USER AND
MAINTENANCE MANUAL
101-050
FAMILY CODE
Multi-channel transmitter for RADAR II
radio remote controls
“RADAR NEW TXF”
Codice foglio: 997-101-50366 Rev: // Data: Venerdì 16 giugno 2017 Codice fascicolo: 997-101-50370

pag.4
O.M.F.B. S.p.A. Hydraulic Components
We reserve the right to make any changes without notice.
Edition 2017.05 No reproduction, however partial, is permitted.
Via Cave, 7/9 25050 Provaglio d’Iseo (Brescia) Italy Tel.: [phone]
Fax: [phone] Internet:www.omfb.it e-mail:[e-mail]
101-050USER AND MAINTENANCE MANUAL
1. General comments ............................................................................................... 5
1.1 Description of individual push-button and LED functions ........................................... 5
1.2 Distinguishing features............................................................................................. 6
1.3 Standard supplies..................................................................................................... 6
1.4 Technical specifications ............................................................................................ 6
1.5 Specific features ...................................................................................................... 6
1.6 Replacing the batteries ............................................................................................ 7
1.7 Emergency command from the transmitter................................................................ 7
2. Use in combination with the RADAR II 2CH and 4CH receiver ......................... 8
2.1 Programming .......................................................................................................... 8
2.2 Use ......................................................................................................................... 8
3. Use in combination with the RADAR II 8CH receiver ......................................... 9
3.1 Programming .......................................................................................................... 9
3.2 Use ......................................................................................................................... 9
4. Use in combination with the RADAR II 12CH receiver ......................................10
4.1 Programming .........................................................................................................10
4.2 Use ........................................................................................................................10
5. Product Markings and certification ................................................................... 11
“RADAR NEW TXF”
Codice foglio: 997-101-50366 Rev: // Data: Venerdì 16 giugno 2017 Codice fascicolo: 997-101-50370

pag.5
O.M.F.B. S.p.A. Hydraulic Components
We reserve the right to make any changes without notice.
Edition 2017.05 No reproduction, however partial, is permitted.
Via Cave, 7/9 25050 Provaglio d’Iseo (Brescia) Italy Tel.: [phone]
Fax: [phone] Internet:www.omfb.it e-mail:[e-mail]
1. General comments
1.1 Description of individual push-button and LED functions
101-050USER AND MAINTENANCE MANUAL
STOP/EMERGENCY
button
Active transmission
feedback LED
Battery charge
status LED
Function buttons
Column for selec-
ting the A, B or C
receiver
“RADAR NEW TXF”
Codice foglio: 997-101-50366 Rev: // Data: Venerdì 16 giugno 2017 Codice fascicolo: 997-101-50370

pag.6
O.M.F.B. S.p.A. Hydraulic Components
We reserve the right to make any changes without notice.
Edition 2017.05 No reproduction, however partial, is permitted.
Via Cave, 7/9 25050 Provaglio d’Iseo (Brescia) Italy Tel.: [phone]
Fax: [phone] Internet:www.omfb.it e-mail:[e-mail]
1.2 Distinguishing features
• Compatible with the receivers: RADAR II 2CH, 4CH, 8CH, 12CH
• Transmitting commands: up to 12 (2 Channels x 2 Functions x 3 Banks selectable)
• Equipped with STOP/Emergency command
1.3 Standard supplies
• 1 Transmitter
• 2 AA batteries (ALKALINE)
• 1 User and maintenance manual
1.4 Technical specifications
Min Typical Max Unit
Work frequency centre 433.82 433.92 434.02 MHz
Effective radiated power (E.R.P.) 5.0 10 mW
Modulation OK On-Off Keying
Power supply (2xAA) 2.2 3 3.3 V
Current consumption in Tx 40 50 mA
Current consumption in stand-by 0 uA
Battery life 3 (1) 5 years
Serial code 28 bit
Hopping code 32 bit
Combinations 232 -
Working temperature -10 +55 °C
Dimensions 75x169x32 mm
The use of rechargeable batteries does not ensure correct operation of the transmitter because the supply
voltage generated by the batteries is at the minimum card operating limit.
1.5 Status information
101-050USER AND MAINTENANCE MANUAL
“RADAR NEW TXF”
Battery LED Tx LED Battery
OFF ON
steady when a function button is pressed
Charged
Normal operation
ON flashing ON
steady when a function button is pressed
Partly discharged
Normal operation
ON flashing ON
flashing when a function button is pressed
Abnormal operation transmission of the si-
gnal is not stable.Battery flat immediate re-
placement is recommended.
ON quick flashing OFF
when a function button is pressed
There is no signal transmission the transmit-
ter cannot be used to complete the opera-
tion.Battery dead dispose of the batteries
and replace.
If the batteries are replaced with new ones, the tx can be used immediately to complete any operations
that are currently underway.
Codice foglio: 997-101-50366 Rev: // Data: Venerdì 16 giugno 2017 Codice fascicolo: 997-101-50370

