on networks DSG005 User manual

Easy, Reliable & Secure Installation Guide
Gigabit Ethernet Switch
DSG005/DSG008

Trademarks
Brand and product names are trademarks or registered trademarks of their
respective holders. Information is subject to change without notice.
Statement of Conditions
In the interest of improving internal design, operational function, and/or
reliability, On Networks reserves the right to make changes to the products
described in this document without notice. On Networks does not assume
any liability that may occur due to the use or application of the product(s) or
circuit layout(s) described herein.
This symbol is placed in accordance with the European Union
Directive 2002/96 on the Waste Electrical and Electronic Equipment
(the WEEE Directive). If disposed of within the European Union, this
product should be treated and recycled in accordance with the laws
of your jurisdiction implementing the WEEE Directive.

3
Package Contents
This package includes:
• Gigabit Ethernet Switch DSG005/DSG008
• AC power adapter
• Installation guide (this document)

4
Install the Switch and Connect Devices
1. Place the switch on a flat surface.
2. For each device, use an Ethernet cable to connect it to a port on
the switch.
DSG008 8-port
Ethernet switch
modem
router
3. Connect the power adapter cord into the back of the switch and
then plug the adapter into a power source (such as a wall socket or
power strip).

5
4. Check the LEDs to verify that the equipment is connected correctly.
Power
LED Activity
Power • On. Switch has power.
• Off. No power.
Ports • On. A powered-on device is connected to the port.
• Blinking. Activity on this port.
• Off. No activity on this port.

Technical Specifications
Standards
compatibility • IEEE 802.3i 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX
• Gigabit Ethernet, IEEE 802.3ab 1000 BASE-T, IEEE
802.3x Flow Control
Network interface RJ-45 connector for 10BASE-T, 100BASE-TX, or
1000BASE-T
Power 12W max. and 12V @ 1A DC input
Powerconsumption
(max.) DSG005: 3.56W DSG008: 3.64W
Dimensions
(w x d x h) DSG005: 127 x 87 x 29 mm (5 x 3.43 x 1.14 in.) DSG008: 157 x 95 x 32 mm (6.18 x 3.74 x 1.26 in.)
Weight DSG005: 0.15 kg (0.33 lb)
DSG008: 0.2 kg (0.44 lb.)
Operating
temperature 0° to 40° C (32° to 104° F)
Operating humidity 10% to 90% relative humidity, non-condensing
Electromagnetic
compliance FCC, CE, C-Tick
6

7
Technical Support
Thank you for selecting On Networks products.
After installing your device, locate the serial number on the label of
your product, and use it to register your product at
www.on-networks.com/register. Registration is required before you
can use the telephone support service.
For support, visit www.on-networks.com/support/products/DSG005/
and www.on-networks.com/support/products/DSG008/.
For complete DoC, visit www.on-networks.com/doc.
WARNING: Do not stack equipment, or place equipment in tight
spaces, in drawers, or on carpets. Make sure that your equipment is
surrounded by at least 2 inches (5 cm) of air space.
For indoor use only.

September 2012
