Onn ONA21DP001A User manual

User Manual
Model: ONA21DP001A
9'' Portable DVD Player with Swivel Screen

DANGEROUS VOLTAGE:The lighting flash with arrowhead symbol within
an equilateral triangle is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure that may
be of sufficient magnitude to constitute a risk of electric shock to persons.
ATTENTION:The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
WARNING:TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE
THIS UNIT TO RAIN OR MOISTURE.
CAUTION: TO REDUCE THE ELECTRIC SHOCK, DO NOT REMOVE THE
COVER (OR BACK). NO USER SERVICEABLE PART INSIDE, REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
2
Before using the unit, be sure to read all operating instruction carefully, please
note that these are general precautions and may not pertain to your unit. For
example, this unit may not have the capability to be connected to an outdoor
antenna.
1. Read these instructions
All the safety and operating instructions should be read before the appliance is
operated.
2. Keep these instructions
The safety and operating instructions should be kept for future reference.
3. Heed all warnings
All warnings on the appliance and in the operating instructions should be
adhered to.
4. Follow all instructions
All operation and use instructions should be followed.
5. Do not use this apparatus near water
The appliance should not be used near water; for example, near a bath tub,
washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming
pool.

6. Clean only with dry cloth
The appliance should be cleaned only as recommended by the manufacturer.
7. Do not block any ventilation openings.Install in accordance with the
manufacturer’s instructions.
Slots and openings in the cabinet and in the back or bottom are provided for
ventilation, to ensure reliable operation of the product and to protect it from
overheating. These openings must not be blocked or covered. The openings
should never be blocked by placing the product on a bed, sofa, rug, or similar
surface. This product should never be placed near or over a radiator or heat
source. This product should not be placed in a built-in installation, such as a
bookcase or rack unless proper ventilation is provided or the manufacturer’s
instructions have been adhered to.
8. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The
wide or the third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly
at plugs, convenience receptacles, and the point where they exit from the
apparatus.
11. Only use attachments / accessories specified by the manufacturer.
12. Use only with a cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury
from tip-over.
An appliance and cart combination should be moved with care. Quick stop,
excessive fore and uneven surfaces may cause the appliance and cart
combination to overturn.
13. Unplug this apparatus during lightning storms or when unused for
long periods of time.
To protect your product from a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall outlet and disconnect
the antenna or cable system. This will prevent damage to the product due to
lightning and power-line surges.
Portable Cart Warning
3

15. Power source
This product should be operated only from the type of power source indicated
on the marking label. If you are not sure of the type of power supply to your
home, consult your appliance dealer or local power company. For products
intended to operate from battery power, or other source, refer to the operation
instructions.
16. Power lines
An outside antenna system should not be located in the vicinity of overhead
power lines or other electric light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside antenna system, extreme
care should be taken to keep from touching such power lines or circuits as
contact with them might be fatal.
17. Overloading
Do not overload wall outlets and extension cords as this can result in a risk of
fire or electric shock.
18. Object and liquid entry
Never push objects of any kind into the product through openings as they may
touch dangerous voltage points or short out parts that could result in fire or
electric shock. Never spill or spray any type of liquid on the product.
4
Do not attempt to service this product yourself as opening or removing covers
may expose you to dangerous voltage or other hazards. Refer all servicing to
qualified service personnel.
When replacement parts are required, be sure the service technician uses
replacement parts specified by the manufacturer or those that have the same
characteristics as the original parts. Unauthorized substitutions may result in
fire or electric shock or other hazards.
Upon completion of any service or repairs to this product, ask the service
technician to perform safety checks to determine that the product is in proper
operating condition.
19. Service
20. Replacement parts
21. Safety check
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.

b)If liquid has been spilled or objects have fallen into the product.
c)If the product has been exposed to rain or water.
d)If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions, as an adjustment of other controls may result in damage and will
require extensive work by a qualified technician to restore the product to its
normal operation.
e)If the product has been dropped or the cabinet has been damaged.
f)When the product exhibits a distinct change in performance- this indicates a
need for service.
NOTE: Refer all servicing to qualified service personnel. Servicing is
required when the unit has been damaged in any way such as the
following: the power-supply cord or plug has been damaged, liquid has
been spilled into unit, the unit has been exposed to rain or moisture, the
unit has been dropped or the unit does not operate normally.
Unplug this product from the wall outlet and refer service to qualified service
personnel under the following conditions.
a)When the power- supply cord or plug is damaged.
5
Minimum 20cm distances around the apparatus for sufficient ventilation;
No naked flame sources, such as lighted candles, should be placed on apparatus;
Attention should be drawn to the environmental aspects of battery disposal ;
The apparatus shall be used in moderate climates.
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
The batteries (battery pack or batteries installed) shall not be exposed
to excessive heat such as sunshine, fire or the like.
To avoid battery subjected to extremely low air pressure.
The mains plug of power adapter is used as the disconnect device, The
socket outlet shall be installed near the equipment and shall be easily
accessible.
The USB port does not support USB charging for external circuit.
The maximum operation temperature is 40°C.
22. Damage requiring service
Warning:
To prevent possible hearing damage, do not listen at high volume
levels for long periods.

