oneup 1600 User manual

ONEUP 1600 User Manual

Read the ENTIRE user manual to be familiar with the features of this product before operating. Failure
to operate the product correctly may result in damage to the product or personal property and
cause serious injury. ONEUP will not assume any legal responsibility. DO NOT use the product with
incompatible components or alter the product in any way without following the instructions provided by
ONEUP. Otherwise, you cannot get after-sales service from ONEUP under warranty condition. These
Safety Guidelines include instructions for safety, operation and maintenance. It is important to read and
follow all the instructions and warnings in the user manual before assembly, setup or use the product.
DISCLAIMER

1. Specifications
4. FAQS
5. Storage & Maintenance
6. Troubleshooting
7. What’s In the Box
8. Fcc Statement
3.1 Product Details
3.2 LCD Screen
3.3 General Product Usage
3.4 AC Charging
3.5 Solar Charging
3.6 Car Charging
3.7 Smart Inverter Mode
3.8 Emergency Power Supply (EPS)
3
4
4
6
7
7
8
8
9
9
10
11
11
2. Safety Instructions
3. Getting Started
CONTENTS
2
2
1
2.1 Usage
2.2 Disposal Guide

1
Input Ports
AC Charge
AC Input Voltage
Solar Charger
Car Charger
X-Stream Fast Charge 1600W Max, 15A
100-120V~ 50Hz/60Hz
11-100V 10A, 800W Max
Supports 12V/24V Battery, Default 8A
Max Device(s) Power Supported by Smart
Inverter Mode
USB-A (x2)
USB-A Fast Charge (x2)
USB-C (x2)
Car Charger
DC5521 Output (x2)
2800W
General Info
Output Ports
Net Weight
Dimensions
Capacity
Approximately 48lbs
19.6x9.5x12in
1612Wh 50.4V
Battery Info
Cell Chemistry
Cycle Life
NCM
500 cycles to 80%+ capacity
* Car charger shares power with the DC5521 output port, offering a maximum output of 126W.
AC (x6) Pure Sine Wave, 2000W total (surge 5000W),
120V~ 60Hz
Environmental Operating Temperature
Optimal Operating Temperature
Discharge Temperature
Charge Temperature
Storage Temperature
68°F to 86°F(20°C to 30°C)
-4°F to 113°F (-20°C to 45°C)
32°F to 113°F(0°C to 45°C)
-4°F to 113°F (-20°C to 45°C) (optimal: 68°F to 86°F
[20°C to 30°C])
Protection
Over Voltage Protection, Overload Protection, Over
Temperature Protection, Short Circuit Protection, Low
Temperature Protection, Low Voltage Protection, Overcurrent
Protection
5V 2.4A 12W Max, per port
5V 2.4A 9V 2A 12V 1.5A 18W Max, per port
5/9/12/15/20V 5A 100W Max, per port
12.6V 10A, 126W Max
12.6V 3A, per port
1. Specifications

