Onsite Cameras AutoCam GPS FHD V57Gs Quick start guide

AutoCam GPS FHD V57Gs
Important Notes ©
Congratulations on purchasing an AutoCam GPS FHD V57Gs.
Please take time to read these notes in conjunction with your User Manual
If you have not already received and read the User Manual for your AutoCam GPS FHD V57Gs, download the
User Manual from FAQ on our website at www.onsitecameras.com/FAQ
OnSite Cameras have pre-set your new dash camera for you, see below for settings.
Getting Started
Insert the micro SD Memory Card
Insert the memory card into the micro SD slot on the side of the dash camera.
Attaching the dash camera to your windscreen
Using the windscreen suction mount (or 3M sticker mount) fit the dash camera high to the left of your
windscreen. (Often the best place is close to the rear vision mirror, if your vehicle has one.) When fitted correctly
the dash camera should not obscure the driver’s vision. Each State has their own legal requirements for where
dash cameras can be installed please check these laws before installing and ensure that your dash cam complies.
(It is illegal and dangerous to move or operate your dash camera whilst driving).
To power the dash camera
Insert the power lead into the dash camera via the mini USB port and plug the power lead into the cigarette
lighter. WARNING: Do not use USB cables in your vehicle to power the dash camera, as this will result in your
dash camera receiving too much voltage and will void your warranty. If you have chosen to hardwire the dash
camera, ensure it is an approved hardwire kit supplied by OnSite Cameras only, and all components are tested
thoroughly, by an Auto Electrician, before installation. The circuit for the hardwire kit should be the same as the
cigarette lighter circuit (coming on and off with the vehicle’s power and does not stay powered 24/7). Any
electrical work performed on the vehicle such as hardwire installation is done at your own risk and OnSite
Cameras cannot be held responsible for any installation costs or additional costs that may be incurred after a
fault or failure of dash camera, mount, hardwire kit, or car electrics. We strongly recommend that you hire a
fully qualified, insured, and experienced Auto Electrician to install the hardwire kit for you. The dash camera is
ONLY 5V/1A, and using a power lead not supplied by OnSite Cameras will void your warranty.
Once the dash camera is powered it will automatically come on and start recording
Format the micro SD memory card
You must format your micro SD memory card in the dash camera prior to its first use. To stop the dash camera
from recording press the DOWN button and to format your SD card select Menu/File Management/Format.
Press OK to start recording again. We recommend you format your micro SD memory card at least once a
month. This reduces the chance of SD card errors which can cause operational malfunctions with the dash
camera. WARNING: All files are permanently deleted when your micro SD card is formatted. Please ensure you
have downloaded and saved any/all files that you require prior to formatting, this function cannot be undone.
Micro SD memory cards
The dash camera should always be turned off to remove or to insert the micro SD memory card. It is
recommended to get an SD with SDHC Class 10 (or above). Beware of imitation or inferior micro SD memory

cards they may cause operational malfunctions or permanent damage to your dash camera. Ensure you buy
from reliable suppliers only.
Loop record times on micro SD memory cards
Loop recording means the dash camera continually records, in video clips of 2/3/5 minutes and re-writes over
old files once the SD card is full. No vision is lost between clips as it has a no cycle save time feature. Please
ensure you save any files, to your computer, you may require before the dash camera overwrites the file.
Tip: It is often a good idea to carry a spare micro SD memory card to ensure you do not overwrite vital footage
before it is saved to a computer.
Approximate loop record times are shown below (Please Note: these are estimates, based on 3 minute files
and to be used as a guide only. OnSite Cameras recommends you do your own testing to confirm loop record
times)
Resolution/Car
d Size
16GB
32GB
64GB
128GB
1080P / 30fps
2 ½ hours
5 hours
10 hours
20 hours
720P / 60fps
2 hours
4 ½ hours
9 ½ hours
19 hours
720P / 30fps
4 hours
8 hours
17 hours
35 hours
Note–Record times are guides only and will vary for many reasons including the brand and quality of the micro SD
memory card. Imitation and inferior micro SD memory cards will not work or often fail if used.
Pre-set menu settings
OnSite Cameras have pre-set your AutoCam GPS FHD V57Gs to the settings outlined below. We recommend
that you do not change any of the menu settings unless there is a specific change you require for your recording
needs. To make any changes please refer to the User Manual which can be downloaded from our website at
www.onsitecameras.com/faq
To access the Menu you will need to stop the dash camera from recording by pressing the DOWN arrow. You can
then press the MENU button to access the Menu and make your required changes.
Menu
Sub- Menu
Pre -set by OnSite Cameras
System Setting
Date Time
Set to correct time for your State
Screen Setting
On
Voice
On (Vol 3)
Language
English
Default Setting
No
GPS Setup
Satellite Setting
UTC of your state (Vic UTC+10, or UTC+11 DST)
Camera Alert
Off (this function not supported in Australia)
Speed Unit
Km/h
DST
Off
Current Speed Display
On
Overspeed Alert Tolerance
Off
My Locations
Use to manually add fixed speed camera locations
Overspeed Alert Management
Off
Video Setting
Resolution
1080P / 30fps
File format
TS
Auto Record
On
Recording Interval
3 min
Time Stamp
On

