Omron NE1A-EDR01 User manual

OPERATION MANUAL
Cat. No. Z912-E1-01
NE1A Series
NE1A-EDR01
EtherNet/IP-DeviceNet Router

NE1A Series EtherNet/IP-DeviceNet Router:
NE1A-EDR01
Operation Manual
Produced July 2007

iv

v
Notice:
OMRON products are manufactured for use according to proper procedures by a qualified operator
and only for the purposes described in this manual.
The following conventions are used to indicate and classify precautions in this manual. Always heed
the information provided with them. Failure to heed precautions can
result in injury to people or damage to property.
!WARNING Indicates a potentially hazardous situation which, if not avoided, will result in minor or
moderate injury, or may result in serious injury or death. Additionally, there may be signifi-
cant property damage.
!Caution Indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury, or property damage.
OMRON Product References
All OMRON products are capitalized in this manual. The word “Unit” is also capitalized when it refers to
an OMRON product, regardless of whether or not it appears in the proper name of the product.
The abbreviation “PLC” means Programmable Controller. “PC” is used, however, in some Program-
ming Device displays to mean Programmable Controller.
Visual Aids
The following headings appear in the left column of the manual to help you locate different types of
information.
IMPORTANT Indicates important information on what to do or not to do to prevent failure to
operation, malfunction, or undesirable effects on product performance.
Note Indicates information of particular interest for efficient and convenient opera-
tion of the product.
1,2,3... 1. Indicates lists of one sort or another, such as procedures, checklists, etc.
Indicates general prohibitions for which there is no specific symbol.
Indicates general mandatory actions for which there is no specific symbol.

vi
Trademarks and Copyrights
CIP, EtherNet/IP, DeviceNet, and DeviceNet Safety are registered trademarks of the Open DeviceNet
Vendors Association.
Windows is a registered trademark of Microsoft Corporation.
Other product names and company names in this manual are trademarks or registered trademarks of
their respective companies.
OMRON, 2007
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form, o
r
by any means, mechanical, electronic, photocopying, recording, or otherwise, without the prior written permission o
f
OMRON.
No patent liability is assumed with respect to the use of the information contained herein. Moreover, because OMRON is con-
stantly striving to improve its high-quality products, the information contained in this manual is subject to change without
notice. Every precaution has been taken in the preparation of this manual. Nevertheless, OMRON assumes no responsibility
for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained in
this publication.

vii
TABLE OF CONTENTS
PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xv
1 Intended Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi
2 General Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi
3 Precautions for Safe Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi
4 Regulations and Standards. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xviii
SECTION 1
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1-1 EtherNet/IP-DeviceNet Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1-2 Nomenclature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SECTION 2
Installation and Network Connections . . . . . . . . . . . . . . . . . 5
2-1 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2-2 Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2-3 Connecting to DeviceNet. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
2-4 Connecting to Ethernet (EtherNet/IP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2-5 ED Router Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
SECTION 3
Status Indicators and Troubleshooting. . . . . . . . . . . . . . . . . 25
3-1 Status Indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3-2 Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3-3 Error History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
SECTION 4
Accessing Devices by UDP . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
4-1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
4-2 Formats . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
4-3 Operating Examples. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
4-4 Mitsubishi Ethernet Interface Module Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4-5 Sample Ladder Programs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
4-6 NE1A Series Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
4-7 DST1 Series Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Appendices
A Specifications and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
B Settings from the Network Configurator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Revision History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

viii
TABLE OF CONTENTS

ix
About this Manual:
This manual describes the installation and operation of the NE1A-EDR01 EtherNet/IP-DeviceNet
Router. The NE1A-EDR01 EtherNet/IP-DeviceNet Router was developed using OMRON‘s advanced
control technology and vast know-how. It functions to route FA data between EtherNet/IP and
DeviceNet networks.
Please read this manual carefully and be sure you understand the information provided before
attempting to install or operate the NE1A-EDR01 EtherNet/IP-DeviceNet Router. The following manu-
als are also related to the NE1A-EDR01 EtherNet/IP-DeviceNet Router or NE1A-series Safety Net-
work Controllers. Refer to these manuals as required during installation and operation.
EtherNet/IP-DeviceNet Router Operation Manual (this manual) (Z912)
This manual describes the specifications, functions, and application methods of the EtherNet/IP-
DeviceNet Router in detail.
DeviceNet Safety System Configuration Manual (Z905)
This manual explains how to configure the DeviceNet Safety system using the Network Configurator.
DeviceNet Safety NE1A Series Safety Network Controller Operation Manual (Z906)
This manual describes the specifications, functions, and usage of the NE1A-SCPU01 and NE1A-
SCPU02.
DeviceNet Safety Safety I/O Terminal Operation Manual (Z904)
This manual describes the DST1-series Slave models, specifications, functions, and application meth-
ods in detail.
DeviceNet Operation Manual (W267)
This manual describes the construction and connection of a DeviceNet network. It provides detailed
information on the installation and specifications of cables, connectors, and other peripheral equip-
ment used in the network, and on the supply of communications power. Obtain this manual and gain a
firm understanding of its contents before using a DeviceNet system.

