oneup 1000 User manual

Contact us:
[e-mail]
WARNING
1. Keep ONEUP 1000 and the accessories dry and do not expose
them to high heat.
2. Never disassemble, puncture, shock, crash, or incinerate
the product or the accessories.
3. Recycle and dispose of ONEUP 1000 in accordance with the
local regulations.
4. Pay attention to safety when handling the ONEUP 1000.
5. People with disabilities or children should use the machine
under the protection of the supervisor.
ONEUP 1000 | User Manual

GLOSSARY
PRODUCT SAFETY GUIDELINES
The following terms are used in this document to indicate various levels of potential harm that may be caused by
improper operation.
The instructions, if not properly followed, may result in property damage and minor physical damage.
Improper use may result in fire, property damage or personal injury. Make sure to use the product according to
the following safety rules and guidelines.
WARNING
WARNING
Read the ENTIRE user manual to be familiar with the features of this product before operating. Failure to
operate the product correctly may result in damage to the product or personal property and cause serious
injury. ONEUP will not assume any legal responsibility. DO NOT use the product with incompatible components
or alter the product in any way without following the instructions provided by ONEUP. Otherwise, you cannot
get after-sales service from ONEUP under warranty condition. These Safety Guidelines include instructions for
safety, operation and maintenance. It is important to read and follow all the instructions and warnings in the
user manual before assembly, setup or use the product.
NOTICE
The instructions, if not properly followed, may result in property damage and serious physical damage.
CAUTION
The instructions, if not properly followed, may result in property damage, major accident and serious injury.
WARNING
1. Do not expose ONEUP 1000 to any liquid. Keep the ONEUP 1000 away from rain or any liquid. Do not drop the
ONEUP 1000 into the water. If the battery in the ONEUP 1000 comes into contact with water, it may cause chemical
decomposition of the battery. This may cause the battery to catch fire or explode.
2. Never use NON-ONEUP batteries. ONEUP takes no responsibility for any damage caused by non-ONEUP batteries.
3. Never use or charge swollen, leaky, or damaged batteries. If your battery is abnormal, contact ONEUP support or a
ONEUP authorized dealer for further assistance.
4. Never install or remove a battery from the ONEUP 1000 when it is turned on.
5. DO NOT use the batteries in strong electrostatic or electromagnetic environments. Otherwise, the battery control
board may malfunction and cause a serious accident during use.
Product use:

6. Never disassemble or pierce the product in any way. Otherwise, it may leak, catch on fire, or explode.
7. DO NOT use the product if it was involved in a crash or a heavy bump.
8. If the product falls into the water during use,take the product out immediately and put it in a safe and open area.
Keep a safe distance from it until it is completely dry. Never use it again and dispose it properly as described in the
Battery Disposal section below. If the product catches fire, it is recommended to use fire extinguishing equipment in
the following order: water or water mist, sand, fire blanket, dry powder, carbon dioxide fire extinguisher.
9. DO NOT put the machine in a microwave oven or in a pressurized container.
10. DO NOT allow pins, wires or other metal pieces to insert to the device case, outlets or controls. Metal pieces may
short circuit the product.
11. Avoid collision. DO NOT place heavy objects on the machine.
12. If there is dirt on any plug or outlet surface, use a dry cloth to clean it. Otherwise, it will cause abrasion and result in
energy loss or inability to charge.
1. Dispose the product in specific recycling boxes only after a complete discharge. Batteries are hazardous chemicals.
Please strictly follow your local regulations regarding the battery disposal and recycle.
2. Dispose of the product immediately if it cannot be powered on after over-discharging.
Battery Disposal:
WARNING
Product Charging:
1. Keep the product out of the reach of children. If any children accidentally swallow parts, please go to a doctor immediately.
2. If a low-battery warning appears, charge the battery before store it. Otherwise, long-term storage may cause damage to the
battery in the product. Batteries in the product will enter hibernation mode if it is depleted and stored for a long time.
Recharge the product can bring the battery out of hibernation.
3. DO NOT place the product near a heat source, such as a car in direct sunlight, a fire source, or a heating stove.
4. Store the product in dry environments. DO NOT place the product where it may contact with water.
5. Make sure no small metal objects can fall on or around the product while in storage.
6. Never ship a product with a battery power level higher than 30%.
Product Storage and Transportation:
1. Always use ONEUP approved charging cables. ONEUP takes no responsibility for any damage caused by using
non-ONEUP charging cable.
2. When charging, please place the product on the ground with no flammable or combustible materials around. To
prevent accidents, never leave the machine unattended during charging.
3. DO NOT charge a product immediately after a long heavy load, because the product’s temperature may be too high.
DO NOT charge a product until it cools down to room temperature. The product may be unable to charge out of the
temperature range 32ºF to 113ºF (0 to 45°C). The ideal charging temperature range is 71ºF to 82ºF(22°C to 28°C).

