Okina SIR-754AILP-IO Quick start guide

Copyright © 2010. All Rights Reserved. SIR-754AILP-IO_L-806
http://www.okinausa.com 1 Rev12072010
6
3
2
1
0
7
5
4
SIR-754AILP-IO Kit
SIR-754AILP -IOP
Operational Manual
License Plate Capture Series
D&N LPC Camera w/ 11 IR LED Illuminator
Housing & Bracket
Camera – SHM-7540LPDN-IO
1/3” Sony Super HAD CCD II
Sony HQ-1 DSP, 540 TV Lines
5.0mm~60.0mm Auto Iris Lens
Made in Japan
0.08 Lux @ F1.0
I/O Input/Output
Mechanical IR Cut Filter (ICR)
Built-in Auto Sens-up
High Gain/Low Noise Amplifier - DNR
Advanced 8-step Manual Shutter
CAR-DC Iris Control is available to achieve reliable license
plate recognition for road surveillance when car speed is up
to 90 mi/hr (150 km/hr) in the daytime and 90 mi/hr (150
km/hr) at night time with external IR LEDs.
Dual Power 12V DC / 24V AC
Housing & Bracket – HI11-TKHBL
11 Super Power IR LED, 6pcs x 25° / 5pcs x 45°
IR Distance up to 395ft / 120m 
User Adjustable IR LED Intensity (VR)
Factory Default 80% 
Fully-Cable Managed Bracket
Uses professional rust-proof stainless steel screws
IP66 Rating, Heater & Blower, I/O
24V AC, 60VA (Power Ready Plug for 12V DC Camera)
Please see page 3 for details
Camera
Housing & Bracket
Max Load: 3500g
Material: Die-cast aluminum alloy with light ivory powder coated
and stove finish
Scan Angle: 180°
Title Angle: 90°
Net Weight: 900g
Fixing: 3 Screws with bushings
Lens Mount
This mount is used to install a CS mount lens.
CS adaptor ring is required if using a C mount lens.
CS Mount Fixing Screw
Screw for fixing mount and adjusting back focus if needed.
Mount Adaptor
This adaptor can be attached to either the top or bottom of unit.
Auto Iris Lens Connector (4-pin type)
The lens connector supplies the auto-iris lens (not supplied) with
DC power and a video signal or DC control signal.
ME/AES Shutter Control
(0) 1/100 (120) sec. (1) 1/190 sec.
(2) 1/350 sec. (3) 1/610 sec.
(4) 1/1120 sec. (5) 1/2000 sec.
(6) 1/3240 sec. (7) 1/4000 sec.
FEATURES
Please read the Operational Manual
before attempting to use this product.
PARTS
A
ND FUNCTIONS
DIMEN
S
I
O
N
S
(U
ni
t
: mm
)
SHM-7540LPDN-IO HI11-TKHBL
Note: Do Not Remove Screws
Copyright © 2010. All Rights Reserved. SIR-754AILP-IO_L-806
http://www.okinausa.com 2 Rev12072010
Camera to object moving speed
Shutter
Speed 45~60ft
(15~20m) 60~100ft
(20~35m) 100~180ft
(35~60m)
1/100 sec
1/190 sec
1/350 sec
1/610 sec 15~35 mi/h
r
(30~60 Km/hr) 45~45 mi/h
r
(45~75 Km/hr)
1/1120 sec 20~40 mi/h
r
(35~65 Km/hr) 35~53 mi/h
r
(55~85 Km/hr)
1/2000 sec 25~45 mi/h
r
(45~75 Km/hr) 40~60 mi/h
r
(65~95 Km/hr)
1/3240 sec 30~50 mi/h
r
(50~80 Km/hr) 50~62 mi/h
r
(80~100 Km/hr) 50~62 mi/h
r
(80~100 Km/hr)
1/4000 sec 35~55 mi/h
r
(60~90 Km/hr) 55~65 mi/h
r
(90~105 Km/hr) 55~65 mi/h
r
(90~105 Km/hr)
*The table above is only for reference. Values may change due to the angle of
the camera and the installation location.
Control Switch
SW1. BLC: Backlight Compensation OFF/BLC switch
SW2. Day/Night Mode: D/N / Color switch
SW3. AGC: Automatic Gain Control AGC/S.AGC switch
SW4. Sync Mode: Sync Mode Selection L.L/INT switch
Video Connector
Output for connecting to a video monitor or recorder.
Auto Iris Mode Selection Switch
For switching the output from the auto iris connector. Shutter speed
is fixed at 1/100(120) sec. when switch is set to DC or VIDEO
position.
DC: To be set when using a auto iris lens. Be sure to
adjust proper DC level for D&N operation.
CAR-DC: To be set when using for license plate
capture. (Car speed is up to 90 mi/hr (150 km/hr) in the daytime
and 90 mi/hr (150 km/hr) at night with external IR LEDs).
VIDEO: To be set when using an auto iris lens with built-in amp.
V.P. (Vertical Phase) Adjustor
Used to adjust the vertical phase of the video output signal
Power Input Terminal
Connect the power supply of 12V DC or 24V AC.
NOTE: When using two-cord power cable, please connect them to
“Live” and “Neutral.”
CAMERA
Model SHM-7540LPDN-IO SHM-7540LPDN-IOP
TV System NTSC PAL
Image Sensor 1/3” Sony Super HAD CCD II
DSP Sony HQ-1
Total Pixels 811(H) x 508(V) 795(H) x 596(V)
Video Output 1.0Vp-p Composite / 75ohms
Resolution 540 TV Lines
Minimum
Illumination
0.08 Lux @ F1.0
Color mode automatically switches
to B/W mode under 2 Lux
IR Sensitivity 700~1100nm
Mechanical IR
Cut Filter (ICR) External controlled by D&N IO; Color (IN: 0V or
normal open) / D&N (In: 5~12V DC or normal close)
Electronic
Shutter Speed
AES: 1/50(60) sec ~ 1/100,1000 sec
(0) 1/100(120) sec (1) 1/190 sec
(2) 1/350 sec (3) 1/610 sec
(4) 1/1120 sec (5) 1/2000 sec
(6) 1/3240 sec (7) 1/4000 sec
Intelligent
Shutter Speed
Capturing license plate for vehicle speeds up to
90 mi/hr (150 km/hr) in the daytime and 90 mi/hr
(150 km/hr) at night with external IR LEDs
Back Light
Compensation ON/OFF Switchable
Auto Gain
Control AGC / Super AGC
Auto White
Balance AWB
Day/Night Mechanical IR Cut Filter (ICR)
D/N / COLOR Switchable
I/O Yes
DNR / Sens-up Automatic; High Gain/Low Noise Amplifier
Scan System 2:1 Interlace
Synchronization Internal/Line Lock (AC Version Only)
S/N Ratio More than 50dB (S.AGC OFF)
Adjustment VR DC Level, L.L. V-phase
Automatic IRIS ;
Connector Video/DC ; D4 IRIS Jack