pag.7
O.M.F.B. S.p.A. Hydraulic Components
We reserve the right to make any changes without notice.
Edition 2017.05 No reproduction, however partial, is permitted.
Via Cave, 7/9 25050 Provaglio d’Iseo (Brescia) Italy Tel.: [phone]
Fax: [phone] Internet:www.omfb.it e-mail:[e-mail]
1.6 Replacing the batteries
The power batteries have to be replaced immediately when the BATT LED switches on and flashes quickly
while the function button is active and the TX LED is off.
To do this, move the catch downwards, lift the battery compartment cover and remove the flat batteries.
Replace them with two of the same type (AA 1.5V alkaline), taking care not to reverse the polarity (see
figure). Put the battery compartment cover back and lock with the catch.
If the battery is leaking liquid, immediately remove it and clean the battery compartment, making sure you
do not touch this substance; wash your hands thoroughly after this operation.
ATTENTION: Do not dispose of old batteries in the environment, but throw them into special
containers to facilitate disposal.
1.7 Emergency command from the transmitter
The RADAR TXF is fitted with Emergency command: whenever the emergency button is pressed on the
transmitter, an emergency signal is sent to all programmed receivers.
The emergency button dominates all other commands, thus the receiver stops any function active at that
time.
Pressure on the emergency command is signalled by the receiver, by the continuous sound of a buzzer
inside the receiver itself.
To restore proper operation of the system, press the Green start button on the receiver, the radio remote
control is ready to perform new operations.
Catch.
Pull downwards.
Battery compartment
cover
Remove the battery
upwards.
Negative pole (-)
Positive pole (+)
Positive pole (+)
Negative pole (-)
101-050USER AND MAINTENANCE MANUAL
“RADAR NEW TXF”
Codice foglio: 997-101-50366 Rev: // Data: Venerdì 16 giugno 2017 Codice fascicolo: 997-101-50370

pag.8
O.M.F.B. S.p.A. Hydraulic Components
We reserve the right to make any changes without notice.
Edition 2017.05 No reproduction, however partial, is permitted.
Via Cave, 7/9 25050 Provaglio d’Iseo (Brescia) Italy Tel.: [phone]
Fax: [phone] Internet:www.omfb.it e-mail:[e-mail]
2. Use in combination with the RADAR II 2CH and 4CH receiver
2.1 Programming
This procedure is necessary if you have received a transmitter and receiver(s) separately.
Before using a new TXF transmitter, communication has to be created between the transmitter and the
receiver(s).
To do this please follow the below described programming procedure.
ATTENTION: make sure the receivers have not already been programmed, if they have, cancel the program
and reprogram with the new transmitter.
1. Power up the receiver (insert the battery disconnector and any other switch that may be installed in
series with the receiver power supply);
2. On the transmitter: make sure the TX LED lights up when a function button is pressed in columns A,
B, C;
3. On the receiver: press the red emergency mushroom-head button: the buzzer inside begins to emit
a continuous sound;
4. On the receiver: put a magnet next to the “Learning Zone”: the buzzer inside the receiver
will emit an intermittent sound;
5. On the transmitter: press one of the function buttons (channel 1 Up/Down or channel 2 Up/Down)
in the column on which you wish to program the receiver (A, B or C).
6. On the receiver: the sound issued by the buzzer returns;
7. On the receiver: release by turning the red emergency mushroom-head button;
8. On the receiver: press the green button;
9. Make sure all functions connected to the radio remote control system are correctly activated.
RESET OR PROGRAM CANCELLING PROCEDURE
Each receiver stores up to 5 distinct transmitter codes. When the memory is full, the receiver signals it
by emitting an intermittent high frequency sound. To reset the memory, proceed as for programming up
to step 4 and keep the transmitter at hand. When the continuous beep switches to alternating beeps,
within 5 seconds the alternating beeps will emit a sound at a different frequency. Now, after releasing the
emergency button, press the green button on the receiver.
LEARNING ZONE
101-050USER AND MAINTENANCE MANUAL
“RADAR NEW TXF”
Codice foglio: 997-101-50366 Rev: // Data: Venerdì 16 giugno 2017 Codice fascicolo: 997-101-50370