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment offˈand on, the user is encouraged to
try to correct the interference by one or more of the following measures:
1.Orient or relocate the receiving antenna.
2.Increase the separation between the equipment and receiver.
3.Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
4.Consult the dealer or an experienced radio/TV technician for help.
It is forbidden to carry lithium batteries above a specific capacity on airplanes due to flight regulations. Please check
local flight laws and regulations. DO NOT bring this product on flights.
This product complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This product may not cause harmful interference, and
(2) This product must accept any interference received, including interference that may cause undesired
operation.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 20cm between the radiator & your body.
Travel Notice:
1. Never store the product in environments below -20°C or above 45°C.
2. Battery life may be reduced if not used for a long time.
3. Discharge ONEUP 1000 to 30%, then charge to 85% every 3 month to maintain battery health.
Product Maintenance:
FCC STATEMENT
FCC RADIATION EXPOSURE STATEMENT
Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
W
ARNING
N
O
TICE

CONTENTS
1
ONEUP 1000 USE CARE AND SAFETY GUIDE
2
FEATURES of ONEUP 1000
LCD DISPLAY
SOLAR PANEL CONNECTION
ENTRY-LEVEL UPS AND SERIES MODE
TECHNICAL SPECIFICATIONS
HOW TO RECHARGE ONEUP 1000
FAQs
WHAT’S IN THE BOX
4
8
9
11
12
12
13

Please note:
To turn ON/OFF ONEUP 1000, you need to PRESS & HOLD the Power Button. To turn on the AC power
outlet, you need to PRESS & HOLD the AC Button after turning on ONEUP 1000. This is designed
purposefully: it will save the battery life, so that your ONEUP 1000’s power is available when you need it.
ONEUP 1000 USE CARE AND SAFETY GUIDE
CONGRATULATIONS!
You now own the best quality Portable Battery Generator in the world. This pamphlet is short and is meant to help
you. Please take some time to read it before using the product.
Get to know your ONEUP 1000. Follow this step-by-step introduction to each of ONEUP 1000’s ports, buttons, display
screens and more.
Battery Maintenance:
Understanding the specs that make ONEUP 1000 such a cutting-edge product.
Technical Specifications:
Everything you need to know about recharging your ONEUP 1000 via AC Cable, car charge cable or solar charge cable
(If applicable).
How to Charge ONEUP 1000:
Answers to you some of the most important questions about how to take care of your ONEUP 1000, store your ONEUP
1000, and safely use your ONEUP 1000.
FAQs:
What include in your ONEUP 1000 purchase. If your purchase does not include these items, please contact us at
[email protected].
What’s in the Box:
NOTICE
1

FEATURES OF ONEUP 1000
7. AC ON/OFF Switch
(PRESS & HOLD for ON/OFF)
AC Output Indicator Light
8. Ventilation Vents
9. AC Output Sockets (100-120V)
10. Car Outlet & Car Outlet Indicator
9
1
3
6
25
11 12 13
10
7
4
8
2
1. LCD Display
Charge a wide array of devices such as your iPhone, tablet, GoPro, speakers, or anything that needs to be charged
through a USB-A Port. The USB-A Output Indicator Light will automatically light up when a USB-A port is in use.
2. USB-A Output Ports
11. Solar Charge/Car Charge Input Port
12. AC Charging Input Port
13. Overload Protection Switch
1. LCD Display
2. USB-A Output Ports
3. USB-C Output Port
4. DC ON/OFF Switch
(PRESS & HOLD to switch ON/OFF)
DC Output Indicator
5. Fast Charge USB-A Output Ports
6. Power ON/OFF Button
Full Sine Wave
Displays the various conditions of the product. The screen will turn off after 5 mins. You can turn it on by pressing
ON/OFF button.

