Optelec TwinView
Page 1

Optelec TwinView
English 3
User Manual
English
Version 2.0.0
Copyright 2016 Optelec, the Netherlands
All rights reserved
Optelec
P.O. Box 399
2993 LT Barendrecht
The Netherlands
Telephone: [phone]. Fax [phone]
E-mail: [email protected]
Website: www.optelec.com

Optelec TwinView
4 English
Index
1. Introduction .............................................................................................................5
1.1. About this manual.......................................................................................5
1.2. Getting to know the TwinView.....................................................................5
2. Unpacking, Installation and Setup.........................................................................6
2.1. Installation...................................................................................................6
2.1.1. Monitor Adjustment.....................................................................................6
2.1.2. Connections................................................................................................7
2.1.3. Powering the TwinView...............................................................................7
2.1.4. Connecting the TwinView to a video magnifier...........................................7
2.1.5. Connecting the TwinView to the PC ...........................................................8
2.2. TwinView Intelligent Split Screen Software Setup......................................8
3. Operation .................................................................................................................9
3.1. Switching on/off ..........................................................................................9
3.2. On/Off indicator...........................................................................................9
3.3. Switching between the computer and the ClearView C or another device..9
3.4. Activating the split screen functionality .......................................................9
3.5. Switching between vertical and horizontal split screen...............................9
3.6. Resizing split screen...................................................................................9
4. The TwinView Menu Setup ...................................................................................10
4.1. Introduction...............................................................................................10
4.2. Activating the menu ..................................................................................10
4.3. Navigating the menu.................................................................................10
4.4. Main Menu Setup .....................................................................................10
4.4.1. Menu General...........................................................................................10
4.4.2. Menu Color...............................................................................................10
4.4.3. Menu Image..............................................................................................11
4.4.4. Menu Information......................................................................................11
4.4.5. Menu Language........................................................................................11
4.4.6. Menu Settings...........................................................................................11
4.4.7. Menu Factory Defaults..............................................................................12
4.4.8. Menu Select DVI/VGA ..............................................................................12
4.4.9. Menu Exit..................................................................................................12
5. Troubleshooting....................................................................................................13
Appendix A: Safety and Regulatory Notices..................................................................14
Appendix B: Specifications .............................................................................................15
Optelec offices worldwide................................................................................................16

Optelec TwinView
English 5
1. Introduction
Congratulations on choosing the Optelec TwinView, the true low vision 24 inch monitor
featuring intelligent split screen functionality.
Discover the power of split screen functionality for a low vision workstation by combining
the images of both a video magnifier and a PC simultaneously on a single monitor.
1.1. About this manual
At Optelec, we are constantly improving our products and their functionalities. Therefore, it
is possible that this manual is not the latest version. Please download the most up-to-date
manual on www.optelec.com at the Support section.
This manual will help you to become familiar with the TwinView features and operation.
Please read this manual thoroughly before using your TwinView.
If you have any questions or suggestions concerning the use of this product, please
contact your Optelec distributor or Optelec’s headquarters by consulting the contact
information page located at the end of this manual. We greatly appreciate your feedback.
We hope you enjoy working with your TwinView!
1.2. Getting to know the TwinView
The Optelec TwinView 24 inch screen is a wide viewing angle low vision monitor that
redefines the use of split screen functionality. Simply connect both a video magnifier and a
PC to the TwinView monitor, and the split screen function of your screen magnifier
software is set automatically. Then use the TwinView buttons to select the preferred split
screen orientation –horizontal or vertical. No further adjustments are required within
MAGic, ZoomText or SuperNova.
The high contrast ratio of the TwinView delivers distortion-free images, whilst the wide
viewing angle ensures an ultra-sharp image for low vision users, even when sitting in close
proximity to the screen. As a free-standing flexible monitor, the height and viewing angle of
the TwinView can be adjusted to provide a comfortable reading position. With its stand of
35 cm (13,8 inches) high, 5 cm (2 inch) height adjustment, 20 degrees pivot and 60
degrees swivel panel adjustment, virtually every low vision user can adjust the display to
their exact comfort level to help reduce eye and neck strain.
The TwinView supports all resolutions from VGA 640x480 to full HD 1920x1080. For an
optimal image quality, however, your PC system must be able to support a resolution of
1920x1080.

