ON Semiconductor ADT7476AARQZ-R User manual

©Semiconductor Components Industries, LLC, 2016
February, 2016 − Rev. 7 1Publication Order Number:
ADT7476A/D
ADT7476A
Remote Thermal Controller
and Voltage Monitor
The ADT7476A controller is a thermal monitor and multiple PWM
fan controller for noise-sensitive or power-sensitive applications
requiring active system cooling. The ADT7476A can drive a fan using
either a low or high frequency drive signal and can monitor the
temperature of up to two remote sensor diodes plus its own internal
temperature. The part also measures and controls the speed of up to
four fans, so the fans operate at the lowest possible speed for minimum
acoustic noise.
The automatic fan speed control loop optimizes fan speed
for a given temperature. The effectiveness of the system’s thermal
solution can be monitored using the THERM input. The ADT7476A
also provides critical thermal protection to the system using the
bidirectional THERM pin as an output to prevent system or
component overheating.
Features
•Monitors Up to Five Voltages
•Improved TACH and PWM Performance
•Controls and Monitors Up to Four Fans
•High and Low Frequency Fan Drive Signal
•One On-Chip and Two Remote Temperature Sensors
•Extended Temperature Measurement Range Up to 191°C
•Automatic Fan Speed Control Mode Controls System Cooling Based
on Measured Temperature
•Enhanced Acoustic Mode Dramatically Reduces User Perception of
Changing Fan Speeds
•Thermal Protection Feature via THERM Output
•Monitors Performance Impact of Intel®Pentium®4 Processor
•Thermal Control Circuit via THERM Input
•3-wire and 4-wire Fan Speed Measurement
•Limit Comparison of All Monitored Values
•5.0 V Support on all TACH and PWM Channels
•Meets SMBus 2.0 Electrical Specifications
•This Device is Pb-Free, Halogen Free and is RoHS Compliant
www.onsemi.com
PIN ASSIGNMENT
See detailed ordering and shipping information in the package
dimensions section on page 68 of this data sheet.
ORDERING INFORMATION
MARKING DIAGRAMS
QSOP−24 NB
CASE 492B
+2.5VIN/THERM
PWM1/XTO
VCCP
+12VIN/VID5
+5VIN
D1+
*TACH4/THERM/SMBALERT/GPIO6/ADDR SELECT
VID4/GPIO4
SDA
SCL
GND
VCC
VID0/GPIO0
VID1/GPIO1
VID2/GPIO2
PWM2/
SMBALERT
24
23
22
21
20
19
18
17
8
7
6
5
4
3
2
1
ADT7476A
16
9
15
10
14
11
13
12
VID3/GPIO3
TACH3
TACH1
TACH2
D1−
D2+
D2−
PWM3/ADDREN
*
(Top View)
ADT7476AARQZ = Specific Device Code
# = Pb-Free Package
YYWW = Date Code
xxxx = Assembly Lot Code
ADT7476AARQZ
#YYWW
xxxx
Downloaded from Arrow.com.

ADT7476A
www.onsemi.com
2
Figure 1. Functional Block Diagram
ADT7476A
PWM REGISTERS
AND CONTROLLERS
(HF AND LF)
AUTOMATIC
FAN SPEED
CONTROL
FAN SPEED
COUNTER
PERFORMANCE
MONITORING
THERMAL
PROTECTION
INPUT
SIGNAL
CONDITIONING
AND
ANALOG
MULTIPLEXER
BAND GAP
TEMP. SENSOR
VCC TO ADT7476A
10-BIT
ADC
BAND GAP
REFERENCE
SMBus
ADDRESS
SELECTION
SERIAL BUS
INTERFACE
ADDRESS
POINTER
REGISTER
PWM
CONFIGURATION
REGISTERS
INTERRUPT
MASKING
INTERRUPT
STATUS
REGISTERS
VALUE AND
LIMIT
REGISTERS
LIMIT
COMPARATORS
GND
ADDR
SELECTADDREN SCL SDA SMBALERT
PWM1
PWM2
PWM3
TACH1
TACH2
TACH3
TACH4
THERM
VCC
D1+
D1−
D2+
D2−
+5VIN
VID/GPIO
REGISTER
+12VIN
+2.5VIN
VCCP
VID0/GPIO0
VID1/GPIO1
VID2/GPIO2
VID3/GPIO3
VID4/GPIO4
VID5/GPIO5
GPIO6
ACOUSTIC
ENHANCEMENT
CONTROL
Figure 2. Serial Bus Timing Diagram
P
S
tSU; DAT
tHIGH
tF
tHD; DAT
tR
tLOW
tSU; STO
PS
SCL
SDA
tBUF
tHD; STA
tHD; STA
tSU; STA
Downloaded from Arrow.com.Downloaded from Arrow.com.

ADT7476A
www.onsemi.com
3
Table 1. ABSOLUTE MAXIMUM RATINGS
Parameter Rating Unit
Positive Supply Voltage (VCC) 3.6 V
Maximum Voltage on +12VIN Pin 16 V
Maximum Voltage on +5.0VIN Pin 6.25 V
Maximum Voltage on SDA, SCL, THERM (Pin 22) and GPIO1−5 Pins 3.6 V
Maximum Voltage on all Tach and PWM Pins +5.5 V
Voltage on Remaining Input or Output Pins −0.3 to +4.2 V
Input Current at Any Pin ±5 mA
Package Input Current ±20 mA
Maximum Junction Temperature (TJMAX) 150 °C
Storage Temperature Range −65 to +150 °C
Lead Temperature, Soldering
IR Reflow Peak Temperature
Pb-Free Peak Temperature
Lead Temperature (Soldering, 10 sec)
220
260
300
°C
ESD Rating 1,500 V
Stresses exceeding those listed in the Maximum Ratings table may damage the device. If any of these limits are exceeded, device functionality
should not be assumed, damage may occur and reliability may be affected.
NOTE: This device is ESD sensitive. Use standard ESD precautions when handling.
Table 2. THERMAL CHARACTERISTICS (Note 1)
Package Type qJA qJC Unit
24-lead QSOP 122 31.25 °C/W
1. JA is specified for the worst-case conditions, that is, a device soldered in a circuit board for surface-mount packages.
Table 3. ELECTRICAL CHARACTERISTICS
(TA=T
MIN to TMAX, VCC =V MIN to VMAX, unless otherwise noted) (Note 1)
Parameter Conditions Min Typ Max Unit
Power Supply
Supply Voltage 3.0 3.3 3.6 V
Supply Current, ICC Interface Inactive, ADC Active 1.5 3.0 mA
Temperature-to-Digital Converter
Local Sensor Accuracy
Resolution
0°C≤TA≤85°C
−40°C≤TA≤125°C− −
−
±0.5
−
0.25
±1.5
±2.5
−
°C
Remote Diode Sensor Accuracy
Resolution
0°C ≤TA≤85°C
−40°C≤TA≤125°C− −
−
±0.5
−
0.25
±1.5
±2.5
−
°C
Remote Sensor Source Current Low Level
High Level − −11 180 − −mA
Analog-to-Digital Converter (Including MUX and Attentuators)
Total Unadjusted Error (TUE) For 12 V Channel
For All Other Channels − −− −±2 ±1.5 %
Differential Non-Linearity (DNL) 8 Bits − − ±1 LSB
Power Supply Sensitivity −±0.1 − %/V
Conversion Time
Voltage Input
Local Temperature
Remote Temperature
Averaging Enabled −
−
−
−
11
12
38
−
−
−
−
ms
Total Monitoring Cycle Time Averaging Enabled
Averaging Disabled − −145 19 − −ms
Input Resistance For VCCP Channel
For All Other Channels 70 70 200 114 − −kW
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

