Omron ZR-RX40 User manual

User's Manual
Portable Multi Logger
ZR-RX40
Cat. No. Z260-E1-04
Portable Multi LoggerZR-RX40 User's Manual
Authorized Distributor:
In the interest of product improvement,
specifications are subject to change without notice.
Cat. No. Z260-E1-04
Printed in Japan
1209-0.5C (0407) (M)
© OMRON Corporation 2009 All Rights Reserved.
OMRON Corporation Industrial Automation Company
OMRON ELECTRONICS LLC
One Commerce Drive Schaumburg,
IL 60173-5302 U.S.A.
Tel: [phone]/Fax: [phone]
Contact: www.ia.omron.com
Tokyo, JAPAN
OMRON ASIA PACIFIC PTE. LTD.
No. 438A Alexandra Road # 05-05/08 (Lobby 2),
Alexandra Technopark,
Singapore 119967
Tel: [phone]/Fax: [phone]
OMRON (CHINA) CO., LTD.
Room 2211, Bank of China Tower,
200 Yin Cheng Zhong Road,
PuDong New Area, Shanghai, 200120, China
Tel: [phone]/Fax: [phone]
Regional Headquarters
OMRON EUROPE B.V.
Sensor Business Unit
Carl-Benz-Str. 4, D-71154 Nufringen, Germany
Tel: [phone]/Fax: [phone]

Introduction
Registered Trademarks
Type of Manuals
Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corp. in the
United States and/or other countries.
Other product and company names herein may be either registered trademarks or trademarks
of their respective owners.
The manuals of the ZR-RX40 series consist of the following.
Select the manual suitable for your purpose and read it before starting operation.
The basic information to use the ZR-RX40 series is described,
such as the information for safe and correct use, confirmation
of the package, procedure from connection to measurement,
and the information of functions and specifications of the ZR-RX40
series.
Manuals contained in the utility CD-ROM (pdf data)
Software Manual
Information for installing PC software, basic operation, explanation
of screen and setting methods is described.
Two PC software manuals are contained:
·Special PC software "Wave Inspire RX"
·Basic PC software "Smart Viewer RXW"
User's Manual (this manual)
·Information for safe and correct use
·Before use: connection and wiring in details, language change
of display, etc.
·Procedure in details for setting and measurement
·Specifications of the ZR-RX40 series and accessories
·Other information which is required for the use of the ZR-RX40
series
Manual packaged in the product (brochure)
This manual provides information regarding functions, performance and operating methods that are
required for using the ZR-RX40.
When using the ZR-RX40, be sure to observe the following:
The ZR-RX40 must be operated by personnel knowledgeable in electrical engineering.
To ensure correct use, please read this manual thoroughly to deepen your understanding of the product.
Please keep this manual in a safe place so that it can be referred to whenever necessary.
User's Manual (this manual)User's Manual (this manual)

1
1
2
3
4
User's Manual
APPLICATION CONSIDERATIONS
(Please Read)
BEFORE USE
SETTINGS AND MEASUREMENT
SPECIFICATIONS
Portable Multi Logger
ZR-RX40
APPENDIX
ZR‑RX40UME.book 1 ページ ２００９年１２月１１日 金曜日 午前１０時５８分