Optelec TwinView
6 English
2. Unpacking, Installation and Setup
Please unpack the TwinView carefully before proceeding with the installation, and consult
the accompanying installation guide. Please contact your Optelec distributor for further
instructions if required.
Your TwinView consists of the following:
- The Optelec TwinView monitor with stand;
- Two VGA cables;
- Two DVI cables;
- One USB cable;
- 12V DC monitor power cable to connect and power the TwinView monitor from
the ClearView+ monitor power socket;
- Adaptor cable to enable use of a standard ClearView+ power supply;
- An installation poster;
- CD containing the TwinView driver software;
- This user manual.
2.1. Installation
This chapter describes how to set up and connect the TwinView and install the TwinView
intelligent split screen software.
2.1.1. Monitor Adjustment
The height and viewing angle of the TwinView can be adjusted to provide a comfortable
reading position. With its stand of 35 cm (13,8 inches) high, 5 cm (2 inch) height
adjustment, 20 degrees pivot and 60 degrees swivel panel adjustment, virtually every low
vision user can adjust the display to their exact comfort level to help reduce eye and neck
strain.
Alternatively, for those using the PC frequently, the TwinView can be mounted on an off-
the-shelf monitor arm (purchased locally, for example).
To adjust the height of the TwinView stand, the transport lock needs to be unlocked first.
Press and hold the button located at the back of the stand and gently increase the height
of the stand. The TwinView can be adjusted in both height and viewing angle for an
optimal reading position. Grip the flat panel on both sides to adjust to your preferred
position.

Optelec TwinView
English 7
2.1.2. Connections
All connections are located on the back of the TwinView. When the back of the TwinView
is facing you, the connections from left to right are:
Power connector
oUse the 12V DC monitor power cable to connect and power the TwinView from
the ClearView+ monitor power socket, or
oUse the included adaptor cable to connect a standard ClearView+ power supply
to the TwinView monitor’s DC jack.
USB to PC connector –to connect the TwinView to the PC and establish the
communication between the TwinView and the MAGic, ZoomText or SuperNova
magnifier intelligent split screen adjustment.
DVI channel B to PC connector –to connect the PC to the TwinView over DVI.
VGA channel B to PC connector –to connect the PC to the TwinView over VGA.
DVI channel A to video magnifier connector –to connect a video magnifier or other
device to the TwinView over DVI.
VGA channel A to video magnifier connector –to connect a video magnifier or other
device to the TwinView over VGA.
2.1.3. Powering the TwinView
To power the TwinView, there are two options:
When using the TwinView with a ClearView+, use the 12V DC monitor power cable to
connect and power the TwinView from the ClearView+ monitor power socket, located
on the back of the ClearView+ (please refer to the Installation Guide).
When using the TwinView with another video magnifier than the ClearView+, use the
adaptor cable to connect a standard ClearView+ power supply to the TwinView
monitor’s DC jack. The ClearView+ power supply needs to be ordered separately.
Please contact your Optelec distributor for more information.
2.1.4. Connecting the TwinView to a video magnifier
The TwinView supports two input channels, channel A and channel B. Per channel, the
TwinView has a VGA and DVI connection. To connect a device either the VGA or DVI
connection can be used, depending on the device to be connected and your personal
preference. The two connections per channel make it possible to connect a maximum of
four devices to the TwinView, of which the output from two devices can be displayed
simultaneously in a horizontal or vertical split.
Channel A is reserved to specifically connect the TwinView to a video magnifier. To
connect the video magnifier, use the included VGA or DVI cable and connect the video
magnifier VGA or DVI monitor connection to the TwinView channel A VGA or DVI
connection.