x

xi
Read and Understand this Manual
Please read and understand this manual before using the product. Please consult your OMRON
representative if you have any questions or comments.
Warranty and Limitations of Liability
WARRANTY
OMRON's exclusive warranty is that the products are free from defects in materials and workmanship for a
period of one year (or other period if specified) from date of sale by OMRON.
OMRON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, REGARDING NON-
INFRINGEMENT, MERCHANTABILITY, OR FITNESS FOR PARTICULAR PURPOSE OF THE
PRODUCTS. ANY BUYER OR USER ACKNOWLEDGES THAT THE BUYER OR USER ALONE HAS
DETERMINED THAT THE PRODUCTS WILL SUITABLY MEET THE REQUIREMENTS OF THEIR
INTENDED USE. OMRON DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED.
LIMITATIONS OF LIABILITY
OMRON SHALL NOT BE RESPONSIBLE FOR SPECIAL, INDIRECT, OR CONSEQUENTIAL DAMAGES,
LOSS OF PROFITS OR COMMERCIAL LOSS IN ANY WAY CONNECTED WITH THE PRODUCTS,
WHETHER SUCH CLAIM IS BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT
LIABILITY.
In no event shall the responsibility of OMRON for any act exceed the individual price of the product on which
liability is asserted.
IN NO EVENT SHALL OMRON BE RESPONSIBLE FOR WARRANTY, REPAIR, OR OTHER CLAIMS
REGARDING THE PRODUCTS UNLESS OMRON'S ANALYSIS CONFIRMS THAT THE PRODUCTS
WERE PROPERLY HANDLED, STORED, INSTALLED, AND MAINTAINED AND NOT SUBJECT TO
CONTAMINATION, ABUSE, MISUSE, OR INAPPROPRIATE MODIFICATION OR REPAIR.

xii
Application Considerations
SUITABILITY FOR USE
OMRON shall not be responsible for conformity with any standards, codes, or regulations that apply to the
combination of products in the customer's application or use of the products.
At the customer's request, OMRON will provide applicable third party certification documents identifying
ratings and limitations of use that apply to the products. This information by itself is not sufficient for a
complete determination of the suitability of the products in combination with the end product, machine,
system, or other application or use.
The following are some examples of applications for which particular attention must be given. This is not
intended to be an exhaustive list of all possible uses of the products, nor is it intended to imply that the uses
listed may be suitable for the products:
• Outdoor use, uses involving potential chemical contamination or electrical interference, or conditions or
uses not described in this manual.
• Nuclear energy control systems, combustion systems, railroad systems, aviation systems, medical
equipment, amusement machines, vehicles, safety equipment, and installations subject to separate
industry or government regulations.
• Systems, machines, and equipment that could present a risk to life or property.
Please know and observe all prohibitions of use applicable to the products.
NEVER USE THE PRODUCTS FOR AN APPLICATION INVOLVING SERIOUS RISK TO LIFE OR
PROPERTY WITHOUT ENSURING THAT THE SYSTEM AS A WHOLE HAS BEEN DESIGNED TO
ADDRESS THE RISKS, AND THAT THE OMRON PRODUCTS ARE PROPERLY RATED AND INSTALLED
FOR THE INTENDED USE WITHIN THE OVERALL EQUIPMENT OR SYSTEM.
PROGRAMMABLE PRODUCTS
OMRON shall not be responsible for the user's programming of a programmable product, or any
consequence thereof.

xiii
Disclaimers
CHANGE IN SPECIFICATIONS
Product specifications and accessories may be changed at any time based on improvements and other
reasons.
It is our practice to change model numbers when published ratings or features are changed, or when
significant construction changes are made. However, some specifications of the products may be changed
without any notice. When in doubt, special model numbers may be assigned to fix or establish key
specifications for your application on your request. Please consult with your OMRON representative at any
time to confirm actual specifications of purchased products.
DIMENSIONS AND WEIGHTS
Dimensions and weights are nominal and are not to be used for manufacturing purposes, even when
tolerances are shown.
PERFORMANCE DATA
Performance data given in this manual is provided as a guide for the user in determining suitability and does
not constitute a warranty. It may represent the result of OMRON's test conditions, and the users must
correlate it to actual application requirements. Actual performance is subject to the OMRON Warranty and
Limitations of Liability.
ERRORS AND OMISSIONS
The information in this manual has been carefully checked and is believed to be accurate; however, no
responsibility is assumed for clerical, typographical, or proofreading errors, or omissions.

