OKPOS Optimus User manual

OKPOS Optimus Service Manual

2
Contents
Before Using the Product
Read this rst 4
Safety Information 4
Information on Copyrights 5
Overview
What’s in the Box 6
System Overview 7
Front 7
Rear and I/O ports 8
Adjusting LCD Angle 9
Installation
Connecting Peripherals 10
Removing the I/O port cover 10
Removing the stand’s rear cover 11
Connecting peripheral devices 11
Connecting the power cord 12
Replacing the I/O port cover 12
Replacing the stand’s rear cover 13
Installing Optional Devices 14
Card reader (IC & MSR) 14
VFD 16
LCD Customer Display 17
COM and SATA sub-board 20
Turning the SYSTEM On/O 21
Turning On 21
Turning O 21
System Disassembly
Disassembling the System 22
➊Removing the cover 22
➋Removing the COM and SATA
sub-board (optional) 25
➌Removing the main board 26
➍Removing the touch panel 27
➎Removing the LCD module 28
Re-assembling the System 29
Components Replacement 30
Replacing the M.2 SSD 30
Replacing the memory module (RAM) 32
Replacing the CMOS battery 34
Replacing the SSD (optional) 35
Application Programs
Drivers 37
Utilities 37

3
Setting Up the Touch Screen 37
Setting Up the Card Reader 41
Running the setup program 41
Track setting 42
Sound setting 42
I/Button setting 43
Error code setting 43
Setting Up the VFD 44
Setting Up the LCD Customer Display 46
System Setup (BIOS) 48
Entering Setup 48
BIOS action keys 48
Main menu 49
Feature menu 49
Advanced menu 50
Chipset menu 53
Security menu 54
Boot menu 56
Save & Exit menu 57
HDD Recovery 58
System Boards
Main Board 59
Mainboard layout 59
I/O Ports of Main B/D 61
Jumper Settings 61
Headers and connectors 62
Touch Control B/D 66
Specications 66
Board Layout 67
COM and SATA Sub-board (optional) 68
Board Layout 68
Connector Descriptions 68
Cable Pin Assignment
LVDS Cable 70
MSR/IC Cable 71
COM1 Cable 71
COM2 Cable 72
COM3 Cable 72
COM4 Cable 73
Specications
General 74
Main Board 75

4
Before Using the Product
Read this rst
Before using your system, please read this Manual carefully, and keep it on hand for future
reference.
●
The contents of this manual may be changed without notice.
●
Depending on the system model and type, some parts of this manual may dier from the actual
product.
●
The basic drivers and utilities that come with your system are subject to change.
●
OKPOS assumes no responsibility for damages resulting from a use of the product that is not
approved by OKPOS, or failure to follow the precautions and instructions provided in this User
Manual.
●
As some of the storage space is used for the system OS and built-in software, the actual capacity
available is less than the storage capacity listed in the product specications. In addition, the
amount of available space may vary after you perform system OS and software updates.
Safety Information
Please observe the following safety instructions to protect your computer from damage and ensure
your personal safety.
●
Do not install the system in a location that is wet, damp, or near water. This may cause a re or an
electrical shock.
●
Only use the system in the specied power environment. The system may not work, and may
even cause a re, if it is used with a dierent power source or equipment, or in a country that has
dierent power specications.
●
Make sure the plug is not bent or crushed by a heavy object. A damaged plug can cause a re or an
electrical shock.
●
Do not modify or extend the power cable. Cable damage may cause an electrical shock or re.

Before Using the Product
| Information on Copyrights 5
●
Do not use a damaged power cord or plug, or a loose outlet. These may cause a re, short circuit,
or electrical shock.
●
Do not install the system in a location where it is likely to overheat or where it will be exposed to
direct sunlight. Ensure the system is kept a safe distance away from any heating device. Installation
in such locations could cause damage to the cabinet and the electronic components.
●
Do not drop or apply any strong shock to the system. This may cause damage to the system and
the SSD or HDD installed inside it.
●
Do not use a sharp-pointed object on the display or apply excessive pressure to the display. This
may cause damage to the touch LCD display.
●
Do not block or cover slots or openings in the system cabinet. These have been provided for
ventilation, to prevent the system from overheating.
●
Do not use this system on a bed, sofa, rug or other similar surface.
●
Never insert any object into the system through the cabinet openings, as they may touch
dangerous voltage points or short out parts, which could result in a re or electrical shock.
●
Never spill liquid of any kind on the product.
●
Unplug the system from the electrical power outlet before cleaning. Clean the system, using a
damp or dry cloth. Do not use abrasives, kerosene, benzene, thinner, hydrochloric acid, or hot
water, and do not use a tough sponge or a brush, as these may cause discoloration or deterioration
of the cabinet.
●
Use only a 3-wire grounding type plug to avoid electric shock and damages due to short circuits.
●
If you have to use an extension cord, make sure that the total amperage rating of all equipment
plugged into it does not exceed the amperage rating of the extension cord and only use a 3-wire
grounding extension cord with a 3-prong grounding plug and outlet.
Information on Copyrights
●
Copyright © 2018 OKPOS Co., Ltd.
●
This manual is protected under international copyright laws. No part of this manual may be
reproduced, distributed, translated, or transmitted in any form or by any means without the prior
written permission of OKPOS Co., Ltd.
●
OKPOS and Optimus are registered trademark of OKPOS Co., Ltd.
●
Windows 7/10 is a registered trademark of Microsoft.
●
All other trademarks and copyrights are the property of their respective owners.

