Olympus WM-P1 Series Operating instructions

EKeyMed 2012
K 5070557
Issue 20
July 2012
MAINTENANCE & REPAIR MANUAL
WM--P1 SERIES MOBILE WORKSTATIONS
WM--NP1
WM--WP1
WM--DP1
117071, Moscow, Malaya Kaluzhskaya 19, bld. 1, fl.2, Russia
Fax: [phone] Telephone: [phone]
491B, River Valley Road #12-01/04, Valley Point Office Tower, Singapore 248373
Fax: [phone] Telephone: [phone]
(Premises/Goods delivery) Wendenstrasse 14-18, 20097 Hamburg, Germany
(Letters) Postfach 10 49 08, 20034 Hamburg, Germany
Fax: [phone] Telephone: [phone]
3500 Corporate Parkway, P.O. Box 610, Center Valley, PA
18034-0610, U.S.A.
Fax: [phone] Telephone: [phone]
31 Gilby Road, Mount Waverley, VIC., 3149, Australia
Fax: [phone] Telephone: [phone]
KEYMED LTD.
KeyMed House, Stock Road, Southend-on-Sea, Essex SS2 5QH, United Kingdom
Fax: [phone] Telephone: [phone]
2951 Ishikawa-cho, Hachioji-shi, Tokyo 192-8507, Japan
Fax: [phone] Telephone: [phone]
OLYMPUS MEDICAL SYSTEMS CORP.
OLYMPUS SINGAPORE PTE LTD.
OLYMPUS MOSCOW LIMITED LIABILITY COMPANY
OLYMPUS AUSTRALIA PTY. LTD.
OLYMPUS AMERICA INC.
OLYMPUS EUROPA HOLDING GMBH
OLYMPUS (BEIJING) SALES & SERVICE CO,. LTD.
A8F, Ping An International Financial Center, No. 1-3, Xinyuan South Road,
Chaoyang District, Beijing, 100027 P.R.C.
Fax: [phone] Telephone: [phone]
5301 Blue Lagoon Drive, Suite 290 Miami, FL 33126-2097, U.S.A.
Fax: [phone] Telephone: [phone]
OLYMPUS LATIN AMERICA INC.
OLYMPUS KOREA CO,. LTD.
Olympus-Tower, 114-9 Samseong-Dong, Gangnam-Gu, Seoul 135-090 Korea
Fax: [phone] Telephone: [phone]

Page2of 76
Issue 20 : July 2012
WM--P1 SERIES WORKSTATIONS
MAINTENANCE & REPAIR MANUAL
M- NP1 / WM- WP1 / WM- DP1 WORKSTATIONS
CHANGE OF ISSUE LOG
When an up--issued copy of this manual is received, record its receipt on this page.
A brief description of the change can be found on the last page of the manual : Summary of Change History.
Changes made to the current issue are highlighted in the manual by a vertical line in the right hand margin.
Each up--issued copy of the manual will include an up--issued copy of this page but it does not have to be retained unless needed as a
continuation sheet.
Date Issue
number of
manual
Signature Date Issue
number of
manual
Signature

Page3of 76
Issue 20 : July 2012
WM--P1 SERIES WORKSTATIONS
MAINTENANCE & REPAIR MANUAL
WM- NP1 / WM- WP1 WM- DP1
Manual Contents
Page
Preliminary Material
Title Page 1..................................................................
Change of issue log 2...........................................................
Manual Contents (this page) 3.....................................................
Chapters
1 Introduction 4.........................................................
2 General Information 6...................................................
3 Specifications 8.......................................................
4 Tools & Test Equipment 12...............................................
5 Test and Inspection 14..................................................
6 Part Replacement 16...................................................
7 Illustrated Parts List 27..................................................
8 Accessories Illustrated Parts List 39.........................................
Summary of Change History 76............................................

Page4of 76
Issue 20 : July 2012
WM--P1 SERIES WORKSTATIONS
Chapter 1 Introduction
Table of Contents
Page
Introduction 5.........................................................

Page5of 76
Issue 20 : July 2012
WM--P1 SERIES WORKSTATIONS
1INTRODUCTION
This Maintenance and Repair Manual has been produced by KeyMed to enable the repair and servicing of the Olympus WM--P1
series mobile workstation.
Although every effort has been made to ensure that this document is correct and complete, KeyMed cannot be held responsible
for the safety or reliability of any equipment which has been repaired other than by suitably qualified personnel. It is essential
that this manual is read and understood before commencing any work.
Should any additional information or advice be required, please contact:
Olympus KeyMed
Technical Services
Technical Support
KeyMed House
Stock Road
SOUTHEND--ON--SEA
Essex SS2 5QH
United Kingdom
Tel: [phone]
Fax: [phone]
Telex: 995283

Page6of 76
Issue 20 : July 2012
WM--P1 SERIES WORKSTATIONS
Chapter 2 General Information
Table of Contents
Page
General information 7...................................................