Devices that charge through a USB-C port, such as a MacBook Pro, Android phone, or other devices can be
charged by the ONEUP 1000 USB-C port. The USB-C Output icon will appear on LCD Display when a USB port is in
use.
3. USB-C Output Ports
The USB-A Output Indicator Light will automatically light up when a USB-A port is in use. Fast charge-enabled devices
can be charged at a maximum speed of 18W. If your device does not support fast charging, the device will charge in
regular speed.
5. Fast Charge USB-A Output Ports
Press and hold the power button to turn ONEUP 1000 on or off. When ONEUP 1000 is turned on the LCD Display Screen
will light up. To turn ON/OFF LCD Display Screen and keep ONEUP 1000 working, press the Power Button. The Power
Indicator Light will automatically light up when ONEUP 1000 senses any of the output ports is in use. The Power
Indicator Light will flash when none of ONEUP 1000’s output ports is in use, meaning ONEUP 1000 is in the Idle State.
After 5 minutes in the Idle State, ONEUP 1000’s screen will enter into the sleep mode( the battery is still running). After
30 mins of not using in Idle State, ONEUP 1000 will automatically shut down to protect its batteries.
6. Power ON/OFF Button
The AC power button controls the AC output of the ONEUP 1000. The AC power needs to be turned on manually. To
enable AC power, press the AC power button. When AC power is not in use to charge a device, press the AC power
button to turn off the AC power. Make sure to unplug the power cord from the AC port. When the AC power of the ONEUP
1000 is enabled, the AC indicator will light up. If the AC power is not used for more than 12 hours, the product will turn off
automatically.
7. AC ON/OFF Switch (PRESS & HOLD for ON/OFF)
The fans prevent ONEUP 1000 from overheating.
8. Ventilation Fans
Charging devices that need car ports to be charged, such as drone batteries. The Car Outlet Indicator Light will
automatically light up when the car port is in use.
10. Car Outlet & Car Outlet Indicator
Charging devices that require 100-120V AC wall chargers to be charged,such as laptops, TVs, mini refrigerators,
vacuums etc,.
9. AC Output Sockets x6
Press DC ON/OFF to turn on or off ONEUP 1000 DC power. The DC ON/OFF button controls the ONEUP 1000’s DC
output. ONEUP 1000 could not recognize when low-power devices, such as earphone, is charging. So ONEUP 1000 is
designed to keep the DC power on for 24 hours. The DC power will go off after 24 hours of not using it. If you want to extend
your standby time to 24 hours, turn the DC button on.
4. DC ON/OFF Switch (PRESS & HOLD to switch ON/OFF) & DC Output Indicator
3

LCD DISPLAY
Supports a maximum of three 110W solar panels to be connected in series. Do not put more than two solar panel for parallel
connection. ONEUP 1000 has a limit input of 400W. Supports car charge with a maximum input of 8A.
11. Solar Charge/Car Charge Input Port
The number indicates the remaining charge/discharge time (in minutes) for ONEUP 1000.
a. Remaining Charge Time
Plug in an AC cable with a universal three-pin plug (one that can withstand an effective current of 15A) into the port and
connect the cable to an AC power source. Please note that U.S. version only support chargings in 100-120Vac (50/60Hz).
User can use the ONEUP 1000 AC socket while the device is connected to a wall socket with AC power supply (the AC
power comes from the grid, not the battery). When the grid loses power suddenly, the device can automatically switch to
ONEUP 1000 battery power mode in <=30ms to ensure your work is not interrupted. This is an entry-level grade UPS function
that does not support 0ms switching.
Do not connect devices with high uninterrupted power supply requirements. Please perform multiple tests to
confirm compatibility before connecting devices, such as data servers and workstations to ONEUP 1000.
ONEUP will not be responsible for any loss of data or equipment damage caused by customers’ failure in
following the instruction.
12. AC Charging Input Port
When the input current continuously exceeds 20A during a charge, the AC charging port will trigger the overload
protection (the Overload Protection Switch icon will automatically pop out). When the device is confirmed to be in normal
status, press the overload protection switch button to continue charging.
13. Overload Protection Switch
i
j
4