xiv

xv
PRECAUTIONS
1 Intended Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi
2 General Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi
3 Precautions for Safe Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xvi
4 Regulations and Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xviii

xvi
Intended Audience 1
1 Intended Audience
This manual is intended for the following personnel, who must have knowl-
edge of electrical systems (an electrical engineer or the equivalent).
• Personnel in charge of introducing FA and safety systems into production
facilities
• Personnel in charge of designing FA and safety systems
• Personnel in charge of managing FA facilities
• Personnel who have the qualifications, authority, and obligation to provide
safety during each of the following product phases: mechanical design,
installation, operation, maintenance, and disposal
2 General Precautions
The user must operate the product according to the performance specifica-
tions described in the operation manuals.
Before using the product under conditions which are not described in the
manual or applying the product to nuclear control systems, railroad systems,
aviation systems, vehicles, combustion systems, medical equipment, amuse-
ment machines, safety equipment, and other systems, machines, and equip-
ment that may have a serious influence on lives and property if used
improperly, consult your OMRON representative.
Make sure that the ratings and performance characteristics of the product are
sufficient for the systems, machines, and equipment, and be sure to provide
the systems, machines, and equipment with double safety mechanisms.
This manual provides information for programming and operating the Unit. Be
sure to read this manual before attempting to use the Unit and keep this man-
ual close at hand for reference during operation.
!WARNING It is extremely important that a PLC and all PLC Units be used for the speci-
fied purpose and under the specified conditions, especially in applications that
can directly or indirectly affect human life. You must consult with your OMRON
representative before applying a PLC System to the above-mentioned appli-
cations
3 Precautions for Safe Use
■Handling with Care
Do not drop the EtherNet/IP-DeviceNet Router or subject it to excessive vibra-
tion or mechanical shock. The EtherNet/IP-DeviceNet Router may be dam-
aged and may not function properly.
■Installation and Storage Environment
Do not use or store the EtherNet/IP-DeviceNet Router in any of the following
locations:
• Locations subject to direct sunlight
• Locations subject to temperatures or humidity outside the range specified
in the specifications
• Locations subject to condensation as the result of severe changes in tem-
perature
• Locations subject to corrosive or flammable gases
• Locations subject to dust (especially iron dust) or salts

xvii
Precautions for Safe Use 3
• Locations subject to water, oil, or chemicals
• Locations subject to shock or vibration
Take appropriate and sufficient measures when installing systems in the fol-
lowing locations. Inappropriate and insufficient measures may result in mal-
function.
• Locations subject to static electricity or other forms of noise
• Locations subject to strong electromagnetic fields
• Locations subject to possible exposure to radioactivity
• Locations close to power supplies
■Installation and Mounting
• Use the EtherNet/IP-DeviceNet Router within an enclosure with IP54 pro-
tection or higher according to IEC/EN 60529.
• Use DIN rail (TH35-7.5/TH35-15 according to IEC 60715) to install the
EtherNet/IP-DeviceNet Router into the control panel. Mount the EtherNet/
IP-DeviceNet Router to the DIN rail using PFP-M End Plates (not included
with the EtherNet/IP-DeviceNet Router) to prevent it falling off the DIN rail
because of vibration.
• Space must be provided around the EtherNet/IP-DeviceNet Router, at
least 5 mm from its side and at least 50 mm from its top and bottom sur-
faces, for ventilation and wiring.
■Installation and Wiring
• Use the following to wire external I/O devices to the EtherNet/IP-
DeviceNet Router.
• Disconnect the EtherNet/IP-DeviceNet Router from the power supply
before starting wiring.
• Properly apply the specified voltage to the EtherNet/IP-DeviceNet Router
inputs. Applying an inappropriate DC voltage or any AC voltage may inter-
fere with functionality, may reduce safety, or may cause the EtherNet/IP-
DeviceNet Router to be damaged or burnt.
• Be sure to separate the communications cables and I/O cables from near
high-voltage/high-current lines.
• Be cautious not to get your fingers caught when attaching connectors to
the plugs on the EtherNet/IP-DeviceNet Router.
• Tighten the DeviceNet connector screws correctly (0.25 to 0.3 N·m).
• Incorrect wiring may lead to loss of safety functions. Wire conductors cor-
rectly and verify the operation of the EtherNet/IP-DeviceNet Router before
using the system in which the EtherNet/IP-DeviceNet Router is incorpo-
rated.
• After wiring is completed, be sure to remove label for wire clipping preven-
tion on the EtherNet/IP-DeviceNet Router to enable heat to escape or
proper cooling.
■Power Supply Selection
Use a DC power supply satisfying the following requirements.
Solid wire 0.2 to 2.5 mm2(AWG 24 to AWG 12)
Stranded (flexi-
ble) wire 0.34 to 1.5 mm2(AWG 22 to AWG 16)
Stranded wires should be prepared by attaching insulated bar
terminals (DIN 46228-4 standard compatible) to the ends before
connecting them.

