Olmo OSH-07FRH2 User manual

REMOTE CONTROLLER
USER’S MANUAL
EN
EDGE Inverter NEW
Series
OSH-07FRH2
OSH-09FRH2
OSH-12FRH2
OSH-18FRH2
OSH-24FRH2
Thank you very much for purchasing this Air Conditioner. Please read this instructions
carefully before using this appliance and keep this manual for future reference.

Remote controller 1
Operation instructions
Operation modes 3
Airflow direction control 4
SUPER mode 5
QUIET mode
CLEAN mode
5
11
TIMER OFF mode
TIMER ON mode
LOCK mode
8
11
8
SMART mode 6
SLEEP mode
IFEEL mode
8°CHEAT mode
9
10
10
ECONOMY mode 7
DIMMER button
Power control mode
7
7
Remote controller Instructions

ON
OFF
8
Remote controller
1
Indication symbols on LCD:
Note: Each mode and relevant function will be further specified in following pages.
Signal transmit
Dry indicator
Fan only indicator
Heating indicator
8℃Heat indicator
Cooling indicator
5 fan speed
3 fan speed
Display temperature
Display set timer
Auto fan speed
ON
OFF
4 fan speed
2 fan speed
1 fan speed Ifeel
Smart indicator
Super indicator
Quiet indicator
Economy indicator
Sleep 4 indicator
Sleep 3 indicatorSleep 2 indicatorSleep 1 indicator
The remote controller transmits signals to the system.
FAN SPEED
Used to select fan speed in sequence auto,
higher,high, medium low or lower.
SLEEP
Used to set or cancel Sleep Mode operation.
SMART(invalid for
some models)
Used to enter fuzzy logic operation directly,
regardless of the unit is on or off.
POWER
The appliance will be started when it is
energized or will be stopped when it is
in operation, if you press this button.
MODE
Press this button to select the operation mode.
Remote controller
5
TEMP
Used to adjust the room temperature and
the timer, also real time.
SWING
Used to stop or start vertical adjustment
louver swinging and set the desired up/
down airflow direction.
SWING(invalid for
some models)
Used to stop or start Horizontal adjustment
louver swinging and set the desired left/right
airflow direction.
(invalid for
some models)
QUIET
Used to set or cancel Quiet Mode operation.
Press this button for about 5 seconds to set
or cancel IFEEL mode
(invalid for
some models)
ECONOMY
Used to set or cancel Economy Mode
operation.
SUPER
TIMER ON/OFF
Used to set or cancel the timer operation.
DIMMER
When you press this button, all the display
of indoor unit will be closed. Press any
button to resume display.
(invalid for
some models)
Lock indicator
When in Cooling mode (except Super mode),
press this button for about 5 seconds once
to start Power control mode ,press this
button for about 5 seconds once again to
stop it
Used to start or stop LOCK mode.
Used to start or stop mode.8°C HEATING
LOCK (optional)
8°C HEATING
+
+
Power control indicator
Battery power indicator Clean indicator
Used to start or stop the fast cooling/ fast heating.
Press this button about 5 seconds to enter the
auto-clean mode.
删除 内容
ON
OFF
8

Remote controller
2
How to Insert the Batteries
Battery cover
Storage and Tips for Using the Remote Controller
The remote controller may be stored mounted on a wall with a holder.
Note: The remote controller holder is an optional part.
To operate the room air conditioner, aim the remote controller
to the signal receptor.The remote controller will operate the air
conditioner at a distance of up to 7m when pointing at signal
receptor of indoor unit.
Remote controller
Note:
Use 2 LR03 AAA(1.5volt) batteries. Do not use rechargeable batteries. Replace batteries with new ones of the same type
when the display becomes dim.
Signal receptor
Remove the battery cover according to the arrow direction.
Insert new batteries making sure that the (+) and (-) of battery are matched correctly.
Reattach the cover by sliding it back into position.
1.
2.
3.
1 2 3
How to Use
CAUTIONS
For appropriate signal transmission between remote controller and
indoor unit, keep the signal receiver away from the following items:
 Direct sunlight or other strong lights or heat
 Flat panel television screen or other electrical appliances that
react to the remote controller
Additionally, the air conditioner will not operate if curtains, doors or
other materials block the signals from the remote controller to the
indoor unit. If the signal may not be transmitted properly, either move
these materials or consult your local dealer.
The picture shows the installation instructions, the appearance of the remote controller and other parts is subject to the
actual product.
ON
OFF
ON
OFF
ON
OFF
ON
OFF

