HT-R591
North American and Brazilian models ---> “DIMMER”
Asian models ---> “RT/ PTY/ TP”
RC-799M
AV RECEIVER
MODEL HT-R591(B)
Ref. No. 4381
032012
Black model for HT-S5500
120V AC, 60Hz
220-240V AC, 50/60Hz
B MDC, B MDS
B MMK, B MMQ

HT-R591
SERVICE PROCEDURE-1
Clear Stand-by
VCR/DVR
ON/STANDBY
1. Replacing the fuses
2. Safety check out
(U.S.A. model only)
After correcting the original service problem, perform the following safety check before releasing the unit to the customer.
Leakage current Check
Measure the leakage current to a known earth ground (water pipe or conduct etc.) by connecting a leakage current
tester between the earth ground and exposed metal parts of the unit (input/output ground terminals, screw heads or metal overlays etc.).
Plug the power supply cord directly into a 120Vac 60Hz wall socket and turn ON/STANDBY button on.
Any current measured must not exceed 0.5mA.
3. To initialize the unit
1. Press ON/STANDBY button while pressing down VCR/DVR button when the unit is POWER ON, then the FL displays
"CLEAR", and turn to STAND-BY.
Preset memory and each mode stored in the memory, are initialized and will return to the factory settings.
2. Remove power cord from wall outlet.
This symbol located near the fuse indicates that the
fuse used is slow operating type, For continued protection against
fire hazard, replace with same type fuse, For fuse rating, refer to
the marking adjacent to the symbol.
Ce symbole indique que le fusible utilise est e lent.
Pour une protection permanente, n'utiliser que des fusibles de meme
type. Ce demier est indique la qu le present symbol est apposre.
F6401
F6401 or
F6402
F6402 or
F901
F901
F901 or
F901 or
F9001
10A-UL/T-233
10A-T/UL-ST2
10A-UL/T-233
10A-T/UL-ST2
4A-SE-EAK
8A-UL/T-233
8A-T/UL-ST2
4A-SE-TL250V
5A-UL-125V
252330GR
252333GR
252330GR
252333GR
252077GR
252329GR
252261GR
252277GR
252385T
!
!
!
!
!
!
!
!
FUSE
FUSE
FUSE
FUSE
FUSE
FUSE
FUSE
FUSE
FUSE
REF NO. PART NAME DESCRIPTION PART NO. REMARKS
<MMK, MMQ>
<MDC, MDD, MDS>
<MDC, MDD, MDS>
<MMK, MMQ>

HT-R591
SERVICE PROCEDURE-2
M:1.00/11Z22ALU
DISPLAY
M:1.00/11Z22ALU
D:1.00/11Z05aL
O:1.00/11Z02AL
(TONE)
(TONE)
(TONE)
(TONE)
(TONE)
(TONE) (TONE)
ON/STANDBY
(TONE)
4. To check version of each Firmware
1. Press ON/STANDBY (Power On)
2. Press DISPLAY + ON/STANDBY.
3. Press (Tone) ---> Forward
Press (Tone) ---> Reversed.
4. Press ON/STANDBY (Power Off).
Main Microprocessor
DSP
HDMI/Video Microprocessor
Version displayed
only for 3 seconds.
Version of Main Microprocessor displayed
only for 3 seconds.
e.g.
e.g.
e.g.
e.g.

HT-R591
SERVICE PROCEDURE-3
Resistor
Top
5. Notes on repairs (Power supply board)
Some parts on BAPS-1120 may remain high voltages
even after the power cord is disconnected from AC power source.
Before starting repair and any other work , please discharge C9002 by connecting resistors between its terminals. See the figure below
(recommended resistor spec: 5 k ohms/ 10W)
It is dangerous to touch the "HIGH VOLTAGE PRIMARY" area surrounded by white lines without discharging.
U0080
POWER SUPPLY(PRI) PC BOARD ASS'Y
BAPS-1120

TX-SR313/ HT-R358/391/558/591/ HT-RC430
DEBUG MODE-1
AUDIO DEBUG MODE-1/5
To set in Debug mode
1. Press and hold down DISPLAY button, then press ON/STANDBY button.
2. Press +(TONE) button while the version number of microprocessor is displayed.
3. Press DISPLAY button while the version number of DSP is displayed.
11. Press DISPLAY button.
D1.05/12327AEA
M1.06/12417AE
AUDIO dubug mode
The status of DSP and DIR etc
will be displayed.
4D48K1N 0FFPo0
e.g.
The version number of microprocessor is displayed
only for 3 seconds.
The version number of DSP is displayed
only for 3 seconds.
The operations of DSP and DIR etc are able to checked by the information displayed on FL in this debug mode.
This information will help to analysing digital audio no sound trouble.
Exit
e.g.
e.g.
ON/STANDBY + (TONE) DISPLAY
e.g.