Page7of 76
Issue 20 : July 2012
WM--P1 SERIES WORKSTATIONS
2GENERAL INFORMATION
The Olympus WM--P1 series mobile workstation is intended for use in medical facilities under the direction of a trained
physician, and has been designed to accommodate the Olympus video system center and associated ancillary devices as a
practical mobile workstation to facilitate GI endoscopy, endoscopic ultrasound, respiratory and surgical endoscopic procedures.
Olympus will not be responsible for damage or injury to equipment or personnel, caused by unauthorised modification or repair
to this unit.
Maintenance
In the interest of safety and good maintenance, ensure that all fixings are secure. It is recommended that the security fixing
torques of the monitor platform, shelf’s, castors and side column fixings specified in the illustrated parts list, are checked every
six months.

Page8of 76
Issue 20 : July 2012
WM--P1 SERIES WORKSTATIONS
Chapter 3 Specifications
Table of Contents
Page
3.1 WM--NP1 / WM--WP1 series mobile workstations 9..............................
3.2 WM--DP1 series mobile workstations 10......................................
3.3 WM--T1 series separation transformers 10....................................

Page9of 76
Issue 20 : July 2012
WM--P1 SERIES WORKSTATIONS
3SPECIFICATIONS
3.1 WM- NP1 / WM- WP1 series mobile workstations
Product name WM--NP1 / WM--WP1 mobile workstation
Dimensions (mm) Height: 1370 (scope in lowest position)
2140 (scope in highest position)
1160 (to top tray)
1826 max (with 19” LCD monitor in highest position)
Depth: 650
Width: 645 (WM--NP1) 795 (WM--WP1)
Weight 85kg (WM--NP1) 90kg (WM--WP1) unladen, including fitted transformer.
Load capacity
(evenly distributed)
Top tray 20kg
Intermediate shelves 31kg each
Base panel 31kg
NOTE: Equipment stored on the mobile workstation should not exceed
the size of the shelf.
Castors 4 x 125mm non--antistatic, two with brakes.*
Ambient temperature Storage: --40Cto+70C
(--40F to +158F) Operation: 10 -- 40C (50 -- 104F)
Relative humidity 95% maximum @ 40C (104F) non--condensing
Atmospheric pressure Storage: 23.5--106 kPa (3.4--15.37lbf/in2)
Operation: 70--106 kPa (10.15--15.37lbf/in 2)
* UK workstations fitted with Antistatic castors from Oct 2007.

Page 10 of 76
Issue 20 : July 2012
WM--P1 SERIES WORKSTATIONS
3.2 WM- DP1 series mobile workstations
Product name WM--DP1 mobile workstation
Dimensions (mm) Height: 1370 (scope in lowest position)
2140 (scope in highest position)
1160 (to top tray)
1826 max (with 19” LCD monitor in highest position)
Depth: 655
Width: 1100
Weight 120kg unladen, including fitted transformer.
Load capacity
(evenly distributed)
Top tray 10kg
Intermediate shelves 26kg each
Base panel 45kg
NOTE: Equipment stored on the mobile workstation should not exceed
the size of the shelf.
Castors 4 x 125mm non--antistatic, two with brakes.*
Ambient temperature Storage: --40Cto+70C
(--40F to +158F) Operation: 10 -- 40C (50 -- 104F)
Relative humidity 95% maximum @ 40C (104F) non--condensing
Atmospheric pressure Storage: 23.5--106 kPa (3.4--15.37lbf/in2)
Operation: 70--106 kPa (10.15--15.37lbf/in 2)
* UK workstations fitted with Antistatic castors from Oct 2007.
3.3 WM- T1 series separation transformers
Product name Olympus Separation Transformer
Identification Market Japan USA UK, Europe,
Rest of the world
Model No. MAJ--173 MAJ--174 MAJ--175
Part No. K10000289 K10000290 K10000291
Power input
requirements
Input voltage 100V 110--120V 220--240V
Frequency 50/60Hz 60Hz 50/60Hz
Power input (max) 1350VA 1300VA 1900VA
Power cable part No. K10001001 K10001002 K10001003 (UK)
K10001004 (Europe)
K10001005 (RoW)
Power output Maximum load 1250VA *1250VA 1800VA
* Maximum 10A load per IEC socket outlet (MAJ--173 only)
Overload
protection
Input circuit breakers 2 x 15A 2 x 13A 2 x 9A
Output fuse T15AH T15AH T10AH