OFF
OFF
Operation instructions
The operation modes change in sequence:
The fan speed is changed in sequence:
Selecting mode
FAN mode
Heating mode is not available for cooling only air conditioner.
At FAN ONLY mode, "Auto" is not available.
At DRY mode, Fan speed is set at "AUTO” automatically, "FAN SPEED" button
is ineffective in this case.
Setting temperature
Turning on
Changing modes during operation, sometimes the unit does not response at once. Wait 3 minutes.
Wait 3 minutes before restarting the appliance.
During heating operation, air flow is not discharged at the beginning. After 2－5 minutes, the air flow will be discharged
until temperature of indoor heat exchanger rises.
3
Operation modes
Press button once
Press button .
Result :
Result :
Press button once by once
Press button once by once
Auto 54321
HEATING
COOLING
DRY
FAN ONLY
Raise temperature setting by 1℃ or 1°F
Lower temperature setting by 1℃ or 1°F
Press button once
Result :
Result :
T he RUN indicator of the indoor unit lights up.
Result :
PRESS
PRESS
16℃~30 61℃( °F~86°F)
Range of available set temperature
*HEATING, COOLING
DRY -7 ~ 7
unable to set
FAN ONLY
* Note: Press and hold “ ” button and “ ” button together for about 2 seconds will alternate the temperature display between
the ℃ and °F scale.
* Note: Heating mode is NOT available for cooling only models.
* Note: At Dry mode, a decrease or rise of up to 7 ℃ can be set with Remote controller if you still feel uncomfortable.
* Note: At FAN ONLY mode, setting temperature is not available.
When the remote controller turns on,
functions can be operated. T
except the CLEAN and the TIME ON function, all the other
he operation modes refer to below.

Operation instructions
Vertical airflow(Horizontal airflow) is automatically adjusted to
a certain angle in accordance with the operation mode after
turning on the unit.
The direction of airflow can be also adjusted to your own requirement by pressing the " "
button of the remote controller.
Operation mode
Direction of airflow
COOLING, DRY
*HEATING,
FAN ONLY
horizontal
Horizontal airflow control
Vertical airflow control
downward
Using remote controller to set various angles of flow or specific angle as you like.
Do not turn the vertical adjustment louvers manually, otherwise malfunction may occur. If that happens, turn off the
unit first and cut off the power supply, then restore power supply again.
It is better not to let the vertical adjustment louver tilt downward for a long time at COOLING or DRY mode to prevent
condensed water from dripping.
* Note: Heating mode is only available for heat pump models.
Airflow direction control (invalid for some models)
Press " " button once.
Press " " button again .
A
B
The louvers swing to a suitable angle as desired.
The vertical adjustment louver will swing up and down automatically.Result :
Result :
Vertical airflow control (with the remote controller)
4
Using remote controller to set various angles of flow or specific angle as you like.
Press " " button once.
Press " " button again .
The horizontal adjustment louver will swing left and right automatically.
The louvers swing to a suitable angle as desired.
Result :
Result :
Horizontal airflow control (with the remote controller)
Note: If the unit doesn’t have four ways airflow function, you can adjust
horizontal airflow by yourself. (invalid for some models)
PRESS
PRESS
PRESS
PRESS

Operation instructions
SUPER mode can be set when the appliance is in operation .or energized
Note:
* SMART and buttons are not available in SUPER mode.
* SUPER button is not available in mode.
* The Appliance will continue working in SUPER mode, if you don't escape from it by pressing any of the buttons
mentioned above.
*
ECONOMY
ECONOMY
Heating is not available for cooling only air conditioner.
SUPER mode
SUPER mode is used to start or stop fast cooling or heating. I n SUPER mode, the super indicator will
display on LCD.
How to set SUPER mode?
Press button at the cooling, dry or fan only mode.
Result : At 5 fan speed ,the set temperature
automatically to 16℃.(61°F)
Press button at the heat mode.
Result : At auto fan speed ,the set temperature
automatically to 30℃.(86°F)
How to cancel SUPER mode?
5
Press . SUPER , ON/OFF, FAN SPEED, MODE, SLEEP or QUIET button
Result : The display return to the original mode.
In SUPER mode, you can set temperature, airflow direction or timer.
Escape from SUPER mode.
PRESS
PRESS
Cancel
QUIET mode (invalid for some models)
In this mode, the air conditioner will work with low noise performance.
In this mode, you can start the SLEEP mode at the same time.
Note:
* Press MODE, FAN SPEED, SMART or SUPER button to cancel QUIET mode.
* QUIET button is only available in COOLING, HEATING and FAN ONLY mode.
PRESS
QUIET

