Onkyo BD-SP808 User manual

BLU-RA Y DISC PLAYER
SD-SPBOB
Instruction Manual
Thank you for purchasing an Onkyo BLU-RAY DISC
PLAYER. Please read this manual thoroughly before
making connections and
plugging in the unit.
Following
the instructions in this manual will enable
you
to obtain optimum performance and listening
enjoyment from your new BLU-RAY DISC PLAYER.
Please retain this manual for future reference.