Press to turn upward.
Press to start playing or pause, press again to resume during playing.
5. Press to open the disc door.
Press to confirm the operations.
OK
1
2
3
5
4
VOL- : Press to decrease volume.
SETUP: Press and hold to enter set up menu.
VOL +: Press to increase volume.
MENU : Press to enter root menu.
SOURCE : Press and hold to switch to "AV IN" mode, press and hold again to resume.
Press to skip to previous track.
Press to skip to next track.
Press to turn downward.
Press to turn left.
Press to turn right.
Press to fast backward.
Press to fast forward.
STOP: Press and hold to pre-stop playing, press and hold again to stop playing competely.
Function Panel View:
LOCATION OF CONTROLS
1.
2.
3.
4.
6

6. USB Port
7. SD/MMC/CARD Slot
8. EARPHONE Jack
9. AV OUT Jack
10. AV IN Jack
11. POWER ON/OFF Switch
12. DC IN Jack
LOCATION OF CONTROLS
Right Side View:
Front Side View:
13. CHARGE Indicator 15. POWER Indicator
6 7 8 9 10 11 12
13 15
14
14. Remote Sensor
7
CHARGE POWER
IR

1
2
3
4
5
6
7
89
10
11 12
13 14
15
POWER
16
17
18
19
20
21
22
23
24
25
26
27
28
1. POWER Button
2. VOLUME +/– Buttons
4. MENU Button
ŻŻ
7.
ǿŻŻ
6.
12.
15. SLOW Button
16. LCD ON/OFF Button
17. Numeric Buttons
18. SETUP Button
21.
22. SUBTITLE Button
23. ANGLE Button
24.
26. STEP Button
27. ZOOM Button
28. A-B Repeat Button
9.
TITLE Button
8.
USB/CARD Button
10.
AUDIO Button
GOTO Button
REPEAT Button
13.
11.
14.
OK
25.
3. MUTE Button
5. Direction Buttons
(Skip Forward) Button
(Fast Forward) Button
(Play/Pause) Button
(STOP) Button
OSD (On Screen Display) Button
■
PROG (Program) Button
REMOTE CONTROL
MENU
TITLE
OK Button
8
19.
20.
(Fast Backward) Button
(Skip Backward) Button

BATTERY INSTALLATION (REMOTE CONTROL)
Remarks:
1. When there is an obstacle between the unit and the transmitter, the transmitter may not operation.
2. When direct sunlight, an incandescent lamp, fluorescent lamp or any other strong light shines on
remote control of the unit, the remote operation may be unstable.
POWER
Battery installation:
1. Press the tab on the battery door and lift it off.
2. Install two (2) x AAA size batteries into the battery
compartment as the figure on right and the polarity
markings inside battery compartment.
3. Replace the battery door.
Battery Precautions:
Follow these precautions when using a battery in this device:
1. Use only the size and type of battery specified.
3.Besure to follow the correct polarity when installing the battery as indicated in
the battery compartment. A reversed battery may cause damage to the device.
batteries to prevent damage or injury from possible battery leakage.
manufacturer's directions).
7.Don't disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a Battery.
9.Clean the battery contacts and also those of the device prior to battery installation.
4. Do not mix different types of batteries together (e.g. Alkazline and Carbon-zinc)
or old batteries with fresh ones.
5.If the batteries in the device are consumed or the device is not to be used for a long period
of time, remove the
6.Do not try to recharge the battery not intended to be recharged; it can overheat and rupture.
(Follow battery
Remote Control Sensor:
AAA
AAA
9
CHARGE POWER
IR
To avoid battery subjected to extremely low air pressure.
2.Avoid replacement of a battery with an incorrect type.
8.Don’t leaving a battery in an extremely high temperature surrounding Environment.
10.

