Onkyo HTS5300B User manual

HT-S5300 7.1-Channel Home Theater Receiver/Speaker Package ( ith Dock for iPhone™/iPod®)
BLACK
The Ideal Foundation for Fully Immersive Home Entertainment
Onkyo has built a reputation for making advanced features and performance more affordable for budget-conscious fans of home
entertainment. Take, as a prime example, the HT-S5300 receiver and speaker package. At the heart of this 7.1-channel system, you have
an A/V receiver sporting four of the latest HDMI®1.4a inputs—enough for all your high-def sources. HDMI 1.4a brings compatibility
with 3D video—coming soon—and an Audio Return Channel. With the HT-S5300, you can also adjust settings on the fly with a handy
overlaid on-screen display. The receiver offers a broad range of connectivity options, such as a front input for portable devices and a
Universal ort for one-cable connection of the included Dock for i hone/i od. High-quality Burr-Brown DACs ensure pristine analog
conversion of all digital audio sources, including HD audio formats from Dolby and DTS. And Dolby®ro Logic®IIz gives you the option
of a new height-channel set-up with the included 7.1-channel speaker package.
HT-R580 7.1-Channel Home Theater Receiver
• 160 W/Ch at 6 Ω, 1 kHz, 1 Channel Driven, JEITA
• HDMI®(Version 1.4a to Support 3D and Audio Return
Channel) with Deep Color™, x.v.Color™, LipSync,
Dolby®TrueHD, DTS-HD Master Audio™, DVD-
Audio, Super Audio CD, Multichannel CM, and CEC
• Audio and 1080p Video rocessing via HDMI
(4 Inputs and 1 Output)
• Dolby®TrueHD, DTS-HD Master Audio™, Dolby®
Digital lus, DTS-HD High-Resolution Audio™Decoding
• Dolby®ro Logic®IIz for New Surround Channels
• Burr-Brown 192 kHz/24-Bit DACs ( CM1690)
for All Channels
• Jitter-Cleaning Circuit Technology
• Audyssey EQ™for System Equalization
• Audyssey Dynamic Volume™
• Audyssey Dynamic EQ™for Loudness Correction
• owered Zone 2 and Zone 2 Line-Out for layback of
Separate Source in Another Room
• Overlaid On-Screen Display (OSD) via HDMI
• WRAT (Wide Range Amplifier Technology)
• H.C. .S. (High Current ower Supply) Massive
High- ower Transformer
• Optimum Gain Volume Circuitry
• Advanced 32-Bit rocessing DS Chip
• 4 DS Modes for Gaming: Rock, Sports, Action, and
R G (Role laying Game)
• Music Optimizer™for Compressed Digital Music Files
• Direct Mode
• Double Bass Function
• CinemaFILTER™
• Non-Scaling Configuration
• A-Form Listening Mode Memory
• Theater-Dimensional Virtual Surround Function
• Universal ort for Single-Cable Connection of U -A1
Dock for i hone/i od
• HDTV-Capable (720p/1080i) Component Video
Switching (2 Inputs and 1 Output)
• Front- anel Audio Input for ortable Devices
• Front- anel Auxiliary A/V Input
• 4 Digital Inputs (2 Optical and 2 Coaxial)
• 4 A/V Inputs and 1 Output
• Video Output (Monitor)
• 1 Audio Input
• Subwoofer re Out
• Color-Coded, Banana lug-Compatible Speaker osts
(Except Front High or Zone 2)
• Headphone Jack
• Crossover Adjustment (40/50/60/80/100/120/150/
200 Hz)
• A/V Sync Control Function (Up to 100 ms in
10 ms Steps)
• Tone Control (Bass/Treble) for Front L/R Channels
• 3-Mode Display Dimmer (Normal/Dim/Dimmer)
• 40 FM/AM Random resets
• RIHD (Remote Interactive over HDMI) for
System Control
• Compatible with RI (Remote Interactive) Dock for i od
• reprogrammed RI Remote Control
HTP-580 7.1-Channel Home Theater
Speaker System
SKF-580 2- ay Bass Reflex Front Speakers
• 12 cm OMF Diaphragm Woofer
• 2.5 cm Balanced-Dome Tweeter
• Max. Input ower: 130 W
• Gloss-Finished Top anel
• Magnetically Shielded
SKC-580 2- ay Bass Reflex Center Speaker
• 8 cm Cone Woofer x 2
• 2.5 cm Balanced-Dome Tweeter
• Max. Input ower: 130 W
• Gloss-Finished Side anel
• Magnetically Shielded
SKR-580/SKB-580 Full-Range Acoustic Suspension
Surround/Surround Back Speakers
• 8 cm Cone
• Max. Input ower: 130 W
• Gloss Finished
Note: All speakers feature an impedance of 6 Ω, color-coded speaker
terminals and cable, and wall-mounting capability.