Lens Mount CS/C (with adaptor)
Power Supply 12V DC / 24V AC
Power
Consumption 3.0W
Operation
Temperature 14F ~ 122F / -10oC ~ 50oC
Storage
Humidity RH 80% or less
Storage
Temperature -4oF ~ 140oF / -20oC ~ 60oC
Dimension 4.72”(L) x 2.36”(W) x 1.97”(H)
120mm(L) x 60mm(W) x 50mm(H)
Weight 0.88 lbs / 400g
Specifications are subject to change without notice
SPECIFICATIONS PIC: L-806
CABLE INSTALLATION THROUGH BRACKET
EXTERN
A
L POWER INPUT CONNECTION
Copyright © 2010. All Rights Reserved. SIR-754AILP-IO_L-806
http://www.okinausa.com 3 Rev12072010
HOUSING
Model HI11-TKHBL
LED Quantity 11 Super Power IR LEDs
IR LED Beam
Angle 6pcs 25° / 5pcs x 45°
IR Wave Length 850nm
IR Distance 395ft / 120m 
IR Light On/Off Auto Light Sensor Control
Heater Control 64°F / 18°C (on) ; 82°F / 28°C (off)
Blower Control 95°F / 35°C (on) ; 77°F / 25°C (off)
IP Rating IP66
Temper Glass
Thickness 4mm
Mounting
Bracket Full-Cable Management
Construction Die-Cast Aluminum Alloy
Coating Ivory Powder Stove
Required Power
Supply /
Transformer* 24V AC (+/-10%), 60VA
Power
Consumption 16 Watts
Dimension 16.73”(L) x 6.30”(W) x 6.50”(H)
425mm(L) x 160mm(W) x 165mm(H)
Camera Space 7.87”(L) x 4.33”(W) x 4.53”(H)
200mm(L) x 110mm(W) x 115mm(H)
Weight 7.72 lbs / 3500g (w/out bracket)
11.75 lbs / 5330g (with bracket)
Specifications are subject to change without notice
*Power Supply / transformer not included
NOTE 1: IR light distances are entirely dependant upon environmental
site conditions and the location at which the unit is situated. The type of
camera being used is also very important.
NOTE 2: Factory default for the IR LED activation level is 80%. If there
is not enough IR light, adjust the VR level to maximum 100%.
One (1) SHM-7540LPDN-IO/SHM-7540LPDN-IOP Camera
One (1) HI11-TKHBL IR Illuminator Housing
One (1) Fully-Cable Managed Bracket
One (1) Main Accessories Pack
Three (3) Rust-proof Stainless Steel Wall Screws
Three (3) Rust-proof Stainless Steel Mounting Screws
Three (3) Stainless Steel Washers
Three (3) Plastic Washers
One (1) Allen Wrench
One (1) Secondary Accessories Pack
Three (3) Screw-on Connectors
One (1) Rubber Pad
One (1) Rust-proof Stainless Steel Camera Screw
One (1) Plastic Washer
One (1) Operational Manual
*For any returns, please include all components listed above with
original packaging in Resalable Condition. Absolutely No Returns
will be accepted if any component is missing/damaged or if any cable is
cut or tampered with.
1. Never point the camera toward the sun
Do not expose the lens directly to the sun or to strong light as
this may damage the pick-up device.
2. Handle this camera with care
Avoid any shock or bumping of the camera. Improper handling
could damage the camera.
3. Requires a proper operating environment
This camera is designed for outdoor or indoor use. The allowable
temperature range for operation of this camera is between
14F ~ 122F / -10C ~ 50C and the allowable humidity is
80%RH maximum.
4. Clean the front face to the pick-up device
It is recommended that the pick-up device surface be cleaned
before lens installation or whenever the lens is changed.
Cleaning should be done by using a chamois, a very fine soft
cloth, lens tissue, or cotton tipped applicator and ethanol to
carefully remove any fingerprint or dust.
5. Check the power source voltage
The power source voltage should be within the specified range.
(Camera must meet the specifications). Camera must be
connected to a surge protector at all times.
6. Objects and liquid entry
Never push objects of any kind into this camera as this may
touch dangerous voltage points of short out parts that could
result in a fire or electric shock. Never spill any kind of liquid on
the video product.
7. Servicing
Do not attempt to service this video product by yourself as
opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all service to qualified servicing
personnel.
8. Damage requiring service
Unplug this video product from the wall outlet and refer service
to qualified servicing personnel under the following conditions:
a. When the power supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the
video product.
c. If the video product has been dropped or the cabinet has
been damaged.
d. When the video product exhibits a distinct change in
performance.
OKINA USA products are covered under warranty for one year from
the date of purchase. The warranty will automatically be voided if
any of the following occurs:
1. Camera sticker is removed
If the camera sticker is removed, we will not be able to confirm
any information regarding when and where the product was
purchased. We have no other way to verify the purchase record
without the serial number on the camera sticker; therefore, it
should not be removed.
2.
Camera is modified in any way
If the camera is scratched, damaged, or modified in a manner
not described in this manual, the warranty will be voided
immediately. It is the customer’s responsibility to keep the
camera in good condition.
3. Video or power cable is cut
The video cable and the power cable should not be tampered
with. Cutting or modifying of the cables will result in termination
of the warranty.
CAUTION
WARRANTY
PACKAGE
CO
N
T
ENTS

