Onkyo DW-S500 User manual

Ref. No.3707
082001
SERVICE MANUAL
SERVICE MANUAL
CD Receiver System
DW-S500,HS-N1(S).(T)
DW-S500/HS-N1(S).(T)
DD,DT 120V,60Hz
PP,PA 230-240V,50Hz
GR,GQ,GT 220-230V,50Hz
DD : U.S.A.,Canada model
DT : Taiwan model
PP : Europe model
PA : Australia model
GR : China model
GQ : Hong Kong model
GT : Asia model
Center unit Speaker unit
DW-S500MDD CR-N1(S)MDD D-N1MD
HS-N1(T)MPP CR-N1(T)MPP D-N1MP
HS-N1(S)MPA CR-N1(S)MPA D-N1MD
HS-N1(S)MDT CR-N1(S)MDT D-N1MD
HS-N1(S)MGR CR-N1(S)MGR D-N1MR
HS-N1(S)MGQ CR-N1(S)MGQ D-N1MD
HS-N1(S)MDD CR-N1(S)MDD D-N1MD
HS-N1(S)MGT CR-N1(S)MGT D-N1MD
COMBINATION

DW-S500/HS-N1(S).(T)
SPECIFICATIONS
CR-N1(S).(T)
Amplifier
CD Player
USB
Power output
(U.S. & Canadian models)
2 x 6.5 watts min., RMS at 8 ohms, 50 Hz-20 kHz, with no more than 0.6%
total harmonic distortion (FTC)
2 x 9.5 watts min., RMS at 4 ohms, 50 Hz-20 kHz, with no more than 0.8%
total harmonic distortion (FTC)
2 x 15 watts at 4 ohms (EIAJ)
Power output
(Other models)
2 x 10 watts at 4 ohms, 1 kHz (DIN)
2 x 8.5 watts at 6 ohms, 1 kHz (DIN)
2 x 7 watts at 8 ohms, 1 kHz (DIN)
2 x 6.5 watts min., RMS at 8 ohms, 1 kHz, no more than 0.6% THD (FTC
rating)
2 x 15 watts at 4 ohms (EIAJ)
Dynamic power 2 x 15 watts at 4 ohms
2 x 9 watts at 8 ohms
Total harmonic distortion 0.4% at 5 watts output into 4 ohms, 1 kHz
IM distortion 0.4% at 5 watts output into 4 ohms, 1 kHz
Damping factor 25 at 4 ohms
50 at 8 ohms
LINE IN sensitivity and
impedance 500 mV, 47kW
Frequency response 10 Hz-20 kHz, +3/-3 dB
Acoustic presence 1: +6.0 dB at 80 Hz
2: +10.0 dB at 80 Hz
Signal to noise ratio 95 dB (IHF-A)
Muting -50 dB
Signal readout system Optical non-contact
Reading rotation Approx. 500-200 rpm (constant linear velocity)
Linear velocity 1.2-1.4 m/s
Error correction system Cross interleave Reed Solomon code
D/A converter 1 bit
Digital Þlter 352.8 kHz, 8-times oversampling
Number of channels 2 (stereo)
Frequency response 5 Hz20 kHz
Wow & ßutter Below threshold of measurability
Connection method USB (Universal Serial Bus) Ver 1.1
Sampling rate (input) 32/44.1/48 kHz compatible
Frequency response 5 Hz-20 kHz

DW-S500/HS-N1(S).(T)
SPECIFICATIONS
CR-N1(S).(T)
Tuner
General
Specifications and features are subject to change without notice.
Power supply and voltage specifications depend on where the unit is purchased.
Tuning range
FM 87.9-107.9 MHz (200 kHz steps) (U.S. & Canadian model)
87.5-108.00 MHz (50 kHz steps) (Other area models)
AM
530-1710 kHz (10 kHz steps) (U.S. & Canadian model)
522-1611 kHz (9 kHz steps) (European & Australian
models)
531-1602 kHz (9 kHz steps) (Asian models)
Usable sensitivity FM Mono 11.2 dBf, 1.0 µV (75 ohms IHF)
11.2 dBf, 0.9 µV (75 ohms DIN)
Stereo 17.2 dBf, 2.0 µV (75 ohms IHF)
17.2 dBf, 23.0 µV (75 ohms DIN)
AM 30 µV
50 dB quieting sensitivity FM Mono 17.2 dBf, 2.0 µV (75 ohms)
Stereo 37.2 dBf, 20.0 µV (75 ohms)
Capture ratio FM 2.0 dB
Image rejection ratio FM 40 dB (U.S. & Canadian model)
85 dB (Other area models)
AM 40 dB
IF rejection ratio FM 90 dB
AM 40 dB
Signal to noise ratio FM Mono 73 dB, IHF
Stereo 67 dB, IHF
AM 40 dB
Selectivity FM 50 dB DIN
(±300 kHz at 40 kHz deviation)
AM suppression ratio 50 dB
Harmonic distortion FM Mono 0.2%
Stereo 0.3%
AM 0.7%
Frequency response FM 30 Hz-15.0 kHz (±1.5 dB)
Stereo separation FM 35 dB at 1 kHz
25 dB at 100 Hz-10.0 kHz
Stereo threshold FM 17.2 dBf, 2.0 µV (75 ohms)
Power supply
AC 120 V, 60 Hz, 39 W (U.S. & Canadian model, some Asian
models)
AC 230 V, 50 Hz, 32 W (European model)
AC 220 V, 50/60 Hz, 32 W (Other area models)
Dimensions (W x H x D) 203 x 270 x 234 mm
8" x 10-5/8" x 9-3/16"
Weight 4.2 kg (9.3 lbs)

