OmniPower POWER TROLLEY 8 User manual

POWER TROLLEY 8 INSTRUCTION MANUAL
POWER TROLLEY 8
Model: SINE 1548
Instruction Manual for:
Self-Contained Sinewave Mobile Power Backup System
Version 07

POWER TROLLEY 8 INSTRUCTION MANUAL
CONTENTS
Page
1. INTRODUCTION.......................................................................................1
2. USING THE POWER TROLLEY……………………. ................................2
3. BATTERY BACKUP TIME LOAD FACTOR..............................................3
4a. INPUT AND OUTPUT CONNECTION ....................................................4
4b. CONNECTING TO THE POWER TROLLEY 8 .......................................5
5. FRONT PANEL INDICATORS EXPLAINED.............................................6
6. INTERFACING WITH THE POWER TROLLEY........................................7
7. GENERATOR USE. .................................................................................8
8. TROUBLE SHOOTING .............................................................................8
9. OVERLOAD RESET .................................................................................9
10. TECHNICAL SPECIFICATIONS......................................................10/11
11. WARRANTY..........................................................................................12
IMPORTANT!!!
Please read the entire instruction manual before
connecting the “Power Trolley 8”

POWER TROLLEY 8 INSTRUCTION MANUAL
1
1. INTRODUCTION
Thank you for purchasing a “Power Trolley 8”
Your Power Trolley is a versatile unit specifically designed to provide power
when normal Utility power fails. It can provide quick-acting emergency power
for many situations where either power has failed or when a ready source of
portable mains power is needed for small businesses, service professionals
and home use for powering TV’s, DSTV Decoders, M-Net Decoders, Lights,
Alarm Systems, Laptop Computers, Desktop Computers, DeskJet Printers,
Radios, Hi-Fi Systems, Security Systems, Cash Registers, PABX systems,
modems, hubs, routers, etc.
It is very user friendly and has the added benefit of being emission-free and
noiseless. It requires no installation, virtually no maintenance, and is
inexpensive to operate.
It has a number of advanced features allowing you to:
See at a glance the condition of the unit with easy-to-understand
LED indicators
Have virtually instantaneous back-up power when a mains power
failure occurs –very smooth changeover.
Easily wheel the unit to where it is needed
Tip or tilt or turn over the unit without fear of spilling acid from the
fully-sealed internal batteries
Smooth sine–wave power –no worries about interference with
electronic equipment
This manual describes the simple steps to use the unit and explains to you the
operation of the “Power Trolley 8”.

POWER TROLLEY 8 INSTRUCTION MANUAL
2
2. USING THE POWER TROLLEY
Moving the unit to where you want to use it is easy. It comes with a retractable
handle exactly the same as you have on your “carry-on” airline suitcase. Push
the button on the handle, lift and fully extend the handle. Put your foot on the
centre axle between the wheels, tilt the unit to about 45° and you’ll find the
unit easy to wheel wherever you need it. If you have to lift it into the boot of a
car, for instance, it is easier with two people using the white handles on both
sides.
Handling the trolley
Avoid rough terrain and do not twist the handle

POWER TROLLEY 8 INSTRUCTION MANUAL
3
3. FOR HOW LONG WILL YOU GET POWER BACKUP?
The Power Trolley 8 comes with internal batteries fitted.
The power available is load dependant. Depending on what is plugged into
the unit, up to 7 hours’backup is possible with the ‘built-in’ battery with a
100W load.

POWER TROLLEY 8 INSTRUCTION MANUAL
4
4a. INPUT AND OUTPUT CONNECTION
Connecting the Power Trolley to the AC Input
Connecting the Power Trolley to computer equipment

POWER TROLLEY 8 INSTRUCTION MANUAL
5
4b. CONNECTING TO THE POWER TROLLEY
Supplied with the Power Trolley is a 2,5m 3-pin 15A cable with a 3pin ‘kettle
connector’. This cable is for the built-in battery charger in the Power Trolley
and supplying mains while on standby.
1. Check the rating label on the rear panel to be sure that the line input
voltage rating is correct. Normally 220V –230VAC / 50Hz.
2. Plug the supplied 3-pin kettle connector to the provided socket and then to
a wall socket AC power outlet. Leave the cable permanently plugged-in
to the mains unless you wish to transport the unit. Do not leave the unit
disconnected from the mains supply for longer than 2 months.
3. If you are using the equipment for the first time, allow the unit to charge its
internal batteries for at least 12 hours.
4. Connect the equipment to one or both of the 15A output sockets.
5. Press the “ON-OFF” switch on the front panel to ON (I) and check after a
few seconds if the green “ON-LINE” LED is lit only.
6. Check that the “FAULT/OVERLOAD” is not lit – if it is, you will need to
reduce the load connected to the AC outlet.
AC 3 Pin Kettle input
power connector socket
DB9
Connector

