OmniSTAR 5220HP User manual

OmniSTAR 5220HP
User Manual
Issue 1.32 Dec. 2010

OmniSTAR 5220HP User Manual
Issue 1.32 12/2010 ii
Notice to Customers
This manual has been produced to ensure the very best performance of your
OmniSTAR receiver, as well as to ensure its trouble free usage.
This publication could contain technical inaccuracies or typographical errors.
Changes are periodically made to the information herein; these changes will be
incorporated in new editions of the manual.
Should you require further assistance please contact your local dealer or the
OmniSTAR office.
OmniSTAR Customer Support and 24-Hour Help Line
The Netherlands:
OmniSTAR B.V.
Dillenburgsingel 69
2263 HW Leidschendam
The Netherlands
Tel: [phone]
Fax: [phone]
Web : www.omnistar.nl
E-Mail: [e-mail]
Australia: South Africa:
OmniSTAR Pty Ltd OmniSTAR Pty Ltd
Tel: [phone] Tel: [phone]
Fax: [phone] Fax: + 27 11 312 1774
Web : www.omnistar.com.au Web : www.omnistar.co.za
E-Mail: [e-mail] E-Mail: [e-mail]
Singapore: USA:
Fugro OmniSTAR Pte Ltd OmniSTAR Inc.
Tel: [phone] Tel: [phone]
Fax: [phone] Fax: [phone]
E-Mail: [e-mail] Web: www.omnistar.com
E-Mail: [e-mail]

OmniSTAR 5220HP User Manual
Issue 1.32 12/2010 iii
One-Year Limited Hardware Warranty
OmniSTAR B.V and its operating companies world-wide (OmniSTAR), warrants
this product to be free from defects in workmanship and material for a period of
one year from the date of original sale by OmniSTAR or its authorised dealers, to
the original purchaser or end user.
OmniSTAR reserves the right to repair and/or replace, at its option, any part or
parts found to be defective, provided such defects, in their opinion, are due to
faulty material or workmanship and are not caused by unauthorised or improper
repair or abuse, or normal wear. Purchaser shall be responsible for shipping and
insurance of the returned product for repair under this warranty. OmniSTAR will
pay shipping and insurance for the product's return to purchaser provided that the
product returned proves to be defective under this limited warranty.
This warranty applies only to normal usage of the product. It does not apply to
units or electronic circuit boards defective due to improper installation or handling.
Physical damage due to lightning or other electrical discharge and units subjected
to fresh or salt-water contamination are not covered. OmniSTAR reserves the
right not to warrant the product if, upon request, sufficient proof of recommended
installation compliance as laid out in this manual is not provided. No other
warranties are expressed or implied. No other warranties exist.
OmniSTAR assumes no responsibility for any consequential or incidental losses
or damages of any nature with respect to the use of this product.
REVISION HISTORY
Issue Date Description Check
Issue 0.1 January 2009 Initial draft derived from 5120VBS HV
Issue 1.0 January 2009 Changes made by RH HV
Issue 1.1 01 April 2009 Added Firmware upload. Nmea selection HV
Issue 1.2 19 June 2009 Added Seeding HV
Issue 1.31 08 Sep 2009 Modified AFSAT to EUSAT replaced
surveyplanner for skyfix
HV
Issue 1.32 24 Dec 2010 WEEE Waste Electrical & Electronic
Equipment Directive
HV
Manual Reference: OmniSTAR 5220HP User Manual
Copyright OmniSTAR B.V. 2010. No part of this manual can be reproduced
without the express permission of OmniSTAR B.V.

