Olympus DS-5000 Operating and maintenance manual

Thank you for purchasing an Olympus
Digital Voice Recorder.
Please read these instructions for information
about using the product correctly and safely.
Keep the instructions handy for future reference.
To ensure successful recordings, we recommend that
you test the record function and volume before use.
DETAILED
INSTRUCTIONS
DIGITAL VOICE
RECORDER
DS-5000
DS-5000iD
EN

2
Microsoft and Windows are registered trademarks of Microsoft Corporation.
Macintosh is a trademark of Apple Inc.
Intel and Pentium are registered trademarks of Intel Corporation.
SD and microSD are trademarks of SD card Association.
SDHC and microSDHC are trademarks of SD card Association.
Other product and brand names mentioned herein may be the trademarks or registered
trademarks of their respective owners.
●The contents of this document may be changed in the future without advanced notice.
Contact our Customer Support Center for the latest information relating to product names
and model numbers.
●The utmost care has been taken to ensure the integrity of the contents of this document. In
the unlikely event that a questionable item, error, or omission is found, please contact our
Customer Support Center.
●Any liability for passive damages or damage of any kind occurred due to data loss incurred
by a defect of the product, repair performed by the third party other than Olympus or an
Olympus authorized service station, or any other reasons is excluded from the Olympus’s
liability.
Trademarks
Introduction
Introduction

3
1
2
3
5
7
4
INDEX
INDEX
Table of Contents
Safe and Proper Usage
Getting Started
Basic Operations
Advanced Operations
Managing Files on Your PC
Other Practical Use Methods
Other Information
P. 11
P.27
P. 4 1
P. 6 9
P. 7 7
P. 7 8
P. 4
P. 6
6

4
Table of Contents
Table of Contents ...................................... 4
Safe and Proper Usage ............................ 6
General Precautions ................................. 7
1Getting Started
Main Features ........................................ 11
Memory Card ......................................... 12
Identification of Parts ............................. 14
Installing Batteries ................................. 16
Charging Battery Pack .......................... 18
Using the Battery Pack .......................... 20
Using the AC Adapter ............................ 21
Turning ON the Recorder ...................... 22
Power Save Mode (Power Save) .......... 22
Inserting and Ejecting a SD card .......... 23
Setting Time and Date (Time & Date) ... 24
Setting Recording Destination
(Card Select) ................................... 26
2Basic Operations
Recording .............................................. 27
Microphone Sensitivity (Mic Sense) ...... 31
Recording Modes (Rec Mode) .............. 32
Using the Variable Control Voice Actuator
(VCVA) ............................................. 33
Hands-free Recording ........................... 34
Recording Monitor ................................. 34
Playing ................................................... 35
Erasing ................................................... 37
3Advanced Operations
Menu List ............................................... 41
Learning to Use the Menu ..................... 43
Selecting Folders and Files ................... 44
Displaying File Information .................... 45
Device Lock Function ............................ 46
Locking Files (Lock) .............................. 50
Pending Files (Pending) ........................... 51
Setting Priority Levels (Priority) ............ 52
Setting the Author ID and Work Type.... 53
Verbal Comment .................................... 56
Index Marks ........................................... 57
Language (Language) ........................... 58
Backlight (Backlight) .............................. 59
LED (LED) ............................................. 60
LCD Contrast Adjustment (Contrast) .... 61
System Sounds (Beep) ......................... 62
Inserting and Ejecting a microSD card .... 63
Formatting the Card (Format) ............... 64
Check System Information (System info.) .. 66
Changing the USB Class (USB Class) .... 67
Customizing the Recorder ..................... 68
4Managing Files on Your PC
DSS Player Software............................. 69
Installing DSS Player Software ............. 71
Uninstalling DSS Player Software......... 72
Using Online Help ................................. 73
Connecting Recorder to PC .................. 74
Running DSS Player Software .............. 76

5
Table of Contents
5Other Practical Use Methods
Using as External Memory of the Computer ... 77
6Other Information
Alarm Message List ............................... 78
Troubleshooting ..................................... 79
Accessories ........................................... 80
Specifications ........................................ 81
Technical Assistance and Support ........ 82

6
Convention Used In this Manual
•The word “card” is used to refer to the SD
card and microSD card.
•The word “DSS Player” is used to refer to
the DSS Player Pro R5 Dictation Module
in Windows environment and DSS Player
in Apple Macintosh environment.
•The Notes at the bottom of a page are
used for additional information,
exceptions, or related events.
•Words in uppercase form such as PLAY
or REC are used to describe a function,
button, or switch position on the recorder.
Safe and Proper Usage
Before using your new recorder, read this
manual carefully to ensure that you know
how to operate it safely and correctly. Keep
this manual in an easily accessible location
for future reference.
Important Safety Precautions
Certain symbols are used in the user’s
manual and on this product to help protect
users, their surroundings, and their
property from possible injury or damage.
Please familiarize yourself with the
following definitions and meanings for each
symbol before reading the precautions.
Symbols prohibiting a specific action
Prohibited Do not
disassemble
Symbols requiring a specific action
Mandatory Unplug from
power outlet
Signifies danger which
may result in serious
injury or death.
Indicates items or actions
which may cause serious
injury or death.
Indicates items or actions
which may result in
damage or personal injury.
Danger
Warning
Caution

7
General Precautions
