One Remote 2805 User manual

Page 4
Operating with Beolink 1000
Beolink 1000 does not have as many
keys as the DVD/HDD recorder’s
original remote control. Thus certain
Beolink 1000 keys have got
alternative functionality. To get to this
phas to be pressed first, i.e.
pfollowed by 9on a
Beolink 1000 corresponds to “Power”
on the original remote control.
The table shows how special Beolink
1000 key operations translate to
operations of the original remote
control.
To be able to operate the DVD/HDD
recorder correctly with the Beolink
1000 the user has to be familiar with
operations with the original remote
control as described in the
DVD/HDD’s user manual.
The DVD/HDD recorder is
automatically turned on when
selecting its ion the TV. The
ican be VTAPE, DVD, SAT
etc.
There is no key on a Beolink 1000
marked i.
Beolink 1000 Operation
pp Play
g Enter
x Return
iZ HDD
iX DVD
iq Power off
hX Prog/ Check
hC >>
hV <<
pq Pause
pC Top menu
pV Menu
pZ Previous chapter
pX Next chapter
p0 Clear
p1 Functions
p2 Showview
p3 Timeslip
p4 Timer
p5 Display
p6 Erase
p7 Rec mode
p8 Record
p9 Power
px Input select
iC CH+
iV CH-
Beocompatible* Operation via
Oneremote Interface Module 2805
for Panasonic DMR-HS2
Beo4 and Beolink 1000 are remote control terminals from Bang & Olufsen. Oneremote supplies interface modules that allow third party equipment to be operated via a Bamg & Olufsen remote control system.
made in the EU by www.oneremote.dk
Type 2805gb3

Page 2
Congratulations
With the interface module EXT from
www.oneremote.dk connected to your
Panasonic DVD/HDD recorder and a Bang
& Olufsen TV you can operate the receiver
with your Bang & Olufsen remote control
terminal. This user guide tells you how.
Plug and Play
The DVD/HDD can be connected directly to
a vacant linkequipped AV socket on the
Bang & Olufsen TV with the special EXT
scart connection cable and adaptor. The
powersupply connects to the EXT and the
mains.
The EXT IR diode is taped underneath the
receiver as close as possible to the front and
the receiver’s own IR receiver.
Following the correct programming of the
AV connection the DVD/HDD recorder is
ready to operate. For programming of the
AV connection check the Bang & Olufsen
TV User Manual.
If the Bang & Olufsen TV does not have a useable
vacant AV socket a Oneremote AV Selector can be
supplied.
Bang & Olufsen Remote Controls
With your beocompatible* DVD/HDD
recorder connected to a Bang & Olufsen TV
you may operate it with your Beolink 1000,
5000, 7000 or Beo4.
With Beo4 the operation is slightly easier.
Thus Beo4 is the recommended remote
control for this DVD/HDD recorder.
Operation in a Beolink Videosystem
In a Bang & Olufsen Beolink videosystem
full operability is ensured in all link rooms.
*Beocompatible means that the equipment is installed
as a Bang & Olufsen product and can be operated with
a Bang & Olufsen remote control when connected to a
B
ang & Olufsen TV.
Page 3
Operating with Beo4
Beo4 does not have as many keys as the
DVD/HDD recorder’s original remote
control. Thus certain Beo4 keys have got
alternative functionality. To get to this
Ohas to be pressed first, i.e.
Ofollowed by qon a Beo4
corresponds to PAUSE on the original
remote control.
The table shows how special Beo4 key
operations translate to operations of the
original remote control.
To be able to operate the DVD/HDD
recorder correctly with the Beo4 the user has
to be familiar with operations with the
original remote control as described in the
DVD/HDD’s user manual.
The DVD/HDD is automatically turned on
when selecting its ion the TV. The
i
can be VTAPE, DVD, SAT etc.
There is no key on a Beo4 marked i.
Beo4 Operation
OO Play
oD Top menu
oF Menu
oA Previous track
oS Next track
QEnter
WProg/ Check
E <<
R>>
i
A HDD
i
S DVD
i
qPower off
e
Return
oe Input select
oQ Functions
oW Showview
oE Record
oR Display
oq Pause
o0 Clear
o3 Timeslip
o4 Timer
o6 Erase
o7 Rec mode
o8 Record
o9 Power
i
D CH+
i
F CH-