pag.9
O.M.F.B. S.p.A. Hydraulic Components
We reserve the right to make any changes without notice.
Edition 2017.05 No reproduction, however partial, is permitted.
Via Cave, 7/9 25050 Provaglio d’Iseo (Brescia) Italy Tel.: [phone]
Fax: [phone] Internet:www.omfb.it e-mail:[e-mail]
2.2 Use
1. Power up the receiver (insert the battery disconnector and any other switch that may be installed in
series with the receiver power supply);
2. On the transmitter: press the desired functions, remembering that, if you are controlling a RADAR
II 2 CH, the 2 commanded functions are controlled by the channel 1 Up/Down function buttons,
but if you are controlling a RADAR II 4 CH, the 4 functions correspond to the function buttons in the
first column A; if the red LED signalling the battery’s charging status lights up and the TX LED is not
active, follow the instructions in paragraph 1.6 to replace the batteries.
3. Use in combination with the RADAR II 8CH receiver
RADAR II 8CH radio remote control systems are configured thusly:
• Qty. 2 4CH Receivers;
• Qty. 1 Transmitter.
The TXF transmitter controls, respectively, the first 4CH receiver on the “Receiver A” and the second 4CH
receiver on “Receiver B” of the transmitter: in other words, to activate the devices connected to the first
receiver you must press the button “A” on the transmitter, while to control the devices connected to the
second receiver you must press the button “B”.
Note: The receivers are perfectly identical to one another, and completely interchangeable. It is the
operator or installer who defines which is the first and second receiver, during the programming
stage described below.
3.1 Programming
1. Power up the receivers (insert the battery disconnector and any other switch present in series with the
receiver power supply);
2. On the transmitter: press a function button in the A, B or C column and make sure the TX LED lights
up flashing;
3. On the receiver 1: press the red emergency mushroom-head button: the internal buzzer begins to
emit a continuous sound;
4. See paragraph 2.1 to program with REED;
5. Make sure all functions connected to the first receiver of the radio remote control system are correctly
activated;
6. On the receiver 2: press the red emergency mushroom-head button: the internal buzzer begins to
emit a continuous sound;
7. See paragraph 2.1 to program with REED;
8. On the transmitter: press one of the function buttons (channel 1 Up/Down or channel 2 Up/Down)
in the column on which you wish to program the receiver, with the exception of those already
programmed in A, B or C.
9. Make sure all functions connected to the radio remote control system are fully functional.
Test that the emergency function from the Transmitter is sent to the two receivers.
3.2 Use
1. Power up the receivers (insert the battery disconnector and any other switch that may be installed in
series with the receiver power supply);
2. On the transmitter: press the desired functions, remembering that the first column is for receiver A
and the second column is for receiver B.
3. The transmitter automatically switches off.
101-050USER AND MAINTENANCE MANUAL
“RADAR NEW TXF”
Codice foglio: 997-101-50366 Rev: // Data: Venerdì 16 giugno 2017 Codice fascicolo: 997-101-50370