Optelec TwinView
8 English
Please note: If you connect a video magnifier via DVI, the video source selection in menu
A needs to be set to DVI. Please refer to chapter 4, “The TwinView Menu Setup”.
2.1.5. Connecting the TwinView to the PC
The TwinView supports two input channels, channel A and channel B. Per channel, the
TwinView has a VGA and DVI connection. To connect a device either the VGA or DVI
connection can be used, depending on the device to be connected and your personal
preference. The two connections per channel make it possible to connect a maximum of
four devices to the TwinView, of which the output from two devices can be displayed
simultaneously in a horizontal or vertical split.
Channel B is reserved to specifically connect the TwinView to a PC. To connect a PC, use
the included VGA or DVI cable and connect the PC to the TwinView channel B connection.
Please note: If you connect the PC using the channel B DVI connection, the video source
selection in menu B needs to be set to DVI. Please refer to chapter 4, “The TwinView
Menu Setup”.
Please note: For optimal image quality, Optelec recommends to set the PC’s resolution to
full HD 1920x1080. Please refer to your Microsoft Windows or operating system’s manual
or help system on how to change the monitor resolution.
2.2. TwinView Intelligent Split Screen Software Setup
To use the intelligent split screen functionality of the TwinView and combine the images of
both the video magnifier and a PC simultaneously on a single monitor, connect both the
video magnifier and a PC to the TwinView as described in the previous two paragraphs.
Connect the USB cable to the TwinView and the PC.
If you are using MAGic version 13.1, ZoomText version 10.1 or SuperNova version 15.02
or later, install the included TwinView software from the Optelec TwinView CD. To
determine the version of MAGic, ZoomText or SuperNova that you work with, check the
“About” box in the help menu.
Simply use the TwinView buttons to select the preferred split-screen orientation
–horizontal or vertical –and the split screen functionality of MAGic, ZoomText or
SuperNova is set automatically. No further adjustments are required within MAGic,
ZoomText or SuperNova.
Please note: Earlier versions of MAGic, ZoomText and SuperNova, as well as other
screen magnification software, are not supported by the TwinView software. If you are
using an older version of MAGic, ZoomText or SuperNova, or other screen magnification
software, you will need to adjust the split screen functionality manually. Please refer to
your screen magnification manual for instructions on how to manually configure the split
screen function.

Optelec TwinView
English 9
3. Operation
The control buttons of the TwinView are located on the front panel of the unit, below the
screen.
3.1. Switching on and off
To power the TwinView, press the On / Off button located at the bottom right of the
monitor. When no signal is detected, the TwinView will switch off automatically.
3.2. On / Off indicator
When the TwinView is switched on, the indicator will be lit green. When no input signal is
detected, the indicator will be lit orange. When the unit is switched off, the indicator will not
be lit.
3.3. Switching between the computer and the ClearView C or another device
Press the button located at the left below the screen (labelled A) to display the full video
magnifier image. To display the full PC image, press the button labelled B (to the right of
the cursor cross). When no input signal is detected, the TwinView will automatically switch
channels after 5 seconds.
Please note: to display the PC image correctly on your TwinView monitor, make sure that
the resolution of your PC is set to 1920x1080.
3.4. Activating the split screen functionality
Pressing the A/B button –the centre button of the cursor cross –enables the split screen,
displaying both the PC and the video magnifier images simultaneously.
3.5. Switching between vertical and horizontal split screen
To switch between a vertical or horizontal split, press the left or right arrow for a vertical
split, or the up and down arrow for a horizontal split.
3.6. Resizing split screen
When the vertical or horizontal split screen is activated, pressing the up or down arrow or
left or right arrow will move the split up, down, left or right respectively.