xviii
Regulations and Standards 4
• The secondary circuits of the DC power supply must be isolated from the
primary circuit by double insulation or reinforced insulation.
• The DC power supply must satisfy the requirements for class 2 circuits or
limited voltage/current circuits given in UL 508.
• The output hold time must be 20 ms or longer.
■Periodic Inspections and Maintenance
• Disconnect the EtherNet/IP-DeviceNet Router from the power supply
before replacing the EtherNet/IP-DeviceNet Router. Devices connected to
the EtherNet/IP-DeviceNet Router may operate unexpectedly.
• Do not disassemble, repair, or modify the EtherNet/IP-DeviceNet Router.
Doing so may lead to loss of safety functions.
■Disposal
• Be cautions not to injure yourself when dismantling the EtherNet/IP-
DeviceNet Router.
4 Regulations and Standards
The EtherNet/IP-DeviceNet Router has been certified as follows:
Certifying organization Standards
UL UL508, UL1604,
CSA22.2 No142, CSA22.2 No213

1
SECTION 1
Overview
This section introduced the EtherNet/IP-DeviceNet Router and it’s functionality.
1-1 EtherNet/IP-DeviceNet Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1-1-1 Accessing All Devices on a Network from a Network Configurator 2
1-1-2 Monitoring DeviceNet or DeviceNet Safety Systems via Ethernet
from Controllers Made by Other Manufacturers . . . . . . . . . . . . . . . 3
1-2 Nomenclature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

2
EtherNet/IP-DeviceNet Router Section 1-1
1-1 EtherNet/IP-DeviceNet Router
The NE1A-EDR01 EtherNet/IP-DeviceNet Router is an FA router with one
Ethernet port and one DeviceNet port, and is used for routing messages
between Ethernet and DeviceNet Networks. In this manual the NE1A-EDR01
EtherNet/IP-DeviceNet Router is called the “ED Router.”
1-1-1 Accessing All Devices on a Network from a Network Configurator
Using an ED Router makes it possible to set devices, such as NE1A-series
Controllers and DST1-series Slaves, from a Network Configurator running on
a PC connected to an Ethernet or EtherNet/IP Network.
In addition, when multiple DeviceNet or DeviceNet Safety Networks are con-
figured for an Ethernet or EtherNet/IP connection using an ED Router, it is
possible to set devices such as NE1A-series Controllers and DST1-series
Slaves connected to another DeviceNet or DeviceNet Safety network from a
Network Configurator running on a PC connected to a DeviceNet or NE1A-
series USB port.
Note (1) To access other networks, use the NE1A-SCPU01-V1 (unit version 2.0 or
later) or the NE1A-SCPU02 (unit version 2.0 or later) to connect the Net-
work Configurator.
(2) To access other networks, use Network Configurator version 2.0@or
higher.
ED Router
(NE1A-EDR01)
Ethernet (EtherNet/IP)
USB
DeviceNet Safety
NE1A Safety Network
Controller
DeviceNet Safety
DST1-series Slaves
DeviceNet Safety
DST1-series Slaves
DeviceNet Safety
Network
Configurator
Network
Configurator Network
Configurato
r

3
EtherNet/IP-DeviceNet Router Section 1-1
1-1-2 Monitoring DeviceNet or DeviceNet Safety Systems via Ethernet
from Controllers Made by Other Manufacturers
Devices on a DeviceNet or DeviceNet Safety network can be accessed from
general-purpose controllers (e.g., PLCs or computers) in an Ethernet network
using the UDP service.
This enables monitoring a DeviceNet or DeviceNet Safety control system via
Ethernet from a machine controller or monitor computer that does not support
a DeviceNet interface. This can be used to easily add a DeviceNet Safety con-
trol system to an existing system.
ED Router
(NE1A-EDR01)
PLC (OMRON or other maker)
OR
Ethernet
Command via UDP Command via UDP
DeviceNet Safety
NE1A Safety Network Controller
Computer
Socket service (UDP)
DeviceNet Safety
DST1-series Slaves
DeviceNet Safety
DST1-series Slaves
DeviceNet Safety
Safety controls can be monitored by accessing
devices on the DeviceNet Safety network using the
UDP service from a general-purpose controller on
the Ethernet network (e.g., a PLC or computer).