If the circle icon on ONEUP 1000’s display screen is flashing, please contact our Product Experts at support@oneuppow-
er.com.
b. Battery Failure Warning
Shows the percentage of the power. If it displays 0%, please charge ONEUP 1000 immediately.
c. Battery Level Indicator
The ONEUP 1000 fan speed is intelligently controlled by the ONEUP 1000, and the displayed speed is related to
the fan speed.
When the temperature of the ONEUP 1000 is too high, a high-temperature warning icon appears on the screen to warn that
the temperature of the product is too high. Please cool down the product before use it again .
A low-temperature warning icon appears on the screen to warn that the temperature of the ONEUP 1000 is too low. Please
move the product to a warm place and wait until it turns to working temperature before use it.
e. Low temperature indicator
Shows the current input power of ONEUP 1000 in watts.
g. Current Input
Shows the current output power of ONEUP 1000 in watts.
h. Current Output
Indicates the usage status of each port.
j. Port Usage Indicators
The ONEUP 1000 display screen uses different icons and combined icons to indicate different protections for the
product.
. Protection Information Instruction
There are two types of overload protection. The first type protection: in the DC area, when any port is powering
devices that exceed maximum current limit, or the output power of the AC jack exceeds the maximum AC power output
(Overload 1%-10% will work 3mins overload 11%-30% will work 1min; overload 31%-49% will work 1s; overload
50%-100% will work 100ms), and when the vehicle power supply output exceeds the maximum current, the overload
indication and the corresponding interface indicator will flash simultaneously for 15 seconds. The output of the interface
will be automatically shut down immediately, and other ports will continue to work.
Second type of protection: When the power output from the DC or AC jack, and the vehicle power outlet exceeds the
battery maximum power output, the overload indicator and the corresponding port indicator will flash simultaneously for
15 seconds. ONEUP 1000 will automatically shut down immediately. After an overload occurs, remove the overloaded
device first, and then restart ONEUP 1000 to resume work.
i. Overload Warning
5
f. Fan indicator
d. High Temperature Indicator

USB-C and High-Temperature icons flash together.
Let product cool before connecting each appliance
back.
USB-A and OVERLOAD icons flash together.
Disconnect all electrical appliances and wait 10
seconds before adding each appliance back.
Overload icon flashes.Unplug all the electrical devices
and restart the product
RECHARGING TIME, Exclamation and High-tempera-
ture icons flash together. This happens usually after a
heavy battery use. Let ONEUP 1000 cool down before
recharging it.
Exclamation and High-temperature icons flash together.
The power supply can be resumed after battery is
cooled down.
Exclamation and Low-Temperature icons flash together.
Place ONEUP 1000 in a warmer place and wait for it
back to its working temperature before recharging it.
RECHARGING TIME, Exclamation and Low-temperature
icons flash together. Place ONEUP 1000 in a warmer
place and wait for it back to its working temperature
before recharging it.
RECHARGING TIME, Exclamation and OVERLOAD icons
flash together. Unplug Charging cables, restart ONEUP
1000 and plug back in, If light keeps flashing contact
[email protected]
Exclamation and OVERLOAD icons flash together.
Disconnect all appliances, restart ONEUP 1000, and
plug each appliance back in turn. Please note that
electrical appliances must be operated within rated
power.
USB-A Overload
Protection
USB-C High Temperature
Protection
Product Overload
High Temperature
Discharge-protection
High Temperature
Recharge-protection
Low Temperature
Discharge-protection
Low Temperature
Recharging-protection
Overload
Recharging-protection
Overload
Discharging-protection
6