OmniSTAR 5220HP User Manual
Issue 1.32 12/2010 iv
TABLE OF CONTENTS
INTRODUCTION .................................................................................................. 8
ABOUT THIS MANUAL .......................................................................................... 8
SYSTEM FEATURES ............................................................................................. 8
RECEIVER FEATURES .......................................................................................... 9
HOUSING............................................................................................................ 9
Accessories............................................................................................ 10
RF Input ................................................................................................. 11
INSTALLATION AND SET UP ........................................................................... 13
INSTALLATION CONSIDERATIONS ........................................................................ 13
COUNTER ELECTROMAGNETIC FORCE (CEMF)................................................... 14
CABLE INSTALLATION ........................................................................................ 14
FEATURES AND INFORMATION ............................................................................ 15
One Pulse Per Second........................................................................... 15
Event marker.......................................................................................... 15
Receiver status....................................................................................... 15
MOUNTING THE RECEIVER.................................................................................. 16
POWER SUPPLY REQUIREMENTS ....................................................................... 17
OPERATING CONSIDERATIONS...................................................................... 18
NUMBER OF VISIBLE SATELLITES......................................................................... 18
MULTIPATH....................................................................................................... 18
POSITION DILUTION OF PRECISION (PDOP) ........................................................ 19
SATELLITE ELEVATIONS ..................................................................................... 19
OMNISTAR CORRECTIONS ................................................................................ 19
INTERFERENCE ................................................................................................. 19
GETTING STARTED .......................................................................................... 20
CONFIGURATION ............................................................................................... 20
INSTALLATION ................................................................................................... 20
STARTING UP THE RECEIVER .............................................................................. 21
COMMUNICATION WITH THE RECEIVER................................................................ 22
Serial ports ............................................................................................. 22
USB Ports .............................................................................................. 22
USB Logging .......................................................................................... 23
THE MENU SYSTEM ......................................................................................... 24
TOP MENUI.................................................................................................... 27
GPSI.................................................................................................... 27
L-BandI................................................................................................ 27
Config WizardI..................................................................................... 27
System SetupI..................................................................................... 27
GPSI............................................................................................................ 28
Position statusI.................................................................................... 28
SatellitesI............................................................................................. 29

OmniSTAR 5220HP User Manual
Issue 1.32 12/2010 v
ConfigureI............................................................................................ 29
L-BANDI........................................................................................................ 30
Signal StatusI....................................................................................... 30
ConfigureI............................................................................................ 30
SubscriptionI........................................................................................ 30
Diff IL-Band.......................................................................................... 30
CONFIG WIZARDI............................................................................................ 31
Proceed WizardI.................................................................................. 31
Save CurrentI....................................................................................... 31
Delete SavedI...................................................................................... 31
Use Previous .......................................................................................... 32
CancelI................................................................................................. 32
SYSTEM SETUPI............................................................................................. 33
Display AppsI....................................................................................... 33
Display FormatI.................................................................................... 33
Baud RatesI......................................................................................... 33
Display LogsI....................................................................................... 33
Software DispI...................................................................................... 34
ContrastI.............................................................................................. 34
AnimationIOff ....................................................................................... 34
SubscriptionI........................................................................................ 34
Flip DisplayINO .................................................................................... 34
LCD OffInever...................................................................................... 34
LanguageI............................................................................................ 34
DATA LOGGINGI............................................................................................. 35
ConfigI................................................................................................. 35
Start RecordingI................................................................................... 35
TERMINAL COMMANDS................................................................................... 36
BASIC COMMANDS............................................................................................. 37
$JI .......................................................................................................... 38
$JSHOW ................................................................................................ 39
$JT ......................................................................................................... 41
$JAGE.................................................................................................... 41
$JMASK ................................................................................................. 42
$JNP ...................................................................................................... 42
$JASC.................................................................................................... 43
$JOFF .................................................................................................... 44
$JAPP .................................................................................................... 44
$JBAUD ................................................................................................. 45
$JRESET ............................................................................................... 45
$JSAVE.................................................................................................. 46
OMNISTAR COMMANDS .................................................................................... 47
$JFREQ ................................................................................................. 48
$JLBEAM ............................................................................................... 49
$JLBEAMEX........................................................................................... 50
$JGEO ................................................................................................... 51
$JOMS ................................................................................................... 52
$JLIMIT .................................................................................................. 52