1.
3. During charging, the red indicator will light, and it will turn green when finished charging.
Your battery will last longer if you follow these simple guidelines for caring and storing it:
A. Do not overcharge (longer than 24 hours). Excessive charging or discharging may shorten
B. Battery life naturally shortens slowly over time.
2. This is a special negative grounded
Car Adapter. Using this Car Adapter
with a plus grounded car can cause
malfunction.
3. Do NOT plug in the Car Adapter until
the car ignition is turned on.
4. Disconnect the Car Adapter from the
cigarette ligher and the unit after use.
To the cigarette
lighter socket
Connect the small plug from the supplied AC/DC Adaptor to the DC IN Jack on the right of unit.
Connect the AC/DC Adaptor to the wall outlet having AC 100-240V~; 50/60Hz.
the battery’s life.
1. Connect to the cigarette lighter socket of a vehicle that has a 12V battery as the figure below.
It is not compatible with a vehicle that has a 24V battery.
Charging by supplied AC/DCAdaptor:
Charging by the supplied Car Adaptor:
2.
POWER SOURCE
Notes: For saving energy, unplug the AC/DC Adaptor from wall outlet if the unit will not use for long
period of time.
To DC IN Jack on the unit
10
C. The rechargeable battery incorporated in this product is not user replaceable.

Audio/Video cable (not included)
Connected to the TV Connected to the Video Player
AUDIO OUT
LR
120V ~ 60Hz
VIDEO OUT
VIDEO
Video Player
DIGIT A L
Video input jack (Yellow)
Audio left channel input jack (White)
Audio right channel input jack (Red)
NOTE:
CONNECTIONS
Connecting to a TV or Video Player (such like DVD; VCR; DVR Players ... ) with AV connection cable.
The default setting of the unit is AV Out, if connect to external Video Player (such like DVD; VCR;
DVR Players ... ), press and hold the SOURCE button to set to AV IN mode ("AV IN" will appear
on the screen), press and hold again to resume.
Using the Earphone (not included) to listen privately.
11

a
d
c
b
180°
The viewing angle of the swivel panel can be adjusted as below as desired:
SWIVEL PANEL
12

3. During playback:
~ Press the or buttons on remote control repeatedly to fast search for a specific section forward/backward.
the Power ON/OFF switch to "ON" position to power on
2. Press the OPEN button to open the disc door. Place the disc on the center spindle with label side facing up. Close
the disc door and the player will start playback automatically. If this dosen't occur, press the button.
1. Lift up the panel and turn to desired angle. Slide
the unit, the green Indicator on front of the player will light.
Press button on remote control to resume normal playback.
~ Press the or button on remote control repeatedly to skip to specific track or chapter.
~ Press button on remote control to pause, press button again to resume normal playback.
~ Press the VOL (Volume) +/- buttons on remote control to adjust volume level.
~ Press the STOP button on the remote control to pre-stop. The player will remember the point where the disc
4. For saving energy, always power off the player by slide the Power ON/OFF switch on the player to OFF position
or unplug the wall power adaptor from player and wall outlet.)
OPERATIONS
was stopped. When press button again, playback will start from this point. Press the STOP button twice
to stop completely, press button to start from beginning.
13
Repeat Playback: (DVD)
Repeat Playback: (CD)
Press the REPEAT button once; the current track will playback repeatedly and continuously.
Press the REPEAT button twice; all the tracks on the disc will playback repeatedly and continuously.
Press the REPEAT button repeatedly to turn off the repeat mode.
1. During CD or DVD playback, press the 352* (Program) button.
4. Using the Direction buttonsto select and highlight the "PLAY" or button on the screen then press the OK
button to start program playback.
(CD/DVD)Program:
2.
DVD CD
T C
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
T C T C T C
--:--
--:--
--:--
--:--
--:--
--:--
--:--
--:--
--:--
--:--
--:--
--:--
--:--
--:--
--:--
PLAY CLEAR
TRACK01
TRACK02
TRACK03
TRACK04
TRACK05
TRACK06
0/16
3.
Using the Direction, OK and Numeric buttons to select and set the desired T (Title), C (Chapters), tracks
(for CD) of the movie /music you wants. The Program menu will appear as follows.
+
+
Using the Direction buttonsto select and highlight the "CLEAR" or button on the screen then press the
OK button to clear all the programmed items when there is wrong programming.
Press the REPEAT button once, the current chapter will playback repeatedly and continuously.
Press the REPEAT button twice, the current Title will playback repeatedly and continuously.
Press the REPEAT button the third time, all files will playback repeatedly and continuously.
Press the REPEAT button repeatedly to turn off the repeat mode.
--:--

