Olimpia electronics RT-52/HACCP User manual

WALL MOUNTING ELECTRIC INSECTICIDES WITH GLUE TRAP
HACCP Certification
The above products are designed based on Hazard Analysis
Critical Control Points (HACCP), in order to be appropriate
for placement in storage space, processing and food
distribution.
They have a special adhesive surface that prevents
scattering of trapped insects, as well as lamps with a special
film that does not shattered in case the trap falls.
ΙΝ GENERAL
Electric insecticides are used to exterminate various insects.
They use special fluorescent tubes
RT-
52/HACCP and RT-62/HACCP are produced according to
HACCP regulations .One glue trap is included in the
packaging of the electric insecticide.
/HACCP
18
220-240VAC.
/HACCP
36
220-240VAC.
Spare Parts- Replacements
- Á1066. A package that contains 6
replacement glue traps for RT
52/HACCP and RT-62/HACCP.
- Á1068. A package that contains 12
replacement glue traps suitable for
RT-52/HACCP and RT-62/HACCP.
- A1056. External metallic protection grid.
(1 for RT-52/HACCP and 2 for
RT-62/HACCP)
(Black Light) to attract the
insects from a distance. They can be used in any areas
where there are many insects. A special glue trap within the
insecticide in used to trap the insects. If they are placed
outdoor then a special external metallic grid is available to
protect birds that might happen to come near the trap. These
traps protect us from all kinds of insects (mosquitoes, gnats,
flies, e.t.c) without using any chemicals. The insecticides are
mounted high above the floor level and in a clearly visible
place in order to attract the insects more easily. The
RT-52 . This model uses a special glue trap for
insects and incorporates two
2 x W special fluorescent tubes (blacklight) placed in the
front of the glue trap. The device is powered by a voltage of
RT-60 . This model uses a special glue trap for
insects and incorporates two
2 x W special fluorescent tubes (blacklight) placed in the
front of the glue trap. The device is powered by a voltage of
925062000_09_006
RT-52/HACCP RT-62/HACCP
TECHNICAL CHARACTERISTICS
OPERATION TEMPERATURE RANGE
RELATIVE HUMIDITY
CONSTRUCTION MATERIALS
DIMENSIONS
TYPICAL WEIGHT
GUARANTEE
OPERATION VOLTAGE
CONSUMPTION
DEGREES OF COVER PROTECTION
PRODUCED IN ACCORDANCE WITH
LAMPS
220-240V AC/50-60Hz
IP 20
2x18W 2x36W
147VA 167VA
EN 60335-1, EN 60335-2-59
0 to 60 C
o
Up to 95%
Aluminum, ABS self extinguished
2 years (1 year for the lamp)
8360kgr.5780kgr.
68 x 40 x 10 mm 127 x 40 x 10 mm
Changing the lamp
If the lamp must be changed then follow the procedure bellow:
1. Remove the power plug from the wall
outlet.
2. Replace the lamp which is not operating,
with a suitable type.
3. Insert the power plug into the wall outlet.
The lamp type used are :SYLVANIA type T12 F18W/BL350S
for RT-52/HACCP and T8 F36W / BL368FEP for
RT-62/HACCP.
Maintenance
The glue must be replaced once a month for maximum
efficiency of the insect trap.
In periods where high quantities of insects are observed or if
the insect trap has been installed in areas with high levels of
dust then the glue trap must be checked more frequently. If the
surface of the glue is covered with dust or insects then it must
be replaced.
Page 1 from 2
Thank you for your trust in our products
Olympia Electronics - European manufacturer

Page 2 from 2925062000_09_006
Flange
Lamp protector
Retaining ring with internal threading
Cap with internal threading
Lamp
Threading
Internal threading
used to tighten the cap
Hanging form
the ceiling
Mounting holes
WARNING!!!
- The device is suitable for internal installation or for external
but in places that covered.
- The device must be kept away from children.
- The device must not be used in area that contain flammable
gases or explosive dust.
- If the power cable of the device is worn then it must be repaired
by OLYMPIA ELECTRONICS SERVICE department.
WARRANTY
Olympia Electronics guarantees the quality, condition and operation of the goods. The period of warranty is specified in the official catalogue of
Olympia Electronics and also in the technical leaflet, which accompanies each product. This warranty ceases to exist if the buyer does not follow
the technical instructions included in official documents given by Olympia Electronics or if the buyer modifies the goods provided or has any
repairs or re-setting done by a third party, unless Olympia Electronics has fully agreed to them in writing. Products that have been damaged can
be returned to the premises of our company for repair or replacement, as long as the warranty period is valid.
Olympia Electronics reserves the right to repair or to replace the returned goods and to or not charge the buyer depending on the reason of
defection. Olympia Electronics reserves the right to charge or not the buyer the transportation cost.
