OmniPower SPS-600 User manual

Attention
Please read all the information below before using your equipment in order to protect yourself and
others from injury and to prevent damage to your equipment.
ŸDo not expose the SPS to fire or heat and operate or store in an environment below 50° C
ŸDo not immerse the SPS into water. Store the product in a cool and dry environment.
ŸDo not use the SPS in flammable or explosive environments (gasoline, gas, chemicals, mines,
etc.).
ŸDo not use SPS in corrosive environments.
ŸThe output of this product is standard alternating current. As with any household electrical outlet,
there is the potential of electric shock. Keep product away from children.
ŸDo not disassemble, refit or repair this product.
ŸIf the SPS is to be placed into storage, the battery must be charged every six months.
Misuse of this product will void your warranty
Warning
The SPS produces a modified sinewave output.
ŸModified sinewave / squarewave inverters are not compatible with all electronic equipment.
ŸSome charger equipment designed for charging rechargeable batteries is not suitable for
connecting to the SPS and will damage the unit. For example: rechargeable flashlights, razors,
searchlights.
ŸDO NOT plug in battery chargers for cordless power tools if the charger carries a warning that
dangerous voltages are present at the battery terminals.
ŸNot suitable for inductive loads.
ŸNever exceed the rated power output of the SPS.
ŸIf you are unsure about the loads that can be powered by the SPS, please contact your product
supplier.
Included in box
ŸSPS Multifunctional Standby Power Supply
ŸPower cord
ŸUser Manual
Multifunctional SPS Diagram
1. Multifunctional LCD display. 2. AC output switch 3. AC output socket common 4. 5V USB
output socket 5. Fast-charging USB output socket 6. UPS/INV switch 7. USB output switch 8.
Solar charging input port 9. AC input socket 10. Heat dissipation fan
SPS LCD Display Screen
1. Battery capacity indicator
2. Battery voltage display
3. Solar charging (when the icon is
illuminated, solar charging is in
progress)
4. AC mode (when the icon is illuminated,
grid power charging is in progress)
5. Battery mode (when the icon is
illuminated, battery power is being
supplied - standby mode)
6. AC Output Voltage
7. Load
8. Commercial power charging current
(displays max commercial power
charging current in commercial power
mode)
9. Battery type (displays battery type)
10. Fan
11. Silence
12. AC Main powers Input Mode
13. Priority Model of Commercial
Power/Solar Energy

Standby Power Supply Operation and Control Functions
1. AC output switch. Press once to turn on AC output of the SPS, press and hold for 3
seconds to turn off AC output of SPS.
2. USB ON/OFF switch can turn on or turn off the USB output
3. UPS/INV switch can switch the AC input voltage range of the SPS. Switching to the UPS
state, the SPS will obtain more stable output voltage when switching to local power and
standby work, and when switching to INV state, the SPS will be allowed to work in a lower
local power voltage range.
How to use the SPS
1. To charge the SPS with commercial power. Connect the input power line to the AC input
socket of the SPS, then insert the standard 3-hole municipal power socket with grounding
to charge the SPS.
2. To charge the SPS with solar panels, insert the solar panel/s into the solar charging port of
the SPS. The specifications of the solar energy input port are 2.1mm in inner diameter and
5.5mm in outer diameter, positive and negative inside. 18V/100W solar panels are
recommended. The charging speed of solar energy is determined by the power and
sunshine intensity of the solar panels and has nothing to do with the SPS itself.
3. Connect the AC load, connect the AC equipment to the AC output socket of the standby
power supply, then turn on the AC output of the SPS. If multiple AC devices need to be
connected, they should be turned on one by one and the devices with higher power should
be turned on first. Charging digital products such as mobile phones and tablets with USB
interface, plugging the USB charging connection into the USB port of the SPS and opening
the USB switch will charge the device. If AC devices are not being used when charging
USB devices, please turn off AC output to reduce power loss.
LITHIUM BATTERY
CHARGE FROM SOLAR POWER/
GRID POWER. Solar panel sold
separately.
SPS
PORTABLE BACKUP POWER
USER MANUAL V1.1
Model SPS-600 SPS1000 SPS-1200
Rated Power (Peak Power) 300W (600W) 500W (1000W) 600W (1200W)
Voltage Range (AC Mode) USB Mode: 180~260VAC; INV Mode: 140~260VAC
Solar Power Input Voltage 18V/5A
AC Output Voltage Range AC Mode: Synchronizes with the input range of commercial power
Standby Mode: 220VAC +-10%
AC Output Frequency AC Mode: Synchronizes with the input range of commercial power
Standby mode: 220VAC +-10Hz
USB Output Common white USB output port: 5V/3A
Blue Fast-Charging USB Output Port: Automatically adjusts the output voltage and current
according to the identified fast-charging protocol. Supported protocols are QC3., PE2.0,
FCP, SCP, AFC, SFCP, BC1.2
AC Charging Current 5A 10A
Battery Voltage and Capacity Label on enclosure rear panel
Environment Temperature: 0 – 40° C, Humidity: 30% to 90% without condensation
Storage Temperature -10 to 50° C