2ZR-RX40 User’s Manual
READ AND UNDERSTAND THIS DOCUMENT
Please read and understand this document before using the products. Please consult your OMRON
representative if you have any questions or comments.
WARRANTY
OMRON’s exclusive warranty is that the products are free from defects in materials and workmanship for a
period of one year (or other period if specified) from date of sale by OMRON.
OMRON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, REGARDING NON-
INFRINGEMENT, MERCHANTABILITY, OR FITNESS FOR PARTICULAR PURPOSE OF THE PRODUCTS.
ANY BUYER OR USER ACKNOWLEDGES THAT THE BUYER OR USER ALONE HAS DETERMINED THAT
THE PRODUCTS WILL SUITABLY MEET THE REQUIREMENTS OF THEIR INTENDED USE. OMRON
DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED.
LIMITATIONS OF LIABILITY
OMRON SHALL NOT BE RESPONSIBLE FOR SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES,
LOSS OF PROFITS OR COMMERCIAL LOSS IN ANY WAY CONNECTED WITH THE PRODUCTS,
WHETHER SUCH CLAIM IS BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT LIABILITY.
In no event shall responsibility of OMRON for any act exceed the individual price of the product on which
liability is asserted.
IN NO EVENT SHALL OMRON BE RESPONSIBLE FOR WARRANTY, REPAIR, OR OTHER CLAIMS
REGARDING THE PRODUCTS UNLESS OMRON’S ANALYSIS CONFIRMS THAT THE PRODUCTS WERE
PROPERLY HANDLED, STORED, INSTALLED, AND MAINTAINED AND NOT SUBJECT TO
CONTAMINATION, ABUSE, MISUSE, OR INAPPROPRIATE MODIFICATION OR REPAIR.
SUITABILITY FOR USE
THE PRODUCTS CONTAINED IN THIS DOCUMENT ARE NOT SAFETY RATED. THEY ARE NOT DESIGNED OR
RATED FOR ENSURING SAFETY OF PERSONS, AND SHOULD NOT BE RELIED UPON AS A SAFETY COMPO-
NENT OR PROTECTIVE DEVICE FOR SUCH PURPOSES.
Please refer to separate catalogs for OMRON’s safety rated products.
OMRON shall not be responsible for conformity with any standards, codes, or regulations that apply to the
combination of products in the customer’s application or use of the product.
At the customer’s request, OMRON will provide applicable third party certification documents identifying ratings
and limitations of use that apply to the products. This information by itself is not sufficient for a complete
determination of the suitability of the products in combination with the end product, machine, system, or other
application or use.
The following are some examples of applications for which particular attention must be given. This is not
intended to be an exhaustive list of all possible uses of the products, nor is it intended to imply that the uses
listed may be suitable for the products:
• Outdoor use, uses involving potential chemical contamination or electrical interference, or conditions or
uses not described in this document.
ZR‑RX40UME.book 2 ページ ２００９年１２月１１日 金曜日 午前１０時５８分

ZR-RX40 User’s Manual 3
• Nuclear energy control systems, combustion systems, railroad systems, aviation systems, medical
equipment, amusement machines, vehicles, safety equipment, and installations subject to separate industry
or government regulations.
• Systems, machines, and equipment that could present a risk to life or property.
Please know and observe all prohibitions of use applicable to the products.
NEVER USE THE PRODUCTS FOR AN APPLICATION INVOLVING SERIOUS RISK TO LIFE OR
PROPERTY WITHOUT ENSURING THAT THE SYSTEM AS A WHOLE HAS BEEN DESIGNED TO
ADDRESS THE RISKS, AND THAT THE OMRON PRODUCT IS PROPERLY RATED AND INSTALLED FOR
THE INTENDED USE WITHIN THE OVERALL EQUIPMENT OR SYSTEM.
PERFORMANCE DATA
Performance data given in this document is provided as a guide for the user in determining suitability and does
not constitute a warranty. It may represent the result of OMRON’s test conditions, and the users must correlate
it to actual application requirements. Actual performance is subject to the OMRON Warranty and Limitations of
Liability.
CHANGE IN SPECIFICATIONS
Product specifications and accessories may be changed at any time based on improvements and other
reasons.
It is our practice to change model numbers when published ratings or features are changed, or when significant
construction changes are made. However, some specifications of the product may be changed without any
notice. When in doubt, special model numbers may be assigned to fix or establish key specifications for your
application on your request. Please consult with your OMRON representative at any time to confirm actual
specifications of purchased products.
DIMENSIONS AND WEIGHTS
Dimensions and weights are nominal and are not to be used for manufacturing purposes, even when
tolerances are shown.
ERRORS AND OMISSIONS
The information in this document has been carefully checked and is believed to be accurate; however, no
responsibility is assumed for clerical, typographical, or proofreading errors, or omissions.
PROGRAMMABLE PRODUCTS
OMRON shall not be responsible for the user’s programming of a programmable product, or any consequence
thereof.
COPYRIGHT AND COPY PERMISSION
This document shall not be copied for sales or promotions without permission.
This document is protected by copyright and is intended solely for use in conjunction with the product. Please
notify us before copying or reproducing this document in any manner, for any other purpose. If copying or
transmitting this document to another, please copy or transmit it in its entirety.
ZR‑RX40UME.book 3 ページ ２００９年１２月１１日 金曜日 午前１０時５８分

4ZR-RX40 User’s Manual
The following signal words are used in this manual.
The following alert symbols are used in this manual.
Meanings of Signal Words
Indicates a potentially hazardous situation which, if not avoided, will result in minor
or moderate injury, or may result in serious injury or death. Additionally there may
be significant property damage.
Indicates a potentially hazardous situation which, if not avoided, may result in
minor or moderate injury or in property damage.
Meanings of Alert Symbols
Indicates the possibility of explosion under specific conditions.
Indicates the possibility of electric shock under specific conditions.
Indicates prohibition when there is a risk of minor injury from electrical shock or other
source if the product is disassembled.
Indicates general prohibitions for which there is no specific symbol.
ZR‑RX40UME.book 4 ページ ２００９年１２月１１日 金曜日 午前１０時５８分