ADT7476A
www.onsemi.com
4
Table 3. ELECTRICAL CHARACTERISTICS (continued)
(TA=T
MIN to TMAX, VCC =V MIN to VMAX, unless otherwise noted) (Note 1)
Parameter UnitMaxTypMinConditions
Fan RPM-to-Digital Converter
Accuracy 0°C≤TA≤70°C
−40°C≤TA≤+120°C− −− −±6 ±10 %
Full-Scale Count − − 65,535
Nominal Input RPM Fan Count = 0xBFFF
Fan Count = 0x3FFF
Fan Count = 0x0438
Fan Count = 0x021C
−
−
−
−
109
329
5,000
10,000
−
−
−
−
RPM
Open-Drain Digital Outputs, PWM1 TO PWM3, XTO
Current Sink, IOL − − 8.0 mA
Output Low Voltage, VOL IOUT = −8.0 mA − − 0.4 V
High Level Output Current, IOH VOUT = VCC − 0.1 20 mA
Open-Drain Serial Data Bus Output (SDA)
Output Low Voltage, VOL IOUT = −4.0 mA − − 0.4 V
High Level Output Current, IOH VOUT = VCC − 0.1 1.0 mA
SMBus Digital Inputs (SCL, SDA) (Note 2)
Input High Voltage, VIH 2.0 − − V
Input Low Voltage, VIL − − 0.8 V
Hysteresis − 500 − mV
Digital Input Logic Levels (TACH Inputs)
Input High Voltage, VIH Maximum Input Voltage 2.0 − 5.5 V
Input Low Voltage, VIL Minimum Input Voltage −0.3 − 0.8 V
Hysteresis − 0.5 − V p-p
Digital Input Logic Levels (THERM) ADTL+
Input High Voltage, VIH 0.75 ×VCCP − − V
Input Low Voltage, VIL − − 0.8 V
Digital Input Current
Input High Current, IIH VIN = VCC −±1 − mA
Input Low Current, IIL VIN = 0 −±1 − mA
Input Capacitance, CIN − 5.0 − pF
Serial Bus Timing (See Figure 2)
Clock Frequency, fSCLK 10 − 400 kHz
Glitch Immunity, tSW @ 100 kHz − − 50 ns
Bus Free Time, tBUF @ 100 kHz 4.7 − − ms
SCL Low Time, tLOW @ 100 kHz 4.7 − − ms
SCL High Time, tHIGH @ 100 kHz 4.0 − 50 ms
SCL, SDA Rise Time, tr@ 100 kHz − − 1,000 ns
SCL, SDA Fall Time, tf@ 100 kHz − − 300 ms
Data Setup Time, tSU;DAT @ 100 kHz 250 − − ns
Detect Clock Low Timeout, tTIMEOUT Can be Optionally Disabled 15 − 35 ms
Product parametric performance is indicated in the Electrical Characteristics for the listed test conditions, unless otherwise noted. Product
performance may not be indicated by the Electrical Characteristics if operated under different conditions.
1. All voltages are measured with respect to GND, unless otherwise specified. Typical voltages are TA=25°C and represent a parametric norm.
Logic inputs accept input high voltages up to VMAX, even when the device is operating down to VMIN. Timing specifications are tested at logic
levels of VIL = 0.8 V for a falling edge, and VIH = 2.0 V for a rising edge.
2. SMBus timing specifications are guaranteed by design and are not production tested.
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

ADT7476A
www.onsemi.com
5
Table 4. PIN ASSIGNMENT
Pin No. Mnemonic Description
1 SDA Digital I/O (Open Drain). SMBus bidirectional serial data. Requires SMBus pullup.
2 SCL Digital Input (Open Drain). SMBus serial clock input. Requires SMBus pullup.
3 GND Ground Pin.
4 VCC Power Supply. Powered by 3.3 V standby, if monitoring in low power states is required. VCC is also
monitored through this pin.
5 VID0/
GPIO0 Digital Input. Voltage supply readouts from CPU. This value is read into the VID/GPIO register (0x43). General-Purpose Open Drain Digital I/O.
6 VID1/
GPIO1 Digital Input. Voltage supply readouts from CPU. This value is read into the VID/GPIO register (0x43). General-Purpose Open Drain Digital I/O.
7 VID2/
GPIO2 Digital Input. Voltage supply readouts from CPU. This value is read into the VID/GPIO register (0x43). General-Purpose Open Drain Digital I/O.
8 VID3/
GPIO3 Digital Input. Voltage supply readouts from CPU. This value is read into the VID/GPIO register (0x43). General-Purpose Open Drain Digital I/O.
9 TACH3 Digital Input (Open Drain). Fan tachometer input to measure speed of Fan 3.
10 PWM2/
SMBALERT
Digital Output (Open Drain). Requires 10 kWtypical pullup. Pulse width modulated output to control Fan
2 speed. Can be configured as a high or low frequency drive.
Digital Output (Open Drain). This pin can be reconfigured as an SMBALERT interrupt output to signal
out-of-limit conditions.
11 TACH1 Digital Input (Open Drain). Fan tachometer input to measure speed of Fan 1.
12 TACH2 Digital Input (Open Drain). Fan tachometer input to measure speed of Fan 2.
13 PWM3
ADDREN
Digital I/O (Open Drain). Pulse width modulated output to control the speed of Fan 3 and Fan 4.
Requires 10 kWtypical pullup. Can be configured as a high or low frequency drive.
If pulled low on powerup, the ADT7476A enters address select mode, and the state of Pin 14 (ADDR
SELECT) determines the ADT7476A’s slave address.
14 TACH4/ Digital Input (Open Drain). Fan tachometer input to measure speed of Fan 4.
THERM/
SMBALERT/
GPIO6/
ADDR SELECT
Alternatively, the pin can be reconfigured as a bidirectional THERM pin. Times and monitors assertions
on the THERM input. For example, it can be connected to the PROCHOT output of Intel’s Pentium®4
processor or to the output of a trip point temperature sensor. Can be used as an output to signal
overtemperature conditions.
Digital Output (Open Drain). This pin can be reconfigured as an SMBALERT interrupt output to signal
out-of-limit conditions.
General-Purpose Open Drain Digital I/O.
If in address select mode, the logic state of this pin defines the SMBus device address.
15 D2– Cathode Connection to Second Thermal Diode.
16 D2+ Anode Connection to Second Thermal Diode.
17 D1– Cathode Connection to First Thermal Diode.
18 D1+ Anode Connection to First Thermal Diode.
19 VID4/ Digital Input. Voltage supply readouts from CPU. This value is read into the VID/GPIO register (0x43).
GPIO4 General-Purpose Open Drain Digital I/O.
20 +5.0 VIN Analog Input. Monitors 5.0 V power supply.
21 +12 VIN/
VID5 Analog Input. Monitors 12 V power supply. Digital Input. Voltage supply readouts from CPU. This value is read into the VID/GPIO register (0x43).
22 +2.5 VIN/
THERM Analog Input. Monitors 2.5 V supply, typically a chipset voltage. Alternatively, this pin can be reconfigured as a bidirectional/omnidirectional THERM pin. Can be used to
time and monitor assertions on the THERM input. For example, can be connected to the PROCHOT
output of Intel’s Pentium®4 processor or to the output of a trip point temperature sensor. Can be used as
an output to signal overtemperature conditions.
23 VCCP Analog Input. Monitors processor core voltage (0 V to 3 V).
24 PWM1/
XTO
Digital Output (Open Drain). Pulse width modulated output to control the speed of Fan 1. Requires 10 kW
typical pullup.
Also functions as the output from the XOR tree in XOR test mode.
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

ADT7476A
www.onsemi.com
6
TYPICAL PERFORMANCE CHARACTERISTICS
Figure 3. Temperature Error vs. Capacitance
Between D+ and D− Figure 4. Remote Temperature Error vs. PCB Resistance
Figure 5. Remote Temperature Error vs.
Common-Mode Noise Frequency Figure 6. Remote Temperature Error vs. Differential-Mode Noise Frequency
Figure 7. Normal IBDDBvs. Power Supply Figure 8. Internal Temperature Error vs. Power
Supply Noise
CAPACITANCE (nF)
0
TEMPERATURE ERROR (°C)
−60 246810
−50
−40
−30
−20
−10
0
12 14 16 18 20 22 LEAKAGE RESISTANCE (MW)
0
TEMPERATURE ERROR (°C)
−40
D+ To VCC
20 40 60 80 100
−30
−20
0
10
20
30
D+ To GND
−10
NOISE FREQUENCY (Hz)
0
TEMPERATURE ERROR (°C)
−5
100 mV
100M 200M 300M 400M 500M 600M
0
5
10
15
20
25
30
60 mV
40 mV
NOISE FREQUENCY (Hz)
0
TEMPERATURE ERROR (°C)
−10
100 mV
100M 200M 300M 400M 500M 600M
0
10
20
30
40
50
60
60 mV
40 mV
70
VDD (V)
3.0
IDD (mA)
0.98 3.1 3.2 3.3 3.4 3.5 3.6
1.00
1.02
1.04
1.06
1.08
1.10
1.12
1.14
1.16
1.18
1.20
FREQUENCY (Hz)
0
TEMPERATURE ERROR (°C)
−15
100 mV
100M 200M 300M 400M 500M 600
M
−10
−5
0
5
10
15
250 mV
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

