Olympus WM-DP1 User manual

INSTRUCTIONS
MOBILE WORKSTATION
WM-DP1

WM-DP1 MOBILE WORKSTATION
1
Contents
Important Information — Please Read Before Use. . . . . . . . . . . . . . . 2
Intended use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Instruction manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Signal words . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Chapter 1 Standard Set and Accessories . . . . . . . . . . . . . . . . . . . 3
1.1 Optional accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Chapter 2 Warnings and Cautions . . . . . . . . . . . . . . . . . . . . . . . . 5
Chapter 3 Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Chapter 4 Preparation for Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.1 General information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4.2 Shelf positions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.3 Remote switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.4 Equipment installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.5 Cable hanger and blanking caps. . . . . . . . . . . . . . . . . . . . . . 16
4.6 Water container holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.7 Rear panels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.8 Fitting the MAJ-181 restrictor . . . . . . . . . . . . . . . . . . . . . . . . 18
Chapter 5 Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Chapter 6 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6.1 Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6.2 Manoeuvring and Transportation . . . . . . . . . . . . . . . . . . . . . 24
Chapter 7 Care, Storage and Maintenance . . . . . . . . . . . . . . . . . . 26
7.1 Care. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
7.2 Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
7.3 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Chapter 8 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
8.1 WM-DP1 mobile workstation. . . . . . . . . . . . . . . . . . . . . . . . . 28
8.2 Separation transformer (WM-T1) . . . . . . . . . . . . . . . . . . . . . 28
Chapter 9 Spares . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Chapter 10 Technical Description . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Chapter 11 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Chapter 12 End of Life . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Important Information — Please Read Before Use
MOBILE WORKSTATION WM-DP1 2
Important Information — Please Read Before Use
Intended use
The Olympus WM-DP1 mobile workstation is intended for use in medical facilities
under the direction of a trained physician, and has been designed to be used with
a range of Olympus equipment to facilitate GI endoscopy, endoscopic
ultrasound, respiratory and surgical endoscopic procedures. Do not use the
equipment for any purpose other than its intended application.
The safety and performance of an endoscopic system depends not only on the
endoscope but also on the ancillary equipment used with it. Ensure any ancillary
equipment is compatible with the endoscope and other equipment used.
Instruction manual
Please read this manual carefully before attempting to use the Olympus
WM-DP1 mobile workstation as it contains important information on the proper
care, handling and use of the equipment. In addition, read the manuals of any
other units (light source, endoscope, etc.) that form part of the system.
If you have any questions or comments regarding the information in this manual,
please contact Olympus. These instructions should be retained for reference
during the life of the product.
Signal words
The following signal words are used throughout this manual:
WARNING
Indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury. It may also be used to alert against
unsafe practices or potential equipment damage.
NOTE
Indicates additional helpful information.

Standard Set and Accessories
MOBILE WORKSTATION WM-DP1
3
Chapter 1 Standard Set and Accessories
Please refer to the standard set below and check that all items are present. Contact Olympus
if any parts are damaged or missing. Workstations that are fitted with antistatic castors can
be identified by the following label affixed to the rear of each shelf.
1
Contents Qty
1 WM-DP1 mobile workstation (includes separation transformer) 1
2 Rear panel - narrow 1
3 Rear panel - wide 1
4 Blister pack 1
Blanking cap (cable port, 2pcs)
Blanking cap (monitor port, 2pcs)
Blanking cap (scope pole, 2pcs)
L-wrench ball driver 6mm A/F, 1 piece
Cable tie, 6 pcs
5 Blister pack 1
Blanking cap (cable port, 2pcs)
Blanking cap (monitor port, 1 piece)
6 Instruction manual 1
7 Cable hanger 2
8 Universal IEC cable 2.5m 4
Universal IEC cable 1.5m 4
9 IEC adaptor cable (USA only) 2
10 MAJ-181 restrictor assembly 2
INSTRUCTIONS
4
7
6
5
9
23
810

