Okina HD21T-8AVF User manual

HDC-28
Copyright © 2013. All Rights Reserved. R201310-V24
HD21T-8AVF
HD SDI 1080p Super Mini Box Camera
USER MANUAL
FEATURES
•SDI 1080p - 1920 x 1080
•2 Megapixel
•1/2.8" Sony Exmor
•2.8~12.0mm Auto Iris Vari-focal Lens – Made in Korea
•0.02 Lux @ F1.2
•OSD Control
•250mA
•12V DC
*Fixed or Vari-focal lens can also be installed on this camera.
We recommend using high quality megapixel lens in order to
get the best result in terms of picture.

2
Disposal of Old Electrical & Electronic Equipment (Applicable in the
European Union and other European countries with separate collection
systems).
This symbol on the product or on its packaging indicates that this product shall not be treated as
household waste. Instead it shall be handed over to the applicable collection point for the recycling
of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. The recycling of materials will
help to conserve natural resources. For more detailed information about recycling of this product,
please contact your local city office, your household waste disposal service or the shop where you
purchased the product.
CAUTION
1. Never point the camera toward the sun
Do not expose the lens directly to the sun or to strong light as this may damage the pick-up
device.
2. Handle this camera with care
Avoid any shock or bumping of the camera. Improper handling could damage the camera.
3. Requires a proper operating environment
This camera is designed for indoor use. The allowable temperature range for operation of this
camera is between 14°F ~ 122°F / -10°C ~ 50°C.
4. Clean the front face or lens
It is recommended that the surface be cleaned every 3~6 months. Cleaning should be done by
using a chamois, a very fine soft cloth, lens tissue, or cotton tipped applicator and ethanol to
carefully remove any fingerprint or dust.
5. Check the power source voltage
The power source voltage should be within the specified range. (Camera must meet the
specifications). Camera must be connected to a surge protector at all times.
6. Objects and liquid entry
Never push objects of any kind into this camera as this may touch dangerous voltage points of
short out parts that could result in a fire or electric shock. Never spill any kind of liquid on the
video product.
Please read the Manual before attempting to use this product.
Specifications and appearance are subject to change without notice.

3
7. Servicing
Do not attempt to service this video product by yourself as opening or removing covers may
expose you to dangerous voltage or other hazards. Refer all service to qualified servicing
personnel.
8. Damage requiring service
Unplug this video product from the wall outlet and refer service to qualified servicing personnel
under the following conditions:
a. When the power supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the video product.
c. If the video product has been exposed to rain or water.
d. If the video product has been dropped or the cabinet has been damaged.
e. When the video product exhibits a distinct change in performance.
LIMITED WARRANTY
OKINA USA products are covered under warranty for three (3) years from the date of
purchase. The warranty will automatically be voided if any of the following occurs:
1. Camera sticker is removed
If the camera sticker is removed, we will not be able to confirm any information regarding when
and where the product was purchased. We have no other way to verify the purchase record
without the serial number on the camera sticker; therefore, it should not be removed.
2. Camera is modified in any way
If the camera is scratched, damaged, or modified in a manner not described in this manual, the
warranty will be voided immediately. It is the customer’s responsibility to keep the camera in
good condition.
3. Video or power cable is cut
The video cable and the power cable should not be tampered with. Cutting or modifying of the
cables will result in termination of the warranty.
PACKAGE CONTENTS
1. One (1) HD21T-8AVF Camera
2. One (1) 2.8~12.0mm Auto Iris Vari-focal Lens
3. CVBS (BNC) Output and 12V DC Power Input Wire
4. One (1) User Manual
* For any returns, please include all components listed above with original packaging in
Resalable Condition. Absolutely No Returns will be accepted if any component is
missing/damaged.

