OMT OV1021 User manual

USER GUIDE
OV1021 | Part No. 114804
OV1021
FIXED LEG TABLE

2 | OV1021
User Guide: OV1021
FEATURES
• Full table base (add your own work surface)
• Meets BIFMA X5.5 standards (glides only)
• Easy assembly
• Ten-year warranty
• Over 150 color options
PRODUCT OVERVIEW
OV1021
FIXED LEG TABLE

OV1021 | 3
User Guide: OV1021
Parts Diagram 4
Safety Information 5
Assembly Instructions 6-7
TABLE OF CONTENTS
STANDARDS & CERTIFICATIONS
Meets 2014 BIFMA standards (glides only).
WARRANTY
Contact your sales representative for warranty information.

4 | OV1021
User Guide: OV1021
2
1
3
PARTS Qty/Package
1. Leg 2
2. Wood Screw Kit (#10 x ¾") 1
3. Crossbar 2
For standing height tables in
48" and 60"widths
PARTS DIAGRAM
OV1021
PARTS DIAGRAM

OV1021 | 5
User Guide: OV1021
SAFETY
INFORMATION
IMPORTANT SAFETY INSTRUCTIONS Save these instructions.
INSTALL ONLY APPROVED WORK SURFACES
This table system does not include a work surface (desktop). Maximum load for table is 200 lb, including work
surface. Maximum desktop dimensions are 30"x72". If you are unsure if your preferred work surface meets
specications, contact customer service.
DO NOT OVERLOAD DESK
To prevent table from tipping or collapsing, make sure the desk frame is not overloaded by the weight
of tabletop and objects on table. Evenly distribute load; excess loads near edges can reduce stability
and cause table to tip over.
• Do not exceed maximum load (including weight of desktop) of 200 lb (91Kg)
• Do not exceed edge load of 25 lb when positioning monitors or mounting accessories
• Do not sit or stand on table
USE CARE WHEN MOVING TABLE
• Remove all objects and mounted accessories from the table before moving
• Clear objects and equipment from table before rolling to reduce the risk of tipping over
SAFETY INFORMATION

6 | OV1021
User Guide: OV1021
ASSEMBLY
INSTRUCTIONS
(FOR ALL COFFEE TABLE AND DESK HEIGHT TABLES)
INSTALL LEGS TO THE TABLE TOP
Center legs front to back on the table top (See Illustration A). Mark the locations of the
pilot hole on the table top.
Drill the pilot holes to the size recommended by the table top manufacturer.
Install the #10 x ¾" screws through the mounting plate into the table top.
ASSEMBLY INSTRUCTIONS
The assembly of the table frame to be made in accordance with this manual.
Changes to the table frame or improper use may affect the safety, function, and life of your product.
Step 1 applies to the following table legs: 16.75"and 27.7"high legs (coffee and desk height).
See Step 2 for instructions for 40.75"high (standing height) legs in 48"and 60"widths.
1
CENTERLINE OF TABLE TOP
1.5 in
ILLUSTRATION A
*Please make sure top supports are mounted 1.5"from edge of work surface.

OV1021 | 7
User Guide: OV1021
Drill the pilot holes to the size recommended by the table top manufacturer.
Install the #10 x ¾" screws through the mounting plate into the table top.
ASSEMBLY INSTRUCTIONS
CENTERLINE OF TABLE TOP
End of life cycle: Once product is disassembled, all steel components can be recycled at your local
metal collector. For products with electronic components, see Disassembly Guide.
(FOR STANDING HEIGHT TABLES IN 48"AND 60"WIDTHS)
INSTALL CROSSBAR
Stand both legs up far enough apart to insert crossbars into their
corresponding slots in legs. Insert tab of crossbar into slot and
tap down on crossbar until set in slot. Repeat until crossbars
are rmly set in slots.
(FOR STANDING HEIGHT TABLES IN 48"AND 60"WIDTHS)
INSTALL LEGS TO THE TABLE TOP
Flip leg assembly over onto the table top. Center legs front to back and side to side on the bottom
of the table top (See Illustration B). Mark the locations of the pilot hole on the table top.
2
3
ILLUSTRATION B

OV1021
USER GUIDE
Part No. 114804
Rev A | 102419