This manual suits for next models

1

Other Okina Digital Camera manuals

Okina LPC Series Quick start guide

Okina

Okina LPC Series Quick start guide

Okina Eco Series Quick start guide

Okina

Okina Eco Series Quick start guide

Okina SHM-7550DNP Quick start guide

Okina

Okina SHM-7550DNP Quick start guide

Okina LPC Series User manual

Okina

Okina LPC Series User manual

Okina SEMI96-600LP025 User manual

Okina

Okina SEMI96-600LP025 User manual

Popular Digital Camera manuals by other brands

Canon Powershot SX520 HS user guide

Canon

Canon Powershot SX520 HS user guide

Bosch PS90 Operating/safety instructions

Bosch

Bosch PS90 Operating/safety instructions

Enlaps Tikee quick start guide

Enlaps

Enlaps Tikee quick start guide

Guide TU Series quick start guide

Guide

Guide TU Series quick start guide

HP Photosmart c20 manual

HP

HP Photosmart c20 manual

Olympus C-750 - 4MP Digital Camera Manuel de Référence

Olympus

Olympus C-750 - 4MP Digital Camera Manuel de Référence

Casio QV-10 Repair guide

Casio

Casio QV-10 Repair guide

SWELLPRO ZERO user manual

SWELLPRO

SWELLPRO ZERO user manual

Raptor Photonics OWL 1280 user manual

Raptor Photonics

Raptor Photonics OWL 1280 user manual

Sony Cyber-shot DSC-TX10 instruction manual

Sony

Sony Cyber-shot DSC-TX10 instruction manual

rock space C1 user manual

rock space

rock space C1 user manual

Panasonic DMCFZ40 - DIGITAL CAMERA - ADVANCED FEATURES Basic operating instructions

Panasonic

Panasonic DMCFZ40 - DIGITAL CAMERA - ADVANCED FEATURES Basic operating instructions

Bosch MIC IP starlight 7000i installation manual

Bosch

Bosch MIC IP starlight 7000i installation manual

Youthnet V900 user manual

Youthnet

Youthnet V900 user manual

Pentax S45 Connection manual

Pentax

Pentax S45 Connection manual

Rollei COMPACTLINE 202 datasheet

Rollei

Rollei COMPACTLINE 202 datasheet

Zetronix NANO-4K user manual

Zetronix

Zetronix NANO-4K user manual

IMOU Turret quick start guide

IMOU

IMOU Turret quick start guide

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
