Onyx FALCON TS1 User manual

rim Capacity
Fast, Powerful & Efficient
13" to 28"
FALCON TS1
PREMIUM TOUCHLESS TIRE CHANGER
1-888-570-ONYX
ONYXMACHINES.COM

86.6"/2200mm 49.2"/1250mm
PROUDLY MANUFACTURED IN ITALY TO ONYX
SPECIFICATIONS AND North American STANDARDS
FALCON TS1 specifications
Operating Voltage
Rim Clamp Capacity
Wheel Lift Lifting Capacity
Max. Tire Diameter
Max. Tire Width
Rotation Torque
Rotation Speed (2 Speeds)
Bead Breaker Force
Operating Pressure Range
Crate Shipping Weight
Weight of Machine
115V, 1 PH, 50/60 Hz, 0.75 kW
13"-28"
187 lbs (85 kg)
47"
15"
882 ft/lb
7-18 rpm
1708 lbs @ 150psi
125psi-165psi
1,144 lbs (520 kg)
935 lbs (425 kg)
Maximum Dimensions
74.8"/1900mm
5-100683C
Multi-Locking Handle
Clamps and locks the wheel in place
to the turntable
Tire Mounting Paste w/
Brush
FALCON TS1 sTandard equipment
4-103229A
5.7" Cone
4-103230B
4.7" Cone 4-103235C
2.3" Cone
4-118294
2.9" Cone
4-103236B
Handle Extension
262417E
Anti Skid Clamp (2x)
Used to help with difficult tires such
as run flats
4-103232A (2x)
Plastic Protection Cones
4-121068
12.5" Magnetic Tool Tray
4-405496A
Bead Starting Tool
Inserted when removing a tire, this
tool helps the bead stay stationary
with the wheel
2201716
3 Pc Rim Protector Kit
Prevents rim from being scratched.
Short kit also included
Mount Head Insert Kit
(4x)
8-11100039
Reverse Mount Kit

The Falcon comes equipped with an upper and lower bead breaking disc.
The radial positioning of the discs is made easier through an automation
device preventing the operator from wrong manual positioning. This
system helps guarantee speed, precision, and repeatability.
FALCON TS1 Features
With an adjustable working height, and spring system to return
to position, the powerful assist arm makes working with run flat
tires, and other tough wheel assemblies a piece of cake!
Manual rotation of the tool allows for the operator to easily
switch from demounting to mounting mode.
The zero effort Wheel Lifter allows the operator to
lift the wheel on to the tire changer with little to no
effort and without changing working position.
The innovative mount/demount tool is positioned using the
controls on the panel. The part used for demounting is equipped
with a patented spring system to facilitate the entry of the bead
breaker disc between the rim without risk of damage to the tire.
Clamping the wheel is simple, using the pneumatic
clamping system. By using the provided locking
handle and cones, the wheel is locked into place with
the press of a pedal.
6
3
2
1
5
4
INDUSTRY LEADING BUMPER TO BUMPER 2 YEAR PARTS, 1 YEAR
LABOUR WARRANTY COMES STANDARD. EXTENDED MAINTENANCE
AND WARRANTY PLANS AVAILABLE
7The multi functional control panel is
great for dynamic bead breaking and
mounting tires. It is positioned at a
working height that makes operating
the machine and changing tires, simple
and efficient!