Page 11 of 76
Issue 20 : July 2012
WM--P1 SERIES WORKSTATIONS
Potential
equalisation
Terminals fitted 2 at input, 2 x 6 at output
Standards compliance
The Separation Transformer conforms to the relevant
requirements of
EN IEC 60601--1/EN IEC 60601--1--1:2001, Annex EEE/UL
60601--1 and CAN/CSA Std. No. C22.2 No. 601.1--M90
C
l
a
s
s
i
f
i
c
a
t
i
o
n
Type of protection against electric
shock.
Class I equipment.
C
l
a
s
s
i
f
i
c
a
t
i
o
n
Degree of protection against
explosion
NONE -- The Separation transformer should not be used
within the zone of risk of flammable gases
Degree of protection against ingress
of water. IPXO as defined in EN IEC 60529:1992, ordinary equipment.
Mode of operation Continuous
A
m
b
i
e
n
t
t
e
m
p
e
r
a
t
u
r
e
Storage: --40Cto70C(--40F to 158F)
Environmental
A
m
b
i
en
t
t
empera
t
ure Operation: 10Cto40C(50F to 104F)
E
n
v
i
r
o
n
m
e
n
t
a
l
c
o
n
d
i
t
i
o
n
s
A
t
m
o
s
p
h
e
r
i
c
p
r
e
s
s
u
r
e
S
t
o
r
a
g
e
/
O
p
e
r
a
t
i
o
n
:
7
0
-
-
1
0
6
k
P
a
(
1
0
3
-
-
1
5
4
l
b
f
/
i
n
2
)
c
o
n
d
i
t
i
o
n
s
A
t
mosp
h
er
i
c pressure
S
t
orage
/
O
pera
t
i
on:
7
0
--
1
0
6
k
P
a
(
1
0
.
3
--
1
5
.
4
l
b
f
/
i
n
2
)
Relative humidity 95% maximum @ 40C (104F) non--condensing
Regulatory status
220--240V units are CE marked in
accordance with Directive 93/42/EEC of
14 June 1993 concerning medical
devices, as an accessory to a medical
device, Class I. Year of manufacture is
given in first two digits of serial number.
End of Life
European Economic Area (EEA) In accordance with European Directive
2002/96/EC on Waste Electrical and
Electronic Equipment, this symbol
indicates that the product must not be
disposed of as unsorted municipal waste,
but should be collected separately. Refer
to your local Olympus distributor for return
and/or collection systems available in your
country.
The Olympus WM--P1 series Mobile Workstation and Separation Transformer is manufactured in the
UK by KeyMed (Medical & Industrial Equipment) Ltd.

Page 12 of 76
Issue 20 : July 2012
WM--P1 SERIES WORKSTATIONS
Chapter 4 Tools & Test Equipment
Table of Contents
4.1 Standard Tools and Test equipment required 13................................
4.2 Specialised tools required 13..............................................
4.3 Consumables 13......................................................

Page 13 of 76
Issue 20 : July 2012
WM--P1 SERIES WORKSTATIONS
4TOOLS & TEST EQUIPMENT
4.1 Standard Tools required
Flat blade screwdriver Torque driver
No 2 Pozidrive tool bit No 3 Pozidrive tool bit
4mm Hex tool bit 8mm Hex tool bit
10mm Hex tool bit 10mm A/F socket
13mm A/F Slim socket Ball driver 6mm A/F
Short No 2 Pozidrive screwdriver Torx bit T30
Torque wrench (1/2” drive).. M12 tap
Britool part no AVT300A Torque range 5 to 33 Nm.
Insulation tester which works at 500Vdc. --
4.2 Specialised Tools
Castor spanner WM--P1 -- K10005023 --used with 1/2” drive torque wrench.
FIGURE 4-1
CASTOR SPANNER WM--P1 --
K10005023
4.3 Consumables
Loctite 243 10ml bottle -- part number K10006486
Loctite 243 -- part number 3001857

Page 14 of 76
Issue 20 : July 2012
WM--P1 SERIES WORKSTATIONS
Chapter 5 Test and Inspection
Table of Contents
Page
5.1 Power supply 15.......................................................
5.2 Castor security 15.....................................................
5.3 Castor -- electrical resistance test 15........................................

