Okina WDEM-7680 User manual

Copyright © 2010. All Rights Reserved.
www.okinausa.com 1 REV012011-V05
WDEM-7680 680 TVL
WDEM-7610 610 TVL
P
A
CKAGE CONTENTS
WDE-7680
Color: 680 TVL, B/W: 700 TVL
Powerful 510x WDR (54dB)
WDE-7610
Color: 610 TVL, B/W: 630 TVL
Powerful 256x WDR (53dB)
1/3" Hyper Wide Dynamic Color Camera, Effio WDR DSP
Color: 0.03 Lux @ F1.0, B/W: 0.01 Lux @ F1.0,
Sense-up: 0.0001 Lux @ F1.0
Mechanical IR Cut Filter (ICR)
Multi-Language OSD Control / RS485 Control
Ideal for Backlight Environments
2D/3D Noise Reduction & Sense Up (512x) Functions
High Contrast Images; Face Detection of up to 4 faces
E-zoom Function (1~256x)
Advanced Motion Detection Function
Polygonal Mosaic Privacy Mask; Freeze / Timer Clock
12V DC / 24V AC, 3.0W
FEATURES
One (1) WDEM-7680 or WDEM-7610 camera
One (1) DC Connector
One (1) CS Mount Ring
One (1) DC Plug
One (1) Allen Wrench
One (1) Warning Sign Sticker
One (1) Quick Setup Guide
One (1) CD with User Manual
*For any returns, please include all components listed above with
original packaging in Resalable Condition. Absolutely No Returns will
be accepted if any components are missing/damaged or if any cable is
tampered with.
DIMENSIONS
(
Unit: mm
)
DESCRIPTION OF CAMERA PARTS
(1) Lens Mount
This mount is used to install a CS-mount lens. CS-adaptor ring is
required when using a C mount lens.
(2) Camera Mounting Screw Holes
Screw hold for mounting the camera.
(3) Mount Adapter
The adapter can be attached onto the top or bottom of the unit.
(4) Auto Iris Lens Connector (4-pin type)
The lens connector supplies the auto-iris lens (not supplied) with DC
control signal
(5) S-Video Output Terminal
Separate Y (brightness) and C (color) signal are outputs from this
terminal to obtain better video quality at a video monitor.
1. C signal: 0.3V (p-p), 75Ω, unbalance 3. C signal Ground
2. Y signal: 1.0V (p-p), 75 Ω, unbalance, 4. Y signal Ground
negative synchronizing
(6) Iris Mode Selection Switch
Select DC or VIDEO mode according to the lens.
(7) OSD Control Buttons
ENTER button
UP & DOWN buttons
LEFT & RIGHT buttons
(8) Video Connector
Video can be outputted via this BNC connector (75Ω).
(9) Communication Connectors
1. RS485+ 4. Day & Night Output
2. RS485- 5. Alarm Out
3. Day & Night External Input 6. Ground
(10) Power Input Indicator Light
When the camera is connected to a power source, the indicator light
will be on.
(11) RS485 Terminal Impedance Switch
Set the first and the last equipment terminal impedances as 120Ω
and set the rest parallel connection equipment in the middle as HiZ to
obtain the best transmitting status.
(12) Power Input Terminal
Connect the power input of 12V DC/24V AC (10.8~39V DC/24V AC).
Hyper Wide Dynamic Camera
Effio WDR
Quick Setup Guide
** Please refer to User Manual CD for detailed information **

Copyright © 2010. All Rights Reserved.
