omtime CT-Router LAN User manual

CT-Router LAN
user manual

CT-Router LAN
2
Copyright © comtime GmbH
Copyright Statement
The contents of this publication are protected by copyright. Translations, reprints, reproduction and storage
in data processing systems require the express permission of comtime GmbH.
© 2011 comtime GmbH
All rights reserved.
comtime GmbH
Gutenbergring 22
22848 Norderstedt
Germany
Tel: [phone]
Fax: [phone]
Internet: http://www.comtime-com.de
email: [e-mail]
Subject to technical alterations.
All trademarks and product designations are trademarks, registered trademarks or product designations of
their respective owners.
comtime GmbH provides all goods and services on the basis of the General Terms and Conditions of
comtime GmbH currently valid. All information is based on information provided by the manufacturer(s). No
responsibility or liability will be assumed for incorrect or missing entries. The descriptions of the
specifications in this manual do not constitute an agreement.
Product no: 266-000
, Nachdruck, Vervielfältigung sowie Speicherung in
Datenverarbeitungsanlagen bedürfen der ausdrücklichen
Genehmigung der comtime GmbH.
© 2011 comtime GmbH
Alle Rechte vorbehalten.GPRS

CT-Router LAN
3
Content
Copyright © comtime GmbH..........................................................................................................................2
Technical data ................................................................................................................................................. 5
Hardware installation......................................................................................................................................6
LED indicators ............................................................................................................................................... 7
Configuration WBM.........................................................................................................................................8
Device information..........................................................................................................................................9
Hardware ....................................................................................................................................................... 9
Software.......................................................................................................................................................10
Status..............................................................................................................................................................11
Network Connections...................................................................................................................................11
I/O status .....................................................................................................................................................12
ComSERVER –status (optional)..............................................................................................................13
Routing table................................................................................................................................................ 14
DHCP Leases..............................................................................................................................................15
Local network ................................................................................................................................................16
IP configuration............................................................................................................................................16
DHCP server................................................................................................................................................17
Static routes.................................................................................................................................................18
Wide Area Network........................................................................................................................................19
WAN Setup.................................................................................................................................................. 19
Static Address.............................................................................................................................................. 20
DHCP Client ................................................................................................................................................ 21
PPPoE .........................................................................................................................................................22
Static routes.................................................................................................................................................23
DynDNS.......................................................................................................................................................24
Connection Check .......................................................................................................................................25
Network security ...........................................................................................................................................26
General setup..............................................................................................................................................26
Firewall ........................................................................................................................................................27
NAT Table.................................................................................................................................................... 28
VPN .................................................................................................................................................................29
IPSec ...........................................................................................................................................................29
Connections .............................................................................................................................................29
Connections settings................................................................................................................................30
Connection IKE ........................................................................................................................................32
Certificates ...............................................................................................................................................34
Status.......................................................................................................................................................35
Tunnel ......................................................................................................................................................36
Server.......................................................................................................................................................38
Port Forwarding........................................................................................................................................40
Certificates ...............................................................................................................................................41
Static keys................................................................................................................................................42
Status.......................................................................................................................................................43

CT-Router LAN
4
Content
I/O....................................................................................................................................................................44
Inputs...........................................................................................................................................................44
Outputs ........................................................................................................................................................45
Socket Server ..............................................................................................................................................46
System............................................................................................................................................................47
Web configuration........................................................................................................................................ 47
User .............................................................................................................................................................48
Log configuration.........................................................................................................................................49
Log file .........................................................................................................................................................50
ComSERVER - Serielle Schnittstelle konfigurieren (optional)....................................................................51
SMTP Configuration ....................................................................................................................................52
Configuration Up-/Download .......................................................................................................................53
RTC..............................................................................................................................................................54
Reboot .........................................................................................................................................................55
Firmware update.......................................................................................................................................... 56
Inquiry and control via XML files.................................................................................................................57
Examples of the basic entries:.................................................................................................................57
a) I/O system .......................................................................................................................................57
b) Query General Information ..................................................................................................................58
c) send SMS.............................................................................................................................................58
d) send eMail............................................................................................................................................58
Functional test...............................................................................................................................................60
Examples of an application..........................................................................................................................61

CT-Router LAN
5
Technical data
Supply
Supply voltage
10 V DC ... 30 V DC via plugable screw terminals
Nominal current consumption
< 90mA at 24V
LED display
Power (LED green) Continuous light: Operation
Protocols / Interfaces
Protocols / services
DHCP-Server, HTTP-Server, FTP, NAT, Firewall, SMS, OpenVPN, IPSec,
DynDNS, NTP
VPN
Secure data encryption with IPSec and Open VPN (including X.509
support)
Ethernet interface
Connection
2 x RJ45 socket, shielded
Transmission rate
10/100 MBit/s
Supported protocols
TCP/IP, UDP/IP, FTP, HTTP
Auxiliary protocols
ARP, DHCP, PING( ICMP), SNMP V1, SMTP
LED display / control signal
ACT (LED yellow), Ethernet data transmission
LINK (LED green), Ethernet link established
Serial interface
optional
I/O
4 inputs, 4 outputs via plugable screw terminals
Physical features
Size (HxWxD)
101x116 x22,5 mm
Environmental temperature
Operation -25...+70°C, Storage -40 …+85°C
Humidity
0...95% (not condensing)
Protection class
IP30
CE conformity according to R&TTE directive 1999/5/EC
EMV
EN 61000-6-2, EN55022 Class A
Safety
EN 60950
Radio
EN 301511
Certifications
UL, USA / Kanada
in processing
Technical changes reserved

CT-Router LAN
6
Hardware installation
Terminal assignment
Supply voltage
10V - 30V DC
0V
NC
NC
Digital output
O4
O3
O2
O1
Digital input
I4I I4
I3
I2
I1
Ethernet 1
Ethernet 2
USB