SKW-580 Bass Reflex Powered Subwoofer
• 25 cm Cone
• Max. Output ower: 290 W (Dynamic ower)
• Output Level Control
UP-A1 Dock for iPhone/iPod
• Audio and Video layback with i hone/i od
• Easy Connection via Universal ort
• Recharges i hone/i od
UP-A1 Dock for i hone/i od
HT-S5300_EX_HT-S5300 10/03/29 14:53 ページ 1Downloaded from www.Manualslib.com manuals search engine

O kyo Corporatio 2-1 Nisshin-cho Neyagawa-shi Osaka 572-8540 JAPAN Tel: [phone] Fax: [phone] http://www.o kyo.com/
O kyo Chi a Limited Unit 1 & 12 9/F Ever Gain Plaza Tower 1 88 Container Port Road Kwai Chung N.T. Hong Kong SAR of CHINA Tel: [phone] Fax: [phone] http://www.ch.o kyo.com/
O kyo U.S.A. Corporatio 18 Park Way Upper Saddle River N.J. 07458 U.S.A. Tel: [phone] (Toll free) Fax: [phone] http://www.o kyousa.com/
O kyo Europe Electro ics GmbH Liegnitzerstrasse 6 82194 Grobenzell GERMANY Tel: [phone] Fax: [phone] http://www.eu.o kyo.com/
Due to a policy of continuous product improvement, On yo reserves the right to change specifications and appearance without notice. Manufactured under license from Dolby Laboratories. Dolby, Pro Logic, and the double-D symbol are trademar s of Dolby Laboratories. DTS is a
registered trademar and the DTS logos and Symbol are trademar s of DTS, Inc. iPod is a trademar of Apple Inc., registered in the U.S. and other countries. iPhone is a trademar of Apple Inc. "Made for iPod" means that an electronic accessory has been designed to connect
specifically to iPod and has been certified by the developer to meet Apple performance standards. "Wor s with iPhone" means that an electronic accessory has been designed to connect specifically to iPhone and has been certified by the developer to meet Apple performance
standards. Manufactured under license from Audyssey Laboratories. U.S. and foreign patents pending. EQ, Dynamic EQ, and Dynamic Volume are trademar s of Audyssey Laboratories. HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademar s or registered
trademar s of HDMI Licensing LLC in the United States and other countries. x.v.Color is a trademar of Sony Corporation. WRAT, OMF, Music Optimizer, CinemaFILTER, and Theater-Dimensional are trademar s of On yo Corporation. All other trademar s and registered trademar s
are the property of their respective holders.
HT-S5300 7.1-Channel Home Theater Receiver/Speaker Package ( ith Dock for iPhone™/iPod®)
NPR No. 10N10 02/10
HDMI®1.4a Support for 3D Video and
Audio Return Channel
The four HDMI 1.4a inputs on the HT-S5300’s A/V
receiver let you simultaneously connect high-def
sources such as a Blu-ray player, a gaming console,
and a cable/satellite tuner. A single output then
sends a pristine signal to your connected high-
resolution display. As the latest version of this
connector, HDMI 1.4a adds the exciting possibilities
of 3D video and an Audio Return Channel. 3D
video is the next big thing in home entertainment,
with movie, game, and broadcast content on the
increase and 3D-compatible TVs on the near
horizon. This system also offers the convenience of
an Audio Return Channel via HDMI. Audio content
received directly by your HDTV’s tuner can be sent
“upstream” to the A/V receiver, without the need
for a separate S/PDIF audio cable.
Dolby®Pro Logi ®IIz Adds New
Dimensions to Surround Sound
On the HT-S5300’s A/V receiver, Dolby Pro Logic
IIz enables you to incorporate two “front high”
speakers into your surround-sound set-up as an
alternative to the two surround back speakers. The
front high channels carry ambient, non-directional
audio that helps immerse you even more deeply
into your movies and games.
192 kHz/24-Bit Burr-Brown DACs
Improve Jitter Performan e to Deliver
Clearer Sound
High-quality Burr-Brown DACs (PCM1690) work
to optimize analog audio performance on the
HT-S5300’s A/V receiver. These DACs perform
advanced 24-bit signal processing and support
sampling rates of up to 192 kHz, while displaying
high resistance to clock jitter and offering a 113 dB
dynamic range.
Convenient Overlaid On-S reen Display
via HDMI
Changing your A/V receiver’s settings is now more
seamless than ever, thanks to Onkyo’s new overlaid
On-Screen Display (OSD) feature. On-screen set-up
menus appear overlaid on the video image you’re
watching. This means you can adjust the settings
immediately, without having to switch back and forth
from a blank screen background.