POWER TROLLEY 8 INSTRUCTION MANUAL
6
5. FRONT PANEL CONTROLS & DISPLAY
1
Power ON/OFF switch.
Operates the Power Trolley On/Off
2
Overload fault indicator
Unit ‘beeps’ continually if LED is lit
3
Load indicator 100%
LED is lit when max power is drawn
4
Load indicator 50%
LED is lit when at half load power
5
Load indicator 20%
LED is lit when minimum power drawn
6
Test button
ON-LINE and ON BAT checks (see note)
7
On Line indicator
Utility AC power is available
8
On Battery indicator
Unit running on internal batteries
9
ON AVR
Unit in Automatic Voltage Regulation
mode. Line AC voltage too high or low
10
Battery Weak/Low
LED is lit to indicate battery needs
recharging
NOTE :
If the unit is in “ON-LINE” mode, i.e. running off of the AC mains, pressing the
“TEST” button momentarily transfers the unit to run off its internal batteries to
do a check on the condition of the batteries. If the unit is in “ON BATTERY”
mode, i.e. running off of the internal batteries, pressing the “TEST” button
momentarily causes the unit to silence the buzzer.

POWER TROLLEY 8 INSTRUCTION MANUAL
7
6. RS232 INTERFACING WITH THE POWER TROLLEY
The Power Trolley 8 provides communications signals such as Power Failure,
Low Battery and External Shutdown via an RS232 DB9 cable connection to
the user’s computer. The communication protocol is:
PIN
ASSIGNMENT
2
PF : Power Failure Alarm (Closes an internal relay contact to indicate
a power failure and the Unit is in battery mode)
4
Common pin. (Signal ground for pin 5 and pin 2)
5
LB : Low Battery Alarm (Closes an internal relay contact to indicate
that battery voltage is low and shutdown is imminent)
6
RS232 RXD –Receive Data / External Shut-Down. A +5V/+12V signal
held down for 0.5 sec. when the Unit is in battery back-up mode, will
shut the Unit down 20 seconds later. The Unit will auto-restart when
line voltage recovers.
7
Ground for RS232 and External Shut Down
9
RS232 TXD Transmit Data
Baud rate
2400
Data
8
Stop
1
Parity Bit
None
1
. Free potential
contacts are available
on pin 2 and pin 5 with
4
as common.
Max. 30VDC /0,1A
2
. Standard RS232
available at pin 6, 9 and
7
system ground.

POWER TROLLEY 8 INSTRUCTION MANUAL
8
7. GENERATOR USE
If the “Power Trolley 8” is powered via a small, good quality generator, a
Genset of at least 2.5 - 3 KVA should be used. The Genset must have either
a mechanical or electronic governor / regulator installed.
Cheap small imported generators from the east should be avoided as the
output voltage is often not regulated and can damage your Power Trolley 8.
8. TROUBLESHOOTING
Problem
Check
I’ve plugged in the equipment I want
to use but there’s no power output.
Have you checked that you’ve plugged the unit
into a wall socket and that the switch is ON? Is
the Power Trolley internal battery fully charged?
Check the “BAT WEAK” LED. Is it lit?
Have you switched the “Master Switch” to ON? Is
the “ON LINE” green LED ON? Is the external
Resettable CB pushed in?
I’ve plugged in the equipment I want
to use but there’s poor power
output, the buzzer keeps beeping.
The internal battery is correctly
charged and the
“Master Switch” is ON.
Check the status of the LOAD
LEVEL LED indicators. Is the OVERLOAD LED
lit? Disconnect the equipment connected to the
Power Trolley. Reconnect the output equipment
one –by - one until you reach 100% LOAD.
The internal battery is correctly
charged, the “Master Switch” is ON
but neither the ON LINE nor ON
BAT indicators are lit.
If no LED is lit an internal problem has occurred
and the system must be sent to your nearest
Dealer to be checked out
The Power Trolley was working then
just stopped. Neither the ON LINE
nor ON BAT LED’s are lit.
The “FAULT” LED is lit.
You’ve got a problem with the internal protection
of the Power Trolley. Try switching OFF then ON
the Master Switch with the AC output plug(s)
removed. If the unit does not come back on again
you’ll have to take the unit to your Dealer to be
checked out.
The Power Trolleys are sophisticated electronic microprocessor-controlled
equipment and we recommend you do not try to open the system by yourself.
The unit contains internally high and dangerous voltages which can lead to
injuries if not handled carefully. Only let a fully qualified & authorised
electronic technician work on the system.