POWER: Press to turn to standby mode. Press again to turn on.
Volume +/–: Press to increase or decrease volume.
LCD ON/OFF: Press to turn on or off the LCD display.
Press to turn off the sound, press again to resume.
(Function depends on the recording of disc)
During DVD playback, press repeatedly to select the viewing angle.
TITLE: Press to return to disc's title page (Function depends on the recording of the disc).
Press to return to disc's menu page (Function depends on the recording of the disc).
During playback, press repeatedly to read the information of playback status.
During movie playback, press repeatedly to play the movie frame by frame.
Press the button to resume normal playback.
OPERATIONS
MUTE:
MENU:
During DVD playback, press repeatedly to select the desired subtitle.
(Function depends on the recording of the disc)
OSD (On Screen Display) :
SUBTITLE:
STEP:
ANGLE:
AUDIO:
GOTO:
A-B Repeat:
During Playback, press the A-B button to define where you want the section to start. Press the A-B button
again to define where you would like the section to end, the unit will then plays the selected section
repeatedly and continuously. Press the A-B button again to resume normal playback.
(This function is not available on all discs)
SLOW:
During playback, press the SLOW button repeatedly to set the slow motion speed. Press button resume
to normal playback.
During DVD playback, press repeatedly to select the desired audio language. (Function depends on the
recording of disc)
ZOOM:
During movies playback, press the ZOOM button repeatedly to zoom in/out the picture. When in zoom in
mode, press Direction buttons to select the parts of the zoomed picture to watch. (This function is not
available on all discs)
14
Press to display the TRK (Track) and time selection, input the desired track or playback time.
(For audio CD disc) Press the OK button to confirm.
Press to display the TT (Title), CH (Chapter) and time selection, input the desired title, chapter or playback
time. ( For DVD disc) Press the OK button to confirm.
During CD playback, press repeatedly to select the desired audio channel. (Function depends on the
recording of disc)

1. Insert the USB device or SD/MMC memory card into the USB port /card slot as the figure below.
NB: The unit supported to playback:
~ MP3; (Music file)
~ JPG (Pictures)
Make sure correct files were saved in the USB device or memory cards.
USB or SD/MMC CARD PLAYBACK
3. During playback:
2. In Power ON mode, press the USB/CARD button on remote control, the "DVD, CARD, USB"
selection window will pop up on the screen. Using the Direction buttons to select and highlight the
source then press the OK button to confirm. Using the Direction and OK buttons to select desired
Folder or File then press the OK button to start playback.
15
~ Press the or button on remote control repeatedly to skip backward/forward.
~ Press the or button on remote control repeatedly to fast searching backward/forward.
~ Press the button to pause. Press again to resume normal playback.
~ Press the (STOP) button on remote control to return to menu.

SYSTEM SETUP
16
4. If TV Type is selected, set the aspect ratio to match the connected TV.
TV System
POWER RESUME
Screen Saver
TV Type
Video
Default
SYSTEM SETUP
1. If TV System is selected, it can be set to NTSC, PAL or AUTO to match the connected TV.
2. If POWER RESUME is selected and set On, the unit will start playback from the position where the disc was
stopped last time.
3. If Screen Saver is selected and set On, the screen saver will come on when the unit idles or the image is
paused for several minutes.
6.If Default is selected and set it to restore, all settings will be restored to factory setting.
TFT
Press the SETUP button on remote control or press and hold the SETUP button on the unit, the setting menu
will appear on the screen as below. During setting, using Direction , , , buttons to select and highlight
the function needed to set or reset, press the OK button to confirm the selection. After setting, press the SETUP
button to save and exit.
If Video is selected, using the Direction and OK buttons to set it to CVBS to match the connected TV.5.
1. If Osd Language (On Screen Display Language) is selected, using the Direction and OK buttons
to set the priority of the available language. (Function depends on the recording of the disc)
If Audio Lang (Audio Language) is selected, using the Direction and OK buttons to set the priority of
the
available language.
If Menu Lang (Menu Language) is selected, using the Direction and OK buttons to set the priority of
the available language of the on screen menu.
If Subtitle Lang (Subtitle Language) is selected, using the Direction and OK buttons to set the priority
of the available language or set it off.
2.
3.
4.
LANGUAGE SETUP:
Osd Language
Audio Lang
Subtitle Lang
Menu Lang
LANGUAGE SETUP
TFT