ZR-RX40 User’s Manual 5
The following alert statements apply to the products in this manual. Each alert statement also appears at the
locations needed in this manual to attract your attention.
Alert Statements in this Manual
This product cannot be used for directly or indirectly detecting human bodies to ensure
safety.
Do not use this product as a human body protection device.
Serious hazard may occur in rare occasions due to ignition, rupture or combustion of
the lithium battery contained in this product.
Never disassemble, deform under pressure, heat or incinerate this product.
Serious hazard may occur in rare occasions due to ignition, rupture or combustion.
Never disassemble, deform under pressure, heat or incinerate the lithium ion battery
pack ZR-XRB1 (GRAPHTEC: B-517).
Injuries from electric shock may occur in rare occasions as the result of disassembly.
Never disassemble, deform under pressure or incinerate the main unit.
Hazard may occur from serious fire or electric shock.
Do not connect voltages exceeding the rated voltage to the signal input terminals.
Fire or hazard may occur in rare occasions from ignition, rupture or combustion.
Do not use battery packs other than ZR-XRB1.
ZR‑RX40UME.book 5 ページ ２００９年１２月１１日 金曜日 午前１０時５８分

6ZR-RX40 User’s Manual
Be sure to observe the following items as they are very important to ensure safety.
1.Installation environment
• Do not store or use in locations where the temperature exceeds the rated range.
• Do not use in locations where the relative humidity exceeds the 30 to 80 %RH range.
• Do not use in locations subject to steam.
• Do not use in flammable or explodable gas environment.
2.Power supply and wiring
• Do not connect voltages exceeding the rated voltage to signal cables.
• Be sure to check the polarity of the signals when connecting the signal cables.
• When using the battery pack, be sure to read the cautions on the battery pack carefully for correct usage.
• Be sure to use only the specified battery pack.
• Be sure to use only the AC cable and the AC adapter provided as standard accessories.
• Do not connect power supplies exceeding the rated voltage to the AC adapter.
• Be sure to turn off the power supply when connecting to the input terminals.
• Do not touch the input terminals during measurement.
3.Installation category
• The ZR-RX40 conforms to the IEC60664-1 installation category I, and must not be used under the
environment of the installation category II, III and IV.
4.Others
• Dispose of this product as industrial waste.
• If there are any troubles, stop usage immediately, turn off the power supply and contact OMRON branch or
sales office.
Precautions for Safe Use
ZR‑RX40UME.book 6 ページ ２００９年１２月１１日 金曜日 午前１０時５８分

ZR-RX40 User’s Manual 7
Please observe the following precautions to prevent inoperability, misoperation of the product or negative
effects on the performance and the device.
1.Installation Location
Do not install this product in the following locations.
• Locations where the temperature exceeds the rated range
• Locations where severe changes in temperature occur (where condensation occurs)
• Locations subject to corrosive or flammable gases
• Locations subject to dust, salt or iron powder
• Locations subject to direct shock or vibration
• Locations subject to direct sunlight or near heating devices
• Locations where water, oil or chemical products may be splashed
• Locations subject to strong magnetic fields or strong electric fields
2.Power supply, connecting and wiring
• The cables should be wired apart from high-tension or power lines.
Malfunction or damage may occur due to induction.
• After wiring, check the adequacy of power supply voltage, miswiring such as overvoltage/load short-
circuiting and adequacy of load current before turning on the power supply.
Malfunction may occur due to miswiring and such.
• Always turn off the power supply when attaching or removing peripheral devices.
Attaching or removing of peripheral devices with the power supply on can cause malfunction or data
corruption.
3.Installation
• Do not cover the vent hole when using this product.
Leave at least 30cm of installation space around this product.
The generated heat may cause malfunction or damage.
• When measuring temperature, install the product so that the input terminals are not subject to severe
changes in temperature by wind or sunlight.
It may cause calculation errors.
• Do not install this product in a slanted or vertical position.
• Connect the GND terminal for safe measurement. This product must also be grounded when sharing a
common ground level with other devices.
4.Warm up
• For stable measurement, wait at least 30 minutes after turning on the power supply before using.
5.Handling
• Be sure to take backups of captured data in your PC. The captured content may be altered or lost due to
misuse or malfunctions during usage.
• Do not drop or apply strong impact or force to the product.
It may cause malfunction of the monitor or the main unit.
6.Maintenance
• Do not use thinner, benzine, acetone or kerosene to clean this product.
• Calibration should be performed periodically to maintain measurement accuracy.
Precautions for Correct Use
ZR‑RX40UME.book 7 ページ ２００９年１２月１１日 金曜日 午前１０時５８分