www.okinausa.com 2 REV012011-V05
PIC T-409 T-411
Model WDEM-7680 WDEM-7610
Image Sensor 1/3" Sony 760H Double-speed (Double-density) CCD
Number of Total Pixels NTSC: 1028(H) x 508(V)
PAL: 1024(H) x 596(V)
NTSC: 811(H) x 508(V)
PAL: 795(H) x 596(V)
Resolution Color: 680TVL, B/W: 700TVL
Sony Effio WDR
Color: 610TVL, B/W: 630TVL
Sony Effio WDR
Minimum Illumination Color: 0.03 Lux @ F1.0; B/W: 0.01 Lux @ F1.0; Sense-up: 0.0001 Lux @ F1.0
Wide Dynamic Range 510x Normal Camera (54dB) 256x Normal Camera (53dB)
Video Output 75Ω(BNC), S-Video (Y/C)
Signal to Noise Ratio More than 52dB (AGC off, Weight on)
Gamma Correction 0.45
Mechanical IR Cut Filter (ICR) Automatically Switches (Switching lux level can be adjusted)
Menu OSD Control or by RS485 Control
Title TITLE (LOCATION)
Synchronizing System INTERNAL / LINE LOCK
Digital Day&Night Mode COLOR / B&W / AUTO / EXT / SCHEDULE
Electronic Shutter AUTO(1/50(60)~1/100,000sec.) / SCHEDULE or DAY&NIGHT / MANUAL: 1/50(60), FL 1/120(100), 1/200, 1/250, 1/350, 1/500, 1/750, 1/1,000, 1/1,500, 1/2,000, 1/3,000, 1/4,000,
1/10,000, 1/30,000, 1/60,000, 1/100,000 sec.
Automatic Gain Control AUTO / MANUAL / OFF
White Balance ATW / AWB / AWC (Push Lock) / MANUAL /
OUTDOOR(1800°K~10500°K) / INDOOR(4500°K~8500°K) / ANTI CR
Back Light Compensation WDR / BLC / OFF
Flickerless ON / OFF
Dynamic Noise Reduction 3D / 2D
Sense Up AUTO (Limit x2~x512) / OFF
Face Detection 4 Face Detection
Language ENGLISH / TRADITIONAL CHINESE / SIMPLIFIED CHINESE
E-Zoom x1~x256, Pan / Tilt Adjustable
Motion Detection ; Privacy ON / OFF (24x16 Zones, Alarm) ;
ON / OFF
(
16 Zones Pro
g
rammable
,
Pol
yg
onal Mosaic
)
Timer Clock Year / Month / Date, Hour / Minute / Second
Camera Control Interface RS485 Interface OSD control by Pelco-D, Pelco-P
Automatic IRIS ; Connector VIDEO / DC ; D4 IRIS Jack
Lens Mount C / CS mount (with Adaptor)
Lens Not Included
Power Input ; Consumption 12V DC / 24V AC (10.8~39V DC / 24V AC) ; 3.0W
Operation ; Storage Temp. 14˚F~122˚F ; -4˚F~140˚F ; -10˚C~50˚C ; -20˚C~60˚C
Operation ; Storage Humidity Maximum: RH80% ; RH90%
Dimensions 2.36”(W) x 1.97”(H) x 4.68”(L) / 60mm(W) x 50mm(H) x 119mm(L)
Net Weight 0.77 lbs / 350g
* Specifications are subject to change without notice.
PAL version also available.
Use OSD Control Buttons to operate OSD and adjust settings.
SPECIFICATION
OSD OPERATION
1. Start to operate the OSD menu
Press the ENTER button to bring up the OSD main menu to start
operating OSD menus.
2. Select items with the cursor buttons
yUse buttons cand dto move the cursor up and down.
yUse buttons eand fto switch the modes or to adjust the
parameters or the values of the settings.
3. Switch to the sub-menu
Items with “<┘” symbol in the end contains sub-menus. For further
settings of those items, select the desired item with the button cor d
and press the ENTER button to bring up the sub-menu and edit.
4. Return to the previous page
Select RETURN and press the ENTER button to return to the previous
page.
5. Exit the OSD menu
Select EXIT with the button cor dand press the ENTER button to exit
the OSD menu.