OmniSTAR 5220HP User Manual
Issue 1.32 12/2010 vi
$JASC,D1 .............................................................................................. 53
$JOMD ................................................................................................... 54
SEEDING........................................................................................................ 55
$JHP,POS,PRESENT ( or $JHP,POS,P ) ............................................ 55
$JHP,POS.............................................................................................. 55
$JHP,SEED, lat,lon,hgt .......................................................................... 56
NMEA MESSAGES ............................................................................................ 57
APPENDIX A...................................................................................................... 58
TECHNICAL SPECIFICATIONS .............................................................................. 58
Signals ................................................................................................... 58
Environmental ........................................................................................ 58
Data inputs & outputs ............................................................................. 58
Connectors............................................................................................. 58
Power ..................................................................................................... 59
Physical Characteristics ......................................................................... 59
Position Accuracy................................................................................... 59
Initialisation times: .................................................................................. 59
Signal Reacquisition ............................................................................... 59
Dynamics ............................................................................................... 59
Data Pin-out ........................................................................................... 60
Standard Accessories............................................................................. 60
APPENDIX B...................................................................................................... 61
NMEA 0183 MESSAGE OPTIONS........................................................................ 61
NMEA 0183 MESSAGE FORMATS ...................................................................... 61
GGA –GPS Fix Data ........................................................................ 62
GLL –Geographic Position - Latitude/Longitude .............................. 63
RRE –GPS Range Residual Error.................................................... 63
GSA –GPS DOP and Active Satellites............................................. 64
GST –GPS Pseudorange Noise Statistics ....................................... 65
GSV –GPS Satellites in View........................................................... 66
RMC –Recommended Minimum Specific GPS Data ........................ 67
VTG –Course Over Ground and Ground Speed............................... 68
ZDA –Time and Date....................................................................... 69
APPENDIX C...................................................................................................... 70
ACRONYMS USED IN THIS MANUAL ...................................................................... 70
APPENDIX D...................................................................................................... 72
USB DRIVER FOR 5220HP ................................................................................ 72
APPENDIX E...................................................................................................... 74
UPDATING THE 5220HP FIRMWARE .................................................................... 74
INSTRUCTIONS FOR LOADING THE FIRMWARE FOR THE 5220HP : .......................... 74
APPENDIX F...................................................................................................... 75
OMNISTAR REFERENCE STATIONS..................................................................... 75

OmniSTAR 5220HP User Manual
Issue 1.32 12/2010 vii
APPENDIX G ..................................................................................................... 76
TEST RESULTS.................................................................................................. 76
APPENDIX H...................................................................................................... 78
RECEIVER SERVICE PROCEDURE ....................................................................... 78
APPENDIX I ....................................................................................................... 79
OMNISTAR RECEIVER PROBLEM REPORT FORM ................................................ 79
APPENDIX J ...................................................................................................... 80
MECHANICAL DRAWING FOR MOUNTING............................................................... 80
APPENDIX K...................................................................................................... 82
WEEE: WASTE ELECTRICAL & ELECTRONIC EQUIPMENT DIRECTIVE ................... 82
WASTE TREATMENT ON YOUR OWN RESPONSIBILITY ............................................ 82
ECOLOGICAL BACKGROUND ............................................................................... 82
LIST OF FIGURES
Figure 1: 5220HP Back Panel ............................................................................ 10
Figure 2: Ant-Aero-06 antenna ........................................................................... 11
Figure 3: Drawing Ant-Aero-06 antenna.............................................................. 12
Figure 4: Multipath.............................................................................................. 18
Figure 5: the receiver home screen .................................................................... 26
Figure 6: Example of an Easylog window ........................................................... 36
Figure 7: DB9 pin layout on receiver (female connector) .................................... 60
Figure 8: screen view of PORTS in device manager........................................... 73
LIST OF TABLES
Table 1: 5220HP Interfaces ................................................................................ 10
Table 2: Basic commands .................................................................................. 37
Table 3: OmniSTAR commands......................................................................... 47
Table 4: OmniSTAR beams worldwide ............................................................... 48

OmniSTAR 5220HP User Manual
Issue 1.32 12/2010 8
Introduction
About This Manual
This manual has been produced to assist the typical user with the installation
and operation of the OmniSTAR 5220HP DGPS Receiver.
System Features
The OmniSTAR 5220HP DGPS Receiver is part of the OmniSTAR worldwide
DGPS Service. The OmniSTAR service is a full-time differential GPS (DGPS)
broadcast system delivering corrections from an array of GPS reference
stations located around the globe. Reference stations provide industry
standard formatted corrections to Network Control Centres (NCC’s) at strategic
geographic locations, where the corrections are decoded, checked, and
repackaged in a highly efficient format for broadcast. The data is modulated
onto an RF carrier that is then up-converted for transmission to an L-band
communications satellite.
The signals are received at the user's location by an antenna, demodulated by
areceiver, and are made available, after selection of the desired individual
reference site's data set, as corrections for use in a GPS, differential-capable,
receiver.
The OmniSTAR 5220HP receivers support the following OmniSTAR®service:
VBS,this is the Virtual Base Station service where single frequency GPS code
and phase measurements are used to create RTCM corrections data
optimised for the users current position.
HP,this is the OmniSTAR High Performance solution using ground reference
stations giving decimetre level accuracy using dual GPS frequency code and
phase measurements
XP,this is the OmniSTAR eXtended Performance solution using precise
satellite orbit and clock corrections giving decimetre level accuracy worldwide
using dual GPS frequency code and phase measurements
HP+,this is the combined mode in which corrections from HP and XP are
merged to give one seamless worldwide decimeter level solution.