Page 15 of 76
Issue 20 : July 2012
WM--P1 SERIES WORKSTATIONS
5TEST AND INSPECTION
5.1 Power supply
(1) Check the power supply cable and plug for excessive protrusion, twists, deformation or other irregularities.
5.2 Castor security
(1) Check the security of castors at six--monthly intervals. If loose use castor spanner ( K10005023) fitted to a standard 1/2”
drive torque driver to tighten to a torque of 30Nm.
If castor spanner ( K10005023) is not used, then torque value on the driver should be set to 38Nm. Refer to Chap 6.6.
5.3 Castors - electrical resistance test
NOTE
This test is only applicable to workstations fitted with ’anti--static’ castors, indicated by a yellow wheel centre or
swivel bearing collar, or a yellow dot on the tyre.
(1) Ensure that the workstation power cable is disconnected from the wall socket.
(2) Thoroughly clean each of the tyres.
(3) Roll a castor onto a metal plate which is insulated from the floor.
(4) Using a proprietary insulation tester working at 500Vdc, measure the resistance between the castor mounting point and
the plate. In cases where it is difficult to attach the test lead directly to the the castor mountings it is permissible to
connect to exposed metalwork (such as a screw head) on the base of the workstation, provided that it is electrically
connected to the castor mounting point.
The average resistance should not exceed 100kfor castors rated as ’Conductive’ according to ISO22881:2004,
measured at three different points on the tyre’s circumference.
(5) Repeat the procedure on the other castors.

Page 16 of 76
Issue 20 : July 2012
WM--P1 SERIES WORKSTATIONS
Chapter 6 Part Replacement
Table of Contents
Page
6.1 General 17...........................................................
6.2 Blanking caps & Cable tidy replacement 17...................................
6.3 Bracket twin LG holder replacement 17......................................
6.4 Rear panel replacement 18...............................................
6.5 Shelf corner moulding replacement 18.......................................
6.6 Castor replacement 19..................................................
6.7 Remote switch replacement 20............................................
6.8 Top tray replacement WM--NP1 21..........................................
6.9 Top tray replacement WM--WP1 22.........................................
6.10 Top tray replacement WM--DP1 23..........................................
6.11 Shelf replacement 24...................................................
6.12 Scope pole clamp P1 series replacement 25...................................
6.13 Runner--scope pole P1 series replacement 25.................................
6.14 Nutstrip P1 series replacement 25..........................................
6.15 Power cable replacement 26..............................................
6.16 Separation transformer replacement 26......................................

Page 17 of 76
Issue 20 : July 2012
WM--P1 SERIES WORKSTATIONS
6PART REPLACEMENT
6.1 General
The item numbers referred to throughout this Chapter are the same as those used in the Illustrated Parts List, Chapter 6.
To aid part replacement the following are available :
MAJ--198 WN--NP1 Sheft kit (Narrow) -- K10001429 MAJ--199 WN--WP1 Shelf kit (Wide) -- K10001430
Rear panel kit WM--NP1 K10005044 Rear panelkit WM--WP K10005041
Free castor kit K10004627 Braked castor kit K10004626
Castor free kit WM--P1 series A/S K10005041 Castor braked kit WM--P1 series A/S K10005040
Castor spanner WM--P1 series K10005023 Remote switch kit WM--P1 series K10005049
Umbilical/camera head holder kit K10006648
Before replacing any part on the workstation ensure that all mains power is disconnected.
Olympus will not be responsible for damage or injury to equipment or personnel, caused by unauthorised modification or
repair to this unit.
In the interests of safety and good maintenance ensure that fixings are tightened to the torque settings shown in the
parts list, illustrated parts list and part replacement chapter.
6.2 Blanking caps & Cable tidy replacement
(1) Refer to Figure 6-1. Blanking caps: Cable port (item 17), Monitor (item 18) and Scope pole (item 19) are a push fit and
so require to be carefully prised out of position.
(2) Unscrew Handknob (item 31) to release Cable tidy (item 29).
FIGURE 6-1
BLANKING CAPS & CABLE TIDY
20
21
29
31
172
182192
472
372502672
6.3 Bracket twin LG holder replacement
(1) Refer to Figure 6-1 . and using 4mm hex drive tool bit remove Bracket twin LG holder (item 20) release two screws
(item 37) and washer crinkle (item 50) with washer (item 47) from jetnut (item 67).
(2) Replace/refit in reverse order. Using 4mm hex drive tool bit in torque driver ensure that screw (item 37) is tightened to a
torque of 6Nm.