Standard Set and Accessories
MOBILE WORKSTATION WM-DP1 4
1.1 Optional accessories
The following items are available as optional accessories. Each accessory is supplied
complete with the necessary fixings, tools and instructions to enable assembly to the mobile
workstation.
compatible – incompatible
CAUTION
Do not attempt to install any other accessories on the WM-DP1.
Recommended use
Description Ref No. GI SP EUS
14” CRT Platform WM-NP1 MAJ-1620 
20” CRT Platform WM-NP1 MAJ-1621 
Cable retaining hook MAJ-195 
CO2cylinder bracket kit large MAJ-188 – –
CO2cylinder bracket kit small MAJ-1614 – –
Drawer pack narrow deep MAJ-194 
Drawer pack narrow standard MAJ-193 
Drawer pack wide deep MAJ-1612 
Drawer pack wide standard MAJ-1611 
ECS cable kit 10m MAJ-186 –
ECS cable kit 15m MAJ-1616 –
Equipment support rail MAJ-190 
EU-C60/2000 shelf kit MAJ-1627 – – 
EUS Arm Mount Kit WM-P1 MAJ-1626 – – 
IV pole kit MAJ-187 – –
Keyboard arm side mounted MAJ-180  –
Keyboard tray sliding MAJ-179 
EU-M30 Keyboard Tray MAJ-1625 – – 
LCD handle MAJ-1610 
LCD monitor arm MAJ-181 
Nurse’s control panel arm (long) MAJ-1628 
Nurse’s control panel arm (short) MAJ-1624 – – 
Scope pole kit MAJ-183 
Shelf kit narrow MAJ-198 
Shelf kit wide MAJ-199 
Universal display arm CRT MAJ-1613 – – 
Universal stowage container MAJ-185 
Videoscope cable holder MAJ-1630 

Warnings and Cautions
MOBILE WORKSTATION WM-DP1
5
Chapter 2 Warnings and Cautions
WARNING
• The WM-DP1 mobile workstation should only be used in a medical
facility under the direction of a trained physician.
• Explosion hazard - never install or use the WM-DP1 mobile workstation
within the zone of risk of flammable gases. If the workstation is fitted
with antistatic castors (see Chapter 8), none of the medical electrical
equipment with which the workstation is intended to be used is ‘AP’ or
‘APG’ rated, therefore never install or use the WM-P1 series mobile
workstation within the zone of risk of flammable gases.
• To prevent patient shock, the combination of equipment used on the
WM-DP1 mobile workstation should never be applied directly to the
heart.
• If the fuse holder cap on the transformer is not fitted correctly, there is a
possibility that the fuse holder will overheat. When replacing the fuse,
ensure the fuse holder cap (Figure 4.3) is tightened using a 6mm to
8mm flat bladed screwdriver. The recommended tightening torque is
0.5Nm.
• Should the equipment become soiled with blood or other potentially
infectious materials, first wipe off all gross debris and then
decontaminate the equipment using a surface disinfectant, otherwise,
blood, mucus and other potentially infectious material from the patient
could pose an infection risk. Confirm that the equipment is completely
dry before use.
• Use personal protective equipment to guard against dangerous
chemicals and potentially infectious material, otherwise, blood, mucus
and other potentially infectious material from the patient could pose an
infection risk. During cleaning, wear appropriate protective equipment,
such as eye wear, face mask, moisture-resistant clothing and chemical-
resistant gloves that fit properly and are long enough so that your skin is
not exposed.
• To prevent user or patient cross-contamination, do not hang
contaminated endoscopes on the scope hanger.
• The WM-DP1 should be used in accordance with the following.
Otherwise, the workstation will be ‘top heavy’ and may lose stability and
topple, causing equipment damage and/or personal injury.
- Two MAJ-181 restrictors are supplied which must be fitted to
MAJ-181 LCD monitor arm(s) if used (refer to section 4.8).
- LCD monitor arms and monitors should be installed after all
other equipment is installed on an appropriate place on the
workstation.
- LCD monitor arms should not be installed or used to the rear
of the workstation, see Figure 2.1.
- Confirm that the workstation does not lose stability when the
monitor arm is extended. If the workstation looks unstable,
relocate heavy equipment from the upper shelf to the bottom
shelf.