OmniSTAR 5220HP User Manual
Issue 1.32 12/2010 9
Receiver Features
The OmniSTAR 5220HP receiver has the following features:
•12 parallel GPS code/carrier tracking channels (L1/L2 code and
carrier) and 3 additional L1 channels.
•LCD top panel display
•Receiver configuration using the front panel
•5cm accuracy (RMS), assuming at least five satellites and a
PDOP (Position Dilution of Precision)
•Input Voltage 8 to 36 VDC
•Low power consumption (typically < 5.8 Watt at 12 VDC)
•1, 5, 10 Hz position output data user selectable, (20 Hz optional)
•Arugged, environmentally-sealed enclosure
•Two RS232 data ports with DB9 connectors, supporting the
following protocols:
RS-232:
NMEA-0183 output,
RTCM SC-104 input and output,
ASCII input, proprietary binary input (if enabled)
1PPS (1 Pulse per second) strobe signal to enable an external
instrument to synchronize its internal time with a time derived
from the very accurate GPS system time.
Event marker
•GPS antenna connector
•1USB 2.0 type B connector to connect a computer
•1USB type A connector to connect a USB 2.0 Memory Stick
Housing
The 5220HP is housed in an enclosure to provide a complete receiver solution.
When connected to an antenna and a power source, the 5220HP is a fully
functioning GPS receiver.
The enclosure offers protection against environmental conditions and RF
interference. In addition, it provides an easy-to-use interface to the data, power
and status signals of the GPS card and a rugged, water, shock and vibration
resistant housing for outdoor applications.

OmniSTAR 5220HP User Manual
Issue 1.32 12/2010 10
Accessories
The following accessories are included with the 5220HP:
•1power cable
•1RS232 data cable
•1USB cable (to connect a computer)
•1antenna cable (5 meters)
•ACD containing PC utilities and product documentation
•
Figure 1: 5220HP Back Panel
Name Description
ON/OFF On/off power switch
POWER 8 - 36 V DC power input
Antenna Antenna connection 50 ohm
DATA COM USB type B wired connector
MEM Stick USB type A port for USB Memory stick
PORT A RS-232 signals,
PORT B RS-232 signals, 1PPS and auxiliary strobe signal
GROUND An extra ground terminal for grounding your receiver
Table 1: 5220HP Interfaces

OmniSTAR 5220HP User Manual
Issue 1.32 12/2010 11
RF Input
The 5220HP is designed to work with active GPS antennas with a LNA gain of
10 to 40 dB. The purpose of this LNA gain above the minimum requirement of
10 dB is to accommodate for losses in the cable system. Essentially, there is a
maximum cable loss budget of 30 dB for a 40 dB gain antenna. Depending on
the chosen antenna, the loss budget will likely be lower (a 24 dB gain antenna
would have a 14 dB loss budget).
When using an antenna and antenna cable please make sure not to exceed
the loss budget. Otherwise, the tracking performance of the 5220HP will be
compromised.
The standard antenna for the 5220HP receiver is the Ant-Aero-06 antenna.
Figure 2: Ant-Aero-06 antenna

OmniSTAR 5220HP User Manual
Issue 1.32 12/2010 12
Figure 3: Drawing Ant-Aero-06 antenna

OmniSTAR 5220HP User Manual
Issue 1.32 12/2010 13
Installation and Set Up
Installation Considerations
Before commencing installation of the OmniSTAR 5220HP in a vehicle or
aircraft, the following should be considered:
•Determine the preferred location for each unit. Consider cable length,
connector attachment space (cable bend radius), stowing excess cable,
moisture, chemical corrosion, vibration and heat exposure.
•Before drilling holes, consider using existing hardware and locations
where equipment was previously installed. Avoid drilling holes that may
damage other equipment (e.g. structural frame members, electrical
cables or fluid lines).
•High vibration and high temperature locations should be avoided
whenever possible.
•In application where vibration exceeds 5Gs acceleration, shock mounts
are required. (Refer to Customer support for mounting
recommendations).
•Vehicle primary power has voltages that may be harmful to personnel and
equipment. Disconnect the battery cable from the battery (negative)
terminal before making connection to any power terminal within the
vehicle.