DEBUG MODE-2
AUDIO DEBUG MODE-2/5
TX-SR313/ HT-R358/391/558/591/ HT-RC430
Contents of Display
FL Display
Display area
e.g. 0A0002:__:00__
1 141312106 87432 5 9 11 15
1. DIR INPUT LOCK/UNLOCK
E:UNLOCK
:LOCK
2. DIR INPUT RX
0:None
1:COAX1
2:COAX2
3:OPT1
4:OPT2
5:FRONT
8:HDMI1
9:HDMI2
3. DIR/ADC,FIX MODE
D:Digital(SPDIF)
A:Analog
M:AnalogMultich
p:PCM FIXED
d:DTS FIXED
4. Sampling Freq,Emphasis
32K: 32 kHz w/o Emphasis
44K: 44.1kHz w/o Emphasis
48K: 48 kHz w/o Emphasis
64K: 64 kHz
88K: 88.2kHz
96K: 96 kHz
176:176.4kHz
192:192 kHz
32e: 32 kHz w Emphasis
44e: 44.1kHz w Emphasis
48e: 48 kHz w Emphasis
5. DIR DETECT TYPE
0:Analog
1:PCM
2:Not PCM
3:Data
4:DTS CD(Not used)
5:Multich
6:Not Decided
6. CODEC CLOCK MODE
N:Normal
U:Up Sampling
H:High Sampling(Double Rate)
D:Down Smapling
Q:Quad Rate
7. DSP PORT
bit0:NIC
bit1:DEC
bit2:BUSY
bit3:EXEC WAIT
1 3 7542 6 8 9 10 11
8. DSP SEQUENCE
00-FE:NotFree
2D:Mute Control
FF:Free
9. DSP DETECT FORMAT
P:PCM(Analog)
D:Dolby Digital
d:DTS
A:AAC
d:DTS
A:AAC
S:DSD
p:DolbyDigital+
T:TrueHD
H:DTSHD High Resolution
M:DTSHD MaterAudio
?:UNKNOWN
10. DSP DECODE OK
o:OK
x:NG
11. Mute
1:Selector
2:Effector
4:DSP
8:DIR
Refer to “DEBUG MODE-3”
Description of the DSP PORT
(NIC/DEC/SPI Busy/Exec wait)
Refer to “DEBUG MODE-4, -5”
Description of the
DSP Sequence
Number of
digits
Number of
Parameters

DEBUG MODE-3
AUDIO DEBUG MODE-3/5
TX-SR313/ HT-R358/391/558/591/ HT-RC430
0
Stable state
Internal state Inferred state
1NIC
2DEC
3NIC+DEC
9Exec wait + NIC
8Exec wait
If you stop at these numbers, please check the DSP Sequence.
If the stop remains "1" is indicated, it is possible that there is an abnormality in
the connection between the microcomputer and the NIC.
4SPI Busy
5SPI Busy + NIC
6SPI Busy + DEC
7SPI Busy + NIC + DEC
FExec wait + SPI Busy
+ NIC + Dec
EExec wait + SPI Busy
+ DEC
DExec wait + SPI Busy
+ NIC
CExec wait + SPI Busy
BExec wait + NIC+DEC
AExec wait + DEC
Description of the DSP PORT(NIC/DEC/SPI Busy/Exec wait)
1 141312106 87432 5 9 11 15
1 3 7542 6 8 9 10 11
Number of
digits
Number of
Parameters
Display
contents
Please check if the input signal Dolby / DTS / AAC / PCM from Coax or OPT.
If the stop remains “2” is indicated, it is possible that there is an abnormality
in the connection between the DIR and the DSP.
There is a case of "2" for the state to stop or pause playback equipment.
And it is normal.
If the stop in these numbers, it is possible that there is an abnormality in
the connection between the DSP and the microcomputer.
If the stop remains "3" is indicated, it is possible that there is an abnormality in
the connection between the microcomputer and the NIC.

DEBUG MODE-4
AUDIO DEBUG MODE-4/5
TX-SR313/ HT-R358/391/558/591/ HT-RC430
Possible Causes
Description of the DSP Sequence(1/2)
1 141312106 87432 5 9 11 15
1 3 7542 6 89 10 11
Number of
digits
Number of
Parameters
Display
contents Inferred state
Stop at "03"
is indicated.
Stop at "05"
is indicated.
Stop at "08"
is indicated.
Stop at
"09 - 0C"
is indicated.
Stop at "17"
is indicated.
Have not been able to communicate
between the microcontroller and
the DSP.
Have not been able to write from
the boot loader of the DSP.
While running the boot loader of DSP,
the main program is not running.
Main program of DSP is not working
properly.
There is a possibility that the power is
turned off during the S / PDIF Update.
1.There is a problem with the connection between the FlashROM and
the DSP, and the SDRAM.
2.Power is not supplied to the DSP.
3.Operation clock is not input to the DSP.
4.Reset port of the DSP is not connected.
5.There is a problem with the line of communication between the
microcontroller and DSP.
6.DSP is broken or Microcomputer.
7.Program has not been successfully written to the Flash ROM. Or the
program is not written.
8.Communication port (such as DIR) other devices are connected to t
he SPI mode is broken short. Terminals are short-circuited.
1.Program is not written correctly to Flash ROM.
2.DSPSDO line of microcomputer is interrupted somewhere.
3.There is a problem with the FlashROM (or SDRAM) of DSP.
4.DSP is broken or Microcomputer.
5.Upper address bus of Flash ROM is not connected properly.
1.SDRAM is broken or Flash ROM.
2.Upper address bus of Flash ROM is not connected properly.
3.Program is not written correctly to Flash ROM.
4.There is a possibility that the power is turned off during
the S / PDIF Update.
1.SDRAM is broken or Flash ROM.
2.Upper address bus of Flash ROM is not connected properly.
3.Program is not written correctly to Flash ROM.
4.There is a possibility that the power is turned off during
the S / PDIF Update.
Solution :
Hold down the VCR/ DVR when the power is turned on, press the
On/Standby key. (Clear)
When out of the state of S / PDIF Update, please press the
On/Standby key.