Wide Dynamic Range (WDR)
On
Function Setting
Collision Detection
Off
Parking Mode
Off
EV
0
Frequency Setting
50Hz
Headlight Reminder
Off
Driver Fatigue Reminder
Off
File Management
Playback
File Delete
Remind to format card
30 Days
Format
Version
GPS Lock
The GPS lock is very sensitive and your AutoCam GPS FHD V57Gs dash camera needs to be as close as possible to
the windscreen glass in your car/truck. GPS lock will usually be achieved in a few seconds; however can take up
to 5 minutes at times (like many automatic GPS systems). Please note, the first time you use your dash camera
GPS lock may take longer than normal. The dash camera will still work but the speed and GPS coordinates will not
be on your video until you get GPS lock.
If your windscreen has a magnetic film on the glass, GPS lock may not be obtained or take much longer. This
includes the top part of the windscreen that can have shading on it. The dash camera needs to be clear of this
film.
If you drive through a tunnel or car park or under a bridge or amongst buildings you may lose GPS lock. This
means you lose all GPS functions (recording of vision is not affected).
EMERG button: if this button is pressed while the dash camera is recording the file that is being recorded at the
time will be saved in a protected manner. This saved file will then not be recorded over until manually deleted, or
more than 10 emergency files are saved in which case it will record over the oldest emergency file. This function is
only recommended for use if you can do so without taking your eyes off the road to push the button. It is often
safer to simply take the micro SD memory card out after an incident has occurred and insert a spare micro SD
card.
Collision detection sensitivity is set to OFF. This sensor is an in-built system that will automatically save the
video clip in a protected manner where an impact or knock occurs. These clips need to be manually deleted,
and if too many protected files are saved the dash camera can stop recording with or without warning. This is
particularly important in trucks and heavy vehicles where vibration in the cabin is much greater than in a
smaller vehicle.
Trouble Shooting
If your dash camera has a Card Full error or does not appear to be Loop Recording, save any files from your micro
SD memory card that may be required and format the card. (Menu/File Management/Format)
If your dash camera will not turn on/off; remove the micro SD card and hold the on/off button down for 7 seconds
to reset the dash camera. Once you have checked that it is coming back on and is getting power, turn the dash
camera off to re-insert the Micro SD card, if this causes the dash camera any errors then format the card (ensure
you have saved any files you may require as all files will be deleted). Then try recording again.
Watching the video on your computer
To watch your video on your PC we recommend VLC media player, as this player has the latest codecs installed.
This is for the video only, not for mapping software.
To watch your video and view Google maps at the same time, you need to ensure you have Google Earth

downloaded on your computer. http://www.google.com/earth/download/ge/agree.html A fast internet
connection is required for Google maps to run smoothly.
Note: Only Windows computers will run the mapping software not MAC. MAC computers can still play the video
from your dash camera perfectly and it will show the video and speed on the screen. However, you will not be
able to watch the tracking part of the video. See our FAQ for generic map tracking software.
Your computer needs to meet the specifications noted on our website, if not it can result in jerky vision. If your
video is jerky or not smooth flowing when playing from the micro SD card out of AutoCam GPS FHD V57Gs, or
from the USB reader, then first transfer the video from the micro SD card to your computer via copy and paste.
Then play the video directly from your hard drive.
You do not need to delete all the files on your micro SD memory card after viewing. Only delete the video files
that have been saved in a protected manner (if collision detection is on) that you no longer wish to keep. The
dash camera overwrites the other unprotected video files, so there is no need to delete them.
WARNINGS:
Do not attempt to modify or open this dash camera or power lead in any way. If you need to hardwire the
camera you can do so but it must still run through the supplied power lead/adaptor (as the camera is only 5
volts/1Amp) and be on the same circuit as the ‘accessories’ so that it goes on and off with the vehicle ignition
and does not stay powered 24/7. AutoCam GPS FHD V57Gs runs on 5 volts/1 Amp only and voltage above this
will destroy the dash camera. If the dash camera or power lead has been tampered with or modified in any way
the OnSiteCameras warranty will be considered null and void.
AutoCam GPS FHD V57Gs is designed to be used in an enclosed vehicle cabin only. If it is exposed to moisture,
rain or excessive dust damage, OnSiteCameras will not be liable to replace or repair the device.
Warranty is not transferable.
Copyright © 2020 OnSiteCameras – All Rights Reserved.