8ZR-RX40 User’s Manual
Checking the Accessories
Item Remarks Quantity
Standard Set
ZR-RX40A Main unit AC adapter/AC cable
User’s Manual (this manual)
Utility disk (CD-ROM)
• Specal PC software “Wave Inspire RX“ (tryout)
• Basic PC software “Smart Viewer RXW”
• User's Manual PDF files (this manual)
• “Wave Inspire RX“ Software Manual PDF files
• “Smart Viewer RXW” Software Manual PDF files
1
1
1
1
ZR‑RX40UME.book 8 ページ ２００９年１２月１１日 金曜日 午前１０時５８分

ZR-RX40 User’s Manual 9
Editor's Note
Meaning of Symbols
Menu items that are displayed on the ZR-RX40's LCD screen, and windows, dialog boxes and other GUI
elements displayed on the PC are indicated enclosed by brackets "[ ]".
Visual Aids
Indicates points that are important to achieve the full product performance,
such as operational precautions.
Indicates application procedures.
Indicates pages where related information can be found.
Important
Note
ZR‑RX40UME.book 9 ページ ２００９年１２月１１日 金曜日 午前１０時５８分

10 ZR-RX40 User’s Manual
MEMO
ZR‑RX40UME.book 10 ページ ２００９年１２月１１日 金曜日 午前１０時５８分

ZR-RX40 User’s Manual 11
CONTENTS
CONTENTS
1.BEFORE USE
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Part Names and Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Connecting the Power Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Connecting to an AC Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Connecting to a DC Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Connecting the Analog Input Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Terminal Configuration and Signal Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Connection diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Connecting the Logic Input Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Attaching USB Memory Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Inserting a USB Memory Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Connecting to a PC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Connection Using a USB Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
LAN Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Using the Battery Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Mounting the Battery Pack. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Connecting the Humidity Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Mounting and Removing the Terminal Unit . . . . . . . . . . . . . . . . . . . . . . . 30
To Remove . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
To Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Mounting the Extension Terminal Base Set . . . . . . . . . . . . . . . . . . . . . . . 32
Set Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
To Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Mounting the 20 Channel Extension Terminal Set. . . . . . . . . . . . . . . . . . 34
Set Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
To Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Precautions to Observe When Performing Measurement. . . . . . . . . . . . 37
Noise Countermeasures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Setting the Date and Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
How to Recharge the Rechargeable Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
How to Set the Date and Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Changing the Display Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
ZR‑RX40UME.book 11 ページ ２００９年１２月１１日 金曜日 午前１０時５８分

12 ZR-RX40 User’s Manual
2.SETTINGS AND MEASUREMENT
Window names and functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Key Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
(1) CH GROUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
(2) SPAN/TRACE/POSITION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
(3) TIME/DIV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
(4) MENU. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
(5) QUIT (LOCAL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
(6) Direction keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
(7) ENTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
(8) FAST FORWARD key (KEY LOCK). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
(9) START/STOP (USB Drive Mode). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
(10) REVIEW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
(11) DISPLAY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
(12) CURSOR (ALARM CLEAR). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
(13) FILE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
(14) NAVI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Operation Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
(1) Free Running . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
(2) Capturing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
(3) Dual View Replaying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
(4) Replaying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Setting Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
(1) AMP settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
(2) DATA settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
(3) TRIG settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
(4) USER settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
(5) Interface settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
(6) OTHR settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
(7) Other menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
WEB Server Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
3.SPECIFICATIONS
Standard Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Standard Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Main Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Accessory/Option Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
PC Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Battery Pack ZR-XRB1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Humidity Sensor ZR-XRH1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
External Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
ZR‑RX40UME.book 12 ページ ２００９年１２月１１日 金曜日 午前１０時５８分

ZR-RX40 User’s Manual 13
CONTENTS
4.APPENDIX
Error Messages and Countermeasures . . . . . . . . . . . . . . . . . . . . . . . . . 102
List of Error Messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
List of File Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
ZR‑RX40UME.book 13 ページ ２００９年１２月１１日 金曜日 午前１０時５８分