DEBUG MODE-5
AUDIO DEBUG MODE-5/5
TX-SR313/ HT-R358/391/558/591/ HT-RC430
Possible Causes
Description of the DSP Sequence(2/2)
1 141312106 87432 5 9 11 15
1 3 7542 6 89 10 11
Number of
digits
Number of
Parameters
Display
contents Inferred state
Stop at
"22-24"
is indicated.
Stop at
"30-33"
is indicated.
Stop at
"26-2F"
is indicated.
Stop at "FF"
is indicated.
Main program of DSP is not working
properly.
main program of DSP is not working
properly.
The audio signal is not input.
main program of DSP is not working
properly.
The audio signal is not input.
DSP settings has failed.
The DSP is functioning properly.
1.SDRAM(or Flash ROM) is broken.
2.Upper address bus of Flash ROM is not connected properly.
3.Program is not written correctly to Flash ROM.
4.Operation clock to the DSP is not a predetermined value.
1.SDRAM(or Flash ROM) is broken.
2.Upper address bus of Flash ROM is not connected properly.
3.Program is not written correctly to Flash ROM.
4.Operation clock to the DSP is not a predetermined value.
5.Audio clock to the DSP is not a predetermined value.
1.SDRAM(or Flash ROM) is broken.
2.Upper address bus of Flash ROM is not connected properly.
3.Program is not written correctly to Flash ROM.
1.SDRAM(or Flash ROM) is broken.
2.Upper address bus of Flash ROM is not connected properly.
3.Program is not written correctly to Flash ROM.
All settings are completed, DSP has started normal operation.
Stop at “21”, to return to the
previous display after a while.
Format display indicator flashes.
There is no sound even though it is
the display of "FF".
Refer to “DEBUG MODE-3”
Description of the DSP PORT
(NIC/DEC/SPI Busy/Exec wait)

TX-SR313/ HT-R358/391/558/591/ HT-RC430
DEBUG MODE-6
HDMI DEBUG MODE-1/6
114 1312106 87432 5 9 11 114
1312106 87432 5 9 11
HDMI-related operations can be checked to some extent by displaying HDMI debug mode.
Content of Display
To enter this mode
Hold down DISPLAY button for 3seconds. Information display will last for about 8 seconds.
114 1312106 87432 5 9 11
Resolution display
Input resolution Output resolution
10
8
0i/601 0
80 i/60
List of standard resolution
4 8 0 i / 6 0
4 8 0 p / 6 0
1 0 8 0 i / 6 0
7 2 0 p / 6 0
1 0 8 0 p / 6 0
2 4 0 p / 6 0
# 4 8 0 i / 6 0
# 4 8 0 p / 6 0
# 2 4 0 p / 6 0
5 7 6 i / 5 0
5 7 6 p / 5 0
1 0 8 0 i / 5 0
7 2 0 p / 5 0
1 0 8 0 p / 5 0
2 8 8 p / 5 0
# 5 7 6 i / 5 0
# 5 7 6 p / 5 0
# 2 8 8 p / 5 0
1 0 8 0 p / 2 4
1 0 8 0 p / 2 5
1 0 8 0 p / 3 0
V G A
1 0 8 0 i 1 0 0
7 2 0 p 1 0 0
5 7 6 p 1 0 0
5 7 6 i 1 0 0
1 0 8 0 i 1 2 0
7 2 0 p 1 2 0
4 8 0 p 1 2 0
4 8 0 i 1 2 0
5 7 6 p 2 0 0
5 7 6 i 2 0 0
4 8 0 p / 6 0
4 8 0 p 2 4 0
4 8 0 i 2 4 0
* 4 8 0 p / 6 0
* 5 7 6 p / 5 0
7 2 0 p / 2 4
7 2 0 p / 2 5
7 2 0 p / 3 07 2 0 p / 3 0

DEBUG MODE-7
HDMI DEBUG MODE-2/6
TX-SR313/ HT-R358/391/558/591/ HT-RC430
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
Display of Output resolution
For a video processor
DVI input signal
VGA input signal
RSEN is OFF
EDID_READ is NG
Resolution Error
No output
(Signal output destination
can not be found.)
Hot-plug of Sink equipment
can not be detected.
Via VSP
VSP skip
i / p will be capitalized.
Display the ” ” in column 5
Display the ” ” in column 14
Display the ” # ” in column 14
Display the ” x ” in column 14
1 0 8 0 i / 6 0
1 0 8 0 i / 6 0
4 8 0 I / 6 0
4 8 0 P / 6 0
4 8 0 p / 6 0
4 8 0 p / 6 0
4 8 0 p / 6 0
4 8 0 p / 6 0 #
x
- - - - - -
O F F
Display the ” ” in column 4
Display of Input resolution
4 8 0 I / 6 0
4 8 0 P / 6 0
DVI input signal
VGA input signal
No input
i / p will be capitalized.
V G A
U n k n o w n
Display the ” ” in column 1