pag.10
O.M.F.B. S.p.A. Hydraulic Components
We reserve the right to make any changes without notice.
Edition 2017.05 No reproduction, however partial, is permitted.
Via Cave, 7/9 25050 Provaglio d’Iseo (Brescia) Italy Tel.: [phone]
Fax: [phone] Internet:www.omfb.it e-mail:[e-mail]
4. Use in combination with the RADAR II 12CH receiver
RADAR II 12CH radio remote control systems are configured thusly:
• Qty. 3 4CH Receivers;
• Qty. 1 Transmitter.
The TXF transmitter controls, respectively, the first 4CH receiver on “Receiver A”, the second 4CH receiver on
“Receiver B”, and the third 4CH receiver on “Receiver C”: in other words, to activate the devices connected
to the first receiver, you must press the button “A”; to control the devices connected to the second receiver,
you must press the button “B”; finally, to control the devices connected to the third receiver you must press
the button “C”.
NB: The receivers are perfectly identical to one another, and completely interchangeable. It is the operator
or installer who defines which are the first, second and third receivers, respectively, during the
programming stage described below.
4.1 Programming
1. Power up the receivers (insert the battery disconnector and any other switch that may be installed in
series with the receiver power supply).
2. On the transmitter: press a function button in the A, B or C column and make sure the TX LED lights
up flashing;
3. On the receiver 1: press the red emergency mushroom-head button: the buzzer inside begins to emit
a continuous sound;
4. See paragraph 2.1 to program with REED;
5. Make sure all functions connected to the first receiver of the radio remote control system are correctly
activated;
6. On the receiver 2: press the red emergency mushroom-head button: the buzzer inside begins to emit
a continuous sound;
7. See paragraph 2.1 to program with REED;
8. On the transmitter: press one of the function buttons (channel 1 Up/Down or channel 2 Up/Down)
in the column on which you wish to program the receiver, with the exception of those already
programmed in A, B or C.
9. Make sure all functions connected to the second receiver of the radio remote control system are
correctly activated;
10. On the receiver 3: press the red emergency mushroom-head button: the buzzer inside begins to
emit a continuous sound;
11. See paragraph 2.1 to program with REED;
12. On the transmitter: press one of the function buttons (channel 1 Up/Down or channel 2 Up/Down)
in the column on which you wish to program the receiver, with the exception of those already
programmed in A, B or C.
13. Make sure all functions connected to the third receiver of the radio remote control system are
correctly activated;
14. Test that the emergency function from the Transmitter is sent to the three receivers.
4.2 Use
1. Power up the receivers (insert the battery disconnector and any other switch installed in series with
the receiver power supply)
2. On the transmitter: press the desired functions, remembering that the first column is for receiver A,
the second column is for receiver B, and the third column is for receiver C.
3. The transmitter automatically switches off.
101-050USER AND MAINTENANCE MANUAL
“RADAR NEW TXF”
Codice foglio: 997-101-50366 Rev: // Data: Venerdì 16 giugno 2017 Codice fascicolo: 997-101-50370

pag.11
O.M.F.B. S.p.A. Hydraulic Components
We reserve the right to make any changes without notice.
Edition 2017.05 No reproduction, however partial, is permitted.
Via Cave, 7/9 25050 Provaglio d’Iseo (Brescia) Italy Tel.: [phone]
Fax: [phone] Internet:www.omfb.it e-mail:[e-mail]
5. Product Markings and certification
RADAR II radio remote controls meets the rules set forth in the following harmonised
technical standards:
Directive 99/5/EC article:
Harmonised standards:
Art. 3.1 (a) - HEALTH
Art. 3.1 (a) - SAFETY
EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011+ AC:2011+ A2:2013 Information
technology equipment - Safety
Assessment of the compliance of low power electronic and electrical equipment with the
basic restrictions related to human exposure to electromagnetic fields (10 MHz to 300
GHz).
Part 1: General requirements
Art. 3.1 (b) - ELECTROMAGNETIC COMPATIBILITY EMC EN 301 489-3: v1.6.1
(2013-08)
Electromagnetic compatibility and radio spectrum matters (ERM); electromagnetic
compatibility (EMC) standard for radio equipment and services. Part 3: Specific conditions
for short-range devices (SRD) operating on frequencies between 9 kHz and 246 GHz.
Art 3.2 - RADIO SPECTRUM EN 300 220-2: v2.4.1
(2012-05)
Electromagnetic compatibility and radio spectrum matters (ERM); short-range devices (SRD);
radio equipment to be used in the 25 MHz to 1000 MHz frequency range with power levels
ranging up to 500 mW. Part 2: Harmonised EN covering essential requirements under
article 3.2 of the R&TTE Directive.
101-050USER AND MAINTENANCE MANUAL
“RADAR NEW TXF”
Codice foglio: 997-101-50366 Rev: // Data: Venerdì 16 giugno 2017 Codice fascicolo: 997-101-50370