AC icon flashes. Restart ONEUP 1000. If the icon keeps
flashing, contact [email protected].
AC and OVERLOAD icons flash together. Wait 10 seconds,
turn AC Power ON/OFF. Do not charge or discharge the
unit. If the icons keep flashing, do not charge or discharge
the unit. Please note that electrical appliances must be
operated within rated power.
AC and High-temperature icons flash together.
Let ONEUP 1000 cool down. Then turn AC Power
On/OFF the interface will automatically resume
operation.
The AC and Low-Temperature icons flash together.
Move ONEUP 1000 to a warmer place and wait for the
inverter to warm up.
AC and Fan icon flashes. Turn off ONEUP 1000 and
carefully clean and vacuum around vents on both
sides. Turn System Power On. If icon keeps flashing
contact [email protected].
Car and OVERLOAD icons flash together.
Restart ONEUP 1000, and make sure that electrical
appliances must be operated within rated power.
Car and High-temperature icons flash together. When
temperature/XT60 Interface is recharging in a High
Temperature. Wait for ONEUP 1000 to cool down and it
will automatically recover.
Car icon flashes. Try to restart the device. If the icon
keeps flashing, please contact our product specialists
via [email protected].
Only the Exclamation icon is flashing. Restart ONEUP
1000. If the light keeps flashing, contact support@o-
neuppower.com.
The Exclamation icon is on. Try to restart the device. If
the light keeps flashing, please contact our product
specialists via [email protected].
Communication
Failure between Main
Board and BMS
Battery Cells Failure
Communication Failure
between Main Board and AC
Inverter Output Overload
Inverter High
Temperature Protection
Inverter Low
Temperature Protection
Fan Blockage
Car Charger Overload
Car Charger High
Temperature Protection
Communication
Failure between Main
Board and MPPT
7

If you need to know more about the connection of a single panel, please refer to Solar Panel User Manual. Here we
focus on demonstrate how serial connection (up to three panels and the parallel connection of up to six panels). ONEUP
1000 supports 10-65Vdc input. When the input exceeds 65V, ONEUP 1000 overload protection will be triggered.
Voltage excessive may damage the product. Users should follow all the instructions in the manual. ONEUP does not
provide free repair services for any product damage caused by connecting many solar panels to the product or
incorrect connection, even during the warranty period.
How to recharge the ONEUP 1000 with solar panels?
a. Users can connect 1 to 3 pieces of solar panels (do not connect more than 3 in series) in series as shown
in the figure below, to the MC4 port.
b. Then, connect to MC4 to XT60 conversion cable.
c. Use XT60 conversion port connect to the XT60 port on ONEUP 1000.
1. Recommended serial connection method
Users can connect up to 2 sets of solar panels in parallel to the MC4 port as shown in the figure. If you want to connect
6 solar panels, you can put them into 2 sets of 3 solar panels connected in series and then connect the 2 sets of solar
panels in parallel. Connect them with our MC4 to XT60 conversion cable and connect XT60 cable to the ONEUP 1000’s
XT60 input to charge the device. The parallel connection cable is an optional accessory needs to be purchased
separately.
2. Serial and parallel connection (Professional solution)
SOLAR PANEL CONNECTION
8
XT60 Connector
ONEUP 1000 Charging Port
SOLAR PANEL-21.6V X3
MC4 Connector
ONEUP 1000

