist persons with specialized tools.
3.3 Bus communication setting
DIP switch in the left figure below is address setting switch; DIP switch in the right figure is baud
rate setting switch. For more information, see table on bus information.

OHM（ChongQing）Electronic Technology CO.,LTD.
Tel: [phone] Fax: [phone] Service:400-920-9120
Ver.: 2016.01.1.0.3 Operating Manual for TCS-C Page 17 of 28
4、Transmitter operation
4.1 Transmitter installation
¾Transmitter battery installation: Check the battery level prior to installation to avoid abnormal
operation caused by insufficient battery voltage; pay attention to the direction of the battery
during installation and ensure reliable battery installation; when the transmitter is not used for
a long time, take out the battery.
¾Transmitter placement: The transmitter shall be put at a safe and striking place to avoid
damages caused by falling.
4.2 Transmitter startup
¾Place a fully charged OHM battery pack into battery compartment.
¾Pull out the emergency stop switch of the transmitter. long press ”Start” to make the green
light normally on; when the green light twinkles once per second, this indicates the machine
is normally started.
4.3 Transmitter shutdown
¾Push the Emergency Push Buttonswitch of the transmitter and then the power indicator lamp
will be off and the transmitter will be shut down.
4.4 Table on transmitter indicator lamp status
4.4.1 Power indicator lamp
The green lamp twinkles once per second The transmitter works fine.
The red lamp twinkles once per second
and is accompanied with sounds of the
buzzer.
The battery is over used.it needs be recharged.
(3.3V-3.5V)
The green and red lamps flash alternately The Smart Card is not identified or lost.
The green and red lamps are always on RF module is not identified.
4.4.2 Status indicator lamp
Determined according to system characteristics; for more information, see the bundled drawing.