ADT7476A
www.onsemi.com
7
TYPICAL PERFORMANCE CHARACTERISTICS (Cont’d)
Figure 9. Remote Temperature Error vs. Power
Supply Noise Frequency Figure 10. Internal Temperature Error vs. ADT7476A Temperature
Figure 11. Remote Temperature Error vs. ADT7476A Temperature
FREQUENCY (Hz)
0
TEMPERATURE ERROR (°C)
−12 100M 200M 300M 400M 500M 600M
−10
−8
−6
−4
−2
0
2
4
6
100 mV
250 mV
OIL BATH TEMPERATURE (°C)
−40
TEMPERATURE ERROR (°C)
−20 0 20 40 60 85 105 125
−1.5
−1.0
−0.5
0
0.5
1.0
1.5
2.0
2.5
3.0
OIL BATH TEMPERATURE (°C)
−40
TEMPERATURE ERROR (°C)
−1.5
−20 0 20 40 60 85 105 125
−1.0
−0.5
0
0.5
1.0
1.5
2.0
2.5
3.0
−2.0
Figure 12. THERM Input Threshold vs. VCCP Voltage
VCCP (V)
0
TRIP POINT (V)
00.2 0.4 0.6 0.8 1.0 1.2 1.4 1.6 1.8 2.0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
2.5 V Applied to 2.5 V Pin
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

ADT7476A
www.onsemi.com
8
Product Description
The ADT7476A is a complete thermal monitor and
multiple fan controller for any system requiring thermal
monitoring and cooling. The device communicates with the
system via a serial system management bus. The serial bus
controller has a serial data line for reading and writing
addresses and data (Pin 1), and an input line for the serial
clock (Pin 2). All control and programming functions for the
ADT7476A are performed over the serial bus. In addition,
a pin can be reconfigured as an SMBALERT output to signal
out-of-limit conditions.
Feature Comparisons Between ADT7476A
and ADT7468
•Dynamic TMIN, dynamic operating point, and
associated registers are no longer available in the
ADT7476A. The following related registers are gone:
♦Calibration Control 1 (0x36)
♦Calibration Control 2 (0x37)
♦Operating Point (0x33, 0x34, and 0x35)
•Previously (in the ADT7468), TRANGE defined the slope
of the automatic fan control algorithm. TRANGE now
defines a true temperature range (in the ADT7476A).
•Acoustic filtering is now assigned to temperature zones,
not to fans. Available smoothing times have been
increased for better acoustic performance.
•Temperature measurements are now made with two
switching currents instead of three. SRC is not available
in the ADT7476A.
•High frequency PWM can now be enabled/disabled on
each PWM output individually.
•THERM can now be enabled/disabled on each
temperature channel individually.
•The ADT7476A does not support full shutdown mode.
•The ADT7476A offers increased temperature accuracy
on all temperature channels.
•The ADT7476A defaults to twos complement
temperature measurement mode.
•Some pins have swapped/added functions.
•The powerup routine for the ADT7476A is simplified.
•The ADT7476A has a higher maximum input voltage
TACH/PWM spec, supporting a wider range of fans.
•VCORE_LOW_ENABLE has been reallocated to Bit 7 of
Configuration Register 1 (0x40).
Recommended Implementation
Configuring the ADT7476A as shown in Figure 13 allows
the system designer to use the following features:
•Two PWM outputs for fan control of up to three fans
(the front and rear chassis fans are connected in
parallel).
•Three TACH fan speed measurement inputs.
•VCC measured internally through Pin 4.
•CPU temperature measured using Remote 1
temperature channel.
•Remote temperature zone measured through Remote 2
temperature channel.
•Local temperature zone measured through the internal
temperature channel.
•Bidirectional THERM pin. This feature allows
Intel®Pentium®4 PROCHOT monitoring and can
function as an overtemperature THERM output. It can
alternatively be programmed as an SMBALERT system
interrupt output.
Figure 13. ADT7476A Configuration
AMBIENT
TEMPERATURE
FRONT
CHASSIS
FAN
REAR
CHASSIS
FAN
ADT7476A PWM1
SMBALERT
TACH2
PROCHOT
TACH1
GND
VID[0:4]/VID[0:5]
D2+
D2−
THERM
SDA
SCL
TACH3
PWM3
D1−
D1+
VCC
+5VIN
+12VIN/VID5
5(VRM9)/6(VRM10)
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

ADT7476A
www.onsemi.com
9
Serial Bus Interface
Control of the ADT7476A is carried out using the serial
system management bus (SMBus). The ADT7476A is
connected to this bus as a slave device, under the control of
a master controller. The ADT7476A has a 7-bit serial bus
address. When the device is powered up with Pin 13
(PWM3/ADDREN) high, the ADT7476A has a default
SMBus address of 0101110 or 0x2E. The read/write bit must
be added to get the 8-bit address. If more than one
ADT7476A is to be used in a system, each ADT7476A is
placed in ADDR SELECT mode by strapping Pin 13 low on
powerup. The logic state of Pin 14 then determines the
device’s SMBus address. The logic of these pins is sampled
on powerup.
The device address is sampled on powerup and latched on
the first valid SMBus transaction, more precisely on the
low-to-high transition at the beginning of the eighth SCL
pulse, when the serial bus address byte matches the selected
slave address. The selected slave address is chosen using the
ADDREN pin/ADDR SELECT pin. Any attempted
changes in the address have no effect after this.
Table 5. HARDWIRING THE ADT7476A SMBUS
DEVICE ADDRESS
Pin 13 State Pin 14 State Address
0Low (10 kWto GND) 0101100 (0x2C)
0High (10 kWPullup) 0101101 (0x2D)
1Don’t Care 0101110 (0x2E)
Figure 14. Default SMBus Address = 0x2E
ADDR SELECT
ADT7476A
14
13
PWM3/
ADDREN
10 kW
ADDRESS = 0x2E
VCC
Figure 15. SMBus Address = 0x2C (Pin 14 = 0)
ADDR SELECT
ADT7476A
14
13
PWM3/
ADDREN
10 kW
ADDRESS = 0x2C
Figure 16. SMBus Address = 0x2D (Pin 14 = 1)
ADDR SELECT
ADT7476A
14
13
PWM3/
ADDR_EN
10 kW
ADDRESS = 0x2D
VCC
Figure 17. Unpredictable SMBus Address if Pin 13
is Unconnected
DO NOT LEAVE ADDREN
UNCONNECTED! CAN
CAUSE UNPREDICTABLE
ADDRESSES.
NOTE THAT IF THE ADT7476A IS PLACED INTO ADDR SELECT
MODE, PINS 13 AND 14 CANNOT BE USED AS THE ALTERNATE
FUNCTIONS (PWM3, TACH4/THERM) UNLESS THE CORRECT
CIRCUIT IS MUXED IN AT THE CORRECT TIME OR DESIGNED
TO HANDLE THESE DUAL FUNCTIONS.
CARE SHOULD BE TAKEN TO ENSURE THAT PIN 13
(PWM3/ADDREN) IS EITHER TIED HIGH OR LOW. LEAVING
PIN 13 FLOATING COULD CAUSE THE ADT7476A TO POWER UP
WITH AN UNEXPECTED ADDRESS.
ADDR SELECT
ADT7476A
14
13
PWM3/
ADDREN
10 kW
VCC
NC
The ability to make hardwired changes to the SMBus
slave address allows the user to avoid conflicts with other
devices sharing the same serial bus, for example, if more
than one ADT7476A is used in a system.
The serial bus protocol operates as follows:
1. The master initiates data transfer by establishing a
start condition, which is defined as a high-to-low
transition on the serial data line SDA while the
serial clock line SCL remains high. This indicates
that an address/data stream follows. All slave
peripherals connected to the serial bus respond to
the start condition and shift in the next eight bits,
consisting of a 7-bit address (MSB first), plus a
R/W bit, which determine the direction of the data
transfer, that is, whether data is written to or read
from the slave device.
The peripheral whose address corresponds to the
transmitted address responds by pulling the data
line low during the low period before the ninth
clock pulse, known as the acknowledge bit. All
other devices on the bus now remain idle while the
selected device waits for data to be read from or
written to it. If the R/W bit is a 0, the master writes
to the slave device. If the R/W bit is a 1, the
master reads from the slave device.
2. Data is sent over the serial bus in sequences of
nine clock pulses, eight bits of data followed by an
acknowledge bit from the slave device. Transitions
on the data line must occur during the low period
of the clock signal and remain stable during the
high period. A low-to-high transition, when the
clock is high, can be interpreted as a stop signal.
The number of data bytes transmitted over the
serial bus in a single read or write operation is
limited only by what the master and slave devices
can handle.
3. When all data bytes have been read or written,
stop conditions are established. In write mode, the
master pulls the data line high during the 10th
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