A Suite of Audyssey Te hnologies for the
Ideal Listening Environment
(1) Audyssey EQ™automates the speaker-
configuration process and employs a pre-set
correction filter for each speaker, reducing the
acoustic interference caused by a typical listening
room.
(2) Audyssey Dynamic Volume™automatically
compensates for volume fluctuations in different
audio content—for example, during commercial
breaks—while optimizing the dynamic range.
(3) Audyssey Dynamic EQ™maintains a consistent
bass response, tonal balance, and surround-sound
effect at different volume levels, so you can enjoy
the natural dynamics of your content regardless of
the volume.
SPECIFICATIONS
■A/V RECEIVER
AMPLIFIER SECTION
Power Output
Front L/R 160 W/Ch (6 Ω 1 kHz 1 channel driven JEITA)
Center 160 W (6 Ω 1 kHz 1 channel driven JEITA)
Surround L/R 160 W/Ch (6 Ω 1 kHz 1 channel driven JEITA)
Surround Back L/R 160 W/Ch (6 Ω 1 kHz 1 channel driven JEITA)
Dy amic Power 180 W (3 Ω Front)
160 W (4 Ω Front)
100 W (8 Ω Front)
THD (Total Harmo ic Distortio )
0.08% (1 kHz 1 W)
Dampi g Factor 60 (Front 1 kHz 8 Ω)
I put Se sitivity a d Impeda ce
200 mV/47 kΩ(Line)
Output Level a d Impeda ce
200 mV/2.2 kΩ(Rec out)
Freque cy Respo se 5 Hz–100 kHz/+1 dB -3 dB (DSP bypass)
To e Co trol ±10 dB 50 Hz (Bass)
±10 dB 20 kHz (Treble)
Sig al-to-Noise Ratio 106 dB (Line IHF-A)
Speaker Impeda ce 4 Ω–16 Ω
VIDEO SECTION
Iput Se sitivity/Output Level a d Impeda ce
Video 1.0 Vp–p/75 Ω(Component)
0.7 Vp–p/75 Ω(Component PB/CBPR/CR)
1.0 Vp–p/75 Ω(Composite)
Compo e t Video Freque cy Respo se
5 Hz–100 MHz/0 dB -3 dB
TUNER SECTION
Tu i g Freque cy Ra ge
FM 87.5 MHz–108 MHz
AM 522 kHz–1 611 kHz
530 kHz–1 710 kHz
FM/AM Preset Memory 40 stations
GENERAL
Power Supply AC 220–240 V~ 50/60 Hz
Power Co sumptio 500 W
Dime sio s (W x H x D) 435 x 151.5 x 328.5 mm
Weight 9.4 kg
■SPEAKER SYSTEM
Speaker Type
Front 2-way Bass reflex
Center 2-way Bass reflex
Surround Full-range Acoustic suspension
Surround Back Full-range Acoustic suspension
Subwoofer Bass reflex Powered
Drivers
Front 12 cm OMF diaphragm woofer
2.5 cm balanced-dome tweeter
Center 8 cm cone woofer x 2
2.5 cm balanced-dome tweeter
Surround 8 cm cone
Surround Back 8 cm cone
Subwoofer 25 cm cone
Freque cy Respo se
Front 55 Hz–50 kHz
Center 65 Hz–50 kHz
Surround 80 Hz–20 kHz
Surround Back 80 Hz–20 kHz
Subwoofer 25 Hz–150 Hz
Output Sou d Pressure Level
Front 85 dB/W/m
Center 86 dB/W/m
Surround 81 dB/W/m
Surround Back 81 dB/W/m
Max. I put Power
Front/Center/Surround/Surround Back
130 W
Max. Output Power
Subwoofer 290 W (Dynamic power)
Nomi al Impeda ce
Front/Center/Surround/Surround Back
6 Ω
I put Se sitivity/Impeda ce
Subwoofer 140 mV/20 kΩ
GENERAL
Dime sio s (W x H x D)
Front 155 x 375.5 x 170 mm
Center 420 x 115 x 121 mm
Surround 115 x 230 x 96 mm
Surround Back 115 x 230 x 96 mm
Subwoofer 317.5 x 463 x 398 mm
Weight
Front 2.7 kg
Center 2.4 kg
Surround 1.0 kg
Surround Back 1.0 kg
Subwoofer 10.7 kg
■CARTON
Dime sio s (W x H x D) 772 x 768 x 477 mm
Weight 37.5 kg
■Supplied Accessories
• Indoor FM loop antenna • AM loop antenna • Speaker cable labels
• Subwoofer cable • Color-coded speaker cable • Instruction manual
• Quick start guide • Remote controller • AA (R6) batteries* x 2
*Not included with Chinese model.
HT-R580
