Oldcastle Anchor Block Weston Stone User manual

See back for assembly instructions
Weston StoneTM Fire Pit Kit
with Insert
Rules for Safe Operation:
Read and understand before assembly and use of fire pit
• Always use in accordance with all applicable
local and state fire codes
• Failure to follow these instructions could result
in a hazardous fire causing property damage or
physical injury
• Caution: For outdoor use only
• Use the fire ring on stone, dirt or sand surfaces
• For adult use only — do not allow children to use
the fire ring
• Do not use on lawns, wooden decks, concrete
or asphalt
• Do not use fire ring indoors or under a patio roof
• Do not use in windy conditions
• Do not leave fire unattended at any time
• Do not use under tree branches, trellis, or
overhangs of any kind, including covered porches
• Do not use flammable liquids such as gasoline,
alcohol, diesel fuel, kerosene, or charcoal
lighter fluid to light or relight fires as this
may also cause paint to flake o fire ring
• Care should be taken to make sure all
combustible material is far enough away from
the fire ring not to ignite it
• Avoid using softwoods such as pine or cedar
because they are likely to throw sparks —
hardwoods are recommended
• Keep children and pets away from the fire ring
while it is in use
• Exercise the same precautions you would with
any open fire
• Do not wear flammable or loose clothing when
tending an open fire
• Avoid touching surfaces as they will be
extremely hot
• Assure the fire is completely extinguished before
leaving fire ring
• Any modifications to this appliance may be
dangerous and are not permitted
• Tape Measure
• Marking Paint (for yards)
• Chalk (for marking patios)
• Shovel
• Garden Rake
• Level
Materials Needed:
• Paver Base
• Tamper
• Rubber Mallet
• Concrete Adhesive
• Caulking Gun
• Lava Rock

1. If putting your fire pit on a lawn,
mark a 53-inch diameter circle and
remove all sod and roots inside the
circle. Dig approximately 2 inches
deep. If putting your fire pit on a
patio, mark the circle with chalk and
skip ahead to step 4.
2. Check the level of the soil inside
the circle in all directions. Remove soil
from the high spots to bring it close
to level.
3. Add 1.5-2 inches of paver base to
your circle and rake it level. Using a
tamper, pack the entire area of paver
base until firm. Make sure the surface
is level before laying blocks.
4. Place 19 wall block units on top of
paver base. Lay them tightly together
to form the circle. Level each stone
front-to-back and side-to-side. Make
sure each stone is even with the
previously leveled block. Use a rubber
mallet to level.
5. After the 1st course is set and
leveled, start the 2nd course by
placing the center of the top block
in alignment with the joint between
the blocks below. Continue this all the
way around the circle.
6. Once the 2nd course is all lined
up, carefully remove one block at a
time and apply two thick beads of
concrete adhesive to the center of the
blocks. Reinstall the block and push
down firmly. Continue for all remaining
blocks on 2nd course.
s
© 2018 Anchor Block, 5909 Baker Road, Suite 550, Minnetonka MN, 55345
01/18
7. After the 2nd layer is finished,
install the 3rd by placing the center of
each block in line with the joint of the
blocks below. When the 3rd course is
all lined up, glue the blocks one-at-a-
time as in step 6.
8. Next, lower the fire pit liner inside
the blocks. The outside flange of the
liner should be centered and rest on
the inside edge of wall block units.
9. After the adhesive cure time has
lapsed, pour lava rock into the fire pit
until the level reaches the bottom of
the fire ring liner.
s
Weston Stone™Fire Pit Kit with Insert Assembly Instructions
Always use in accordance with all applicable local and state fire codes