TX-SR313/ HT-R358/391/558/591/ HT-RC430
DEBUG MODE-8
HDMI DEBUG MODE-3/6
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
14
131211
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
4K Upscaling
Display of Output resolution
Display of input resolution
1 0 8 0 i / 6 0
xp/
If the three-digit numbers are refrate
List of resolution
3 8 4 0 x 2 1 6 0 p / 3 0
3 8 4 0 x 2 1 6 0 p / 2 5
4 0 9 6 x 2 1 6 0 p / 2 4
3 8 4 0 x 2 1 6 0 p / 2 4
Resolution Error
EDID_READ_NG
3 8 4 0 x 2 1 6 0 p / 3 0
3 8 4 0 x 2 1 6 0 p / 3 0x
#

TX-SR313/ HT-R358/391/558/591/ HT-RC430
DEBUG MODE-9
HDMI DEBUG MODE-4/6
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
Display of Input resolution
RSEN OFF
EDID READ NG
Resolution Error
3D format
INPUT/OUTPUT
1 0 8 0 p / 2 4 (3 D )
H D M I t4 4 4 3 6 b i
F r a m cP a k i n ge
I N : UO T:
Display the ” ” in column 14
Display the ” # ” in column 9
Display the ” x ” in column 13
1 0 8 0 p / 2 4 (3 D )
H D M I t4 4 4 3 6 b i
#
1 0 8 0 p / 2 4 (3 D )x
Status
Input Mode
Input Color
Deep Color
HDMI input
DVI input
No input
RGB
422
444
24bit
30bit
36bit
- - - t4 4 4 3 6 b i
D V I t4 4 4 3 6 b i
H D M I t4 4 4 3 6 b i
H D M I tR G B 3 6 b i
H D M I t4 2 2 3 6 b i
H D M I t4 4 4 3 6 b i
H D M I tR G B 3 6 b i
H D M I tR G B 3 0 b i
H D M I tR G B 2 4 b i
Resolution display
Status Display

DEBUG MODE-10
HDMI DEBUG MODE-5/6
TX-SR313/ HT-R358/391/558/591/ HT-RC430
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
3D format
Frame Packing
Side-by-Side(Full)
Side by Side(Harf)
INPUT/ OUTPUT
F r a m __ P a k i n ge c
F _ a l _e r n t i v et a
L _ a l _e r n t i v et a
S i d e _y S i e ( F )b d
L d e _t h _ _ _ _ _p _
L d e ct h g a p h ip r
S i d e _y S i e ( H )b d
T o p - mn d - o t t oa B
U N K N _W N _ _ _ _ _O _
I N : O T :U
Field alternative
Line alternative
L+depth
unknown
Top and Bottom
L+depth + graphics

TX-SR313/ HT-R358/391/558/591/ HT-RC430
DEBUG MODE-11
HDMI DEBUG MODE-6/6
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
114 1312106 87432 5 9 11
PC resolution
Display of Input resolution
DVI input
HDMI input
No input
U N K N O W N
Display of Output resolution
Input Resolution
Output Resolution
1 0 2 4 x 7 6 p / 6 08
1 0 2 4 x 7 6 p / 6 08
Three-digit numbers
are Referat
Display uppercase
P/I
Display lowercase
p/i
1 0 2 4 x 7 6 P / 6 08
1 0 2 4 x 7 6 p / 6 08
1 0 2 4 x 7 6 P 1 2 08
Horizontal resolution Vertical resolution Referat
x p /
Horizontal resolution Vertical resolution Referat
x p /
INPUT/ OUTPUT
I N : O T :U
DVI output
HDMI output
Display”-----”
Three-digit numbers
are Referat
EDID READ NG
Resolution through
Display uppercase
P/I
Display lowercase
p/i
Display the ” # ” in
column 13
Display the ” x ” in
column 13
1 0 2 4 x 7 6 P / 6 08
1 0 2 4 x 7 6 p / 6 08
- ----
1 0 2 4 x 7 6 P 1 2 08
1 0 2 4 x 7 6 P / 6 08 #
1 0 2 4 x 7 6 P / 6 08 x