Warnings and Cautions
MOBILE WORKSTATION WM-DP1 6
• Thoroughly review the manuals of all other equipment which will be
used. The manuals contain essential information on using this
equipment safely and effectively.
CAUTION
• Do not exceed the load capacity detailed in Chapter 8.
• Do not lean or stand on any part of the mobile workstation or accessory
as failure of the product may result.
• When assembling equipment onto the mobile workstation, the
installation should meet the requirements of EN IEC 60601-1-1:2001,
the safety standard for medical electrical systems.
• When configuring a system, the user should ensure that there is
sufficient spare equipment available that in the event of a fault in any
part of the system, the endoscopy procedure may be completed or
terminated without endangering the patient.
• Before commissioning an installation including a separation transformer,
ensure its rating will not be exceeded by the equipment connected to it.
• When installing the mobile workstation in the procedure or operating
room, ensure that the mains cable has sufficient slack that it cannot be
pulled taught as the mobile workstation is moved around the working
area. If necessary, relocate the mains connector to a nearer supply
socket.
• Section 6.2 Manoeuvring and Transportation gives detailed instructions
and precautions which must be read and understood before attempting
to move the mobile workstation.
• Spray type medical agents, such as lubricants, anaesthetic or alcohol,
should be used away from the mobile workstation.
Figure 2.1
MAJ-181
(restrictor fitted)
MAJ-1624
or
MAJ-1628
Do not install or operate
LCD monitor arms in this zone

Warnings and Cautions
MOBILE WORKSTATION WM-DP1
7
• Keep open containers of liquid away from electrical equipment used on
the mobile workstation to prevent operator electrical shock and
equipment damage. Do not use the system if liquid has entered the
equipment.
• To minimise risk of injury, it is recommended that heavy items are placed
on the mobile workstation by two people working together. This is
particularly important when placing a monitor on the optional monitor
platform (if fitted). Ensure electrical items used on the mobile
workstation are positioned centrally on the shelves.
• Never place any items on top of a monitor (if fitted) as these may topple
when the mobile workstation is moved.
• Where fitted, the electrical resistance of the conductive antistatic castors
should be tested at regular intervals in accordance with ISO 2878 to
assess antistatic effectiveness.
• Where antistatic castors are fitted, avoid contact of the castor wheels
with oil and avoid a build up of floor cleaning wax and polish as these
will impair the antistatic effectiveness of the castors.
• Store and use the WM-DP1 mobile workstation within the environmental
conditions described in Chapter 8; failure to do so may lead to
equipment malfunction or failure.
• There are no operator-serviceable components on the WM-DP1 mobile
workstation. Refer servicing to qualified service personnel.
• To minimise the risk of injury and/or damage, do not fit accessories other
than those described in Section 1.1 to the WM-DP1 mobile workstation.

Symbols
MOBILE WORKSTATION WM-DP1 8
Chapter 3 Symbols
The following symbols are used on the separation transformer
NOTE
MAJ-175 (220-240V) is shown. Other versions are similar.
Refer to instructions Potential equalisation terminal
Input Output
Not exceeding Ta=40°C Maximum ambient
temperature
Standby position Fuse (output)
Output ON position Remote switch
Non-inherently short circuit
proof separation transformer Class B
Insulation temperature rating
of transformer according to
IEC 60085:2004
Unit complies with relevant
European directives
(MAJ-175 only)
Disposal conditions - see End
of Life (Chapter 12) (MAJ-175
only)
View of the separation transformer rear panel