Optelec TwinView
10 English
4. The TwinView Menu Setup
4.1. Introduction
The TwinView has two menu’s: one menu for channel A and one menu for channel B. This
allows you to change all of the settings, such as brightness and contrast, per channel. For
instance, it is possible to increase the brightness and contrast for the PC output (channel
B) and decrease the contrast and brightness for the video magnifier output (channel A).
4.2. Activating the menu
To activate the menu, first select the channel (A or B) by pressing the A or B button. The A
button can be found to the left of the cursor keys, the B button to the right. Then press the
menu button located to the left of the On / Off switch –this will activate the menu for the
selected channel. All menu changes will only apply to the selected channel. Pressing the
menu button will close the menu.
4.3. Navigating the menu
Use the up and down arrows to navigate between the menu items. The A/B button located
in the middle of the cursor cross will activate the menu item or selection.
4.4. Main Menu Setup
The main menu of the TwinView contains the following menu items:
- General: to set brightness and contrast settings
- Color: to adjust the color settings
- Image: to calibrate the image (this option is only available when the input is set to
VGA)
- Information: to display the resolution and frequency
- Language: to select the preferred menu language
- Settings: to configure the menu timeout
- Factory defaults: to restore all settings to the factory default
- Select DVI/VGA: to set the DVI or VGA port for the selected channel
- Exit: to leave the menu
4.4.1. Menu General
The menu General contains the submenu’s Brightness and Contrast. The default value of
both Brightness and Contrast is 50%. To configure the brightness and contrast settings of
the TwinView:
- Select the channel of which you would like to change the brightness and contrast
settings by pressing the channel A or channel B button;
- Activate the menu by pressing the menu button;
- Select General by using the up and down cursor keys and activate the option by
pressing the A/B button;
- Select Brightness or Contrast and confirm the choice with the A/B button;
- To adjust the brightness and contrast, use the left and right arrow keys and confirm
the choice with the A/B button;
- Use the menu Exit or press the Menu button to leave this submenu.
4.4.2. Menu Color
The color temperature can be adjusted using the submenu Color. There are three settings
in this menu:
- 6500 Kelvin
- 9300 Kelvin
- Custom

Optelec TwinView
English 11
The default setting is 6500 Kelvin. The change this, follow these steps:
- Select the channel of which you would like to change the color temperature by
pressing the channel A or channel B button;
- Activate the menu by pressing the menu button;
- Select Color by using the up and down cursor keys and activate the option by
pressing the A/B button;
- In the submenu Color, select Color again and confirm the choice with the A/B
button;
- To adjust the color temperature, use the left and right arrow keys and confirm the
choice with the A/B button;
- If you selected the custom color setting, the value for red, green and blue can be
adjusted individually;
- Use the menu Exit or press the Menu button to leave this submenu.
4.4.3. Menu Image
Please note: Optelec recommends not to change the settings in the Image menu. The
TwinView will automatically adjust all image settings when turning on the monitor.
Especially the Audio White Balance setting should not be activated, as that may offset the
color calibration of the TwinView.
The menu Image contains image adjustment settings for the VGA connections. If a PC or
video magnifier is connected using the DVI connection, the Image menu will not be
available and will be greyed out. The first item in the Image menu is Auto Adjust. Activating
this menu item will automatically configure the image settings. As the adjustment will take
place when turning on the TwinView, there is no need to activate this option.
4.4.4. Menu Information
The Information menu displays the screen resolution and frequency.
- Select the channel of which you would like to view the resolution and frequency by
pressing the channel A or channel B button;
- Activate the menu by pressing the menu button;
- Select Information by using the up and down cursor keys and activate the option by
pressing the A/B button;
- Use the menu Exit or press the Menu button to leave this submenu.
4.4.5. Menu Language
This menu option configures the language setting of the TwinView menu. The menu
language can be changed individually for channel A and channel B. To set the language:
- Select the channel of which you would like to change the menu language by
pressing the channel A or channel B button;
- Activate the menu by pressing the menu button;
- Select Language by using the up and down cursor keys and activate the option by
pressing the A/B button;
- Select the language of your choice by using the up and down cursor keys and
activate the chosen language by pressing the A/B button;
- Use the menu Exit or press the Menu button to leave this submenu.
4.4.6. Menu Settings
Use the menu Settings to adjust the menu timeout. This is the time that the TwinView
menu will be displayed on screen when no button is pressed. By default, the menu timeout
is set to 30 seconds. To change the timeout setting:

