Omnitron Systems Technology 12/08 User manual

iConverter
iConverter®NMM
Network Management Module
iConverter
TheiConverterNetworkManagementModule(NMM)istheheart
of the iConverter management system. It supports SNMPv1,
SNMPv2c,SNMPv3 andTelnetprotocols, andfeaturesa32-bit,
high performance RISC microprocessor executing a real-time
operatingsystem. SMNPv3provides secure accesstodevices
bya combinationof authenticatingand encryptingpackets over
thenetwork.
TheNMM manages allconvertersand chassis powersupplies
withinitsmanagementdomain (modulesandchassisconnected
to the NMM), continuously collecting status and module
information. It reports the collected status via the SNMP
protocoltothe network managementapplications.
The NMM features a serial port for initial configuration, a
front-planeRJ-45 Ethernetport,a backplaneEthernet portand
a pair of multi-chassis cascade ports.
The Ethernet backplane port is used to connect adjacent
iConverter modulesinthesamechassis(in-bandmanagement),
offeringdirectEthernet backplaneaccesstotheNMM. External
management(out-of-band) isaccomplishedvia thefront-plane
Ethernetport, facilitating IPbased elementmanagement using
NetOutlook®or third-partySNMP management applications.
TheNMM utilizesOperations,AdministrationandMaintenance
(OAM) services for carrier-grade network access with
comprehensiveprovisioning andnetworkmonitoring. It features
IP-basedandIP-lessmanagementofiConverter equipmentwithin
themanagementdomain.
The NMM supports IP-less management through the IEEE
802.3ah management channel and Omnitron’s Secure and
encrypted management channel. With IP-less management,
an NMM in a chassis at the network core can manage up to 18
iConverterNetwork Interface Devices (NIDs) at different edge
locations with a single IP address. This capability simplifies IP
addressmanagement,improvesnetworksecurity,andconserves
the use of IP addresses.
Whenmanaging high-densityconfigurations inaCentral Office
or network core, the NMM can cluster (daisy-chain) up to 19
chassis into a single IP address. In this configuration, NMM
moduleswithin each chassisare connected toeachother over
ahigh speed serial connection.
TheiConverter NMM provides real-timemanagement,
trapnotification and remote configurationof iConverter
equipmentwithinthe same domain
Utilizes IEEE 802.3ah and Omnitron’s Secure
IP-LessOAM management channelsfor managing
remote chassis in the same domain
Up to nineteen chassis can be linked to form a domain
and be managed by a single IP address
Managedvia the Ethernetbackplane, thefront-plane
RJ-45Ethernet port, orthefront-plane serial port
SupportsSNMPv1, SNMPv2c,SNMPv3 andTelnet
protocols
SupportsDying Gasp powerloss trap notification
SNMP management viaOmnitron’s NetOutlook
managementsoftware, or third-partySNMP
managementsoftware
Passwordprotected to preventunauthorizedaccess
LED displays for immediate visual status of each port
Hot-swappablein 19-Module,5-Module, or2-Module
chassis
LifetimeWarrantyandfree 24/7Technical Support

800-675-8410 • 949-250-6510 • www.omnitron-systems.com • [email protected] • 140 Technology Dr. • Irvine, CA 92618
Trademarksare ownedby their respectivecompanies. iConverterandNetOutlook are registeredtrademarks ofOmnitron SystemsTechnology,Inc.
Specificationssubjectto changewithout notice.©2008 OmnitronSystemsTechnology,Inc. All rightsreserved.
091-18000-001H 12/08
Alarms / Traps
• Warm Start
• Link Up/Down
• Chassis Insertion/Removal
• Authentication Failure
• DIP-Switch Configuration Change
• Software Configuration Change
• Temperature Out-of-Range
• Power Supply Out-of-Range
• Power Supply Insertion/Removal
• Chassis Reset
• Module Reset
• Module Insertion/Removal
• Port Link State Change
• Redundancy Primary Up/Down
• Redundancy Secondary Up/Down
• FTP Session Open/Close
• Telnet Session Open/Close
• Dying Gasp (Power Loss Trap)
Active Controls
• Link Propagate/Link Segment
• Remote Fault Detection
• Module Name
• Chassis Name and Number
• IP Address
• 802.3ah OAM Enable
• Secure IP-less OAM Enable
• Subnet Mask
• Gateway
• Management Port Disable
• Alarm Threshold Setting
• Download Software via FTP
• Reset Chassis
• Telnet
• Trap IPs
• FTP Enable
• Password Selection
• Soft Switch Reload
IP-lessmanagement requiresan NMMin thecorechassis,and
amediaconverterwith integratedmanagementinstalledateach
remoteendoftheIP-lessmanagedlink. AniConverter10/100M2
plug-in module is installed in the 19-Module chassis, and
connectedvia the fiberlink toa standalone 10/100M2Network
InterfaceDevice(NID).Thisconfigurationenablesthe19-Module
master chassis to establish an IP-less management channel
between the 10/100M2 link partners. The IP address
resides only at the network core, and does not exist on the
customernetwork.
Model Description
8000-0 iConverter NMM Module w/ Dying Gasp Support
8080-3 NMM Cascade Cable (3 ft.)
8081-3 NMM Serial Cable (DB-9, 3 ft.)
Model Type NMM
Protocols IP, UDP, SNMPv1, SNMPv2c, SNMPv3,
Telnet, TCP, FTP, ARP, ICMP, 802.3ah
Connectors RJ-45, DB-9
Controls UTP cross-over, Frontplane / Backplane
LED Displays Power, Power Supply (3), UTP link,
Master, Slave, Mgt. Poll
Supported MIBs RFC1155, RFC1156, RFC1157,
RFC1212, RFC1213, OST MIB
Dimensions W:0.85" x D:4.5" x H:2.8"
Weight 8 oz.
Compliance UL, CE, FCC Class A, NEBS 3
Power Requirement 0.32A @ 3.3VDC (typical)
Temperature Standard: 0 to 50º C
Wide: -40 to 60ºC
Storage: -40 to 80º C
Humidity 5 to 95% (non-condensing)
Altitude -100m to 4000m
MTBF (hrs) 786,000
Chassis Information
• Part Number
• Serial Number
• Revision
• Description
Chassis Status
• Power Status
• Power Output Voltage
• Chassis Temperature
Module Status
• Module Power
• Link Status
• ActivePort
• Diagnostic Status
• Management
Module Information
• Module Type
• Slot Occupied
• Part Number
• Serial Number
• Configuration
• Revision
• Ports on Module
• User-defined Identifier