4
DIMENSIONS (Unit: inches / mm)
Camera
Lens
CVBS (BNC) Output and 12V DC Power Input Wire
PARTS AND FUNCTIONS
SDI output
CVBS (BNC) Output &
12V DC Power Input Wire
HDMI output
OSD Direction Button

5
HARDWARE RS485 WITH PTZ KEYBOARD SETUP
Default protocol is Pelco-D and default baud rate is 9600 for RS485 communication
between camera and PTZ controller.
NOTE: It is highly recommended that you run an additional cable for your RS485
communication from your camera. Some models may have RS485 setting in menu.
Please leave RS485 baud rate setting at 38400.
OSD
OSD Main Menu
1. LENS
LENS
DC
INDOOR /
OUTDOOR
VIDEO
N/A
MANUAL
Manual: Iris is adjusted manually.
DC: Iris is adjusted automatically by the camera according to light conditions.
Note: Fixed or Vari-focal lens can be installed on this camera. We recommend using
high quality megapixel lens in order to get the best result in terms of picture quality.
2. EXPOSURE
EXPOSURE
SHUTTER
AUTO ,
1/30,1/60(1/50),FLK,1/250,1/500,1/1000,1/2000,1/5000,1/1000
0,
1/50000,X2,X4,X6,X8,X10,X15,X20,X25,X30
AGC
MIDDLE,HIGH,LOW
SENS-UP
AUTO
SENS-UP
X2,X4,X6,X8,X10,X15,X20
,X30,X60
RETURN
RET
OFF
BRIGHTNESS
0~100
ACCE
OFF,LOW,MIDDLE.HIGH
DEFOG
OFF,LOW,MIDDLE.HIGH
SETUP
1. LENS DC
2. EXPOSURE
↲
3. WHITE BAL ATW
4. DAY&NIGHT AUTO↲
5. NR ↲
6. SPECIAL
↲
7. ADJUST
↲
8. RESET
↲
9. EXIT
↲

6
BACKLIGHT
OFF
BLC
GAIN
MIDDLE,HIGH,LOW
AREA
POSITION
SIZE,RET,AGAIN
DEFAULT
RETURN
RET
HBLC
SELECT
AREA1,AREA2,AREA3,AREA4
DISPLAY
ON,OFF
LEVEL
0~100
MODE
ALL DAY,NIGHT
BLACK
MASK
ON,OFF
DEFAULT
RETURN
RET
RETURN
RET
SHUTTER:
AES (auto electronic shutter): The camera automatically sets the optimum shutter
speed.
FL: Flicker less mode avoids interference from light sources (recommended for
video-iris or DC-iris lenses only).=
FIXED: Forces a fixed shutter speed.
AGC:
Regulate the gain or amplification of the video signal, mainly used in low-light
conditions with the iris fully open. *This can only be used when DAY&NIGHT is
not set to AUTO.
SENSE UP:
Allow user selectable digital show shutter speed in order to allow extra light into a
camera thereby providing higher sensitivity in low light conditions.
ACCE (DWDR):
Stand forAdaptive Contrast and Color Enhancement which is equivalent to dynamic
range reduction technique.
The contrast ratio of the image can be effectively expressed and the edge
information can be improved in order to enhance the overall visibility of the image.
DEFOG:
It improves the clarity of images taken in poor conditions, such as fog, smoke, rain or
snow. Applied to live or recorded color video, it provides real time results and
displays visual details that would normally have been difficult to distinguish.
3. WHITE BALANCE
WHITE BAL
ATW
AWC > SET
INDOOR
OUTDOOR
MANUAL
BLUE
0~100
RED
0~100
RETURN
RET

7
4. DAY & NIGHT
DAY & NIGHT
AUTO
DELAY
0~60
N-D(AGC)
0~100
N-D(AGC)
0~100
RETURN
COLOR
B/W
BURST
ON,OFF
Ir SMART
ON,OFF
IR LED
ON,OFF
IR PWM
0~100
RETURN
RET
EXT
5. NR
NR
2DNR
ON,OFF
3DNR
ON
S-LEVEL
0~100
E-LEVEL
0~100
RETURN
RET
LEVERL
0~100
SMART NR
ON,OFF
RETURN
RET
SMART NR:
Avoid over exposure problem when the camera is focus on area with wall.
6. SPECIAL
SPECIAL
CAM TITLE
OFF
ON
0123456789ABCDEFGHIJKLMNOPQRSTU
VWXYZ ＜＞
CLR POS END
D-EFFECT
FREEZE
OFF,ON
MIRROR
OFF,MIRROR,V-FLIP,ROTATE
D-ZOOM
OFF
ON
PIP
OFF,ON
D-ZOOM
X2.0~62.0
PAN&TILT
D-ZOOM
DEFAULT
RETURN
NEG.IMAGE
OFF,ON
RETURN
MOTION
OFF
ON
SELECT
AREA1,AREA2,AREA3
DISPLAY
OFF
ON
POSITION
SENSITIVITY
0~100
MOTION
VIEW
OFF,ON