TX-SR313/ NR414/ HT-R391/358/558/591/758/ RC430/440
OPERATION CHECK-1
1.OPERATION CHECK(1/2)
1-1. OPERATIONS OF VOLTAGE-DETECTION PROTECTORS.
See “OPERATION CHECK-3, -5” for TEST MODE operation.
NOTE: Don't connect load nor short speaker terminals.
a. Change the state to "TEST-4-21".
b. It tests by being automatic in order of TEST4-21(FL+) → 22(FR-) → 23(C+) → 24(SL-)
→ 25(SR+) → ( 26(SBL-) → 27(SBR+) ). It becomes the display of "TEST-4-35."
c. It will complete, if displayed on FL TUBE as "TEST-4-35."
d. Check operation of voltage-detection of subwoofer channnel. (HT-R391/358 only)
Change the state to "TEST-1-00".
The speaker relay is OFF immediately after D.C. +1.5v 3v is put at J4082 J4090 to check SW.
The same as above when D.C. -1.5v 3v is put at each place.
1-2. OPERATIONS OF CURRENT-DETECTION PROTECTORS
See “OPERATION CHECK-3, -4” for TEST MODE operation.
a. Change the state to "TEST-4-35".
Even if you connect 3-ohm load for every channel of L, R, C, SL, SR, SBL,SBR and SWch, a relay should not cut off.
If 1-ohm load is connected for every channel of L, R, C, SL, SR,SBL,SBR and SWch, a relay should hold the state of ON.
1-3. CONFIRMATION OF RDS (RADIO DATA SYSTEM) OPERATION (Applied to MPP/MPB type)
a. Input 98MHz,30dBμ signal modurated with RDS data.
b. When a PS information is received, the name of the station "RDS TEST" shall be displayed within 2 seconds instead of the frequency.
1-4. CONFIRMATION OF HEAD PHONE OPERATION.
Confirm the Listening Mode is automatically switched to "STEREO" mode when headphones plug is inserted into the PHONES jack.
1-5. COMFIRMATION OF USB(Except of HT-R358)
See “OPERATION CHECK-3, -4” for TEST MODE operation.
a. Connect ipod to AVR USB port.
b. When set to TEST-3-10, confirm that the display of AVR change "connecting" to "press Push [MODE] button ...." or "iPod"
after few seconds.
The following iPod models can be used for inspection.(The above-mentioned operation is not done excluding the following items.)
iPod classic, 3G nano, 4G nano, 5G nano
1-6. CONFIRMATION OF OUTPUT SENSOR AND THERMAL SENSER.
See “OPERATION CHECK-3, -5” for TEST MODE operation.
a. Set the TEST MODE to "TEST-4-36" and "TEST-4-37".
After light "FM STEREO" on FL display, the relays RL691/692 is OFF and "FM STEREO"is off .(TEST4-37 is only for HT-R591.)
b. Push ON/Standby button while pushing down DISPLAY button to display CPU PROGRAM version.
Push TONE button while displaying CPU PROGRAM version to display value of temparature sensor.
Confirm outside temperature ±20C is displayed immediately after energizing.
Note that the error margin is caused by the rise of the temperature of the heat sink when time passes.
No singal condition (Ex. Display)
>00 034 F:x S:H
Amplifier power
supply voltage condition
H: High-B
L: Low-B
NOTE1: Limit time to apply voltage is 0.5-1.0 seconds each channel.
When protection operation does not occur at once, try several times.
NOTE2: Don't connect load nor short speaker terminals.
NOTE3: The relay shall recover in one second in "TEST-1-00". So it shall not be hold OFF.
Temparature
of thermal sensoor
Voltage
of VOLH port
FAN condition
x: Stop
L: Low speed
M: Mid speed
H: High speed

TX-SR313/ NR414/ HT-R391/358/558/591/758/ RC430/440
OPERATION CHECK-2
1.OPERATION CHECK(2/2)
1-7. CONFIRMATION OF HDMI MAIN OUTPUT OSD(ON SCREEN DISPLAY) OPERATION
a. When SETUP button is pushed, confirm that setup menu is displayed in HDMI Out.
b. Confirm that specified operations for ENTER(with 4-cursor) buttons are made.
1-8. CONFIRMATION OF HDMI AUDIO OPERATION.
See “OPERATION CHECK-3, -6” for TEST MODE operation.
CONFIRMATION OF HDMI I2S SIGNAL
a. Input the one of these signals below from HDMI1 terminal.
DTS-HD MasterAudio 7.1ch
Dolby TrueHD 7.1ch
LPCM 7.1ch
b. Change the state to TEST 6-00. Confirm the signal is output from L/R,SW/C,SL/SR,SBL/SBR.
c. When TEST 6-08, confirm the sound(HDMI1 input) outputs from the TV.
CONFIRMATION OF HDMI SPDIF SIGNAL
d. SPDIF signal is input from HDMI terminal.
e. When TEST 6-06, confirm the sound(HDMI IN1) outputs from the speaker.
f. When TEST 6-07, confirm the sound(BD/DVD analog input) outputs from the TV.(VIDEO is HDMI1)
CONFIRMATION OF HDMI DSD SIGNAL
g. When TEST 6-10,11,12, confirm the sound of DSD 5.1ch input HDMI IN 3, output from the speaker.
1-9. VIDEO FUNCTION CHECK
See “OPERATION CHECK-3, -6” for TEST MODE operation.
a. Confirm Video output signal as shown Table 2, while Video signal are input as shown Table 1.
NOTE: Confirm the HDMI path at 1080p signal.
Table 1
Input
BD/DVD
VCR/DVR
CBL/SAT
GAME
PC
AUX
Composite Video
A
B
C
D
H
E
Component
IN1
---
IN2
---
---
---
F
No
G
No
No
No
HDMI
IN1
IN2
IN3
IN4
IN5
IN6
J
K
L
M
N
O
Test mode
5-05(BD/DVD)
5-06(VCR/DVR)
5-07(CBL/SAT)
5-08(GAME)
5-09(PC)
5-10(AUX)
Composite Video
ZVCR out
A
---
C
D
H
E
Monitor out
A
B
C
D
H
E
Component
OUT
F
---
G
---
---
---
HDMI
OUT
J
K
L
M
N
O
Table 2
b. OPERATIONS OF VIDEO SIGNAL-DETECTION
Set the TEST MODE to "TEST-5-00".
Confirm that "RDS" of FL TUBE lights, when the component video signal is input.
1-10. MISCELLANEOUS
See “OPERATION CHECK-3” for TEST MODE operation.
a. Please confirm LED and FL displaying by the FL test mode. And confirm the destination setting. ---> See to"OPERATION CHECK-3".
b. Confirm Key Operation.
Change the state to KEY TEST under TEST MODE described in Section 4-2. to confirm each key operation.
c. Confirm the version of each firmware.--->See to" SERVICE PROCEDURE-2".
d. Confirm the firmware combination check.
e. Confirm the DSP flash check.(Except TX-NR414, HT-R758 )
When it is normal, FL display indicate "A:OK B:OK"

