1AG6P1P2817-- VH421101
Quick Start Guide
SP-700
TRANSFER IMAGES
a. Install the software
1Insert the OLYMPUS Master CD-ROM.
2Windows:
Click the “OLYMPUS
Master“ button.
Macintosh:
Double-click the “Installer“
icon.
3Simply follow the on-screen
instructions.
b. Connect the camera to the computer
1Connect the camera to the computer using the USB cable provided with
the camera.
The camera monitor will turn on automatically.
2Select [PC] on the monitor, and press Z.
Your PC will now recognize your camera as a
removable storage drive.
USB cable
1
2
Connector cover
Pull the connector cover
forward and then turn it.
Multi-Connector
P C
USB
OK
CUSTOM PRINT
EXIT
EASY PRINT
SELECT
GO
c. Transfer images to the computer
[Transfer Images] window
[Transfer Images]
button
b. Click the “From Camera” icon.
a. Click the “Transfer Images” icon
on the OLYMPUS Master main
menu.
If the [Transfer Images] window is not
displayed automatically:
1With the camera now connected,
open OLYMPUS Master.
The [Transfer Images] window is
displayed.
2Select the images you want to
transfer, and click the [Transfer
Images] button.
REVIEW OR ERASE A PICTURE
a. Set the mode
switch to q
b. Take a closer look
The last picture taken will be displayed.
Zoom Lever
Prev. Picture Next
Mode Switch
Arrow Pad
Press O/Nor X/Y
to scroll around.
Turn the zoom lever
towards T to enlarge
the picture 10x
(closeup playback) and
turn it towards W to
reduce the picture.
Press Zto return to
the original size.
Set the mode switch to Kor A
to return to the shooting mode.
OK
ERASE
YES
NO
SELECT
GO
c. To erase a picture
1Display the picture you want to erase.
2Press the Sbutton.
3Select [YES], and press Z.
The picture is permanently erased.
S Button
TAKE A PICTURE
a. Zoom
Zoom Out: Zoom In:
44
6M
c. Take the picture
1Press the shutter button
completely to take the
picture.
(Pressed Completely)
Shutter Button
b. Focus
1Using the monitor, place the AF target
mark over your subject.
2Press and hold the shutter button halfway
to lock the focus.
The green lamp indicates the focus is locked.
44
6M
Green Lamp
(Pressed Halfway)
Shutter Button
AF Target Mark
GET STARTED
a. Attach the strap
1
Strap
Pull the strap tight so that it does
not come loose.
b. Insert the battery
3
Battery lock
knobInsert
2
1Lift
Slide
d. Set the date and time
1Set the mode switch to Kand
press the obutton to turn it
on.
2Press Zto display the top menu,
and select [MODE MENU] >
[SETUP] > [X].
3Press O/Nto set an item. Press
X/Yto select the next field.
Mode Switch
ZButton
oButton
2005
.
01
.
01
00
:
00
Y M D
SELECT
OK
GOSET
CAM
u
VIDEO OUT
MEM
SETUP
DUAL TIME
SETUP
’05.01.01
00:00
OFF
NTSC
ON
Operation
guide
Date format
BEFORE YOU BEGIN
Gather these items (box contents)
Items not shown: Advanced Manual (CD-ROM), Basic Manual, warranty card. Contents may vary depending on purchase location.
Digital Camera Strap LI-40B Lithium Ion
Battery
Power Cable USB Cable AV CableAC Adapter
(S-D-1AC)
OLYMPUS Master
Software CD-ROM
Start Here
CAMERA DIAGRAM
Self-Timer Lamp
Shutter Button
oButton Flash
Lens
Zoom Lever
Arrow Pad (O/N/X/Y)
ZButton (OK/MENU)
Strap Eyelet
Battery Compartment/
Card Cover Tripod Socket
Connector Cover
Multi-Connector
DC-IN Jack
DISP./GUIDE Button
SButton (Erase)
Monitor
Mode Switch
Microphone
z/<Button
(Custom/Print)
QUICK VIEW Button
Speaker
Power/Card Access Lamp
For more information, please refer to the Basic & Advanced
Manuals or visit: www.olympusamerica.com/support
Printed in Japan © 2005
c. Charge the battery (recommended*)
*Battery comes partially charged.
Power Cable
AC Wall
Outlet
AC Adapter
1
2
3
DC-IN Jack
Connector cover
Pull the connector cover
forward and then turn it.
Power/Card Access Lamp
Blinking red slowly: Charging
Off: Charging complete
(Charging time: Approx. 120 minutes)