ADT7476A
www.onsemi.com
10
clock pulse to assert a stop condition. In read
mode, the master device overrides the
acknowledge bit by pulling the data line high
during the low period before the ninth clock pulse.
This is known as no acknowledge. The master then
takes the data line low during the low period
before the 10th clock pulse, and then high during
the 10th clock pulse to assert a stop condition.
Any number of bytes of data can be transferred over the
serial bus in one operation. However, it is not possible to mix
read and write in one operation because the type of operation
is determined at the beginning and cannot subsequently be
changed without starting a new operation. In the
ADT7476A, write operations contain either one or two
bytes, and read operations contain one byte.
To write data to one of the device data registers or read
data from it, the address pointer register must be set so the
correct data register is addressed. Then, data can be written
into that register or read from it. The first byte of a write
operation always contains an address stored in the address
pointer register. If data is to be written to the device, then the
write operation contains a second data byte that is written to
the register selected by the address pointer register.
This write operation is illustrated in Figure 18. The device
address is sent over the bus, and then R/W is set to 0. This
is followed by two data bytes. The first data byte is the
address of the internal data register to be written to, which
is stored in the address pointer register. The second data byte
is the data to be written to the internal data register.
When reading data from a register, there are two
possibilities:
1. If the ADT7476A’s address pointer register value
is unknown, or not the desired value, then it must
first be set to the correct value before data can be
read from the desired data register. This is done by
performing a write to the ADT7476A as before,
but only the data byte containing the register
address is sent, because no data is written to the
register (see Figure 19).
A read operation is then performed consisting of
the serial bus address; R/W bit set to 1, followed
by the data byte read from the data register (see
Figure 20.)
2. If the address pointer register is already known to
be at the desired address, data can be read from the
corresponding data register without first writing to
the address pointer register (see Figure 20).
It is possible to read a data byte from a data register
without first writing to the address pointer register, if the
address pointer register is already at the correct value.
However, it is not possible to write data to a register without
writing to the address pointer register, because the first data
byte of a write is always written to the address pointer
register.
In addition to supporting the send byte and receive byte
protocols, the ADT7476A also supports the read byte
protocol. See Intel’s System Management Bus Specifications
Revision 2 for more information.
If several read or write operations must be performed in
succession, the master can send a repeat start condition
instead of a stop condition to begin a new operation.
Figure 18. Writing a Register Address to the Address Pointer Register, then Writing Data to the Selected Register
0
SCL
SDA 10 11A1 A0 D7 D6 D5 D4 D3 D2 D1 D0 ACK. BY
ADT7476A
START BY
MASTER
19
1
ACK. BY
ADT7476A
9
D7 D6 D5 D4 D3 D2 D1 D0 ACK. BY
ADT7476A STOP BY
MASTER
19
SCL (CONTINUED)
SDA (CONTINUED)
FRAME 1
SERIAL BUS ADDRESS BYTE FRAME 2
ADDRESS POINTER REGISTER BYTE
FRAME 3
DATA BYTE
R/W
Figure 19. Writing to the Address Pointer Register Only
0
SCL
SDA 1011A1 A0 D7 D6 D5 D4 D3 D2 D1 D0 ACK. BY
ADT7476A STOP BY
MASTER
START BY
MASTER FRAME 1
SERIAL BUS ADDRESS BYTE FRAME 2 ADDRESS POINTER REGISTER BYTE
119
ACK. BY
ADT7476A
9
R/W
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

ADT7476A
www.onsemi.com
11
Figure 20. Reading Data from a Previously Selected Register
0
SCL
SDA 1011A1 A0 D7 D6 D5 D4 D3 D2 D1 D0
NO ACK. BY
MASTER STOP BY MASTER
START BY
MASTER FRAME 1
SERIAL BUS ADDRESS BYTE FRAME 2 DATA BYTE FROM ADT7476A
119
ACK. BY
ADT7476A
9
R/W
Write Operations
The SMBus specification defines several protocols for
different types of read and write operations. The ones used
in the ADT7476A are discussed below. The following
abbreviations are used in the diagrams:
•S – START
•P – STOP
•R – READ
•W– WRITE
•A – ACKNOWLEDGE
•A– NO ACKNOWLEDGE
The ADT7476A uses the following SMBus write protocols.
Send Byte
In this operation, the master device sends a single
command byte to a slave device, as follows:
1. The master device asserts a start condition on SDA.
2. The master sends the 7-bit slave address followed
by the write bit (low).
3. The addressed slave device asserts ACK on SDA.
4. The master sends a command code.
5. The slave asserts ACK on SDA.
6. The master asserts a stop condition on SDA, and
the transaction ends.
For the ADT7476A, the send byte protocol is used to write
a register address to RAM for a subsequent single-byte read
from the same address. This operation is illustrated in
Figure 21.
Figure 21. Setting a Register Address for
Subsequent Read
SLAVE
ADDRESS WASAP
REGISTER
ADDRESS
231564
If the master is required to read data from the register
immediately after setting up the address, it can assert a repeat
start condition immediately after the final ACK and carry
out a single byte read without asserting an intermediate stop
condition.
Write Byte
In this operation, the master device sends a command byte
and one data byte to the slave device, as follows:
1. The master device asserts a start condition on SDA.
2. The master sends the 7-bit slave address followed
by the write bit (low).
3. The addressed slave device asserts ACK on SDA.
4. The master sends a command code.
5. The slave asserts ACK on SDA.
6. The master sends a data byte.
7. The slave asserts ACK on SDA.
8. The master asserts a stop condition on SDA,
and the transaction ends.
This operation is illustrated in Figure 22.
Figure 22. Single-byte Write to a Register
SLAVE
ADDRESS WA DATASAAP
REGISTER
ADDRESS
23156784
Read Operations
The ADT7476A uses the following SMBus read
protocols.
Receive Byte
This operation is useful when repeatedly reading a single
register. The register address is set up beforehand. In this
operation, the master device receives a single byte from a
slave device, as follows:
1. The master device asserts a start condition on SDA.
2. The master sends the 7-bit slave address followed
by the read bit (high).
3. The addressed slave device asserts ACK on SDA.
4. The master receives a data byte.
5. The master asserts NO ACK on SDA.
6. The master asserts a stop condition on SDA, and
the transaction ends.
In the ADT7476A, the receive byte protocol is used to
read a single byte of data from a register whose address has
previously been set by a send byte or write byte operation.
This operation is illustrated in Figure 23.
Figure 23. Single-byte Read from a Register
SLAVE
ADDRESS DATAARSAP
243156
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