* * MAIN MENU **
LENS
AGC
WDR
WHITE BALANCE
2DNR & 3DNR
DAY / NIGHT
SHUTTER
EFFECT
SYSTEM
EXIT
SET<┘
AUTO
WDR<┘
ATW
SET<┘
COLOR
MANUAL<┘
SET<┘
SET<┘
SET<┘

Copyright © 2010. All Rights Reserved.
www.okinausa.com 3 REV012011-V05
Adjust the item with buttons eand f, for the item with sub-menus, click enter to edit it.
1. Never point the camera toward the sun
Do not expose the lens directly to the sun or to strong light as this may damage the pick-up device.
2. Handle this camera with care
Avoid any shock or bumping of the camera. Improper handling could damage the camera.
3. Requires a proper operating environment
This camera is designed for indoor and outdoor use. The allowable temperature range for operation of this camera is between 14˚F~122˚F /
-10°C~50°C and the allowable humidity is 90%RH maximum.
4. Clean the front face to the pick-up device
It is recommended that the pick-up device surface be cleaned before lens installation or whenever the lens is changed. Cleaning should be done by
using a chamois, a very fine soft cloth, lens tissue, or cotton tipped applicator and ethanol to carefully remove any fingerprint or dust.
5. Check the power source voltage
The power source voltage should be within the specified range. (Camera must meet the specifications). Camera must be connected to a surge
protector at all times.
6. Objects and liquid entry
Never push objects of any kind into this camera as this may touch dangerous voltage points of short out parts that could result in a fire or electric
shock. Never spill any kind of liquid on the video product.
7. Servicing
Do not attempt to service this video product by yourself as opening or removing covers may expose you to dangerous voltage or other hazards.
Refer all service to qualified servicing personnel.
8. Damage requiring service
Unplug this video product from the wall outlet and refer service to qualified servicing personnel under the following conditions:
a. When the power supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the video product.
c. If the video product has been exposed to rain or water.
d. If the video product has been dropped or the cabinet has been damaged.
e. When the video product exhibits a distinct change in performance.
OKINA USA products are covered under warranty for one year from the date of purchase. The warranty will automatically be voided if any of the
following occurs:
1. Camera sticker is removed
If the camera sticker is removed, we will not be able to confirm any information regarding when and where the product was purchased. We have no
other way to verify the purchase record without the serial number on the camera sticker; therefore, it should not be removed.
2. Camera is modified in any way
If the camera is scratched, damaged, or modified in a manner not described in this manual, the warranty will be voided immediately. It is the
customer’s responsibility to keep the camera in good condition.
3. Video or power cable is cut
The video cable and the power cable should not be tampered with. Cutting or modifying of the cables will result in termination of the warranty.
BASIC SETTINGS
CAUTION
WARRANTY
** MAIN MENU **
LENS
AGC
WDR
WHITE BALANCE
2DNR & 3DNR
DAY / NIGHT
SHUTTER
EFFECT
SYSTEM
EXIT
SET<┘
AUTO
WDR<┘
ATW
SET<┘
COLOR
MANUAL<┘
SET<┘
SET<┘
SET<┘
yLENS: LENS <┘/ BRIGHTNESS / SPEED
yAGC: AUTO / OFF / MANUAL
yWDR: WDR / BLC / OFF
yWHITE BALANCE: ATW / AWB / AWC / MANUAL / OUTDOOR / INDOOR / ANTI CR
y2DNR & 3DNR: ON <┘/ OFF
yDAY/NIGHT: COLOR / B&W / AUTO / EXTERNAL / SCHEDULE
ySHUTTER: MANUAL / AUTO / DAY/NIGHT
yIMAGE: HIGH RESOLUTION / SHAPRNESS / CHROMA / FREEZE / MIRROR /
POS/NEG
yEFFECT: MOTION DETECTION / FACE DETECTION / VPS / E-ZOOM / PRIVACY
MASK
ySYSTEM: CAMERA TITLE / DATE/TIME / COMM / SYNC / LANGUAGE / FIRMWARE /
RESTORE
yEXIT: Exit the OSD menu