8
DEFAULT
RETURN
RET
PRIVACY
OFF
ON
SELECT
ARE1~ARE8
DISPLAY
ON/POSITION
COLOR
1~16
DEFAULT
RETURN
RET
LANGUAGE
English/ Chinese/ Japanese
DEFECT
LIVE DPC
ON,OFF
LEVEL
0~60
STATIC DPC
ON,OFF
START
LEVEL
0~60
SENS-UP
X2,X4,X6,X8,X10,X15,X20,X30,X60
RETURN
RET
RS485
CAM ID
0~255
ID DISPLAY
OFF
ON
CAM.001~CAM255
BAUDRATE
9600,19200,38400,2400,4800
RETURN
RET,END
RETURN
RET
7. ADJUST
ADJUST
SHARPNESS
SHARPNESS
ON,0FF
LEVEL
0~100(50)
RESOLUTION
ON,OFF
RETURN
RET
MONITOR
LCD
GAMMA
USER,0.45,0.50,0.55,0.60,
0.65,0.70,0.75,0.80,0.85.0.
90,0.95,1.00
BLUE GAIN
0~100
RED GAIN
0~100
RETURN
RET
CRT
BLACK
LEVEL
0~30
BLUE GAIN
0~100
RED GAIN
0~100
RETURN
OSD
TEXT COLOR
1~8
OUTLINE
OFF,ON
RETURN
RET
LSC
ON,OFF
NTSC/PAL
NTSC,PAL
RETURN
REST,END
RESET
FACTORY
RETURN
EXT

9
8. REST
RREST
FACTORY
RETURN
9. EXIT: Exit menu.

10
SPECIFICATION
Model
HD21T-8AVF
Image Sensor
1/2.8" Sony Exmor IMX122 CMOS
Resolution
Max.1920 x 1080 (1080P FULL HD)
DSP
NEXT CHIP 2400
Min. Illumination
0.02 Lux @ F1.2 – AGC ON
Video output
SDI / CVBS / HDMI
Digital Noise Reduce
Yes – 2DNR & 3DNR
Menu
OSD Button Control
Day & Night Mode
Auto
Electronic Shutter
Auto 1/60 (1/50) ~ 1/50,000 sec / Flk
DWDR Function
OFF / Low / Middle / High
AGC
Low / High / OFF
BLC
BLC / HSBLC / OFF
White Balance
AWC-SET / MANUAL / INDOOR / OUTDOR / ATW
Camera Title
ON / OFF
SMART NR
ON / OFF
SENS-UP
ON / OFF (Selectable range 2X~ 30X)
Picture-Effect
Mirror
Language
English / Chinese / Japanese
Lens
Focal Length
2.8 ~ 12mm Auto Iris Lens – Made in Korea
Max.
Aperture Ratio
1:12 – 1:2.3
Aperture
F1.4 Max.
Format
1/2.7”
Horizontal View
Angle (At 1/2.7”)
93° - 28.7°
Min.
Object Distance
0.2m
Back Focal
Length (In Air)
6.39mm
Lens Mount
CS (1° – 32 UNF)
Operation
Zoom
Manual
Focus
Manual
Iris
DC Auto-Iris
Dimensions
Ø1.31” x 1.78”(W) x 1.66”(H)
Ø 33.2mm x 45.2mm(W) x 42.1mm(H)
Operation
Temperature
-4°F ~ 176°F / -20°C ~ 80°C
Power source
12V DC
Power Consumption
250mA
Operation Temperature
14°F ~ 122°F / -10°C ~ 50°C
Storage Temperature
-4°F ~ 158°F / -20°C ~ 70°C
Dimension
1.47”(W) x 1.54”(H) x 2.92”(D)
37.3mm(W) x 39mm(H) x 74.05mm(D)
CVBS output & 12V DC power input wire:
25.6” / 650mm(L)
Net Weight
< 1 lb / < 453g
* Specifications are subject to change without notice.

11

12
www.okinausa.com
MADE IN TAIWAN
Copyright © 2013. All Rights Reserved. HDC-28
www.okinausa.com R201310-V24