ADT7476A
www.onsemi.com
12
Alert Response Address
Alert response address (ARA) is a feature of SMBus
devices, allowing an interrupting device to identify itself to
the host when multiple devices exist on the same bus.
The SMBALERT output can be used as either an interrupt
output or an SMBALERT. One or more outputs can be
connected to a common SMBALERT line connected to the
master. If a device’s SMBALERT line goes low, the
following procedure occurs:
1. SMBALERT is pulled low.
2. The master initiates a read operation and sends the
alert response address (ARA = 0001 100). This is
a general call address that must not be used as a
specific device address.
3. The device whose SMBALERT output is low
responds to the alert response address, and the
master reads its device address. The address of this
device is now known and can be interrogated per
usual.
4. If more than one device’s SMBALERT output is
low, the one with the lowest device address has
priority in accordance with normal SMBus
arbitration.
5. Once the ADT7476A responds to the alert
response address, the master must read the status
registers, and SMBALERT is cleared only if the
error condition goes away.
SMBus Timeout
The ADT7476A includes an SMBus timeout feature. If
there is no SMBus activity for 35 ms, the ADT7476A
assumes the bus is locked and releases the bus. This prevents
the device from locking or holding the SMBus expecting
data. Some SMBus controllers cannot handle the SMBus
timeout feature, so if necessary, it can be disabled.
Table 6. CONFIGURATION REGISTER 1 (REG. 0x40)
Bit Description
[6] TODIS 0: SMBus Timeout Enabled (Default)
1: SMBus Timeout Disabled
Virus Protection
To prevent rogue programs or viruses from accessing
critical ADT7476A register settings, the lock bit can be set.
Setting Bit 1 of Configuration Register 1 (0x40) sets the
lock bit and locks critical registers. In this mode, certain
registers can no longer be written to until the ADT7476A is
powered down and powered up again. For more information
on which registers are locked see Table 49.
Voltage Measurement Input
The ADT7476A has four external voltage measurement
channels. It can also measure its own supply voltage, VCC.
Pin 20 to Pin 23 can measure 5.0 V, 12 V, and 2.5 V
supplies, and the processor core voltage VCCP (0 V to 3 V
input). The VCC supply voltage measurement is carried out
through the VCC pin (Pin 4). The 2.5 V input can be used to
monitor a chipset supply voltage in computer systems.
Analog-to-Digital Converter
All analog inputs are multiplexed into the on-chip,
successive-approximation, analog-to-digital converter,
which has a resolution of 10 bits. The basic input range is 0 V
to 2.25 V, but the inputs have built-in attenuators to allow
measurement of 2.5 V, 3.3 V, 5.0 V, 12 V, and the processor
core voltage VCCP without any external components. To
allow the tolerance of these supply voltages, the ADC
produces an output of 3/4 full scale (768 dec or 300 hex) for
the nominal input voltage, giving it adequate headroom to
cope with overvoltages.
Input Circuitry
The internal structure for the analog inputs is shown in
Figure 24 The input circuit consists of an input protection
diode, an attenuator, plus a capacitor to form a first-order
low-pass filter that gives input immunity to high frequency
noise.
Figure 24. Structure of Analog Inputs
17.5 kW
52.5 kW
VCCP 35 pF
45 kW
94 kW
+2.5VIN 30 pF
68 kW
71 kW
VCC 30 pF
93 kW
47 kW
+5VIN 30 pF
183.6 kW
30 kW
+12VIN 30 pF
MUX
Table 7. VOLTAGE MEASUREMENT REGISTERS
Register Description Default
0x20 2.5 V Reading 0x00
0x21 VCCP Reading 0x00
0x22 VCC Reading 0x00
0x23 5.0 V Reading 0x00
0x24 12 V Reading 0x00
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

ADT7476A
www.onsemi.com
13
Voltage Limit Registers
Associated with each voltage measurement channel is a
high and low limit register. Exceeding the programmed high
or low limit causes the appropriate status bit to be set.
Exceeding either limit can also generate SMBALERT
interrupts.
Table 8. VOLTAGE LIMIT REGISTERS
Register Description Default
0x44 2.5 V Low Limit 0x00
0x45 2.5 V High Limit 0xFF
0x46 VCCP Low Limit 0x00
0x47 VCCP High Limit 0xFF
0x48 VCC Low Limit 0x00
0x49 VCC High Limit 0xFF
0x4A 5.0 V Low Limit 0x00
0x4B 5.0 V High Limit 0xFF
0x4C 12 V Low Limit 0x00
0x4D 12 V High Limit 0xFF
Table 13 shows the input ranges of the analog inputs and
output codes of the 10-bit ADC.
When the ADC is running, it samples and converts a
voltage input in 0.7 ms and averages 16 conversions to
reduce noise; a measurement takes nominally 11 ms.
Extended Resolution Registers
Voltage measurements can be made with higher accuracy
using the extended resolution registers (0x76 and 0x77).
Whenever the extended resolution registers are read, the
corresponding data in the voltage measurement registers
(0x20 to 0x24) is locked until their data is read. That is, if
extended resolution is required, then the extended resolution
register must be read first, immediately followed by the
appropriate voltage measurement register.
Additional ADC Functions for Voltage Measurements
A number of other functions are available on the
ADT7476A to offer the system designer increased
flexibility.
Turn-off Averaging
For each voltage/temperature measurement read from a
value register, 16 readings have been made internally and the
results averaged before being placed into the value register.
When faster conversions are needed, setting Bit 4 of
Configuration Register 2 (0x73) turns averaging off. This
effectively gives a reading 16 times faster but the reading
can be noisier. The default round robin cycle time takes
146.5 ms.
Table 9. CONVERSION TIME WITH AVERAGING
DISABLED
Channel Measurement Time (ms)
Voltage Channels 0.7
Remote Temperature 1 7
Remote Temperature 2 7
Local Temperature 1.3
When Bit 7 of Configuration Register 6 (0x10) is set, the
default round robin cycle time increases to 240 ms.
Bypass All Voltage Input Attenuators
Setting Bit 5 of Configuration Register 2 (0x73) removes
the attenuation circuitry from the 2.5 V, VCCP, VCC, 5.0 V,
and 12 V inputs. This allows the user to directly connect
external sensors or rescale the analog voltage measurement
inputs for other applications. The input range of the ADC
without the attenuators is 0 V to 2.25 V.
Bypass Individual Voltage Input Attenuators
Bits [7:4] of Configuration Register 4 (0x7D) can be used
to bypass individual voltage channel attenuators.
Table 10. BYPASSING INDIVIDUAL VOLTAGE INPUT
ATTENUATORS
Configuration Register 4 (0x7D)
Bit No. Channel Attenuated
[4] Bypass 2.5 V Attenuator
[5] Bypass VCCP Attenuator
[6] Bypass 5.0 V Attenuator
[7] Bypass 12 V Attenuator
Table 11. CONFIGURATION REGISTER 2 (REG. 0x73)
Bit Description
[4] 1: Averaging Off
[5] 1: Bypass Input Attenuators
[6] 1: Single-channel Convert Mode
TACH1 Minimum High Byte (0x55)
[7:5] Selects ADC channel for single-channel convert mode.
Single-channel ADC Conversion
While single-channel mode is intended as a test mode that
can be used to increase sampling times for a specific
channel, and therefore helps to analyze that channel’s
performance in greater detail, it can also have other
applications.
Setting Bit 6 of Configuration Register 2 (0x73) places
the ADT7476A into single-channel ADC conversion mode.
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

ADT7476A
www.onsemi.com
14
In this mode, the ADT7476A can only read a single voltage
channel. The selected voltage input is read every 0.7 ms. The
appropriate ADC channel is selected by writing to Bits [7:5]
of the TACH1 minimum high byte register (0x55).
Table 12. PROGRAMMING SINGLE-CHANNEL
ADC MODE
Bits [7:4], Register 0x55 Channel Selected (Note 1)
000 2.5 V
001 VCCP
010 VCC
011 5.0 V
100 12 V
101 Remote 1 Temperature
110 Local Temperature
111 Remote 2 Temperature
1. In the process of configuring single-channel ADC conversion
mode, the TACH1 minimum high byte is also changed, possibly
trading off TACH1 minimum high byte functionality with
single-channel mode functionality.
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