2
2.2 Disposal Guide
2. Safety Instructions
1. If conditions permit, make sure that the battery is fully discharged before disposing it in a designated battery
recycling bin. The product contains batteries with potentially dangerous chemicals, so it is strictly prohibited
to dispose of it in ordinary trash cans. For more details, please follow the local laws and regulations on battery
recycling and disposal.
2. If the battery cannot be fully discharged due to a product failure, please do not dispose of the battery directly in
the battery recycling box. In such case, you should contact a professional battery recycling company for further
processing.
3. Please dispose of over-discharged batteries that cannot be recharged.
1. Do not use the product near a heat source, such as a fire source or a heating furnace.
2. Avoid contact with any liquid. Do not immerse the product in water or get it wet. Do not use the product in rain or
humid environments.
3. Do not use the product in an environment with strong static electricity/magnetic fields.
4. Do not disassemble the product in any way or pierce the product with sharp objects.
5. Avoid using wires or other metal objects that may result in a short circuit.
6. Do not use unofficial components or accessories. If you need to replace any components or accessories, please
visit official ONEUP channels to check relevant information.
7. When using the product, please strictly follow the operating environment temperature specified in this user
manual. If the temperature is too high, it may result in a fire or explosion; if the temperature is too low, the product
performance may be severely reduced, or the product may cease to work.
8. Do not stack any heavy objects on the product.
9. Do not lock the fan forcibly during use or place the product in an unventilated or dusty area.
10. Please avoid impact, falls, or severe vibrations when using the product. In case of a severe external impact,
turn off the power supply immediately and stop using the product. Ensure the product is well fastened during
transportation to avoid vibrations and impacts.
11. If you accidentally drop the product into water during use, please place it in a safe open area, and stay away
from it until it is completely dry. The dried product should not be used again, and should be properly disposed
of according to Section 2.2 below. If the product catches fire, we recommend that you use the fire extinguishers
in the following order: water or water mist, sand, fire blanket, dry powder, and finally a carbon dioxide fire
extinguisher.
12. Use a dry cloth to clean off dirt on the product ports.
13. Rest the product on a flat surface to avoid damages caused by the product falling over. If the product is
overturned and severely damaged, turn it off immediately, place the battery in an open area, keep it away from
combustible matter and people, and dispose of it in accordance with local laws and regulations.
14. Ensure that the product is kept out of reach of children and pets.
15. Store in dry and well-ventilated place. If exposed or used in a humid environment for a long time (E.g. seaside),
we recommend you use a waterproof bag to keep your battery dry.
2.1 Usage

3
LCD Screen
Solar/Car Charging
Input Port
AC Output Sockets
AC Power Button
Car Outlet
DC5521 Output Port
USB-A Output Port USB-A Fast Charge
Output Port
AC Charging Input Port
USB-C 100W Output Port USB Power Button
Overload Protection Switch
12V DC Power Button
Main Power Button
3.1 Product Details
Ventilation Fan
3. Getting Started
AC Charge Speed Switch

4
3.2 LCD Screen
3.3 General Product Usage
Short Press to Turn On Long Press to Turn Off
Remaining Charge/
Discharge Time
Overload Warning
Fan Indicator
Low Temperature Warning
High Temperature Warning
Remaining Battery Percentage
Battery Failure Warning
Battery Level Indicator
AC Output
12V DC Output Indicator
State of Charge
USB-A Output
USB-C Output
Output Power
Input Power
Battery Level Indicator: The indicator will repeatedly fill while charging. If product is at 0% charge, the indicator will
flash to warn you.
* See Section 6 for more troubleshooting steps.
Short press the Main Power Button to turn on the product; the LCD Screen will light up and the battery level
indicator icon will display.
Product On, Product Off, LCD Screen On
The product enters sleep mode after 5 minutes of idle operation; the LCD Screen will automatically turn off. When
the product senses any load change or operations, the LCD Screen will automatically light up. To turn the LCD
Screen on or off, please short press the Main Power Button.
To power off the product, press and hold the Main Power Button.
The default product standby time is 2 hours. With other Power Buttons turned off and no other load access for 2
hours, the product will automatically shut down.

5
With the Main Power Button turned on, short press the 12V DC
Power Button to use the 12V DC Output port. Short press the 12V
DC Power Button again to turn it off.
With the 12V DC Power Button on, the product will not
automatically shut down.
With the Main Power Button turned on, short press the USB
Power Button to use the USB Output Port. Short press the USB
Power Button again to turn it off.
With the USB Power Button on, the product will not automatically
shut down.
USB Output Port
12V DC Output Port
With the Main Power Button turned on, short press the AC Power
Button to use the AC Output ports. Short press the AC Power
Button again to turn it off.
The default standby time of the AC Output port is 12 hours.
Without any load access for 12 hours, the AC Power will
automatically turn off.
Please turn off AC power button when not in use to save power
consumption.
AC Output Port
Short Press
12V DC Power Button
Short Press
AC Power Button
Short Press
USB Power Button