Operation instructions
6
SMART mode( )invalid for some models
Heat pump models
T+3℃ or below(3°F)
Heat pump models
Cooling only models
Indoor temperature Target temperature
Below T-3℃(3°F) T
T
T
O(3°F)ver T+3℃
O(3°F)ver T+3℃
T-3℃T+3℃(3°F)≤ ≤ (3°F)
Tindoor
Operation mode
HEATING
FAN ONLY
COOLING
Indoor temperature Target temperature
T
T
Operation mode
FAN ONLY
COOLING
How to set SMART mode?
Press the button.
Result : Enter SMART mode(fuzzy logic operation)
directly regardless of the unit is on or off.
Temperature and fan speed are automatically
set based on the actual room temperature.
PRESS
Note: Temperature, airflow and direction are controlled automatically in SMART mode. However, For the on/off,
you can choose from -2 to 2, for the inverter you can choose from -7 to 7. if you still feel uncomfortable.
ECONOMY button is ineffective in SMART mode.
Press MODE button to cancel SMART mode.
For the split-type models, such as wall-mounted air conditioners and some floor-standing air conditioners,
their operation mode and set temperature should be determined based on the indoor temperature.
For commercial air conditioner products, such as cassette type air conditioners, duct type air conditioners,
ceiling & floor air conditioners and some floor-standing air conditioners, their operation mode should be
determined based on the difference between the indoor temperature and set temperature.
Indoor temperature Target temperature
21 70℃ or below( °F) 22℃(72°F)
26℃(79°F)Over 26℃(79°F)
21 (70°F-73°F)℃-23℃
23 (73°F-79°F)℃-26℃
Operation mode
HEATING
FAN ONLY
DRY
Room temperature
decrease 2 (3°F)℃ after
operate for 3 minutes
COOLING
Cooling only models
Indoor temperature Target temperature
23℃ or below(73°F)
26℃(79°F)
Over 26℃(79°F)
23 (73°F-79°F)℃-26℃
Operation mode
FAN ONLY
DRY
Room temperature
decrease 2 (3°F)℃ after
operate for 3 minutes
COOLING
Some models do not have the SMART mode. The SMART button is not available.
SMART button is ineffective in SUPER mode.

Operation instructions
Your feeling
What you can do in SMART mode?
Button Adjust
Uncomfortable because
of unsuitable air flow
volume.
Uncomfortable because
of unsuitable flow
direction.
7
SMART mode(invalid for some models)
How to cancel the SMART mode?
Press the button.
Result :
Indoor fan speed alternates among Auto, 5, 4, 3,
2 and 1 each time this button is pressed.
Press it once, the vertical adjustment louver(horizontal
adjustment louver) swings to change vertical airflow
direction(horizontal airflow direction). Press it again,
swings stops.
The SMART mode will be cancelled.
PRESS
PRESS
PRESS
ECONOMY mode (invalid for some models)
In this mode, the air conditioner will bring you energy saving performance by lower running currency.
DIMMER button (invalid for some models)
Power control mode
* When you press “ ” button, all the display of indoor unit will be
closed.
* Press any button to resume display.
* ECONOMY button is ineffective in SMART and SUPER mode.
* SMART and SUPER ECONOMY
* Press ON/OFF, MODE, TEMP ±, FAN SPEED, SLEEP, QUIET or ECONOMY
button to cancel ECONOMY mode.
buttons are not available in mode.
Note:
The operation modes changed in sequence:
. Power control mode is ineffective in SUPER or ECONOMY mode
When start the Power control mode, the fan will automatically enter low wind speed, but you can change the wind
speed by press the Fan button.
Except for the button of Swing, Dimmer, Ifeel, Timer , Fan, press the other buttons can exit the
Power control mode, and the indicator “ % ” will disappear.
Result :
When the in the press appliance Power control mode, button once by once
75%
55%
35%
When in Cooling mode, press button for about 5 seconds once to start Power control mode ( fan will run in low speed ), press this button for about
5 seconds once again to stop it.
PRESS

Operation instructions
TIMER OFF mode
It is convenient to set the timer off with TIMER button , and you can enjoy a good night sleep
8
Note: * indicates the set number.
Press the or button.
Once to increase or decrease the time setting by 1 hour.
A "beep" can be heard.
The TIMER indicator on the indoor unit lights up. (invalid
for some models)
“OFF *h" stops flashing.
When your desired time displayed on LCD, press the TIMER button and confirm it.
Result :
Result :
Press button.
Press the button again.
A "beep" can be heard and the indicator disappears,
the time on mode has been canceled.
Result :
How to cancel TIMER OFF?
How to set TIMER OFF?
Result : “OFF 0h" flashes on the LCD.
1.
2.
3.
PRESS
PRESS
PRESS
PRESS
PRESS
LOCK mode(optional)
How to set OCK ?L
How to cancel OCK ?L
P for 2 seconds moderess and .
The lock appears on the display
buttons together to start LOCK
indicator
P for 2 seconds moderess and .
The lock appears .
buttons together to stop LOCK
indicator dis
1
Press together
for 2 seconds
Press together
for 2 seconds
2
2
1
OFF