ADT7476A
www.onsemi.com
15
Table 13. 10-BIT ADC OUTPUT CODE VS. VIN
Input Voltage ADC Output
12 VIN 5.0 VIN VCC (3.3 VIN)2.5 VIN VCCP VTT/IMON Decimal Binary (10 Bits)
<0.0156 <0.0065 <0.0042 <0.0032 <0.00293 <0.00220 0 00000000 00
0.0156 to
0.0312 0.0065 to 0.0130 0.0042 to 0.0085 0.0032 to 0.0065 0.0293 to 0.0058 0.00220 to 0.00440 100000000 01
0.0312 to
0.0469 0.0130 to 0.0195 0.0085 to 0.0128 0.0065 to 0.0097 0.0058 to 0.0087 0.00440 to 0,00660 200000000 10
0.0469 to
0.0625 0.0195 to 0.0260 0.0128 to 0.0171 0.0097 to 0.0130 0.0087 to 0.0117 0,00660 to 0.00881 300000000 11
0.0625 to
0.0781 0.0260 to 0.0325 0.0171 to 0.0214 0.0130 to 0.0162 0.0117 to 0.0146 0.00881 to 0.01100 400000001 00
0.0781 to
0.0937 0.0325 to 0.0390 0.0214 to 0.0257 0.0162 to 0.0195 0.0146 to 0.0175 0.01100 to 0.01320 500000001 01
0.0937 to
0.1093 0.0390 to 0.0455 0.0257 to 0.0300 0.0195 to 0.0227 0.0175 to 0.0205 0.01320 to 0.01541 600000001 10
0.1093 to
0.1250 0.0455 to 0.0521 0.0300 to 0.0343 0.0227 to 0.0260 0.0205 to 0.0234 0.01541 to 0.01761 700000001 11
0.1250 to
0.14060 0.0521 to 0.0586 0.0343 to 0.0386 0.0260 to 0.0292 0.0234 to 0.0263 0.01761 to 0.01981 800000010 00
− − − − − − − −
4.0000 to
4.0156 1.6675 to 1.6740 1.1000 to 1.1042 0.8325 to 0.8357 0.7500 to 0.7529 0.5636 to 0.5658 256
(1/4 scale) 01000000 00
− − − − − − − −
8.0000 to
8.0156 3.3300 to 3.3415 2.2000–2.204 21.6650 to 1.6682 1.5000 to 1.5029 1.1272 to 1.1294 512
(1/2 scale) 10000000 00
− − − − − − − −
12.0000 to
12.0156 5.0025 to 5.0090 3.3000 to 3.3042 2.4975 to 2.5007 2.2500 to 2.2529 1.6809 to 1.6930 768
(3/4 scale) 11000000 00
− − − − − − − −
15.8281 to
15.8437 6.5983 to 6.6048 4.3527 to 4.3570 3.2942 to 3.2974 2.9677 to 2.9707 2.2301 to 2.2323 1013 11111101 01
15.8437 to
15.8593 6.6048 to 6.6113 4.3570 to 4.3613 3.2974 to 3.3007 2.9707 to 2.9736 2.2323 to 2.2346 1014 11111101 10
15.8593 to
15.8750 6.6113 to 6.6178 4.3613 to 4.3656 3.3007 to 3.3039 2.9736 to 2.9765 2.2346 to 2.2368 1015 11111101 11
15.8750 to
15.8906 6.6178 to 6.6244 4.3656 to 4.3699 3.3039 to 3.3072 2.9765 to 2.9794 2.2368 to 2.23899 1016 11111110 00
15.8906 to
15.9062 6.6244 to 6.6309 4.3699 to 4.3742 3.3072 to 3.3104 2.9794 to 2.9824 2,23899 to 2.2412 1017 11111110 01
15.9062 to
15.9218 6.6309 to 6.6374 4.3742 to 4.3785 3.3104 to 3.3137 2.9824 to 2.9853 2.2412 to 2.2434 1018 11111110 10
15.9218 to
15.9375 6.6374 to 6.4390 4.3785 to 4.3828 3.3137 to 3.3169 2.9853 to 2.9882 2.2434 to 2.2456 1019 11111110 11
15.9375 to
15.9531 6.6439 to 6.6504 4.3828 to 4.3871 3.3169 to 3.3202 2.9882 to 2.9912 2.2456 to 2.2478 1020 11111111 00
15.9531 to
15.9687 6.6504 to 6.6569 4.3871 to 4.3914 3.3202 to 3.3234 2.9912 to 2.9941 2.2478 to 2.25 1021 11111111 01
15.9687 to
15.9843 6.6569 to 6.6634 4.3914 to 4.3957 3.3234 to 3.3267 2.9941 to 2.9970 2.25 to 2.2522 1022 11111111 10
>15.9843 >6.6634 >4.3957 >3.3267 >2.9970 >2.2522 1023 11111111 11
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

ADT7476A
www.onsemi.com
16
VID Code Monitoring
The ADT7476A has five dedicated voltage ID (VID code)
inputs. These are digital inputs that can be read back through
the VID/GPIO register (0x43) to determine the processor
voltage required or the system being used. Five VID code
inputs support VRM9.x solutions. In addition, Pin 21 (12 V
input) can be reconfigured as a sixth VID input to satisfy
future VRM requirements.
VID/GPIO Register (0x43)
[0] = VID0, reflects logic state of Pin 5.
[1] = VID1, reflects logic state of Pin 6.
[2] = VID2, reflects logic state of Pin 7.
[3] = VID3, reflects logic state of Pin 8.
[4] = VID4, reflects logic state of Pin 19.
[5] = VID5, reconfigurable 12 V input. This bit reads 0 when
Pin 21 is configured as the 12 V input. This bit reflects the
logic state of Pin 21 when the pin is configured as VID5.
VID Code Input Threshold Voltage
The switching threshold for the VID code inputs is
approximately 1.0 V. To enable future compatibility, it is
possible to reduce the VID code input threshold to 0.6 V.
Bit 6 (THLD) of the VID/GPIO register (0x43) controls the
VID input threshold voltage.
VID/GPIO Register (0x43)
[6] THLD = 0, VID switching threshold = 1 V,
VOL < 0.8 V, VIH > 1.7 V, VMAX = 3.3 V.
[6] THLD = 1, VID switching threshold = 0.6 V,
VOL < 0.4 V, VIH > 0.8 V, VMAX = 3.3 V.
Reconfiguring Pin 21 as VID5 Input
Pin 21 can be reconfigured as a sixth VID code input
(VID5) for VRM10 compatible systems. Because the pin is
configured as VID5, it is not possible to monitor a 12 V
supply.
Bit 7 of the VID/GPIO register (0x43) determines the
function of Pin 21. System or BIOS software can read the
state of Bit 7 to determine whether the system is designed to
monitor 12 V or a sixth VID input.
VID/GPIO Register (0x43)
[7] VIDSEL = 0, Pin 21 functions as a 12 V measurement
input. Software can read this bit to determine that there are
five VID inputs being monitored. Bit 5 of VID/GPIO
Register (0x43) always reads back 0. Bit 0 of Interrupt
Status Register 2 (0x42) reflects 12 V out-of-limit
measurements.
[7] VIDSEL = 1, Pin 21 functions as the sixth VID code
input (VID5). Software can read this bit to determine that
there are six VID inputs being monitored. Bit 5 of
Register 0x43 reflects the logic state of Pin 21. Bit 0 of
Interrupt Status Register 2 (0x42) reflects VID code
changes.
VID Code Change Detect Function
The ADT7476A has a VID code change detect function.
When Pin 21 is configured as the VID5 input, VID code
changes are detected and reported back by the ADT7476A.
Bit 0 of Interrupt Status Register 2 (0x42) is the 12 V/VC bit
and denotes a VID change when set. The VID code change
bit is set when the logic states on the VID inputs are different
than they were 11 ms previously. The change of VID code is
used to generate an SMBALERT interrupt. If an
SMBALERT interrupt is not required, Bit 0 of Interrupt
Mask Register 2 (0x75), when set, prevents SMBALERTs
from occurring on VID code changes.
Interrupt Status Register 2 (0x42)
[0] 12 V/VC = 0, if Pin 21 is configured as VID5, Logic 0
denotes no change in VID code within the last 11 ms.
[0] 12 V/VC = 1, if Pin 21 is configured as VID5, Logic 1
means that a change has occurred on the VID code inputs
within the last 11 ms. An SMBALERT is generated, if this
function is enabled.
Programming the GPIOs
The ADT7476A follows an upgrade path from the
ADM1027 to the ADT7476A. In order to maintain
consistency between versions, it is necessary to omit
references to GPIO5. As a result, there are six GPIOs as
follows: GPIO0, GPIO1, GPIO2, GPIO3, GPIO4, and
GPIO6.
Setting Bit 4 of Configuration Register 5 (0x7C) to 1
enables GPIO functionality. This turns all pins configured as
VID inputs into general-purpose outputs. Writing to the
corresponding VID bit in the VID/GPIO register (0x43) sets
the polarity for the corresponding GPIO. GPIO6 can be
programmed independently as, for example, an input or
output, using Bits [3:2] of Configuration Register 5 (0x7C).
Temperature Measurement Method
Local Temperature Measurement
The ADT7476A contains an on-chip band gap
temperature sensor whose output is digitized by the on-chip,
10-bit ADC. The 8-bit MSB temperature data is stored in the
temperature registers (Addresses 0x25, 0x26, and 0x27).
Because both positive and negative temperatures can be
measured, the temperature data is stored in Offset 64 format
or twos complement format, as shown in Table 14 and
Table 15. Theoretically, the temperature sensor and ADC
can measure temperatures from −63°C to +127°C (or −61°C
to +191°C in the extended temperature range) with a
resolution of 0.25°C. However, this exceeds the operating
temperature range of the device, so local temperature
measurements outside the ADT7476A operating
temperature range are not possible.
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