TX-SR313/ NR414/ HT-R391/358/558/591/758/ RC430/440
OPERATION CHECK-3
2.TEST MODE(1/4)
2-1.TEST MODE FOR MODEL, DESTINATION AND FL DISPLAY
NOTE: If VOL value is not 25(initial setting), test mode cannot be set.
a. Push ON/STANDBY key while pushing down TV/CD button button to display "TEST-".
b. Then push DIMMER(RT/PTY/TP) button and get the FL test mode.
c. In the FL test mode, TONE - button is FL TEST UP and TONE + button is FL TEST DOWN.
d. REC OUT and ZONE2 button's originally operation can't work when it is in FL test mode.
e. The contents of the step are as follows.
1. Lit all segment
2. Lit 'FEDCBA987654321'.
3. Lit a even number segment
4. Lit an odd number segment
5. The Destination is displayed. Please see the below for detail.
f. To close the FL test, push POWER button.
S R 313 Dx 2 0 0 0
MODEL Name Destination A B CD
A:Value of AD port of BAND
B:Value of AD port of INIT1
C:Value of AD port of INIT2
D:Value of AD port of INIT3
Dx: USA/Canada
xx: OTHER
2-2. TEST MODE FOR OPERATION
a. Push STANDBY/ON button while pushing down TV/CD button to display "TEST-_".
b. Next, if the following keys are pushed, it becomes a each TEST MODE.
c. In the test mode, (TONE)- button is TEST MODE DOWN and (TONE)+ button is TEST MODE UP.
d. "TEST-1-00" and "TEST-1-01" are used to check a protection circuit, and the relay recovered in one second.
1-00 2-00 3-00 4-00 5-00 6-00 KEY TEST
FIRMWARE
VERSION
BD/DVD MEMORY
(CINEMA FILTER)
TONE
IDLING
TIMER FL TEST
TUNING MODE
(LATE NIGHT)
DIMMER
(RT/PTY/TP)
TEST MODE
FIRMWARE
COMBINATION
CHECK
ENTER When the MPU version
is displayed, push
"MEMORY(CINEMA FILTER)"
CHECK SUM
TEST MODE
Button --->
Test mode No. --->
MODEL
FL DIS Name
Destination
ABCD
Dx
2000
TX-SR313
SR313
xx
8000
HT-RC430
RC430
Dx
2002
HT-R391
HT391
Dx
2020
xx
8020
HT-R358
HT358
xx
8022
HT-R558
HT558
xx
8026
HT-R658
HT658
xx
8024
HT-R591
HT591
Dx
2028
xx
8028
MODEL
FL DIS Name
Destination
ABCD
Dx
2000
TX-NR414
NR414
xx
8000
HT-R758
HT758
Dx
2020
xx
8020
HT-R358
HT358
xx
8022
HT-RC440
RC440
Dx
2002
Others
TX-NR414
/HT-R758 CBL/SAT GAME PC AUX TV/CD
BD/DVD VCR/DVR CBL/SAT GAME AUX TV/CD
DSP FLASH CHECK
When the DSP version is
displayed, push "BD/DVD"