DW-S500/HS-N1(S).(T)
SPECIFICATIONS
D-N1
Type 2way , Bass Reflex
Impedance 4 ohm
Maximum Input Power 30W
Output sound pressure level 83dB/W/m
Frequency Response 63Hz - 35kHz
Crossover Frequency 3000Hz
Cabinet Capacity 2.6 Litter
Woofer 9cm OMF Cone Type
Tweeter 2.5cm Soft Dome Type
Dimensions (W x H x D) 165x271x160 mm
Weight 1.7kg

DW-S500/HS-N1(S).(T)
FRONT PANEL VIEW
CR-N1(S).(T)
AP
Q
R
S
T
U
V
W
X
O
NMLKJ
B
C
D
E
F
G
H
I
A CD compartment
B USB indicator
C ACOUSTIC PRESENCE indicator
D ENERGY SAVE indicator
E STANDBY/ON button
F SOURCE DIRECT indicator
G USB MIX ON indicator
H USB MIX button
I USB MIX LEVEL control
J ENERGY SAVE button
K MEMORY button
L FM MODE button
M Next/Preview/Tuning button
N DISPLAY button
O Previous/Review/Tuning button
P OPEN/CLOSE button
Q PLAY/PAUSE button
R STOP button
S Remote control sensor
T Display
U VOLUME UP button
V VOLUME DOWN button
W ACOUSTIC PRESENCE button
X INPUT selector button

DW-S500/HS-N1(S).(T)
REAR PANEL VIEW
CR-N1(S).(T)
A UP USB port
B LINE IN/OUT connectors
C SUBWOOFER PRE OUT connector
D PHONES jack
E OPTICAL DIGITAL OUTPUT
connector
F Power cord
G FM 75ohm antenna connector
H AM antenna terminals
ISPEAKERS terminals
H
I
G
F
AB C D E
Replace the cover when nothing
is connected to these connectors.
Push up the tab to release the cover .
Connector cover

DW-S500/HS-N1(S).(T)
GETTING CONNECTED
Connect the speakers only as shown here.
Incorrect connections may damage the
CR-N1 or the speakers.
Right
speaker Left speaker
These terminals are located on
the underside of the D-N1 speakers.
-+-+

PACKINGVIEW
DW-S500/HS-N1(S).(T)
PRECISE
PRECISE
DW-S500(S)
Hi-Fi USB COMPATIBLE CD RECEIVER SYSTEM
DW-S500(S)
CR-N1
D-N1
DW-S500(S)
Hi-Fi USBCOMPATIBLE CD RECEIVER SYSTEM
FRAGILE / MANIPULERAVEC SOIN
DW-S500(S)
Hi-Fi USB COMPATIBLECD RECEIVER SYSTEM
FRAGILE / MANIPULER AVEC SOIN
PRECISE
PRECISE
DW-S500(S)
Hi-Fi USBCOMPATIBLE CDRECEIVER SYSTEM
DW-S500(S)
CR-N1
D-N1
C2
A1
A2
A3
A4
A5
B1
B2
B3
B4
B10 B11
B12
B13
B17
B18
C1
B3
C3
C4
B19
C3
Center Unit
Speaker(L)
Speaker(R)
B14B15
B16
B5

DW-S500 HS-N1(T)
DD PP PA DT GR GQ GT DD
A1 29365090 Warranty card O X X X X X X O
29053810 Carton X X O O O O O X
29053809 Carton X O X X X X X X
29053808 Carton O X X X X X X O
A3 282301 Staple O O O O O O O O
A4 29110098 Tape O O O O O O O O
29362925A UPC Label O X X X X X X O
29362960A EAN Label X O X X X X X X
B1 29100037-1A Poly bag (650 x 500) O O O O O O O O
B2 29110149 Tape O O O O O O O O
B3 29100097-1A Poly bag (350 x 250) O O O O O O O O
B4 29092005 Pad ass'y O O O O O O O O
B5 29095906 Protection sheet O O O O O O O O
B10 24140454A Remote controller,RC-454S O O O O O O O O
B11 3010054 Battery,UM-3 O O O O O O O O
B12 232140 Antena coil,NMA-3057 O O O O O O O O
B13 29343196 Instruction manual,E O O O O O O O O
29343199 Instruction manual,CT X X X O X X O X
29343258 Instruction manual,CS X X X X O O X O
B15 29343197 Instruction manual,U3FSI X O X X X X X X
B16 29343198 Instruction manual,U3GSWD X O X X X X X X
292142 FM Antenna ass'y O X X O X X X X
292115 FM Antenna ass'y X O O X O O O O
B18 2010402 Cord ass'y,USB Cable(A-B) O X X X X X X X
B19 25065462 FM Adaptor,YAE21-0237 X X O O O O O O
C1 404-D-N1 Pad O O O O O O O O
C2 434-NS-300 Protection bag,0.5tx440x320 O O O O O O O O
C3 434-ANS-300 Protection sheet,1tx200x60 O O O O O O O O
C4 610-PD-N1 Speaker cable O O O O O O O O
A2
A5
B14
B17
HS-N1(S)
DESTINATION
REF NO. PART NO. DESCRIPTION
DW-S500/HS-N1(S).(T)
PARTS LIST
The parts registration of B1-B19 is done with CR-N1.
The parts registration of C1-C4 is done with D-N1.
