INSTALLATION
Tools:
Adjustable Wrench Plumbers Putty Sealant Tape Rags
Model Number: P-2370T, P-2371T, P-2372T,
P-2374T, P-2375T (CP, BN)
Warnings and Notes:
Check with local plumbing code requirements before installation.
This product should be installed by a local listed plumber.
Do not use plumbers putty on threads.
OLYMPIA FAUCETS, INC.
Interchange City Distribution Center #20
1277 Heil Quaker Boulevard
La Vergne, TN 37086
(888) 772-7701
www.olympiafaucets.com
Installation Steps:
Single Handle Tub And Shower Trim Set
(1) For slip-t Installation:
The 1/2” nominal copper tube must be cut
with a minimum length of 1-1/2” to a maximum length of 3-5/8” and
2-5/8” minimum length to a maximum length of 4-7/8” for 7” extended
tub spout from nished face of tub or wall. Then end of copper tube
should be chamfered free of any burrs to prevent cutting or nicking
o-ring inside the spout. The outside surface may be sanded free from
nicks and scratches. Press and twist the spout over copper tube ush
with the nished tub or wall surface. Tighten the set screw, but do not
overtighten.
(2) For IPS Installation:- The 1/2” threaded pipe nipple must be kept with a
minimum length 1-1/8” to maximum length of 1-3/8” and minimum length
2-1/2” to maximum length of 2-13/16” for 7” extended tub spout from nished
face of tub or wall. Remove the octagonal nut inside the spout by using nose
pliers. Apply sealant tape at the threaded connection. Screw tub spout onto
the threaded pipe nipple and tighten by strap wrench.
3) Caution: To avoid plugging the showerhead spray outlet use sealant tape
on the shower arm threads. Remove temporary nipple from the shower
elbow. Use silicon to caulk the back of the shower arm ange. Slide the
shower arm ange over the shower arm. Apply the sealant tape on the both
threaded ends of shower arm and install the shower arm to the shower
elbow. Carefully tighten with a clean strap wrench. Press the shower arm
ange against the nished wall. Flush out the system. Thread the shower-
head to the shower arm.
(4) Slide the face plate on the valve. Secure the face plate with the help of
face plate screws. Use silicon to caulk around the face plate. Tighten the set
screw on the bottom of handle with help of 3/32” Allen wrench to secure the
handle on the valve.