ADT7476A
www.onsemi.com
17
Table 14. TWOS COMPLEMENT TEMPERATURE DATA
FORMAT
Temperature Digital Output (10-bit) (Note 1)
–128°C1000 0000 00 (Diode Fault)
–50°C1100 1110 00
–25°C1110 0111 00
–10°C1111 0110 00
0°C0000 0000 00
+10.25°C0000 1010 01
+25.5°C0001 1001 10
+50.75°C0011 0010 11
+75°C0100 1011 00
+100°C0110 0100 00
+125°C0111 1101 00
+127°C0111 1111 00
1. Bold numbers denote 2 LSB of measurement in the Extended
Resolution Register 2 (0x77) with 0.25°C resolution.
Table 15. EXTENDED RANGE, TEMPERATURE DATA
FORMAT
Temperature Digital Output (10-bit) (Note 1)
–64°C0000 0000 00 (Diode Fault)
–1°C0011 1111 00
0°C0100 0000 00
1°C0100 0001 00
10°C0100 1010 00
25°C0101 1001 00
50°C0111 0010 00
75°C1000 1001 00
100°C1010 0100 00
125°C1011 1101 00
191°C1111 1111 00
1. Bold numbers denote 2 LSB of measurement in the Extended
Resolution Register 2 (0x77) with 0.25°C resolution.
Remote Temperature Measurement
The ADT7476A can measure the temperature of two
remote diode sensors or diode-connected transistors
connected to Pin 17 and Pin 18, or Pin 15 and Pin 16.
The forward voltage of a diode or diode-connected
transistor operated at a constant current exhibits a negative
temperature coefficient of about –2 mV/°C. Unfortunately,
the absolute value of VBE varies from device to device, and
individual calibration is required to null this out. As a result,
this technique is unsuitable for mass production. The
technique used in the ADT7476A is to measure the change
in VBE when the device is operated at two different currents.
This is given by:
(eq. 1)
DVBE +kT
q In(N)
where:
k is the Boltzmann’s constant.
q is the charge on the carrier.
T is the absolute temperature in Kelvin.
N is the ratio of the two currents.
Figure 25 shows the input signal conditioning used to
measure the output of a remote temperature sensor. This
figure shows the external sensor as a substrate transistor,
which is provided on some microprocessors for temperature
monitoring. It could also be a discrete transistor such as a
2N3904/2N3906.
If a discrete transistor is used, the collector is not grounded
and is linked to the base. If a PNP transistor is used, the base
is connected to the D– input and the emitter to the D+ input.
If an NPN transistor is used, the emitter is connected to the
D– input and the base to the D+ input. Figure 26 and
Figure 27 show how to connect the ADT7476A to an NPN
or PNP transistor for temperature measurement. To prevent
ground noise from interfering with the measurement, the
more negative terminal of the sensor is not referenced to
ground, but is biased above ground by an internal diode at
the D– input.
Figure 25. Signal Conditioning for Remote Diode Temperature Sensors
LOW-PASS FILTER
fC= 65 kHz
REMOTE
SENSING
TRANSISTOR BIAS
DIODE
D+
D−
V
DD
IBIAS IN×I
VOUT+
VOUT−
To ADC
THERMDA
THERMDC
CPU
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

ADT7476A
www.onsemi.com
18
Figure 26. Measuring Temperature by Using
an NPN Transistor
ADT7476A
D+
D−
2N3904
NPN
Figure 27. Measuring Temperature by Using
an PNP Transistor
ADT7476A
D+
D−
2N3906
PNP
To measure DVBE, the sensor switches between operating
currents of I and N ×I. The resulting waveform passes
through a 65 kHz low-pass filter to remove noise and
through a chopper-stabilized amplifier. The amplifier
performs the amplification and rectification of the
waveform to produce a dc voltage proportional to DVBE.
This voltage is measured by the ADC to give a temperature
output in 10-bit, twos complement format. To further reduce
the effects of noise, digital filtering is performed by averaging
the results of 16 measurement cycles.
A remote temperature measurement takes nominally
38 ms. The results of remote temperature measurements are
stored in 10-bit, twos complement format, as illustrated in
Table 22. The extra resolution for the temperature
measurements is held in the Extended Resolution Register 2
(0x77). This gives temperature readings with a resolution of
0.25°C.
Noise Filtering
For temperature sensors operating in noisy environments,
previous practice placed a capacitor across the D+ pin and
the D− pin to help combat the effects of noise. However,
large capacitances affect the accuracy of the temperature
measurement, leading to a recommended maximum
capacitor value of 1,000 pF.
This capacitor reduces the noise but does not eliminate it,
which makes using the sensor difficult in a very noisy
environment. In most cases, a capacitor is not required
because differential inputs by their very nature have a high
immunity to noise.
Factors Affecting Diode Accuracy
Remote Sensing Diode
The ADT7476A is designed to work with substrate
transistors built into processors or with discrete transistors.
Substrate transistors are generally PNP types with the
collector connected to the substrate. Discrete types can be
either PNP or NPN transistors connected as a diode
(base-shorted to the collector). If an NPN transistor is used,
the collector and base are connected to D+ and the emitter
to D−. If a PNP transistor is used, the collector and base are
connected to D− and the emitter is connected to D+.
To reduce the error due to variations in both substrate and
discrete transistors, a number of factors should be taken into
consideration:
•The ideality factor, nf, of the transistor is a measure of
the deviation of the thermal diode from ideal behavior.
The ADT7476A is trimmed for an nfvalue of 1.008.
Use the following equation to calculate the error
introduced at a temperature T (°C), when using a
transistor whose nfdoes not equal 1.008 (see the
processor’s data sheet for the nf values):
DT+(nf *1.008) ǒ273.15 K )TǓ(eq. 2)
To factor this in, the user can write the DT value to the
offset register. The ADT7476A then automatically
adds it to or subtracts it from the temperature
measurement.
•Some CPU manufacturers specify the high and low
current levels of the substrate transistors. The high
current level of the ADT7476A, IHIGH, is 180 mA, and
the low level current, ILOW, is 11 mA. If the ADT7476A
current levels do not match the current levels specified
by the CPU manufacturer, it could be necessary to
remove an offset. The CPU’s data sheet advises
whether this offset needs to be removed and how to
calculate it. This offset can be programmed to the offset
register. It is important to note that if more than one
offset must be considered, then the algebraic sum of
these offsets must be programmed to the offset register.
If a discrete transistor is used with the ADT7476A, the
best accuracy is obtained by choosing devices according to
the following criteria:
•Base-emitter voltage greater than 0.25 V at 11 mA, at
the highest operating temperature.
•Base-emitter voltage less than 0.95 V at 180 mA,
at the lowest operating temperature.
•Base resistance less than 100 W.
•Small variation in the current gain, hFE, (approximately
50 to 150) that indicates tight control of VBE
characteristics.
Transistors, such as 2N3904, 2N3906, or equivalents in
SOT−23 packages, are suitable devices to use.
Nulling Out Temperature Errors
As CPUs run faster, it is more difficult to avoid high
frequency clocks when routing the D+/D– traces around a
system board. Even when recommended layout guidelines
are followed, some temperature errors can still be
attributable to noise coupled onto the D+/D– lines. Constant
high frequency noise usually attenuates, or increases,
temperature measurements by a linear, constant value.
The ADT7476A has temperature offset registers (0x70
and 0x72) for the Remote 1 and Remote 2 temperature
channels. By doing a one-time calibration of the system, the
user can determine the offset caused by system board noise
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