CT-Router LAN
7
Hardware installation
LED indicators
LED Router HSPA
LED
Explanation
Package Data
Off = no connection
Flashing = modem connection
On = package data connection
VPN
Off = no VPN connection
On = VPN connection activated
Power
Off = no power supply
On = power supply activated
Packet Data
Reset
Power
VPN

CT-Router LAN
8
Configuration WBM
The configuration of the CT-Router is performed via a Web browser based function. To do so,
first fulfil the following conditions:
The PC which is used for the configuration of the router is equipped with a LAN interface.
A Web browser (e.g. Google Chrome, Mozilla Firefox, Microsoft IE) is installed on the PC.
The router is connected to a voltage source.
Starting the configuration
1. Establish an Ethernet connection between the PC and the router.
2. Adjust the IP address of the LAN interface to the network of the router.
3. Open Web browser.
4. Enter the IP address of the router (192.168.0.1) into the address field of the browser and confirm by
pressing the Enter key. Then user name/password request is performed.
Upon delivery the user name is "admin" and the password is "admin" (it is described later on how to change
the password).
Furthermore, there are two user levels:
User: Read access on "Device information".
Admin: Read and write access to all areas.
After having entered the user name and the password the main menu will open up to configure the CT-
Router.
.

CT-Router LAN
9
Device information
In this area you can see more detailed information about the built-in hardware as well as about the installed
software.
Hardware
Here you will find a tabular overview of the built-in hardware.

CT-Router LAN
10
Device information
Software
Here you will find a tabular overview of the software installed on the CT-Router.

CT-Router LAN
11
Status
In this menu all current status information about the the network connections are displayed.
Network Connections
Status Network connections
Network conncetions
Explanation
Wireless Network
Link
TCP/IP connected: TCP/IP connection established in the mobile phone network.
VPN connected: VPN connection established in the mobile phone network
Not connected: There is no active connection in the mobile phone network
IP Address
Assigned IP address (pre-setting of the provider)
Netmask
Assigned netmask (pre-setting of the provider)
DNS Server
DNS server IP-address
Sec. DNS Server
alternative DNS-Server IP-address
RX Bytes
Number of the received data since login into the mobile phone network in
bytes.
TX Bytes
Number of the sent data since login into the mobile phone network in bytes.
Local Network
Link
connected: Local Ethernet connection established.
not connected: No local Ethernet connection established.
IP Address
Ethernet IP-address
Netmask
Ethernet netmask

CT-Router LAN
12
Status
I/O status
Here you will find an overview in tabular form of all current input and output settings.

CT-Router LAN
13
Status
ComSERVER –status (optional)
or
Status ComSERVER
ComSERVER
Explanation
Link
The status of the ComServer connection (serial) is displayed:
TCP Remote
Baud Rate
Data bits
Parity
Stop bits
Flow control

CT-Router LAN
14
Status
Routing table
Status Routing table
Routing Table
Explanation
Includes among others information about the target gateway to the subnet mask and metrics.

CT-Router LAN
15
Status
DHCP Leases
Status DHCP leases
DHCP Leases
Explanation
Here you will find an overview in tabular form of all DHCP data assigned by the AK-DinRail-3G-Router.
Host name
Host name of the terminal in the network.
Client MAC address
MAC address of the terminal in the network.
Client IP address
IP address of the terminal in the network.

CT-Router LAN
16
Local network
In the menu "Local network" you can set the local network settings for the CT-Router.
IP configuration
Local network IP configuration
IP configuration
Explanation
Current address
IP Address
Current IP address of the router
Subnet mask
Subnet mask of the current IP address
Type of the IP address
assignment
Static: Static IP address (Standard setting)
DHCP: Dynamic IP address is referred to when starting up the router
from a DHCP server
Alias addresses
Max. 8 additional IP addresses as well as subnet masks can be assigned.
IP address
Alternative IP address of the router
Subnet mask
Alternative subnet mask of the router

CT-Router LAN
17
Local network
DHCP server
Local network DHCP server
DHCP server
Explanation
DHCP server
Deactivated / Activated
Domain name
Enter Domain name which is distributed via DHCP.
Lease time (d,h,m,s)
Period of time during which the network configurations are valid.
Dynamic IP address
allocation
Dynamic IP address assignment: When activating you can enter the
corresponding network parameters / The DHCP server assigns IP
addresses of the indicated IP range.
Begin IP range
Beginning of the IP range
End IP range
End of the IP range
Static IP address allocation
IP addresses are clearly assigned to MAC addresses.
Client MAC address
MAC address of the connected terminal
Client IP address
IP address of the connected terminal
IP addresses must not originate from the dynamic IP address
assignments.
An IP address must not be assigned several times otherwise an IP

CT-Router LAN
18
Local network
Static routes
Local network Static routes
Static routes
Explanation
Network
Network in CIDR form
Gateway
Gateway address of the network
Max. 8 networks can be entered.

CT-Router LAN
19
Wide Area Network
Wireless network
Wireless network
Determine the settings for the use of CT-Router in the “Wide Area Network ” menu.
WAN Setup
Wide Area Networks
WAN Setup
Explanation
Connection Type
Select the connection in the "Connection Type" menu and set it to Enable "Yes".
Then click "Apply"
Possible types of connection in the "Connection Type" menuStatic Address
DHCP Client
PPOE

CT-Router LAN
20
Wide Area Network
Static Address
Setting for use in local area networks
Wide Area Networks
WAN Setup
Explanation
IP Address
IP address of the router on the WAN interface
Subnet Mask
subnet mask
Default Gateway
IP address of the gateway to the Internet
DNS Server
IP address of the DNS server
Sec. DNS Server
IP address of a second DNS server