XT60 Connector
ONEUP 1000 Charging Port
* Users have to buy the solar panels and other
parallel connection accessories seperately.
Solar MC4 parallel connection cable
ONEUP 1000
SOLAR PANEL-21.6V X6
Users can buy universal solar panels of MC4 connection standard on their own to power ONEUP 1000, as long as the
voltage and current (10-65Vdc, 10A max) comply with the specifications of ONEUP 1000, the panels will be able to
recharge ONEUP 1000 through the MC4 to XT60 conversion cable.
Note: ONEUP does not provide free repair services for any damage to the product caused by the quality
issue or improper operation of the third-party solar panels, even in the warranty period.
3. ONEUP 1000 supports the use of third party solar panels (DIY solution)
When ONEUP 1000 has UPS or series mode on, ONEUP 1000's system supports an entry-level UPS function. You can
use the ONEUP 1000 AC socket while the device is connected to a wall socket with AC power supply (The AC power
comes from the grid, not the battery). When the grid suddenly loses power, the device can automatically switch to
ONEUP 1000 battery power mode in <=30ms to ensure your work is not interrupted. Series mode is a multi-level power
series solution developed based on the UPS function. It allows users to connect two ONEUP 1000s in series to get
continuous power that is two times more than a single machine.
Precautions when using ONEUP 1000 UPS and series mode
ENTRY-LEVEL UPS AND SERIES MODE
9

Users can connect the ONEUP 1000 AC charging cable to the power grid and connect a electricity device to ONEUP
1000 turn on the AC switch and automatically enter the entry-level UPS mode. When the external power is cut off, battery
will immediately supplied power to protect your device.
ONEUP 1000 supports the entry-level UPS function with the switching time of less than 30ms. In accordance with the UL
2743 standard, the AC output consist of a double blade, ungrounded configuration. Hence, it is recommended to use
the UPS function of ONEUP 1000 only for temporary emergency usage rather than for long-term usage. DO NOT use
electric appliances with bare metal when charging to avoid the risk of electric leakage and electric shock. It is
recommended NOT to use the UPS function of ONEUP 1000 for products such as databases, servers, etc. If you want to
use the UPS function for devices that is sensitive to the switching time, please purchase a professional-grade UPS
system. Please note that ONEUP is not responsible for any potential data loss due to the use of UPS function.
Notice:Because the AC outlets of the device are in a double blade, ungrounded configuration, it is recommended to
use the UPS function of the device for temperary emergency use only.
Warning:DO NOT use electric devcies with bare metal when charging to avoid the risk of electric shock.
1.Entry-Level UPS user guide
Users can connect no more than 2 fully-charged ONEUP 1000s in series using the AC charging cable to get continuous
power and supply appliances with high output requirements for up to 1.8 hours. In this mode, do not connect ONEUP
1000 to the power grid using an AC charging cable, or the overcurrent protection (<20A) may be triggered. Connect
ONEUP 1000 to a home power grid and charge each ONEUP 1000 separately. We do not recommend you to charge
more than two ONEUP 1000 at the same time. Otherwise, the excessive load may cause damage to the home power
grid. To use this function, you need to set one ONEUP 1000 as the Master and the others as Serve 1. Connect one AC
cable to the AC output port of the master unit and the other side to the input port of Serve 1. After connecting the
ONEUP 1000, turn all the AC switches on ONEUP 1000 on to activate multi-machine series mode. Finally, connect all
the appliances to the AC sockets of the Serve 1. Then you can charge your devices by using ONEUP 1000
and enjoy the benefits from extended powering time.
2. Series mode user guide
(Recommended for power users; all machines must be fully charged)
The principle of using it is when the power of an ONEUP 1000 is used up, the next machine can immediately replace it
to continue the power supply. This a entry-level UPS function that does not support 0ms in switching power.
Do not connect devices require high continuing power supply. Otherwise, please run multiple tests to confirm
it’s compatibility before connecting devices, such as data servers and workstations, with ONEUP 1000.
ONEUP does not take responsibility for any data loss or equipment damage caused by customers’ failure in
following the instruction.
10