OmniSTAR 5220HP User Manual
Issue 1.32 12/2010 14
Counter Electromagnetic Force (CEMF)
Apotential problem inherent in any installation of electronic systems within a
vehicle is Counter Electro-Magnetic Force (CEMF).
CEMF is caused when relays or solenoids, connected to the vehicle DC power
distribution, are de-energised. The voltage produced may exceed 400 volts.
CEMF is produced by equipment such as the following:
•Electric fan brakes
•Air conditioners
•Starter relays
•Electric pump relays
CEMF is more than sufficient to damage or cause erratic operation of any
electronic system that is also connected to the same vehicle DC power supply.
CEMF can be eliminated by installing diodes at the relays and solenoids that
cause the problem, and more importantly at the power supply cable
connections on the receiver.
Cable Installation
Cables must be correctly installed for optimum system operation. Therefore,
the following should be noted:
•Do not route an L-Band receiver remote antenna cable with the cabling of
any other radio system. This may cause interference between both
systems.
•If at all possible, do not run L-Band receiver antenna cables parallel to
other radio system cabling closer than 30 centimetres.
•If cables must cross, ensure that they cross at an angle of 90°. This
minimises the possibility of interference.
•As far as is practicable, ensure that cables and I/O connectors are unique
and fit only in their allocated location.
•Avoid routing cables along-side power generator cabling and other high
electrical noise sources. This can cause interference.

OmniSTAR 5220HP User Manual
Issue 1.32 12/2010 15
•Do not kink cables or force cables into sharp bends that may damage the
cables and cause system failure.
•After installation, ensure that excess cable is looped and clamped or tied
safely away from any control cables, fuel lines, hydraulic lines or moving
parts.
•When stowing over length cabling, form loops not less than 150 mm
minimum cable bend radius.
•Cable routing must avoid high temperature exposure
(e.g. exhaust manifold).
Features and Information
This section contains information on the features of the 5220HP receiver.
One Pulse Per Second
The strobe available on the 5220HP is the One Pulse Per Second (1 PPS)
signal. The output is 3.3 Volts and duration is 1 microsecond. ( Port B, pin 9 )
The rising edge of this signal is synchronised with GPS time.
Event marker
Event marker input creates the possibility to generate a marker with for
instance a camera that shows up in the data stream. The marker is active low,
falling edge sync, 10 k-ohm, 10 pF load. ( Port B, pin 6 )
Receiver status
The 5220HP is equipped with an LCD display showing the status of the
receiver. Using the display and the buttons around the display, the receiver
can be configured without the need to connect a computer. The functions of
the LCD display and the configuration menus are described further on in this
manual.

OmniSTAR 5220HP User Manual
Issue 1.32 12/2010 16
Mounting the receiver
The 5220HP casing is equipped with two mounting brackets to facilitate
mounting the receiver to a surface. This section provides information on how
to mount the receiver.
Note: The receiver casing was not designed for mounting in high-dynamics or
high-vibration environments.
To mount the 5220HP receiver:
1. Use the slots on the side of the receiver to place the mounting brackets.
2. Mark where the holes need to be and then drill holes in the mounting
surface.
3. Use screws to secure the casing to the mounting surface. When using
machine screws, tap the mounting holes to fasten the receiver to the
mounting surface. Alternatively, self-tapping screws can be used.
4. Make sure not to mount the receiver in a location where it can easily be
damaged during normal operation. Try to protect the receiver against
harsh environmental conditions.
When choosing a mounting location, please ensure the menu screen, LEDs
and buttons are visible and accessible. Also make sure it is possible to access
the back panel, in order to switch cables or operate the power button. There is
an option within the menu system to switch the direction of the display, so if it
is easier for you to mount the unit upside down, you may do so and still
operate the display easily.

OmniSTAR 5220HP User Manual
Issue 1.32 12/2010 17
Antenna Location
Antenna positioning is critical to system performance.
The following conditions must be met for optimum system performance:
1. Antenna must be mounted at least 1.5 metres away from transmitting
antennas of any frequency. Closer positioning may cause overloading of
receiver RF circuits.
2. The antenna should be mounted at the highest practical point that will
give a good view of the horizon and be as near level as possible.
3. The antenna must be located along the vehicle centre-line, or at a
relevant reference point on the vehicle.
4. The antenna should not be mounted in a location where it can easily be
damaged during normal operation.
Power Supply Requirements
The 5220HP can be powered by a vehicle or by a customer-supplied power
source of 8-36 VDC, capable of delivering at least 6W continuous output
power. For continued protection against the risk of fire, the power lead to the
5220HP receiver should be provided with a 10 Ampere (maximum) fuse.
Warning: Before powering the receiver, make sure the antenna
cable and antenna are connected and the power and data
cable is connected and secured. Connecting or
disconnecting an antenna or antenna cable when the
receiver is already powered may permanently damage the
receiver’s antenna port or the antenna itself, voiding your
warranty. Connecting or disconnecting the power/data
cable to/from the receiver when the cable is already
powered may result in increased wear or an early failure of
the power/data connector.
Warning: If the voltage supplied is below the minimum specification,
the receiver will suspend operation. If the voltage supplied
is above the maximum specification, the receiver may be
permanently damaged, voiding your warranty.

