OmySalon WMT-W User manual

Wooden Manicure Table
Instruction
(Model No. WMT-W)
Thank you for your purchase. If you have any problem, please feel free to contact us
by sending an email to [email protected]. We will work out an appropriate
solution for you asap. And your suggestions will be helpful for our future
improvement in product and service. (Please include order# in the email subject so
that we can get details about the order and the product you are inquiring about.)

1
PARTS
A × 70
Ø7*35
B × 70
Ø15*12
C × 10
M4*20
D × 5
E × 44
M4*12
F × 4
G × 4
H × 4
I × 4
J× 2
K × 1
700*400*15
L × 1
1200*450*25
M × 1
696*266*15
N × 4
266*172*15
O × 8
300*116*15
P × 4
213*116*15
Q × 4
223*295*5
R × 1
700*400*15
S × 1
700*400*15
T × 1
368*270*15
U × 1
700*270*15
V × 1
700*270*15
W × 2
402*302*15
X × 1
700*400*15
Y × 1

2
ASSEMBLY ILLUSTRATION
Tip:
1.It is suggested not to fully tighten the screws and eccentric wheels until all the
steps have been done and parts are installed correctly.
2.Tools that may be needed for assembly: screwdriver and power drill.
3.Drawer slides are kind of oily. If you want to keep your hands clean, you can
wear gloves.
Step 1 Assemble Drawers
Extend the drawer slide and press the release lever to separate the inner rail from the
outer rail. And put the outer rail (that will be installed to the side panel of the cabinet)
aside.
Locate all the panels for drawers and secure the dowels to pre-inserted nuts on the
front panel and side panels first. And then mount the inner rails of the drawer slides to
the side panels with screws.
Line up the dowels on the front panel with the holes on the side panel and push them
into the holes. Put the eccentric wheels into the holes on the side panels.
Install the bottom panel and the back panel. Put the eccentric wheels into the holes on
the back panel.
Tighten all the eccentric wheels with your screwdriver and install the handle to the
front panel. Then a drawer is done. Assemble other drawers in the same way.

3
Step 2 Assemble Cabinet for Drawers
Locate all the panels for the cabinet. Align the holes on the outer rails of the drawer
slides with the holes on the side panels and then mount the outer rails to the side
panels with screws.
Insert dowels to the pre-inserted nuts on the side panels. Align the dowels on the side
panels with the holes on the back panel of the cabinet and push them into the holes.
Put the eccentric wheels into the holes on the back panel and then tighten them.

4
Secure the dowels to the bottom panel. Align the dowels with the holes at the bottom
of the side panels and back panel and push them into the holes. Put the eccentric
wheels in the holes and tighten them. Then install the wheels to the bottom panel.
Step 3 Assemble Cabinet
Locate all the panels for the cabinet and insert dowels to the pre-inserted nuts on the
panels first. Put together the panels. Insert the eccentric wheels to the holes and
tighten them.

5
Secure the dowels to the bottom panel. Align the dowels with the holes at the bottom
of the side panels and back panel and push them into the holes. Put the eccentric
wheels in the holes and tighten them. Then install the wheels to the bottom panel.
Step 4 Install Cabinet Door & Tabletop
Align the holes on the hinges with the holes on the door panel. Put screws into the
holes and then tighten them. Install then handle to the door.
Align the holes on hinges with the holes on the side panel. Insert screws into the holes
and tighten them.
Secure the dowels to the pre-inserted nuts on the bottom of the tabletop. Line up the
dowels on the tabletop with the holes on the top of the panel and push them into the
holes. Put the eccentric wheels into the holes and tighten them.
Put 4 drawers into the cabinet. A manicure table is done.