14 ZR-RX40 User’s Manual
ZR‑RX40UME.book 14 ページ ２００９年１２月１１日 金曜日 午前１０時５８分

1 BEFORE USE
BEFORE USE
Features 16
Part Names and Functions 17
Connecting the Power Cable 18
Connecting the Analog Input Terminal 21
Connecting the Logic Input Terminal 22
Attaching USB Memory Device 24
Connecting to a PC 25
Using the Battery Pack 27
Connecting the Humidity Sensor 29
Mounting and Removing the Terminal Unit 30
Mounting the Extension Terminal Base Set 32
Mounting the 20 Channel Extension Terminal Set 34
Precautions to Observe When Performing Measurement 37
Noise Countermeasures 38
Setting the Date and Time 39
Changing the Display Language 40
ZR‑RX40UME.book 15 ページ ２００９年１２月１１日 金曜日 午前１０時５８分

Features
16 ZR-RX40 User’s Manual
Features
The ZR-RX40 (with color monitor and internal memory) are compact, lightweight, multi-channel data loggers.
ZR-RX40 are provided with 20 channels as a standard measurement feature, or can be extended up to 200
channels by attaching additional terminal sets.
ZR-RX40 is equipped with an internal flash memory, and attaching USB memory device also allows you to
directly capture a large volume of data to USB memory device.
Furthermore, the data loggers are equipped with USB and Ethernet interfaces to a PC to enable system
configurations according to your application.
The Ethernet feature includes WEB and FTP server functions which allow monitoring from a remote location
and data transfer.
Input
• Adoption of a pluggable M3 screw type input terminal facilitates wiring.
• The ZR-RX40 is provided with 20 channels as a standard measurement feature, or can be extended up to 200
channels by attaching additional terminal sets.
• All channels are isolated, enabling measurement of signals of different references.
Display & Operation
• With the ZR-RX40's 5.7-inch TFT color liquid crystal display, you can confirm the waveforms of measured data and
each channel's settings at a glance.
• Easy operation is achieved through a straightforward menu structure and key allocation which resembles mobile
phones.
Data Capture
• Data can be directly captured and maintained in the internal or USB memory device.
• Internal memory used for the built-in memory maintains captured data even after the power is turned off.
• The Internal memory can be used with disk images thus multiple data items can be maintained.
Data Control & Processing
• The PC software provided lets you set conditions and monitor data on a PC.
• The USB drive mode function enables the ZR-RX40's internal memory to be recognized as an external drive by
your PC. (Connect the ZR-RX40 to your PC and turn on the power supply to the ZR-RX40 while holding down the
[START] key.)
• Captured data can be read from the PC software to files and displayed for processing.
• Data can be transferred off-line to a computer using USB memory device.
• The WEB server function enables control and monitoring from a remote location without using dedicated software.
• The FTP server function enables handling internal memory and USB memory data from a PC.
• Measurement data can be backed up to an FTP server using the FTP client function.
• Time information can be adjusted through the NTP client function.
ZR‑RX40UME.book 16 ページ ２００９年１２月１１日 金曜日 午前１０時５８分

1 BEFORE USE
Part Names and Functions
ZR-RX40 User’s Manual 17
Part Names and Functions
This section describes the names and function of parts of the ZR-RX40.
PC interface terminals
ʯUSB
ʯLAN
Monitor Power switch Operation status LED
ʯPOWER : ON when the power is ON
ʯSTART : ON during data capture
ʯCHARGE : ON while the battery is charging
Control panel keys
AC adapter jack
External input/output terminal
ʯLOGIC/PULSE : LOGIC/PULSE input
ʯEXT TRIG : Trigger input
ʯALARM : Alarm output
Power jack for the humidity sensor
GND terminal
Analog signal input terminals
USB memory terminal
Battery cover
Contains battery pack ZR-XRB1 (Option)
ZR‑RX40UME.book 17 ページ ２００９年１２月１１日 金曜日 午前１０時５８分

Connecting the Power Cable
18 ZR-RX40 User’s Manual
Connecting the Power Cable
This section describes how to connect the power cable and turn on the power. The connection method will vary
depending on the type of power supply used.
Connecting to an AC Power Supply
Use the AC cable and AC adapter that are provided as accessories.
Be sure to use only the AC cable and the AC adapter provided as standard accessories.
1Plug the AC cable into the AC adapter.
2Connect the output side of the AC adapter to the AC adapter connector.
Important
AC Aadapter
AC Cable
AC adapter cable
ZR‑RX40UME.book 18 ページ ２００９年１２月１１日 金曜日 午前１０時５８分