Optelec TwinView
12 English
- Select the channel of which you would like to change the timeout settings by
pressing the channel A or channel B button;
- Activate the menu by pressing the menu button;
- Select Settings by using the up and down cursor keys and activate the option by
pressing the A/B button;
- Select menu Timeout by using the up and down cursor keys and activate the
chosen option by pressing the A/B button;
- Use the left and right arrow keys to adjust the Timeout value;
- Use the menu Exit or press the Menu button to leave this submenu.
4.4.7. Menu Factory Defaults
Activating this menu will restore the TwinView settings to the factory defaults for the
selected channel:
- Select the channel of which you would like to restore the factory default settings by
pressing the channel A or channel B button;
- Activate the menu by pressing the menu button;
- Select Factory Defaults by using the up and down cursor keys and activate the
option by pressing the A/B button;
- The settings will now be restored to the factory defaults;
- Use the menu Exit or press the Menu button to leave this submenu.
4.4.8. Menu Select DVI/VGA
Select the DVI or VGA port of the selected channel to which a ClearView C (or other video
magnifier) or PC has been connected. By default, the VGA port is selected. To select a
port:
- Select channel A or B by pressing the channel A or channel B button;
- Activate the menu by pressing the menu button;
- Select DVI/VGA by using the up and down cursor keys and activate the option by
pressing the A/B button;
- Select DVI or VGA from the submenu by using the up and down cursor keys and
activate the chosen option by pressing the A/B button;
- Use the menu Exit or press the Menu button to leave this submenu.
4.4.9. Menu Exit
Activating this menu item will exit the menu.

Optelec TwinView
English 13
5. Troubleshooting
Manufacturer’s default settings
If you experience any difficulty operating the TwinView, you can reset the factory
default settings in the menu. You will need to reset the factory default settings in both
menu A and menu B.
No image on the TwinView monitor after it is switched on
- Check that all cables and hardware are connected properly and securely.
- Check that the unit is receiving power by verifying that the LED light is lit on the
front of the TwinView when the unit is switched on.
- Ensure that the correct VGA or DVI video source is selected in the TwinView menu.
The video source can be set per channel. Make sure both for channel A in menu A
and channel B in menu B that the correct input is selected.
Image has low contrast
- Ensure that the contrast and brightness levels are set correctly in the menu. The
contrast and brightness can be set per channel. To set the contrast for channel A,
select channel A prior to activating the menu. The same applies for channel B.
The computer image is not displaying
- Verify the computer’s video (VGA or DVI) connection to the TwinView and the PC.
- Ensure that the PC is connected to channel B.
- Ensure that the correct input, VGA or DVI, is selected in the menu.
- Check the display settings of your PC to ensure that the TwinView monitor is
selected.
The PC image is not clear
- Ensure that the computer’s video resolution is set to 1920x1080.
The split screen of the screen magnifier is not adjusting automatically
- Verify that the USB cable is connected to the TwinView and your PC.
- Verify that you are using MAGic version 13.1, ZoomText version 10.1 or SuperNova
version 15.02 or later.
- Ensure that the TwinView software is installed and the TwinView controller is
running. The TwinView controller icon can be found on the taskbar next to the clock.
If the TwinView controller is not running, you can manually launch it from the start
menu.
- Ensure that the TwinView controller is enabled by double clicking on the icon and
checking the status.