6
<2 hrs Full Charge
3.4 AC Charging
AC Charging
Cable
Customized Charging Power Rate
Range 200W to maximum Input Power
(Default: 400W)
Fast Charging
Maximum Charging Mode
ONEUP’s X-Stream fast charge technology is specifically designed for AC charging. You can control the
charging power through the AC Charge Speed Switch. When set to the top, you will have the maximum charging
speed. When set to the bottom it'll be at your custom speed, which is 400W by default. In case of unusual
situations where the AC input current remains higher than 20A, the X-Stream charging input port will initiate
a self-protection function, and the Overload Protection Switch on the product will automatically pop up. After
confirming that there is no product failure, you can press the Overload Protection Switch to resume charging.
The charging power can be adjusted through the AC Charge Speed Switch on the back of the product.
Please use ONEUP AC charging Cable for fast charging. AC Charging Cable should directly plug into 15A(or above)
wall outlet. ONEUP takes no responsibilities for any consequences caused by failures to follow instructions, including
but not limited to charging with AC charging Cable.

7
Users can connect solar panels in series as shown in the figure to recharge the product. The product supports 11-
100V DC input, 10A Max current, and 800W Max charging power.
MC4
When using an ONEUP solar panel to charge the product, please follow the instructions that come with the solar
panel.
Before connecting the solar panel, please ensure that the solar panel’s output voltage is with in 100V to avoid
product damages.
3.5 Solar Charging
3.6 Car Charging
Solar Charging Cable
Car Charging Cable
Users can recharge the product through the Car Charging Input Port. It supports 12V/24V car chargers and an 8A
default charging current.
Please charge using the car charger after you’ve started the car to avoid failure to start due to insufficient car
battery. In addition, please make sure that Car Charging Input Port and the Car Charging Cable are in good
condition. ONEUP takes no responsibilities for any losses or damages caused by failures to follow instructions.

8
To avoid operation failure due to overload protection, the Smart Inverter Mode feature will be automatically
enabled when the total output exceeds the rated output power, which enables the product to power high wattage
appliances at the rated output power.
Smart Inverter Mode Tips:
1. Smart Inverter Mode is enabled by default.
2. Smart Inverter Mode is not available when the AC output is turned on in a recharging state (in bypass mode)
and when Smart Inverter Mode is disabled.
3. Smart Inverter Mode is not applicable for all electrical appliances; it’s incompatible with appliances with strict
voltage requirements. Appliances with voltage protection (such as precise instruments) are not supported.
Smart Inverter Mode is more suitable for heating devices. Please conduct your own tests with your devices with
Smart Inverter Mode enabled.
3.7 Smart Inverter Mode
The product supports EPS. When you connect the grid power to the AC Input Port of the product through an AC
Charging cable, you can power electrical devices through the AC Output Sockets (AC power will come from the grid
and not the power station in this situation). In case of a sudden blackout, the product can automatically switch to the
battery powered supply mode within 30ms. As a basic UPS function, this function does not support 0ms switching.
Please do not connect the product to any device that requires 0ms UPS, such as data servers and workstations.
Please test and confirm the compatibility before using the product. We recommend that you only charge one
device at a time and avoid using multiple ones at the same time to avoid overload protection. ONEUP takes no
responsibilities for any device failures or data losses caused by failures to follow instructions.
3.8 Emergency Power Supply (EPS)