TX-SR313/ NR414/ HT-R391/358/558/591/758/ RC430/440
OPERATION CHECK-4
2.TEST MODE(2/4)
2-2. TEST MODE FOR OPERATION(Continue)
e. Test mode is as follows.
TEST
No
1-00
1-01
1-02
2-00
2-01
2-02
2-03
2-05
2-06
2-07
2-08
2-09
2-10
2-11
2-12
2-13
2-14
2-15
2-16
2-17
2-18
2-19
2-20
2-21
2-22
2-23
2-24
2-25
2-26
3-00
3-01
3-02
3-03
3-04
3-05
3-06
3-10
3-11
3-12
3-13
3-14
3-15
3-16
3-17
3-18
Analog Input
[Rec Sel]
(Zone2)
BD/DVD (Off)
BD/DVD (Off)
BD/DVD (Off)
BD/DVD (Off)
BD/DVD (Off)
BD/DVD (Off)
Multi channel
BD/DVD (Off)
BD/DVD (Off)
BD/DVD (Off)
BD/DVD (Off)
BD/DVD (Off)
BD/DVD (Off)
VCR/DVR (Off)*2
VCR/DVR (Off)*2
CBL/SAT (Off)
GAME (Off)
AUX (Off)
BD/DVD (Off)
BD/DVD (Off)
TV/CD (Off)
BD/DVD (Off)
BD/DVD (Off)
BD/DVD (Off)
BD/DVD(Source)
MIC
MIC
AUX(Off)
PC (Off)
FM/Source
TV/CD
TV/CD
TV/CD
TV/CD (Off)
SXM (Off)
PORT (Source)
USB/(Source)
NET/(Source)
NET/(Source)
NET/(Source)
NET/(Source)
NET/(Source)
NET/(Source)
NET/(Source)
NET/(Source)
Listening Mode/
Input Format
Direct
Direct
Direct
Stereo(Direct)
Stereo(Direct)
DVD Direct
Multich Amp Test
ADC DSP 8ch Thru.
ADC DSP 8ch Thru.
ADC DSP 7ch Thru.
ADC DSP 8ch Thru.
ADC DSP 8ch Thru.
ADC DSP 8ch Thru.
Automatic
Automatic
DIR DSP 8ch Thru
DIR DSP 8ch Thru
DIR DSP 8ch Thru
DIR DSP 8ch Thru
DIR DSP 8ch Thru
Automatic
DIR DSP 8ch Thru
DIR DSP 8ch Thru
DIR DSP 8ch Thru
DIR DSP 8ch Thru
ADC DSP 8ch Thru.
ADC DSP 8ch Thru.
DIR DSP 8ch Thru
DIR DSP 8ch Thru
Stereo(Direct)
Stereo(Direct)
Stereo(Direct)
Stereo(Direct)
ALL CH STEREO
Stereo(Direct)
ADC DSP 8ch Thru.
Stereo(Direct)
Stereo(Direct)
Stereo(Direct)
Stereo(Direct)
Stereo(Direct)
Stereo(Direct)
Stereo(Direct)
Stereo(Direct)
Stereo(Direct)
VIDEO
Input
BD/DVD
BD/DVD
BD/DVD
BD/DVD
BD/DVD
BD/DVD
BD/DVD
BD/DVD
BD/DVD
BD/DVD
BD/DVD
BD/DVD
BD/DVD
VCR/DVR*2
VCR/DVR*2
CBL/SAT
GAME
AUX
BD/DVD
BD/DVD
BD/DVD
BD/DVD
BD/DVD
BD/DVD
BD/DVD
BD/DVD
BD/DVD
AUX
PC
DVD
DVD
DVD
DVD
DVD
DVD
PORT
Last
Last
Last
Last
Last
Last
Last
Last
Last
Compo-
nent V
IN1
IN1
IN1
IN1
IN1
IN1
IN1
IN1
IN1
IN1
IN1
IN1
-
-
-
-
-
-
-
DVD
DVD
DVD
DVD
DVD
DVD
DVD
-
-
DVD
DVD
DVD
DVD
DVD
DVD
-
-
-
-
-
-
-
-
-
-
HDMI
IN1
IN1
IN1
IN1
IN1
IN1
IN1
IN1
IN1
IN1
IN1
IN1
IN1
IN2
IN2
IN3
IN4
-
-
-
IN2
IN2
IN2
IN3
IN3
IN1
IN1
-
-
IN1
IN1
IN1
IN1
IN1
IN1
-
-
-
-
-
-
-
-
-
-
12V
Trigger
A
B
C
-
-
-
-
-
-
-
-
-
Digital Input
/Output
-
-
-
-
-
-
-
-
-
-
-
-
-
*OPT1
*COAX1
*OPT1
OPT1
COAX1
COAX1
*OPT2
*OPT2
*OPT2
*COAX2
*COAX2
-
-
OPT1
OPT1
-
-
-
-
-
SIRIUS JIG Board
-
USB
NET
NET
NET
NET
NET
NET
NET
NET
Config.
-
-
-
-
-
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
-
-
-
-
Y/L/L/L/L
-
-
-
-
-
-
-
-
-
-
-
Master Vol.
/Z2 Vol
Max
Max
MIN
Max
64
Max
64
62
64
57
45
MIN
64
64
64
64
64
64
Max
64
52
64
64
64
64
64
64
59
64
64
Max
64
64
64
43
57
57
48
48
48
48
48
48
48
48
Speaker
Relay
F/CS/SB/Z2
F/CS/SB/Z2
F/CS/SB/Z2
F
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F
F
CS
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F
F/Z2
F/Z2
F/Z2
F/CS/FH
F
F
F
F
F
F
F
F
F
F
F
etc.
SBL,SBR
SW=NO
SW=NO
SW:MUTE
SPRLF OFF
MICMUTE ON
Z2MUTE ON
"Output Level / Distortion"
SN Ratio
Freq. Resp.
Freq. Resp.
Separation
Separation
"Output Level / Distortion"
"Net connectioncheck "
*1 PROTECT
"*1 PROTECTFOR SBL ch"
*3
"WAV,44.1kHz,16bit,1kHz,0dBfs,
from test server"
"WAV,44.1kHz,16bit,-∞dBfs,
from test server"
"WAV,44.1kHz,16bit,20Hz,0dBfs,
from test server"
"WAV,44.1kHz,16bit,20kHz,0dBfs,
from test server"
"WAV,44.1kHz,16bit,1kHz,0dBfs,Lch
from test server"
"WAV,44.1kHz,16bit,1kHz,0dBfs,Rch
from test server"
"WAV,48kHz,16bit,1kHz,0dBfs,
from test server"
display IP address
In all test modes, it is not concerned with detection of VOLH but SEC1H are made "H" fixation. (Except TEST4-36 and 4-37.)
*1: All SP-RELAYs are turned ON only at the time of this STEP.
Moreover, whether make RELAY restoration time at the time of protection operation into 1 second, and PROTECT input "H" is detected
how many times or it continues 1 second or more, RELAY is not held at OFF or POWER OFF is not carried out, either.
When "H" is 1 seconds or more to PROTECT input and it is set to "L", RELAY is turned ON again.
Moreover, not any MUTE is outputted at the time of this STEP.
*2: Selector is CBL/SAT on NR414.
NOTE-1: For inspection procedure of NET, TEST-3-11 should be measured first. (for prevention of the malfunction)
NOTE-2: TTEST of NET/USB can't do immediately after the start-up. It should be measure after other TEST.

