oklahoma joes Longhorn Smoker 06201348 User manual

MODEL 06201348 • ASSEMBLY INSTRUCTIONS
Longhorn TM Smoker
Longhorn Smoker 06201348-42804230(05-13-08)
WARNING
NEVER LEAVE FIRE UNATTENDED!
Do not allow small children near flame. Hot embers can
fly out in breezy conditions. Adequate fire extinguishing
material should be readily available.
WARNING
CARBON MONOXIDE HAZARD
Burning charcoal inside can kill you. It gives off carbon
monoxide, which has no odor. NEVER burn charcoal
inside homes, vehicles or tents.
Read and follow all safety statements, warnings,
assembly instructions and use & care directions before
attempting to assemble.
CAUTION
CAUTION
Some parts may contain sharp edges – especially as
noted in manual. Wear protective gloves if necessary.
WARNING
Do not use this unit on or near combustible surfaces or
structures such as wood decks, dry leaves or grass, vinyl
or wood siding, etc. SEE OWNER’S MANUAL FOR
IMPORTANT SAFETY INFORMATION.
CAUTION
THIS UNIT IS HEAVY!
DO NOT assemble without a helper.
WARNING
All surfaces can be hot during use. Use protection as
required to prevent burning.
Two adjustable wrenches • Hammer
For Outdoor
Use Only Tools needed for assembly:

STOP!
Missing a part?
No need to go back to the store!
The
store where you made your purchase
does not stock parts for this item. If you
need parts, whether they are missing or
damaged, call the Customer Service toll
free Help Line.
Call us and we will gladly ship
Call
the part you need
Our Help Line
ITEM DESCRIPTION QTY
55700282 SMOKER CHAMBER KIT W/LOGO PLATE 1
55710227 FIREBOX KIT 1
55710228 COOLTOUCH HANDLE KIT 2
55710229 WHEELKIT
2
55700286 SMOKESTACK KIT 1
55700452 SHORT LEG KIT 2
55700453 LONG LEG KIT 2
55700289 DOOR LATCH KIT 1
55700290 BUTTERFLYDAMPER KIT 1
60001006 HARDWARE BAG 1
42804230 ASSEMBLYINSTRUCTIONS 1
40002811 FIRE GRATE SET 3
43302822 SMOKER CHAMBER COOKING GRATE 2
43302817 FIREBOX COOKING GRATE 1
55700449 STORAGE RACK KIT 1
55710230 SS FRONT SHELFASSEMBLY 1
12503000 TEMPERATURE GAUGE 1
PARTS LIST
To insure your satisfaction
and for follow-up service,
register your product
online at:
www.Grillregistration.com
ASH TRAY COLLECTORASSEMBLY KIT 1
55710231

Cut
1box strapping and remove top of box. Lay sides of carton on groundnext to carton bottom. Remove parts from inside of unit.
One person should hold the unit steady at the firebox end while anotherremoves the support pieces from the carton.
Smoke chamber
Firebox
With
2one person on smoke chamber end, one person on firebox end, and oneperson holding both doors closed, roll the unti
onto cardboard that was placed on the ground next to the unit. Unitshould now be resting on its smoke chamber handle
brackets with the leg posts pointing upward.
Leg posts
pointing upward
Smoke chamber
handle brackets

On
3each short leg, slide one onto axle, followed by a wheel, then another . Slide a
into the hole at the end of the axle.
1/2” flat washer 1/2” flat washer hitch pin
Wheel
1/2” Flat washer
Axle
Short leg
Hitch pin
1/2” Flat washer
Hitch pin
Slide
4short legs onto posts closest to
firebox, with wheels facing outward. Slide
long legs onto posts at opposite end. Secure
legs to posts using one
per leg.
Do not fully tighten bolts. Tighten just
enough so that leg will not slide off post.
Bolts will be fully tightened when assembly
is complete.
3/8-16x1” hex-head
bolt
NOTE:
Long leg
3/8-16x1”
Hex-head bolt
Short leg
Firebox

Have
5one person hold wood rack in position shown while another attaches rack tolegs using four .
Fully tighten these four bolts. 3/8-16x1” hex-head bolts
Wood rack
MAKE
6SURE THAT LEG BOLTS ARE TIGHT ENOUGH SO THAT LEGS WON’T SLIP OFF OFUPsOinSgTtSh.ree people,
roll the unit over the handle brackets and stand it up onto itslegs. Once standing, fully tighten the four leg bolts.

7
Smoke
8
Attach
chamber
smokestack to end of smoke
chamber by sliding stack into smokestack
receiver. While holding the smokestack in a
vertical position, tighten th3e/8-16x3/4”
hex-head boltin the nut that is welded to
the smokestack receiver.
Firebox
Smokestack
Smokestack receiver
To attach damper to firebox side door, place one onto one . Insert the bolt into the1/4” flat washer 1/4-20x3/4” hex-head bolt
center hole of the firebox side door, from the outside. Place the handle of the damper through the lower opening inthe door
from the inside and place the center hole in the damper over thebolt. Place another onto the bolt and secure1/4” flat washer
with a . Do not over-tighten lock nut. Damper should be able to move freely. Slide door latch behind door catch to1/4” lock nut
keep firebox door closed.
Damper
Side door
Door latch

9
Handle bracket
Hitch pin
Handle
Handle rod
Assembly. . . While holding handle in position between handle brackets,slide rod into one bracket, through handle, and
out through other bracket. Secure at each end of rod with . Repeat process to assemble firebox handle.hitch pins
Handle
10
SS Front
Attach
shelf
front shelf by sliding ends of shelfframeinto brackets welded to smoke chamber.

Temperature gauge

Slide
13 ash collector into ash
collector guide.
Ash collector

WARNING
MOST
SURFACES ON THIS UNIT ARE HOT WHEN IN USE.
USE EXTREME CAUTION. KEEP OTHERS AWAY FROM UNIT.
ALWAYS WEAR PROTECTIVE CLOTHING TO PREVENT INJURY.
HARDWARE LIST
Hardware is shown actual size. You may have spare hardware after assembly is complete.
1/4” Flat Washer
Qty. 4
(2 already installed)
3/8” Lock Washer
Qty. 8
(Already
1/2”Flat
installed)
Washer
Qty. 4 Hitch Pin
Qty. 6
1/4-20x3/4”
Hex-Head Bolt
Qty. 2
(1 already installed)
3/8-16x3/4”
Hex-Head Bolt
Qty. 9
(8 already installed)
1/4-20 Lock Nut
Qty. 2
(1
3/8-16
already installed)
Hex Nut
Qty. 8
(Already installed)
3/8-16x1”
Hex-Head Bolt
Qty. 8
(4 already installed)