Preparation for Use
MOBILE WORKSTATION WM-DP1
9
Chapter 4 Preparation for Use
NOTE
• Multiple fixing positions are provided enabling the shelves to be raised
or lowered to accommodate varying equipment configurations (see 4.2).
• The mobile workstation is designed for use with Olympus OEV LCD
monitors and other monitors that meet the VESA standard. Contact
Olympus regarding compatibility of other monitors.
4.1 General information
Installation of endoscopic video systems requires an understanding of EN IEC 60601-1-1:2001,
the international collateral standard for the safety of medical electrical systems.
This standard requires systems to meet the leakage current requirements of the general medical
electrical safety standard, EN IEC 60601-1, which allows a maximum earth leakage current of
0.5mA in normal condition.
A separation transformer is required under certain circumstances, as combined earth leakage
currents may result in excessive enclosure leakage current under single fault conditions, such as
the interruption of a common protective earth path.
In order to meet EN IEC 60601-1-1:2001, a separation transformer will be required in a system
under one of the following conditions:
(i) Ancillary equipment that does not meet the leakage current requirements of
EN IEC 60601-1 is used (or could be used) within the ‘patient environment’ (as defined
in EN IEC 60601-1-1:2001, that is within a 1.5m radius of, or 2.5m above, the patient
bed). The separation transformer must be used to supply the ancillary equipment, but
may also be used to supply medical electrical equipment, as long as the maximum
transformer rating is not exceeded.
(ii) The total earth leakage current from a combination of medical equipment is above
0.5mA. The separation transformer must be used to supply sufficient of the medical
electrical equipment to reduce the total system earth leakage current to below the above
limit, as long as the maximum transformer rating is not exceeded. High intensity light
sources use arc lamps, which require a high start-up current. It is not recommended for
these to be supplied from the isolation transformer, otherwise its maximum rating may be
exceeded. The transformer may also be used to supply ancillary equipment forming part
of the system as long as the maximum transformer rating is not exceeded.

Preparation for Use
MOBILE WORKSTATION WM-DP1 10
Some system installations, for instance those using two mobile workstations, may require two
separation transformers to be fitted.
NOTE
• The total impedance of the protective earth path for a system may be up
to 0.4
Ω or higher if the conditions of clause 18 g) of EN IEC 60601-1 are
satisfied.
• The power outlets should only be used for powering equipment which
forms part of the endoscopy imaging system.
• All equipment forming part of the system should be powered from the
transformer, unless appropriate isolation is employed as described in
Annex BBB of EN IEC 60601-1-1:2001. This particularly applies where
ancillary equipment as described in (i) forming part of the system is
remotely situated.
CAUTION
• Failure to observe either of the above mentioned points could result in
the isolation of the entire system being compromised, defeating the
protection provided by the transformer in a single fault condition.
Additional fixings are provided (Figure 4.1) to facilitate shelf adjustment or the fitting of the optional
drawer pack(s).

Preparation for Use
MOBILE WORKSTATION WM-DP1
11
Figure 4.1
318.00

Preparation for Use
MOBILE WORKSTATION WM-DP1 12
4.2 Shelf positions
NOTE
The WM-DP1 mobile workstation is supplied with the shelves fitted as
shown in Figure 4.1. It is recommended that shelves are repositioned, if
required, before commencing equipment installation as described
below.
1. Position the mobile workstation on a flat surface and apply both castor brakes (diagonally
opposed).
2. Referring to Figure 4.2, use the 6mm A/F L-wrench to remove the four M8 screws with
crinkle and plain washers from the underside of the shelf.
3. Locate the shelf at the new position and fit the four side fixing screws with crinkle and plain
washers. Tighten all screws using a 6mm A/F L-wrench. It is recommended that after fitting,
the screws are tightened to a torque of 10.5Nm (tool not provided).
Figure 4.2