Net Weight
Dimension
Capacity
Testing and certification
30.9lbs (14kg)
12.7 x 8.3 x 12.2 in (32.3 x 21.0 x 31.1 cm)
1008Wh (50.4V)
UL FCC RoHS UN38.3
General Specs
TECHNICAL SPECIFICATIONS
AC Output (x6)
USB-A Output (x2)
USB-A Fast Charge (x2)
USB-C Output (x2)
Car Power Output (x1)
Output
5Vdc, 2.4A, 12W Max, per port
5Vdc/2.4A, 9Vdc/2A, 12V/1.5A, 18W Max, per port
5Vdc, 9Vdc, 15Vdc, 20Vdc, 3A, 60W Max, per port
108.8W, 13.6Vdc, 8A max
1600W (Surge 3000W)total, 120Vac, 60Hz
AC Charge Input Voltage
AC Charge Input Power (Example 1)
Solar Charge Input
Car Charger (Example 2)
Input
AC Charge 1000W max
400W 10-65Vdc 10A max
12V/24Vdc 8A max
100-120Vac (50Hz/60Hz) ONLY!
Cell Chemistry
Cell Type
Discharge Temperature
Charge Temperature
Shelf Life
Life Span
Battery
Lithium-ion
18650
-4-140°F (-20-60°C)
32-113°F (0-45°C)
1 Year (After fully charged)
500 Cycles to 80% capacity
11
Master unit AC on Serve unit AC on
Example:
100%
100%

1000W Max Charge
(Included)
(Included)
<2 Hours
0-80% charged in 1 hour
Full change in <2 hours
Car Charger
(96W Input)
<10 Hours
AC cable
Example 1:
Example 2:
XT60
Connector
Charging 100% time
required
ONEUP 1000 has an AC charging port and a XT60 charging port located on the side of ONEUP 1000. ONEUP 1000 can
be charged through AC power or solar panel. Besides, you can also use solar panels connect in series (no more than
three) and connect the solar charge cable to the XT60 solar charging port of ONEUP 1000 for charging.
How do I recharge my ONEUP 1000?
How do I care for ONEUP 1000?
Yes, ONEUP 1000 can be charging and outputing power in the same time. When you are charging ONEUP 1000, we do
not recommend connecting an electrical appliance with a power over 800w for discharging, because the current
capacity of the wall outlet is limited.
ONEUP 1000 is designed for various uses. If you need to clean ONEUP 1000, please use a dry and non-abrasive cloth
to clean the surface. You can use cleaners designed for mobile phones or computer screeens can to clean ONEUP
1000, but do not give it a bath!
Can ONEUP 1000 power my devices while it's charging?
HOW TO RECHARGE ONEUP 1000
FAQs
12
We reommend you to start the car before connecting car charger to ONEUP 1000.

1.5m Car Charge Cable
(Input)
User Manual &
Warranty Card
1.5m AC Cable
(Input)
Do not charge the machine right after it is fully discharged (E.g. 1000W keep 40mins or 1500W
keep 30 mins). For your safety, please wait 2 to 3 hours for the product to cool down before
charging it!
If you attempt to charge ONEUP 1000 immediately after a full discharge, ONEUP 1000 will display
as an overheating protection reminder. Please wait 2 to 3 hours for the machine to be cooled
down before recharging it.
1.5m Solar Charge Cable
(MC4 to XT60 Input)
ONEUP 1000
WARNING
How do I store ONEUP 1000?
1. Please store your ONEUP 1000 in a dry environment without surrounded by abrasive objects. For optimal battery
health, store ONEUP 1000 in room temperature.
2. Discharge ONEUP 1000 to 30%, then charge to 85% every 3 month. This can help prolong the battery life and ensure
your ONEUP 1000 is ready to recharge the gears at all times. Without any external sources for power supply during
storage, ONEUP 1000 has a shelf life of over a year.
How do I use ONEUP 1000 safely?
Please use and store ONEUP 1000 according to the following environment temperatures:
Normal use and storage: -4°F to 113°F (-20°C to 45°C)
Optimal use and storage: 68°F to 77°F (20°C to 25°C)
Using ONEUP 1000 outside of its optimal operating temperature range can push the machine beyond its safe and
effective limits. Do not submerge your ONEUP 1000 in water. It is not waterproofed and this will void your warranty. If
you want to protect ONEUP 1000 against moisture and dust, use a ONEUP 1000 protector (IP54). Do not block the
ventilation Fan while using ONEUP 1000.
WHAT’S IN THE BOX
13