TX-SR313/ NR414/ HT-R391/358/558/591/758/ RC430/440
OPERATION CHECK-5
2.TEST MODE(3/4)
2-2. TEST MODE FOR OPERATION(Continue)
Auto Measurement Mode
TEST
No.
4-00
4-01
4-02
4-03
4-04
4-05
4-06
4-07
4-08
4-09
4-10
4-11
4-12
4-13
4-14
4-15
4-16
4-17
4-18
4-19
4-20
4-21
4-22
4-23
4-24
4-25
4-26
4-27
4-28
4-29
4-30
4-31
4-32
4-33
4-34
4-35
4-36
4-37
4-38
4-39
4-40
DSP Output ch
ALL
ALL
ALL
SW
FL,FR
FR,C,SL,SR,SBL,SBR,SW
FL,C,SL,SR,SBL,SBR,SW
FL,FR,SL,SR,SBL,SBR,SW
FL,FR,C,SR,SBL,SBR,SW
FL,FR,C,SL,SBL,SBR,SW
FL,FR,C,SL,SR,SBR,SW
FL,FR,C,SL,SR,SBL,SW
FL,FR,C,SL,SR,SBL,SBR
ALL
ALL
ALL
ALL
ALL
ALL
ALL
ALL
FL
FR
C
SL
SR
SBL
SBR
FL
FR
C
SL
SR
SBL
SBR
ALL
"FL,FR,C,SL,SR"
C,SL,SR,SBL,SBR
ALL
ALL
ALL
DSP Output
Frequency
1kHz
30Hz
20kHz
30Hz
30Hz
10kHz
10kHz
10kHz
10kHz
10kHz
10kHz
10kHz
30Hz
1kHz
30Hz
1kHz
30Hz
100Hz
10kHz
100Hz
10kHz
+DC
-DC
+DC
-DC
+DC
-DC
+DC
-DC
+DC
-DC
+DC
-DC
+DC
-DC
Pulse
1kHz
1kHz
1kHz
30Hz
20kHz
DSP
Output
Voltage
-20dBFS
-20dBFS
-20dBFS
-20dBFS
-20dBFS
-20dBFS
-20dBFS
-20dBFS
-20dBFS
-20dBFS
-20dBFS
-20dBFS
-20dBFS
-20dBFS
-20dBFS
-20dBFS
-20dBFS
-20dBFS
-20dBFS
-20dBFS
-20dBFS
+Max
-Max
+Max
-Max
+Max
-Max
+Max
-Max
+Max
-Max
+Max
-Max
+Max
-Max
Max
0dBFS
0dBFS
-20dBFS
-20dBFS
-20dBFS
Config.
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
N/L/L/L/L
N/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Y/L/L/L/L
Master Vol.
64(-16dB)
64(-16dB)
64(-16dB)
58(-22dB)
64(-16dB)
64(-16dB)
64(-16dB)
64(-16dB)
64(-16dB)
64(-16dB)
64(-16dB)
64(-16dB)
64(-16dB)
64(-16dB)
64(-16dB)
Min(-80dB)
Min(-80dB)
64(-16dB)
64(-16dB)
64(-16dB)
64(-16dB)
Max
Max
Max
Max
Max
Max
Max
Max
Max
Max
Max
Max
Max
Max
58(-22dB)
55(-25dB)
59(-21dB)
55(-25dB)
59(-21dB)
59(-21dB)
59(-21dB)
Speaker
Relay
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
F/CS/SB
etc.
Mute:FL
Mute:FR
Mute:C
Mute:SL
Mute:SR
Mute:SBL
Mute:SBR
Mute:SW
*mut on
*mut on
BASS ALL:+12
TREBLE ALL+12
BASS ALL:-12
TREBLE ALL-12
*1,*2
*1,*2
*1,*2
*1,*2
*1,*2
*1,*2
*1,*2
*1,*2
*1,*2
*1,*2
*1,*2
*1,*2
*1,*2
*1,*2
*1,*3
others: vol = 55
TX-NR414/HT-R758: vol = 59 *4
*4
DSP Gain
DSP Freq.Response
DSP Freq.Response
Characteristic(1)
Characteristic(2)
Separation
Separation
Separation
Separation
Separation
Separation
Separation
Separation
Muting
Muting
Volume Max.Attenuation
Volume Max.Attenuation
BASS Max.
TREBLE Max.
BASS Min.
TREBLE Min.
+DC Protect
-DC Protect
+DC Protect
-DC Protect
+DC Protect
-DC Protect
+DC Protect
-DC Protect
+DC Protect
-DC Protect
+DC Protect
-DC Protect
+DC Protect
-DC Protect
Current Protect
VOLH DET
VOLH DET
*2 : When TEST No. 4-21 34 is setted, DC votage is putted out immediately at each channel. (within 100msec.)
*3 : The following signal is putted out at all channel continuously in TEST4-35
*4 : VOLH is detected and H/L of SEC1H is changed.
A detection level is the same as the normal mode.
When it is detected, light "FM STEREO" on FLD.
20 mS
2 mS 2 mS
Max
Max
*8 : In TEST3-06,when I-Pod pull out from jug I-POD DET is detectedt han change to standby.