Preparation for Use
MOBILE WORKSTATION WM-DP1
13
4.3 Remote switch
The remote switch enables the power to the system components to be controlled from a
single point. The switch is located beneath the top tray and connects to the remote switch
connector on the separation transformer via a 2m cable.
The remote switch has an integral two-colour LED which illuminates whenever the
transformer is connected to the mains supply. Yellow indicates ‘standby’, green indicates
‘output on’.
NOTE
• The remote switch only controls the output socket on the transformer. To
switch OFF the input power supply, set the remote switch to its
‘stand-by’ position, then disconnect the mains connector from the wall
outlet socket.
• In ‘stand-by’ condition, the transformer consumes a small amount of
power, typically 4% of its full load rating. If it is anticipated that the
system will not be used for a significant period of time, it is
recommended that the mains connector is removed from the wall outlet
socket to conserve energy.
1. The mobile workstation is supplied with the remote switch connected to the separation
transformer and no assembly is required. However, check the connection (see Figure 4.3) is
secure before completing full installation.
Figure 4.3
Potential
equalisation
terminals
Remote switch
connector
Fuse

Preparation for Use
MOBILE WORKSTATION WM-DP1 14
4.4 Equipment installation
refer to section 4.1for additional information regarding system installations.
CAUTION
• To minimise risk of injury, it is recommended that two people, working
together, place heavy items of equipment on the mobile workstation.
• High intensity light sources may need to be connected to a properly
grounded AC power outlet and not one of the IEC power sockets on the
mobile workstation, depending on the total system power rating.
• Ensure the fully installed system meets the requirements of
EN IEC 60601-1-1:2001, Medical Electrical Equipment, Collateral
Standard: Safety Requirements for Medical Electrical Systems. For
advice, contact your Olympus representative or qualified service
personnel.
NOTE
Releasable cable straps are provided on the rear of each shelf and
cable ties are provided to secure equipment power cables to the case of
the transformer. Cable access holes are provided in the base of the
mobile workstation. Excess lengths of cables should be coiled neatly
and secured to the rear of a shelf using the cable straps provided.
1. Place items of equipment centrally on the shelving and connect according to individual
instructions. The WM-DP1 mobile workstation is supplied with a universal IEC lead set to
connect equipment on the mobile workstation to the transformer. Potential equalisation
terminals are fitted to both sides of the transformer enclosure for connection to equipment
potential equalisation terminals where fitted. Route all cabling neatly in the side column cable
ducts on the extrusion and along the rear of the shelves, secure using the releasable cable
ties (see Figure 4.4).
Centre column cable ducts are used for interconnection of equipment located on the base,
intermediate and upper shelves.

Preparation for Use
MOBILE WORKSTATION WM-DP1
15
2. When all equipment is positioned on the workstation, install LCD monitor arms or control
panels as required according to their instructions and noting the configuration diagrams
given in Chapter 2 Warnings and Cautions.
MAJ-181 only: One MAJ-181 restrictor (supplied) must be fitted to each MAJ-181 being
fitted, up to a maximum of two. The restrictor provides additional stability by preventing the
monitor arm from swinging outside the footprint of the workstation. Refer to Section 4.8 for
assembly.
WARNING
Do not use the MAJ-181 LCD monitor arm on the workstation without a
restrictor fitted. Otherwise the workstation may lose stability and topple,
causing equipment damage and/or personal injury.
3. Check that all equipment power ON/OFF switches are in the OFF position and connect the
separation transformer (and light source, where separate) power supply cables to properly
grounded AC power outlets. The power outlets should be located such that they are not
obstructed when the mobile workstation is in its normal operating position. The remote switch
LED will illuminate yellow indicating ‘standby’.
4. Set the mobile workstation remote switch to the ON position, the LED will now illuminate
green indicating ‘output on’.
5. Set the power switches for the installed equipment to the ON position.
Figure 4.4
*****
*
*
*
*
*
*
* Denotes hidden cable ties