OmniSTAR 5220HP User Manual
Issue 1.32 12/2010 18
Operating considerations
The 5220HP has proven to be a high-quality positioning device. The accuracy
that the user can obtain depends on several factors, including:
•Number of visible satellites
•Multipath
•Dilution of Precision (DOP)
•Satellite elevations
•OmniSTAR corrections
Number of visible satellites
Aminimum of four satellites is required to calculate a 3-dimensional position.
In general it can be said that every increase in the number of visible satellites
will result in an increase in the systems’ accuracy. As the GPS satellites orbit
the earth the number of visible satellites will change in time. The GPS
constellation has been designed to provide a minimum of 4 visible satellites at
any location at all times. The number of visible satellites can decrease due to
blockage by objects such as trees and buildings.
Multipath
It is possible for satellite signals to reflect off large nearby objects such as
buildings, cars or even the ground, thereby resulting in an erroneous
distance measurement. This phenomenon is known as multipath. Multipath
can cause significant errors in the position determination and it is therefore
important to place the receiver in an environment, which is free of large
reflective surfaces. It is also recommended to mount the receiver directly
onto a surface, while maintaining a clear view of the sky in all directions.
Figure 4: Multipath

OmniSTAR 5220HP User Manual
Issue 1.32 12/2010 19
Position Dilution of Precision (PDOP)
The Position Dilution of Precision (PDOP) is a measure of the satellite
geometry. The closer to 1 the PDOP value, the more accurate the GPS
position will be.
Satellite elevations
The signal from a satellite that is low on the horizon will travel a greater
distance through the atmosphere. This results in lower signal strength and a
delayed reception, thereby causing erroneous and noisy data. By default the
5220HP is configured to ignore any GPS satellites that have an elevation
angle lower than 8°.
OmniSTAR corrections
For accurate positioning it is essential that the differential corrections are
received. In order to ensure reception of the OmniSTAR satellite signal the line
of sight towards the satellite must not be blocked by objects such as trees and
buildings. To find out which OmniSTAR satellite(s) can be received at your
geographic position, please visit the survey planner website
(http://www.surveyplanner.com).
Interference
Although the 5220HP has been designed to provide optimal system
performance under most circumstances, due to the nature of radio
communications it is possible, that the system performance degrades as a
result of local interference sources. When interference levels are too high, the
5220HP may even lose lock to either the OmniSTAR satellite or the GPS
satellites.
Interference sources include radio and television transmitters, radars,
microwave ovens, poorly shielded spark plugs and aeronautical radio
navigation systems, in short: any device producing electromagnetic energy
(directly or through harmonic frequencies) in the 1525 - 1580 MHz band.

OmniSTAR 5220HP User Manual
Issue 1.32 12/2010 20
Getting started
The purpose of this section is to get you started with the 5220HP as quickly as
possible.
Configuration
Generally, when the receiver is supplied, it will be configured for the mode and
data link(s) you have subscribed to. In most cases getting up and running will
be a easy as connecting the appropriate cables and applying power to the
system.
Configuring the receiver via direct commands will be treated later in the
section “Communication with the Receiver”
If at any time you need to return the menu system to the factory default
configuration, simply hold down the “enter” key on power-on until the splash
screen disappears.
Installation
Before operating the receiver for the first time, ensure that the installation
instructions (below) have been followed correctly.
1. Mount the 5220HP receiver in a suitable place (see page 16).
2. Mount the OmniSTAR Aero-06 antenna in a suitable place (see page 17).
3. Connect the antenna to the receiver using an antenna cable, making sure
that both connectors are secured well. Secure the antenna cable using tie
wraps.
4. Connect the data cable to port A of the 5220HP receiver.
5. Connect the receiver to a suitable (8-36 V DC) power supply using the
powercable.