ADT7476A
www.onsemi.com
19
and null it out using the offset registers. The offset registers
automatically add a twos complement 8-bit reading to every
temperature measurement.
Changing Bit 1 of Configuration Register 5 (0x7C)
changes the resolution and therefore, the range of the
temperature offset as either having a −63°C to +127°C range
with a resolution of 1°C or having a −63°C to +64°C range
with a resolution of 0.5°C. This temperature offset can be
used to compensate for linear temperature errors introduced
by noise.
Table 16. TEMPERATURE OFFSET REGISTERS
Register Description Default
0x70 Remote 1 Temperature Offset 0x00 (0°C)
0x71 Local Temperature Offset 0x00 (0°C)
0x72 Remote 2 Temperature Offset 0x00 (0°C)
ADT7463/ADT7476A Backwards Compatible Mode
By setting Bit 0 of Configuration Register 5 (0x7C), all
temperature measurements are stored in the zone
temperature reading registers (0x25, 0x26, and 0x27) in
twos complement in the −63°C to +127°C range. The
temperature limits must be reprogrammed in twos
complement.
If a twos complement temperature below −63°C is
entered, the temperature is clamped to −63°C. In this mode,
the diode fault condition remains −128°C = 1000 0000,
while in the extended temperature range (−63°C to +191°C),
the fault condition is represented by −64°C = 0000 0000.
Table 17. TEMPERATURE READING REGISTERS
Register Description Default
0x25 Remote 1 Temperature −
0x26 Local Temperature −
0x27 Remote 2 Temperature −
0x77 Extended Resolution 2 0x00
Table 18. EXTENDED RESOLUTION TEMPERATURE
MEASUREMENT REGISTER BITS
Bit Mnemonic Description
[7:6] TDM2 Remote 2 Temperature LSBs
[5:4] LTMP Local Temperature LSBs
[3:2] TDM1 Remote 1 Temperature LSBs
Temperature Limit Registers
Associated with each temperature measurement channel
are high and low limit registers. Exceeding the programmed
high or low limit causes the appropriate status bit to be set.
Exceeding either limit can also generate SMBALERT
interrupts (depending on the way the interrupt mask register
is programmed and assuming that SMBALERT is set as an
output on the appropriate pin).
Table 19. TEMPERATURE LIMIT REGISTERS
Register Description Default
0x4E Remote 1 Temperature Low Limit 0x81
0x4F Remote 1 Temperature High Limit 0x7F
0x50 Local Temperature Low Limit 0x81
0x51 Local Temperature High Limit 0x7F
0x52 Remote 2 Temperature Low Limit 0x81
0x53 Remote 2 Temperature High Limit 0x7F
Reading Temperature from the ADT7476A
It is important to note that temperature can be read from
the ADT7476A as an 8-bit value (with 1°C resolution) or as
a 10-bit value (with 0.25°C resolution). If only 1°C
resolution is required, the temperature readings can be read
back at any time and in no particular order.
If the 10-bit measurement is required, this involves a
2-register read for each measurement. Extended Resolution
Register 2 (0x77) should be read first. This causes all
temperature reading registers to be frozen until all
temperature reading registers have been read from. This
prevents an MSB reading from being updated while its two
LSBs are being read and vice versa.
Additional ADC Functions for Temperature
Measurement
A number of other functions are available on the
ADT7476A to offer the system designer increased
flexibility.
Turn-off Averaging
For each temperature measurement read from a value
register, 16 readings have actually been made internally, and
the results averaged, before being placed into the value
register. Sometimes it is necessary to take a very fast
measurement. Setting Bit 4 of Configuration Register 2
(0x73) turns averaging off. The default round robin cycle
time takes 146.5 ms.
Table 20. CONVERSION TIME WITH AVERAGING
DISABLED
Channel Measurement Time (ms)
Voltage Channels 0.7
Remote Temperature 1 7
Remote Temperature 2 7
Local Temperature 1.3
When Bit 7 of Configuration Register 6 (0x10) is set, the
default round robin cycle time increases to 240 ms.
Table 21. CONVERSION TIME WITH AVERAGING
ENABLED
Channel Measurement Time (ms)
Voltage Channels 11
Remote Temperature 39
Local Temperature 12
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

ADT7476A
www.onsemi.com
20
Single-channel ADC Conversions
Setting Bit 6 of Configuration Register 2 (0x73) places
the ADT7476A into single-channel ADC conversion mode.
In this mode, the ADT7476A can be made to read a single
temperature channel only. The appropriate ADC channel is
selected by writing to Bits [7:5] of the TACH1 minimum
high byte register (0x55).
Table 22. PROGRAMMING SINGLE-CHANNEL ADC
MODE FOR TEMPERATURES
Bits [7:5], Register 0x55 Channel Selected
101 Remote 1 Temperature
110 Local Temperature
111 Remote 2 Temperature
Table 23. CONFIGURATION REGISTER 2 (REG. 0x73)
Bit Description
[4] 1: Averaging Off
[6] 1: Single-channel Convert Mode
TACH1 Minimum High Byte (0x55)
[7:5] selects ADC channel for single-channel convert mode.
Overtemperature Events
Overtemperature events on any of the temperature
channels can be detected and dealt with automatically in
automatic fan speed control mode. Register 0x6A to
Register 0x6C are the THERM temperature limits. When a
temperature exceeds its THERM temperature limit, all
PWM outputs run at the maximum PWM duty cycle
(Register 0x38, Register 0x39, and Register 0x3A).
This effectively runs the fans at the fastest allowed speed.
The fans run at this speed until the temperature drops
below THERM minus hysteresis. This can be disabled by
setting Bit 2, the boost bit, in Configuration Register 3
(0x78). The hysteresis value for the THERM temperature
limit is the value programmed into the hysteresis registers
(0x6D and 0x6E). The default hysteresis value is 4°C.
Figure 28. THERM Temperature Limit Operation
THERM LIMIT
TEMPERATURE
FANS 100%
HYSTERESIS (°C)
THERM can be disabled on specific temperature channels
using Bits [7:5] of Configuration Register 5 (0x7C).
THERM can also be disabled by:
•Writing −64°C to the appropriate THERM temperature
limit in Offset 64 mode.
•Writing −128°C to the appropriate THERM
temperature limit in twos complement mode.
Limits, Status Registers, and Interrupts
Limit Values
Associated with each measurement channel on the
ADT7476A are high and low limits. These can form the
basis of system status monitoring; a status bit can be set for
any out-of-limit condition and is detected by polling the
device. Alternatively, SMBALERT interrupts can be
generated to flag out-of-limit conditions to a processor
or microcontroller.
8-bit Limits
The following is a list of 8-bit limits on the ADT7476A.
Table 24. VOLTAGE LIMIT REGISTERS
Register Description Default
0x44 2.5 V Low Limit 0x00
0x45 2.5 V High Limit 0xFF
0x46 VCCP Low Limit 0x00
0x47 VCCP High Limit 0xFF
0x48 VCC Low Limit 0x00
0x49 VCC High Limit 0xFF
0x4A 5.0 V Low Limit 0x00
0x4B 5.0 V High Limit 0xFF
0x4C 12 V Low Limit 0x00
0x4D 12 V High Limit 0xFF
Table 25. TEMPERATURE LIMIT REGISTERS
Register Description Default
0x4E Remote 1 Temperature Low Limit 0x81
0x4F Remote 1 Temperature High Limit 0x7F
0x6A Remote 1 THERM Temp. Limit 0x64
0x50 Local Temperature Low Limit 0x81
0x51 Local Temperature High Limit 0x7F
0x6B Local THERM Temperature Limit 0x64
0x52 Remote 2 Temperature Low Limit 0x81
0x53 Remote 2 Temperature High Limit 0x7F
0x6C Remote 2 THERM Temp. Limit 0x64
Table 26. THERM TIMER LIMIT REGISTER
Register Description Default
0x7A THERM Timer Limit 0x00
16-bit Limits
The fan TACH measurements are 16-bit results. The fan
TACH limits are also 16 bits, consisting of a high byte and
low byte. Because fans running under speed or stalled are
normally the only conditions of interest, only high limits
exist for fan TACHs. Because the fan TACH period is
actually being measured, exceeding the limit indicates a
slow or stalled fan.
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.