Page 18 of 76
Issue 20 : July 2012
WM--P1 SERIES WORKSTATIONS
6.4 Rear panel replacement
Each Rear panel is available as a kit which inclues two feet and a finger latch pack. Fit the finger latch as shown in
Figure 6-2 and discard the keeper plate, if supplied.
WM--NP1 Rear panel -- part no K10005044. WM--WP1 Rear panel -- part no K10005045
(1) Refer to Figure 6-2, pull the finger latch to release the top of the rear panel.
(2) Lift the rear panel from the two studs on the base of the workstation.
(3) Refit /replace the rear panel.
FIGURE 6-2
REAR PANEL REPLACEMENT
Finger
latch
WM--WP1
Rear panel
WM--NP1
Rear panel
Discard
keeper plate
Contents of
Finger latch pack
6.5 Shelf corner moulding replacement
(1) Refer to Figure 6-3 each corner buffer (item 23 & 24) may be levered off.
(2) Reassemble by pushing each buffer into place.
FIGURE 6-3
SHELF CORNER MOULDINGS
24
23

Page 19 of 76
Issue 20 : July 2012
WM--P1 SERIES WORKSTATIONS
6.6 Castor replacement
Each workstation has two lockable castors (item 4) and two free castors (item 3).
Maintenance/Repair kits available:--
Free castor kit K10004627 Braked castor kit K10004626
Castor free kit WM--P1 series A/S K10005041 Castor braked kit WM--P1 series A/S K10005040
Special tool :
Castor spanner WM--P1 series K10005023
(1) Disconnect all power to the workstation.
(2) Remove rear panel and all equipment.
(3) Where fitted remove the scope pole or IV pole.
(4) Where fitted stow Keyboard Tray or Keyboard Arm -- Side Mounted.
(5) Remove the cable winder (item 19)
(6) Place the workstation carefully on to it’s back. The WM--DP1 exceeds 30Kg and must be handled by two people.
(7) Refer to Figure 6-4. For ease of access to the lower castors elevate and securely support the base end of the workstation.
(8) Using Castor spanner tool K10005023 fitted to a 1/2” drive wrench release the castor (item 3 or 4) and washer (item 5).
(9) Ensure that lockable castors(item 4) are refitted in the original location, refer to Figure 6-4
Run a M12 tap through the castor fixing hole to clear any residual Loctite adhesive.
When attaching a castor ensure that the thread of the bolt is smeared with loctite 243 ( item 60 ), use Castor spanner tool
K10005023 fitted to a torque driver to tighten to a torque of 30Nm.
NOTE If Castor spanner tool K10005023 is not used, then the torque value on the driver should be set to 38Nm.
Stand the workstation on it’s castors, re--install the equipment.
To allow the loctite to cure, the workstation should be kept in a location for 24 hours where the temperature is not below
22C and manouvering on bumpy surfaces is avoided.
FIGURE 6-4
CASTOR REPLACEMENT
55
5
5
3
3
Support
4LOCKABLE
4LOCKABLE
CASTOR SPANNER WM--P1 SERIES -- K10005023

Page 20 of 76
Issue 20 : July 2012
WM--P1 SERIES WORKSTATIONS
6.7 Remote switch replacement
(1) Unplug the Remote switch plug from the separation transformer.
(2) Refer to Figure 6-5 for WM--NP1, Figure 6-6 for WM--WP1 and Figure 6-7 for WM--DP1, use a No 2 Pozi drive tool to
release four screws (item 77) securing four p clips (item 78).
(3) Release the remote switch cable from releasable cable tie (item 34).
(4) Free the cable from the column side cable retainer.
(5) Using 4mm hex drive tool release two screws (item 40) with washer (item 50) to release remote switch (item 2).
(6) Reassemble in reverse order, use 4mm hex drive tool in torque wrench to tighten remote switch fixings to 2Nm.
(7) Fit four p clips to remote switch cable. Use a No 2 pozi driver in a torque wrench to fasten four screws (item 77) securing
four p clips (item 78) tighten to torque of 2.2Nm.
(8) Route the remote switch cable to releasable cable tie (item 34). Take up any slack in the cable toward the switch and
tighten the cable tie.
(9) Plug the Remote switch cable into the separation transformer.
(10) Route remaining cable into column side cable retainer.