POWER TROLLEY 8 INSTRUCTION MANUAL
9
PRECAUTIONARY ADVICE
The manufacturer has taken all possible precautions to protect this unit
against overload, over temperature, reverse polarity, etc. If excessive
overload, excessive temperature and/or reverse polarity are applied to the
unit, the protection circuit will work but with excessive mishandling they may
give in after a while and this can cause damage to the unit. It is therefore up to
the user to connect the correct loads and to use the unit within the specified
parameters. The user must also ensure that no reverse power is fed back into
the output sockets of the system.
The unit must not be kept or operated in direct sunlight and should never be
placed in a moist or wet environment.
9. OVERLOAD RESET
You’ll see a ‘resettable’ circuit breaker on the side of the Power Trolley 8. This
is an additional safety device which will trip if you substantially overload the
unit. Disconnect the equipment you’ve connected to the AC connection
sockets, reset the breaker and try connecting with less equipment connected
to the unit.

POWER TROLLEY 8 INSTRUCTION MANUAL
10
10. TECHNICAL SPECIFICATIONS
MODEL
SINE 1548
Inverter:
Output Power Continuous
1500VA / 1000W
Max Surge Power
2000W
Output wave form
Pure Sinewave
Maximum Output Current
< 6.5 Amps
AC Input Voltage
230VAC / 50Hz
AC Output Voltage when in AC
Mode regulated with Buck and
Boost Amplifiers
230VAC / 50Hz
Output Regulation when in Inverter
mode
±5%
Very Fast Transfer Time
Typical 15 mSec
Battery low voltage alarm
YES 44V ± 0.5V
Battery low voltage shutdown
YES 42V ± 0.5V
Battery high voltage shutdown
YES 60V ± 0.5V
Efficiency AC - AC
± 90%
Auto Restart and DC Start -Up
YES
Over Temperature protection
55° C ± 5° C
Overload protection
YES
Output short circuit protection
YES
Input reverse polarity protection /
fuse protected / fuse will blow
YES (Not covered by warranty)
Resettable output circuit breaker for
additional overload protection
YES
Operating Temperature
-0° C - +45° C
Humidity
20% –90% non-condensing

POWER TROLLEY 8 INSTRUCTION MANUAL
11
10. TECHNICAL SPECIFICATIONS (continued)
Battery Charger:
Automatic High Frequency PWM
Switch Mode Battery Charger
48V / 5A
AC Input ( AC Input Range )
230VAC / 50Hz ( 180V –265V)
Charge Voltage Nominal
48VDC / Float +- 54VDC
54V±0.5V
Over Load Protection
YES
Over Temperature Protection
YES
Operating Temperature
-0 deg C - +45 deg C
With isolation transformer for
additional safety
YES
Recharge time from discharged
internal battery in
Only 8 –10 Hr
Miscellaneous:
2 x 15A SA-Socket outputs
YES
Supplied with 12 x 12V/7.2 Ah
fully sealed internal Lead Acid
Batteries in a 48VDC
configuration.
YES
Audible Alarms
YES
LED Display UPS Status
Line, Bat, AVR, Bat-Weak/Low
LED Display Load Status
20%,50%,100%,Overload,Fault
Auto temperature controlled
cooling fan
YES
Dimensions W x D x H mm
(With extended handle )
390×230×450 ( 980 )
Weight net ( With Packaging )
48Kg ( 53 Kg)

POWER TROLLEY 8 INSTRUCTION MANUAL
12
11. WARRANTY
We warrant this product against defects in equipment, materials and
workmanship for a period of 12 months from the date of purchase and will
repair or replace any defective item within the Power Trolley. The unit must be
returned in its entirety to the Dealer from which you purchased the unit. Proof
of purchase must be retained.
Warranty is subject to the unit being used in an adequately ventilated, suitable
environment and excludes any fault attributable to incorrect use, misuse or
service by unauthorised personal.
The warranty is void if the fault is due to the end user or third party causing in
particular, improper or negligent handling, improper operation or use.
Warranty repairs do not include any shipping, transportation or reinstallation
costs.
The Dealer limits liability for any damage caused to external devices
connected to the Power Trolley 8.
It is the responsibility of the end user or third party to ensure sufficient care is
taken to protect the Power Trolley 8 from incorrect connection and overload
when connected to external devices.
No claims will be considered if the Power Trolley was opened by unauthorised
personal and where the Power Trolley 8 is used for applications outside the
functional specifications for which it is intended.
Severability
If a part of the terms and conditions set out above is held invalid, void or
unenforceable due to any particular national or international legislation, it shall
not affect other parts of the terms and conditions remaining. FULL WARRANY
CONDITIONS AVAILABLE FROM SUPPLIER.