Preparation for Use
MOBILE WORKSTATION WM-DP1 16
CAUTION
• Check that all installed equipment operates correctly before using the
system ‘on patient’.
• The WM-T1 separation transformer incorporates a circuit to limit the
input current surge when power is applied. Operating an input power
ON/OFF switch several times in rapid succession may interfere with the
correct functioning of this circuit and may cause the mains power supply
protection to operate.
• Ensure that the video system centre is switched OFF when attaching or
removing the videoscope cable. Serious damage may result if the
videoscope is connected with the video system centre switched ON.
6. When equipment installation is complete, fit the rear door(s) taking care not to trap any
cables.
4.5 Cable hanger and blanking caps
NOTE
• If the cable hanger is not required, fit one blanking cap to the left hand
port in the top tray.
• Blanking caps are provided for each of the accessory fittings and cable
exits in the top tray. If accessories are fitted, the appropriate blanking
cap will not be required and should be stored in case of future use.
1. The blanking caps locate in the positions shown in Figure 4.5 and can be removed/fitted if
required.
2. The cable hanger locates into either left or right hand port in the top tray and is secured in the
required position using handwheel as shown in Figure 4.5.
Figure 4.5
Cable winder (or blanking cap, scope port if cable winder is not used)
Blanking cap, monitor port
Blanking cap, cable port
Handwheel

Preparation for Use
MOBILE WORKSTATION WM-DP1
17
4.6 Water container holder
1. The WM-DP1 mobile workstation is fitted with a water container bracket to hold two water
containers (not supplied). The water container simply clips onto the bracket as shown in
Figure 4.6.
4.7 Rear panels
1. When installation of equipment is complete, lift each rear panel in turn onto the locating studs
on the base of the workstation (Figure 4.7) then push the top of the panel until the latch
engages with an audible click.
Figure 4.6
Figure 4.7
Rear panel - wide
Rear panel - narrow

Preparation for Use
MOBILE WORKSTATION WM-DP1 18
4.8 Fitting the MAJ-181 restrictor
This procedure is only applicable if fitting a MAJ-181 LCD monitor arm to the WM-DP1 workstation.
WARNING
• If using a MAJ-181 on the workstation, the restrictor supplied in this kit
must be fitted to the MAJ-181 and is best assembled with the MAJ-181
in position on the workstation.
• To maintain stability, before installing a second MAJ-181, ensure the first
is assembled with the restrictor fitted.
• Read the instruction manual supplied with the MAJ-181, it contains
important information regarding proper care and use of the equipment.
• The WM-DP1 should be used in accordance with the following.
Otherwise, the workstation will be ‘top heavy’ and may lose stability and
topple, causing equipment damage and/or personal injury.
- Two MAJ-181 restrictors are supplied which must be fitted to
MAJ-181 LCD monitor arm(s) if used.
- LCD monitor arms and monitors should be installed after all
other equipment is installed on an appropriate place on the
workstation.
- LCD monitor arms should not be installed or used to the rear
of the workstation, see Figure 2.1.
- Confirm that the workstation does not lose stability when the
monitor arm is extended. If the workstation looks unstable,
relocate heavy equipment from the upper shelf to the bottom
shelf.
1. Referring to the MAJ-181 instruction manual, relocate the clamp support to another fixing
hole in the support tube (see Figure 4.8) as the restrictor will be fitted through the top hole,
then insert the MAJ-181 into the monitor port in the top tray of the workstation.

Preparation for Use
MOBILE WORKSTATION WM-DP1
19
2. Referring to Figure 4.9, pull out the finger grip on the lower index plunger and rotate it 90°,
the arm is now free to rotate. Rotate the arm until parallel with the top tray as shown.
3. Remove the M8 screw to separate the MAJ-181 restrictor assembly.
4. Referring to Figure 4.10, secure the MAJ-181 restrictor - front to the MAJ-181 restrictor - rear
through the uppermost hole in the monitor arm using the M8 coil washer, M8 plain washer
and M8 x 50mm screw. Fully tighten the screw using the M6 A/F Allen key supplied.
NOTE
The monitor arm must be parallel to the top tray to ensure the tag on the
monitor arm aligns with the cutout in the restrictor (Figure 4.10 inset).
Figure 4.8
Figure 4.9
to disengage
Rotate arm
MAJ-181 Index plunger
Top view
