OLDE MIDWAY PRO18 User manual

PRO18
PRO30
HOT DOG ROLLER
INSTRUCTION MANUAL

2
WARNING
Misuse of this machine may results in serious injury or death.
Please read and follow all precautions below.
This machine is not a toy and is intended for adult use only.
Do not use the machine for other than its intended purpose. Do not modify.
Under no circumstances should the machine be used on an ungrounded outlet.
Do not clean with detergent or abrasive chemicals. Do not immerse in water.
Take proper safety precautions when using this machine.
Do not touch moving parts. Keep body, hair, jewelry, clothes, .etc away from
machine when in use.
Use only 3-prong grounded extension cords that meet or exceed the electrical
rating.
Always switch power off on machine before unplugging from outlet.
SPECIFICATIONS
Model
Temperature
Electric Voltage
Rollers
PRO18
0-250 °
120V
7
PRO30
0-250 °
120V
11

3
PARTS & WIRING DIAGRAM
Glass Shield Parts List
Hotdog Roller Components
Circuit Diagram

4
INSPECT ALL COMPONENTS BEFORE USE.
DO NOT ATTEMPT TO USE THE HOTDOG ROLLER
MACHINE IF ANY PARTS ARE DAMAGED OR MISSING.
1. Locate and remove the pair of screws on the inner left and right sides of
the roller base and set aside.
2. Position the back glass mount onto the roller base. Reinsert the screws
removed in step 1 and hand-tighten as it may need to be adjusted. Repeat
for the remaining 3 mounts.
3. Insert one of the small side glass panels into both the front and back
mounts on one side of the machine with the curved side of the glass facing
the back (away from the controls). If needed, adjust mounts by sliding
forward or backward until the glass is snug; tighten screws to secure.
Repeat for the other side.
4. Place the large curved glass shield into the back mounts pushing gently
all the way down into the channel. Check to make sure the edges of the top
and side glass pieces are flush.
5. Place the stainless steel trim plate over the edge of the top class,
aligning the holes with the glass.
6. Insert a bolt through the trim plate and glass, then secure with nut. DO
NOT OVERTIGHTEN as this may crack the glass.
ASSEMBLY INSTRUCTIONS

5
OPERATION INSTRUCTIONS
1. Before the first use, apply a small amount of vegetable oil onto the surface
of the rollers. Press the power switch ON. The indicator light will glow when the
machine has power and will turn off when the set temperature has been
reached. Note: The machine will become hot very quickly.
2. Adjust the temperature controllers. We recommend using lower
temperatures until you understand the cooking times.
PRO18 (7 rollers) FRONT dial controls front 4 rollers - BACK dial controls the rear 3.
PRO30 (11 rollers) FRONT dial controls front 6 rollers - BACK controls the rear 5.
3. ATTENTION: Rollers are hot –DO NOT TOUCH!
Place hot dog between the rollers using tongs or
other utensil.
4. After approximately 15 minutes the hot dog should be ready to eat
depending on the cooking temperature, diameter of the hot dog and starting
temperature (frozen hot dogs may take longer).
5. Remove the hot dogs using tongs or other utensil. DO NOT USE HANDS.
6. Press the power switch OFF.
7. Unplug from wall outlet and allow cooling completely before touching.
1. Wipe down rollers and removable drip try with a damp soft cloth. Do not
immerse or use excess water. Do not use abrasive cleaners or metal scrubbers
on any part of surface.
2. Allow to dry completely before storing.
CLEANING & MAINTENANCE
PRO18 –Maximum 18 hot dogs.
PRO30 –Maximum 30 hot dogs.