9
1. What battery does the product use?
It uses high-quality lithium-ion battery.
2. What devices can the product’s AC output port power?
With high rated power and peak power, the product’s AC output port can power most household appliances.
Before you use it, we recommend that you confirm the power of the appliances first and ensure the power sum
of all loaded appliances is lower than the rated power.
3. How long can the product charge my devices?
The charging time is shown on the product’s LCD Screen, which can be used to estimate the charging time of
most appliances with stable power usage.
4. How can I know if the product is charging?
When it’s charging, the remaining charging time will be shown on the LCD Screen. Meanwhile, the charging
indicator icon begins to rotate with the remaining battery percentage and the input power shown on the right of
the circle.
5. How to clean the product?
Please gently wipe it with a dry, soft, clean cloth or paper towel.
6. How to store the product?
Before storing, please turn off the product first, and then store it in a dry, ventilated place at room temperature.
Do not place it near water sources. For long-term storage, please discharge the battery to 30% and recharge it
to 60% every three months to extend its battery life.
7. Can I bring the product on a plane?
No.
4. FAQS
5. Storage & Maintenance
1. Please use or store the product in an environment temperature between 68°F to 86°F
20°C to 30°C
, away
from water, heat, and other metal objects.
2. For long-term storage, please discharge the battery to 30% and recharge it to 60% every three months.
3. For safety, please do not store the product in an environment temperature higher than 113°F
45°C
or lower
than 14°F
-10°C
for a long time.
4. If the remaining battery is less than 1% after you finish using the product, please recharge it to 60% before
storing. If the product is left idle for a long time with severely low battery, irreversible damages may be caused
to the battery cell and the product service life will be shortened.
5. If the product has been idle for too long and the battery is severely low, it will enter a deep sleep protection
mode. In such case, please charge the product before using it again.

10
6. Troubleshooting
If the Alarm Prompt shows on the product LCD screen during use and does not disappear after a restart, please
stop using it immediately (do not try to charge or discharge).
If you require any other assitance, please contact ONEUP Customer Service.
Indicator Problem
Resume normal operation by removing
the electrical device connected to the
USB-A port.
Resume normal operation by removing
the electrical device connected to the
USB-C port.
After the product cools down, it will
resume normal operation automatically.
Charging can be resumed automatically
after the battery cools down.
The power supply can be resumed
automatically after the battery cools
down.
Charging can be resumed automatically
after battery temperature rises above
41°F(5˫).
The power supply can be resumed
automatically after the battery
temperature rises above 10°F(-12˫).
Please confirm whether the fan inlet and
outlet are blocked, if not, normal operation
will be resumed automatically after the
product temperature drops.
Normal operation will be resumed
automatically after the product is used at
optimum environmental temperatures.
Please check if the fan is blocked by
foreign materials.
After the product cools down, it will
resume normal operation automatically.
Contact ONEUP Customer Service
Normal operation will be resumed
automatically after you remove the
overloaded device and restart the product.
Electrical appliances should be used within
rated power.
(Refer to Smart Inverter Mode instructions to
get more details about power limitations).
Solution
The product will resume normal operation
automatically after you remove the device
connected to the car charger.
USB-A Overload
Protection
Icons Flash
together
Icons Flash
together
Icons Flash
together
Icons Flash
together
Icons Flash
together
Icons Flash
together
Icons Flash
together
Icons Flash
together
Icons Flash
together
Icons Flash
together
Icons Flash
together
Icons Flash
together
Icon Stays On
USB-C Overload
Protection
USB-C High
Temperature Protection
High Temperature
Charge Protection
High Temperature
Discharge Protection
Low Temperature
Charge Protection
Low Temperature
Discharge Protection
AC Output
Overload Protection
AC High
Temperature Protection
AC Low
Temperature Protection
Fan Blockage
Car Charger
Overload Protection
Car Charger High
Temperature Protection
Battery Failure
Icon Flashes

11
7. What’s In the Box
ONEUP 1600 Solar Charging Cable
DC5521 to DC5525 Cable
Car Charging CableAC Charging Cable
User Manual &
Warranty Card
8. FCC STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
Warning: Changes or modifications not expressly approved by the party responsible for compliance could void
the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interfer-ence at his own expense.
FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