Optelec TwinView
14 English
Appendix A: Safety and Regulatory Notices
Please read the instructions carefully before setting up your Optelec TwinView. Keep this user
manual for future reference.
Use the TwinView indoors. Do not expose the TwinView to extreme or rapid changes in
temperature or humidity.
Do not place the TwinView near a radiator or heater, or where it may be exposed to direct
sunlight. These conditions may damage the TwinView’s electronic components.
Do not place the TwinView on an unstable surface. It may fall, causing serious damage to
the unit, or injury to the user.
The monitor stand contains movable parts. Please be careful when adjusting the stand and
screen position as to prevent fingers or any loose clothing from getting caught in the
operating mechanism. If you have difficulty operating the TwinView safely, please seek
assistance or contact your Optelec distributor.
Contact your Optelec distributor to service this device if necessary. Do not open your
TwinView; this will void the warranty.
Always turn the power off when the TwinView is not in use.
Always unplug the TwinView before cleaning it. Use a soft, damp cloth to clean the exterior
surfaces. Do not use any cleaning agents or any abrasive materials as these will damage
your TwinView.
Only use the power supply or included power connection cable for your TwinView.
Warranty Conditions
Optelec warrants the TwinView, effective from the date of delivery, to be free of any defects in
material and workmanship.
The warranty is not transferable and does not apply to groups, multi-users and agencies. The
TwinView was designed for the individual purchaser to be used at home and work. Optelec
reserves the right to repair or replace any purchased TwinView with a similar or improved product.
In no event shall Optelec or its suppliers be held liable for any indirect or consequential damages.
The original user’s remedies are limited to replacement of the TwinView. This warranty is valid only
when serviced in the country of original purchase, and with intact seals. For additional warranty
claims or service during or after warranty period, please contact your Optelec distributor.
Optelec is not responsible for any uses of this device other than those described in this manual.
Compliance
This product complies with the safety and EMC requirements under the following directives:
FCC: C-Tick EMC: Safety:
FCC part 15 Class B CISPR 22 EN 50081-1 UL 60950
EN 55022
EN 55024
Electrical medical equipment requires special precaution with regard to EMC (Electro Magnetic
Compatibility) and must be installed and put into service according to EMC guidelines.
WARNING: The use of accessories and cables other than those specified and sold by the
manufacturer of the TwinView, as replacement parts for components, may result in increased
emissions or decreased functioning of the TwinView.
This device bears the CE, FCC and UL approval mark.

Optelec TwinView
English 15
Appendix B: Specifications
24 inch full HD low vision monitor with an 178 degree wide angle view, ensuring an
ultra sharp image for low vision users, even when sitting in close proximity to the
screen.
Free standing, height adjustable monitor stand for a more comfortable reading
position.
More overview and more characters on the screen with the same magnification
level as a 22 inch or smaller monitor.
Easy to use buttons with high contrast icons.
TwinView menu settings are displayed in large font for easy adjustment by a
visually impaired user.
Split screen
Simplicity with just a few user controls on the monitor itself (no need for extra
software or control panel).
Split screen from VGA (640x480) up to full HD (1920x1080) resolution.
Intelligent, fully automatic split screen; no further adjustments are required within
the PC magnification software (ZoomText, MAGic and SuperNova), due to the
TwinView software.
Horizontal and vertical split screen adjustment.
Fast en responsive split screen in real time at 60 frames/second; no stuttering or
delays in the image.
PC-connectivity trough USB for fully automatic split screen functionality.
Technical specifications
Full HD resolution 1920x1080
High contrast ratio 3000:1
High brightness screen 300 cd/m2
Response time: 8 ms
178 degree wide viewing angle using A-MVA 3 technology
Supports VGA and DVI input
Weight: 6.7 kg / 14.8 lbs including stand; 4 kg / 8.8 lbs excluding stand
Dimensions: 568 x 339 x 50 mm / 22.4 x 13.35 x 1.97 inch
Supports: VGA and DVI input
Power supply: 12V / 4A
Net frequency: 50-60 Hz
Operating conditions
Temperature : +10°C to +35°C
Humidity : < 70%, no condensation
Storage & transportation conditions
Temperature : -10°C to +40°C
Humidity : < 95%, no condensation

Optelec TwinView
16 English
Optelec headquarters
Optelec
Breslau 4
2993 LT Barendrecht,
The Netherlands
T: [phone]
www.optelec.com
Optelec offices worldwide
Optelec NV
Baron Ruzettelaan 29
8310 Bruges
Belgium
T: [phone]
www.optelec.be
Optelec Canada
1832, Boulevard Marie-Victorin
Longueuil, QC J4G 1Y9
Canada
T: [phone]
www.optelec.ca
Optelec GmbH
Fritzlarer Strasse 25
34613 Schwalmstadt
Germany
T: [phone]
www.optelec.de
Optelec Nederland BV
Breslau 4
2993 LT Barendrecht
The Netherlands
T: [phone]
www.optelec.nl
Optelec UK
2 Millfield House, Woodshots Meadow,
Watford WD18 8YX
United Kingdom
T: [phone]
www.optelec.co.uk
Optelec US Ltd
3030 Enterprise Court
Suite C, Vista, CA 92081
U.S.A.
T: [phone]
www.optelec.com

Optelec TwinView
2 English