6
Overview
What’s in the Box
The package include the following items.
Optimus system
COM 1/2/3/4 cables(1.2 m x 2, 0.35 m x 2)
Quick Start Guide AdaptorPower cable
NOTE:
⦁
If any of the above is missing, please contact the customer center.
⦁
Only use devices with this system that have been supplied or approved by OKPOS. If you use a device supplied
by another provider that is not approved, your system may malfunction or not work.
⦁
The appearance and specications of the system and accessories may be changed without notice.
⦁
If you misplace one of the included components and want to purchase a new one, contact the customer center.

Overview
| System Overview 7
System Overview
Front
Touch display panel
(touch LCD)
Stand

Overview
| System Overview 8
Rear and I/O ports
Stand rear cover
I/O port cover
Cable hole
Power button
Two USB ports
Power (12V DC-IN) jack
Power (12V DC-OUT) jack
COM4 port
COM3 port
Four USB ports
LAN port
Speaker jack
VGA port
COM1 port
COM2 port

Overview
| Adjusting LCD Angle 9
Adjusting LCD Angle
You can tilt the LCD to achieve the optimum viewing angle. The angle can be adjusted within 45
degrees up/down.
Adjust the tilt of the LCD for your convenience.
CAUTION:
⦁
Do not put sharp objects on the surface of the LCD, and never spray cleaner directly onto the display.
⦁
Do not pull the display beyond the maximum tilt angle, and do not apply excessive pressure to the display.

10
Installation
Connecting Peripherals
Removing the I/O port cover
Using your ngers, push and hold the two points marked PUSH on the I/O port cover, then slide the
cover up.

Installation
| Connecting Peripherals 11
Removing the stand’s rear cover
Hold the lower side of the stand’s rear cover and pull it away from the stand.
Connecting peripheral devices

Installation
| Connecting Peripherals 12
Connecting the power cord
Plug the power cord into the power jack on the I/O panel and then plug the other end of the power
cord into an appropriately grounded electrical outlet.
Replacing the I/O port cover
1.
Make sure that all of the connected cables are arranged through the cable hole position of the
I/O port cover so that they will not be pinched when you replace the cover.
2.
Align the I/O port cover, then rmly slide the I/O port cover down.

Installation
| Connecting Peripherals 13
Replacing the stand’s rear cover
1.
Make sure that all cables are arranged inside the cable path of the stand so that they will not be
pinched when you close the stand’s rear cover.
2.
Align the two latch pins on the upper side of the cover with the stand latch holes, and press the
lower side of the cover rmly into place.

Installation
| Installing Optional Devices 14
Installing Optional Devices
Card reader (IC & MSR)
Installing the card reader
To install the card reader, follow these steps:
1.
Place the touch LCD panel side down on a soft, at surface. (Be careful not to damage the touch
LCD panel.)
2.
To remove the dummy cover, press the marked point and slide the dummy cover slightly, and
then lift it up.
3.
Connect the RJ-45 cable of the card reader to the main board.

Installation
| Installing Optional Devices 15
4.
Align the two latch pins on the card reader with the back cover holes and press the card reader
down rmly into place.
5.
Tighten the two screws.
Removing the card reader
You can remove the card reader by following the steps in the installation procedure in reverse order.

Installation
| Installing Optional Devices 16
VFD
Installing the VFD
To install the VFD, follow these steps:
1.
Remove the I/O port cover by following the instructions in “Removing the I/O port cover“ on
page 10.
2.
Detach the plate on the I/O port cover to make space for installing the VFD.
NOTE:
⦁
Completely remove the plate, ensuring that no sharp parts remain. There is the risk of injuring yourself if the
sharp edges are not completely removed.
3.
Place the VFD and tighten it with two thumbscrews.

Installation
| Installing Optional Devices 17
4.
Connect the RJ-45 cable of the VFD to the COM3 port.
5.
Replace the I/O port cover by following the instructions in “Replacing the I/O port cover“ on
page 12.
6.
After installing the VFD, change the BIOS setting by following the instructions in “Setting Up the
VFD“ on page 44.
Removing the VFD
You can remove the VFD by following the steps in the installation procedure in reverse order.
LCD Customer Display
Installing the LCD Customer Display
To assemble the LCD customer display, follow these steps:
1.
Remove the I/O port cover by following the instructions in “Removing the I/O port cover“ on
page 10.

Installation
| Installing Optional Devices 18
2.
Detach the plate on the I/O port cover to make space for installing the LCD customer display.
NOTE:
⦁
Completely remove the plate, ensuring that no sharp parts remain. There is the risk of injuring yourself if the
sharp edges are not completely removed.
3.
Place the LCD customer display and tighten it with two thumbscrews.

Installation
| Installing Optional Devices 19
4.
Connect the power cable of the LCD customer display to the power (12V DC-OUT) jack.
5.
Connect the VGA cable of the LCD customer display to the VGA port.
6.
Replace the I/O port cover by following the instructions in “Replacing the I/O port cover“ on
page 12.
Removing the LCD Customer Display
You can remove the LCD customer display by following the steps in the installation procedure in
reverse order.

Installation
| Installing Optional Devices 20
COM and SATA sub-board
Installing the COM and SATA sub-board
To install the COM and SATA sub-board, follow these steps:
1.
Remove the system cover by following the instructions in “➊Removing the cover“ on page 22.
2.
Connect the COM and SATA sub-board to the COM and SATA header on the main board, and
tighten the two screws.
3.
Replace the system cover by following the instructions for removal in reverse order.
Removing the COM and SATA sub-board
You can remove the COM and SATA sub-board by following the steps in the installation procedure in
reverse order.