17
SYSTEM SETUP
1. , then enter the four default password
"0000" to unlock the rating, press the OK button to confirm. Now the lock status will be .
If Password is selected, press the button to highlight
2.or
►
►
~ Rate levels:
KID SAFE:
G:
PG:
PG 13:
PG-R:
R:
NC-17:
Kid safe
All ages
Parental Guidance
Parental Guidance less than 13 years old
Under 17 years old, Parental Guidance suggested
Under 17 years old, Parental Guidance strongly
17 years old or above
Adult only
ADULT:
To change a new password, highlight the password column and enter a new four digit password under
unlocking status, press the OK button to confirm password changing.
Password
Rating
RATING SETUP
TFT
RATING SETUP:
If Rating is selected after unlocking, press the button to enter rating level, press button to
select the desired rating level, then press the OK button to confirm setting.

DIGIT AL SE T U P:
TFT SE TUP:
Using the Direction and OK buttons to set or reset the picture quality such as the panel's Brightness,
Contrast, Hue, Saturation.
1. If Dual Mono is selected, using the Direction and OK buttons to set it to Stereo, Mono L,
(Plays Left channel on all speakers), Mono R (Plays Right channel on all speakers) or Mix
Mono (Mixed Right and Left channel then plays on all speakers) as desired.
(Functions depend on the recording of the disc).
~ If set to LT/RT, the rear left and rear right channels will plays on both Left and Right Speakers.
~ If set to Stereo, the rear left channel will plays on Left Speaker; the rear right channel will play on
Right Speaker.
2. If Downmix is selected, using the Direction and OK buttons to set it to LT/RT; Stereo as desired.
SYSTEM SETUP
Brightness
Contrast
Hue
Saturation
TFT SETUP
TFT
Dual Mono
Downmix
Dynamic Range
DIGITAL SETUP
TFT
3.If Dynamic Range is selected, using the Direction and OK buttons to set the dynamic level or turn it off.
18

Treat the disc carefully. Handle the disc only by its edges.
Never allow your fingers to contact with the shin , unprinted side of the disc.
● Do not attach adhesive tape, stickers, etc. to the disc label.
● Clean the disc periodically with a soft, lint-free,dry cloth, Never use detergents or abrasive cleaners
to clean the disc. If necessary, use a CD cleaning kit.
● If a disc skips or gets stuck on a section of the disc, it is probably dirty or damaged(scratched).
● When cleaning the disc, wipe in straight lines from the center of the disc to the outer edge of the
disc. Never wipe in circular motions.
● Discs should be stored in their cases after each use to avoid damage.
● Do not expose discs to direct sunlight, high temperatures or dust, etc. Prolonged exposure or
extreme temperatures can warp the disc.
● Do not stick or write anything on either side of the disc. Sharp writing Instruments, or the ink, may
damage the surface.
Cleaning the Unit
● To prevent fire or shock hazard, disconnect your unit from the AC power source when cleaning.
● The nish on your unit may be cleaned with a dust cloth and cared for as other furniture. Use
caution when cleaning and wiping the plastic parts.
● Mild soap and a damp cloth may be used on the front panel.
CARE AND MAINTENANCE
Caring for Discs
19

SYMPTOM POSSIBLE CAUSE POSSIBLE SOULTION
No power
No sound
Sound distortion Volume level too high
The connected device is not
in payback mode
Volume in minimum position
The unit is in Standby mode
Play music/movie in the connected device
as usual and make sure the volume level
of it is in high level.
Press the VOL - button to decrease the
volume level.
The power AC/DC adapter
is not connected
Reduce the volume level of the
connected device.
Connect the power AC/DC adapter to the
unit or wall outlet.
Press the /POWER button to turn
on the unit from Standby mode.
Disc not playing
Try other discs.
Clean disc and insert with label side up.
Wrong type of discs or the
disc is corrupted
The disc is dirty or inserted
incorrectly
Press the VOL + button to increase the
volume level.
20
TROUBLESHOOTINGS
Check the followings before requesting service:
Unplug the earphones to enable sound
from the speaker.
Earphone plugged on this
player
There is no
picture on the
external TV
display
Select the correct source on the external
display.
There is no
picture on the
DVD screen
Press the LCD ON/OFF button on remote
control to turn ON the display.
Plug and connect the AV cable to an
external TV screen.
Input source incorrect
Connect the AV cable correctly.
AV cable is not connected
Display is turn OFF
AV cable is unpluged and
not connected
The remote
control does not
work Remove the obstacle in the transmission
path.
Insert or replace with new batteries.
No batteries inserted or the
battaries were in low position
Obstacle existed
